Title: Spontaneity, Entropy,


1
Spontaneity, Entropy, Free Energy
  • Chapter 16

2
1st Law of Thermodynamics
  • The first law of thermodynamics is a statement of
    the law of conservation of energy energy can
    neither be created nor destroyed. The energy of
    the universe is constant, but the various forms
    of energy can be interchanged in physical and
    chemical processes.

3
Spontaneous Processes and Entropy
  • Thermodynamics lets us predict whether a process
    will occur but gives no information about the
    amount of time required for the process.
  • A spontaneous process is one that occurs without
    outside intervention. This is also considered
    thermodynamically favored.

4
Entropy
  • The driving force for a spontaneous process is an
    increase in the entropy of the universe.
  • Entropy, S, can be viewed as a measure of
    randomness, or disorder.
  • Nature spontaneously proceeds toward the states
    that have the highest probabilities of existing.

5
The expansion of an ideal gas into an evacuated
bulb.
6
(No Transcript)
7
Positional Entropy
  • A gas expands into a vacuum because the expanded
    state has the highest positional probability of
    states available to the system.
  • Therefore,
  • Ssolid lt Sliquid ltlt Sgas

8
Positional Entropy
  • Which of the following has higher positional
    entropy?
  • a) Solid CO2 or gaseous CO2?
  • b) N2 gas at 1 atm or N2 gas at 1.0 x 10-2 atm?

9
Entropy
  • What is the sign of the entropy change for the
    following?
  • a) Solid sugar is added to water to form a
    solution?
  • ?S is positive
  • b) Iodine vapor condenses on a cold surface to
    form crystals?
  • ?S is negative

10
The Second Law of Thermodynamics
  • . . . in any spontaneous(thermodynamically
    favored) process there is always an increase in
    the entropy of the universe.
  • ?Suniv gt 0
  • for a spontaneous process.

11
?SUniverse
  • ?Suniverse is positive -- reaction is
    spontaneous.
  • ?Suniverse is negative -- reaction is spontaneous
    in the reverse direction.
  • ?Suniverse 0 -- reaction is at equilibrium.

12
?S? ?npS?(products) ? ?nrS?(reactants)
  • ?H? ?npH?(products) ? ?nrH?(reactants)

13
?Soreaction
  • Calculate ?S? at 25 oC for the reaction
  • 2NiS(s) 3O2(g) ---gt 2SO2(g) 2NiO(s)

SO2 (248 J/Kmol) NiO (38 J/Kmol) O2 (205
J/Kmol) NiS (53 J/Kmol)
14
  • ?S? ?npS?(products) ? ?nrS?(reactants)
  • ?S? (2 mol SO2)(248 J/Kmol) (2 mol NiO)(38
    J/Kmol) - (2 mol NiS)(53 J/Kmol) (3 mol
    O2)(205 J/Kmol)
  • ?S? 496 J/K 76 J/K - 106 J/K - 615 J/K
  • ?S? -149 J/K gaseous molecules decreases!

15
Effect of ?H and ?S on Spontaneity
16
?G -- Free Energy
  • Two tendencies exist in nature
  • tendency toward higher entropy -- ?S
  • tendency toward lower energy -- ?H
  • If the two processes oppose each other (e.g.
    melting ice cube), then the direction is decided
    by the Free Energy, ?G, and depends upon the
    temperature.

17
Free Energy
  • ?G ?H ? T?S (from the standpoint of the
    system)
  • A process (at constant T, P) is spontaneous in
    the direction in which free energy decreases
  • ??Gsys means ?Suniv
  • Entropy changes in the surroundings are primarily
    determined by the heat flow. An exothermic
    process in the system increases the entropy of
    the surroundings.

18
Free Energy ?G
  • ?G ?H ? T?S
  • ?G negative -- spontaneous
  • ?G positive -- spontaneous in opposite
    direction
  • ?G 0 -- at equilibrium

19
?G, ?H, ?S
  • Spontaneous reactions are indicated by the
    following signs
  • ?G negative
  • ?H negative
  • ?S positive

20
Free Energy Change and Chemical Reactions
  • ?G? standard free energy change that occurs if
    reactants in their standard state are converted
    to products in their standard state.
  • ?G? ?np?Gf?(products) ? ?nr?Gf?(reactants)

21
Temperature Dependence
  • ?Ho ?So are not temperature dependent.
  • ?Go is temperature dependent.
  • ?G ?H ? T?S

22
?G? Calculations
  • Calculate ?H?, ?S?, ?G? for the reaction
  • 2 SO2(g) O2(g) ----gt 2 SO3(g)
  • ?H? ?np?Hf?(products) ? ?nr?Hf?(reactants)
  • ?H? (2 mol SO3)(-396 kJ/mol)-(2 mol
    SO2)(-297 kJ/mol) (0 kJ/mol)
  • ?H? - 792 kJ 594 kJ
  • ?H? -198 kJ

23
?G? CalculationsContinued
  • ?S? ?npS?(products) ? ?nrS?(reactants)
  • ?S? (2 mol SO3)(257 J/Kmol)-(2 mol SO2)(248
    J/Kmol) (1 mol O2)(205 J/Kmol)
  • ?S? 514 J/K - 496 J/K - 205 J/K
  • ?S? -187 J/K

24
?G? CalculationsContinued
  • ?Go ?Ho ? T?So
  • ?Go - 198 kJ - (298 K)(-187 J/K)(1kJ/1000J)
  • ?Go - 198 kJ 55.7 kJ
  • ?Go - 142 kJ
  • The reaction is spontaneous at 25 oC and 1 atm.

25
The Third Law of Thermodynamics
  • . . . The third law of thermodynamics the
    entropy of a perfect crystal at 0K is zero.
  • not a lot of perfect crystals out there so,
    entropy values are RARELY ever zeroevenelements
  • So what? This means the absolute entropy of a
    substance can then be determined at any temp.
    higher
  • than 0 K. (Handy to know if you ever need to
    defend why G H for elements 0. . . . BUT S
    does
  • not!).

26
Hesss Law ?Go
  • Cdiamond(s) O2(g) ---gt CO2(g) ?Go -397 kJ
  • Cgraphite(s) O2(g) ---gt CO2(g) ?Go -394 kJ
  • Calculate ?Go for the reaction
  • Cdiamond(s) ---gt Cgraphite(s)
  • Cdiamond(s) O2(g) ---gt CO2(g) ?Go -397 kJ
  • CO2(g) ---gt Cgraphite(s) O2(g) ?Go 394 kJ
  • Cdiamond(s) ---gt Cgraphite(s) ?Go -3 kJ
  • Diamond is kinetically stable, but
    thermodynamically unstable.

27
So
  • So increases with
  • solid ---gt liquid ---gt gas
  • greater complexity of molecules (have a greater
    number of rotations and vibrations)
  • greater temperature (if volume increases)
  • lower pressure (if volume increases)

28
?Go Temperature
  • ?Go depends upon temperature. If a reaction must
    be carried out at temperatures higher than 25 oC,
    then ?Go must be recalculated from the ?Ho ?So
    values for the reaction.

29
Free Energy Pressure
  • The equilibrium position represents the lowest
    free energy value available to a particular
    system (reaction).
  • ?G is pressure dependent
  • ?S is pressure dependent
  • ?H is not pressure dependent

30
Free Energy and Pressure
  • ?G ?G? RT ln(Q)
  • Q reaction quotient from the law of mass action.

31
Free Energy Calculations
  • . CO(g) 2H2(g) ---gt CH3OH(l)
  • Calculate ?Go for this reaction where CO(g) is
    5.0 atm and H2(g) is 3.0 atm are converted to
    liquid methanol.
  • ?G? ?np?Gf?(products) ? ?nr?Gf?(reactants)
  • ?G? (1 mol CH3OH)(- 166 kJ/mol)-(1 mol
    CO)(-137 kJ/mol) (0 kJ)
  • ?G? - 166 kJ 137 kJ
  • ?G? - 2.9 x 104 J

32
Free Energy CalculationsContinued

2.2 x 10-2
33
Free Energy CalculationsContinued
  • ?G ?G? RT ln(Q)
  • ?G (-2.9 x 104 J/mol rxn) (8.3145
    J/Kmol)(298 K) ln(2.2 x 10-2)
  • ?G (- 2.9 x 104 J/mol rxn) - (9.4 x 103 J/mol
    rxn)
  • ?G - 38 kJ/ mol rxn
  • Note ?G is significantly more negative than
    ?G?, implying that the reaction is more
    spontaneous at reactant pressures greater than 1
    atm. Why?

34
A system can achieve the lowest possible free
energy by going to equilibrium, not by going to
completion.
35
As A is changed into B, the pressure and free
energy of A decreases, while the pressure and
free energy of B increases until they become
equal at equilibrium.
36
Graph a) represents equilibrium starting from
only reactants, while Graph b) starts from
products only. Graph c) represents the graph
for the total system.
37
Free Energy and Equilibrium
  • ?G? ?RT ln(K)
  • K equilibrium constant
  • This is so because ?G 0 and Q K at
    equilibrium.

38
?Go K
  • ?Go 0 K 1
  • ?G? lt 0 K gt 1 (favored)
  • ?G? gt 0 K lt 1 (not favored)

39
Equilibrium Calculations
  • 4Fe(s) 3O2(g) lt---gt 2Fe2O3(s)
  • Calculate K for this reaction at 25 oC.
  • ?Go - 1.490 x 106 J
  • ?Ho - 1.652 x 106 J
  • ?So -543 J/K
  • ?G? ?RT ln(K)
  • K e - ?G?/RT
  • K e 601 or 10261
  • K is very large because ?G? is very negative.

40
Temperature Dependence of K
  • y mx b
  • (?H? and S? ? independent of temperature over a
    small temperature range)
  • If the temperature increases, K decreases for
    exothermic reactions, but increases for
    endothermic reactions.

41
Free Energy Work
  • The maximum possible useful work obtainable from
    a process at constant temperature and pressure is
    equal to the change in free energy
  • wmax ?G

42
Reversible vs. Irreversible Processes
  • Reversible The universe is exactly the same as
    it was before the cyclic process.
  • Irreversible The universe is different after
    the cyclic process.
  • All real processes are irreversible -- (some work
    is changed to heat). ? w lt ?G
  • Work is changed to heat in the surroundings and
    the entropy of the universe increases.

43
Laws of Thermodynamics
  • First Law You cant win, you can only break
    even.
  • Second Law You cant break even.
