The Outer Planets

1
The Outer Planets

• Chap 16, Sec 4

2
Chap 16 Sec 4 Essential Questions

1. What characteristics do the gas giants have in
   common?
2. What characteristics distinguish each of the
   outer planets?

3
The Gas Giants
4
The Gas Giants

• The four outer planets
• Jupiter
• Saturn
• Uranus
• Neptune
• Much larger more massive than Earth
• Do not have solid surfaces
• All are composed mainly of hydrogen helium
• Their gravitational force is much greater than
  Earths because of their massive size
• They have thick atmospheres
• A lot of the hydrogen helium inside the planets
  is liquid because of enormous pressure
• Outer layers of the planets are cold because of
  their distance from the sun, but temperatures
  increase inside the planets
• All have many moons
• All have rings
• A ring is a thin disk of small particles of ice
  and rock

5
Jupiter
6
Jupiter

• The largest most massive planet
• Its mass is about 2 ½ times all other planets
  combined
• Atmosphere
• Thick atmosphere of mainly hydrogen helium
• The Great Red Spot a giant storm larger than
  Earth. Swirling winds blow hundreds of miles an
  hour, similar to a hurricane, but it has lasted
  for 350 years and doesnt appear to be weakening

7
Jupiter

• Structure
• A dense core of rock and iron at the center
• The core is surrounded by a thick mantle of
  liquid hydrogen helium
• Pressure at Jupiters core may be 30 million
  times greater than the pressure at Earths
  surface
• Extreme pressure is caused by its thick atmosphere

8
Jupiters Moons

• Remember Galileo discovered the largest four
• Many more have been discovered as technology
  improved latest count is more than 63
• The four largest are all very different from each
  other and are all larger than our Moon

9
Jupiters Largest Moons

• Io its surface is covered with large, active
  volcanoes. Sulfur gives it an unusual color.
• Europa it has an icy crust and scientists
  suspect it has an ocean of liquid water
  underneath the ice
• Ganymede the largest moon in the solar system
  is larger than Mercury or Pluto
• Callisto has an icy, cratered surface

10
Io
11
Ganymede
12
Europa
13
Callisto
14
Saturn
15
Saturn

• The second-largest planet
• Has a thick atmosphere of hydrogen helium
• Atmosphere has thick clouds and storms though
  not as spectacular as those on Jupiter
• The least dense planet (less dense than water)
• The Voyager probes provided lots of information
  about Saturn

16
Saturns Rings

• Saturn has the most spectacular rings of any
  planet
• The rings are broad and thin like a CD
• The rings are made of chunks of ice and rock,
  each traveling in its own orbit around Saturn

17
Saturns Moons

• Saturn is currently known to have more than 60
  moons
• The largest is Titan
• It has a very thick atmosphere (so thick that
  light can hardly pass through)
• There are four other moons that are larger than
  1,000 kilometers in diameter

18
Two views of Titan
From Far Away
Very Close Up with special Lens
19
Uranus
20
Uranus

• It is about four times the diameter of Earth, but
  much smaller than Jupiter and Saturn
• It is twice as far from the sun as Saturn, so it
  is much colder
• Has a unique blue-green color because of methane
  gas in its atmosphere
• Its rings are thin, flat, and much darker than
  Saturns
• It was the first planet discovered since ancient
  times
• Discovered in 1781 by Willam Herschel in England

21
Unique Features of Uranus

• In the 1980s (200 years after being discovered)
  Voyager 2 arrived at Uranus and sent back
  close-up pictures
• It has few clouds, but astronomers calculated it
  rotated in about 17 hours
• Uranus is tilted on its side
• It rotated top to bottom instead of side to side
  like other planets (and its rings and moons
  rotate around its tilted axis)
• Scientists think it was hit by an object billions
  of years ago that knocked it on its side

22
Uranuss Moons

• Uranus has at least 27 moons
• Voyager 2 discovered the five largest moons have
  icy, cratered surfaces and lava flows

23
Neptune
24
Neptune

• Neptune is similar in size and color to Uranus
• It is a blue color because of methane in its
  atmosphere
• Because it is so far from the sun, it is very
  cold
• It has clouds and storms in its atmosphere
• Scientists think the clouds and storms are
  happening because the planet is slowly shrinking
  and causing the interior to heat up

25
Discovering Neptune

• Neptune was discovered by mathematics
  astronomers noticed Uranuss orbit wasnt the
  exact path it should be and predicted an unseen
  planet was disturbing Uranuss orbit
• By 1846 scientists had calculated the orbit of
  the unseen planet soon after, Neptune was
  identified

26
Flying by Neptune

• In 1989 Voyager 2 flew by Neptune and
  photographed the Great Dark Spot (a storm about
  the size of Earth)
• Storms come and go on Neptune which tells us it
  has an active atmosphere

27
Neptunes Moons

• Neptune has at least 13 moons
• The largest is Triton
• It has a thin atmosphere
• Its south pole is covered in nitrogen ice

28
Pluto

• Pluto is not a gas giant
• It is much smaller and denser than the outer
  planets and has a solid surface
• Pluto is smaller than our Moon
• Pluto is so far from the sun that it takes 240
  Earth years to revolve around the sun once
• Its orbit is very elliptical and it crosses
  inside Neptunes orbit for part of its revolution
• Moons
• Pluto has at least three. The largest is Charon
  and is more than half as big as Pluto

29
Dwarf Planets

• Dwarf planets are round and orbits the sun, like
  a planet, but it has not cleared out the
  neighborhood around its orbit
• Dwarf planet classification was created in 2006
  when an object larger than Pluto and farther from
  the sun was discovered
• At that time Pluto was reclassified as a dwarf
  planet and there are two others

30
Video
31
Essential Questions - Answered

• What characteristics do the gas giants have in
  common?
• No solid surface
• Thick atmosphere made mostly of hydrogen helium
• A set of rings
• Very Large massive
• Rotates quickly, revolves slowly

32

• 2. What characteristics distinguish each of the
  outer planets?
• Jupiter largest most massive planet, Great
  Red Spot, most moons (63)
• Saturn second largest planets, best rings,
  least dense planet
• Uranus blue-green color, rotates on its side
• Neptune blue color, lots of storms
• Pluto solid, rocky surface no longer a planet
