Dia 1

1
CORE Bringing the GSBPM to life! J. Linnerud
J.-P. Kent
2
Main points

1. An ideal development process for a statistical
   system
2. Why this ideal usually is not met
3. How CORE aims at supporting this ideal
   development process

3
Statistics How?

• Specify a statistic
• Design a process that will produce this statistic
• Build a system that will execute this process

4
What is the product?

• Define a statistic
• What does it say?
• Measures, dimensions, explanations
• What does it look like?
• Tables, Press release, Analytic paper
• What is the input?
• Population, variables, data sources
• What is the relation between input and output?
• Methods to apply

5
Statistics How?

• Specify a statistic
• Design a process that will produce this statistic
• Build a system that will execute this process

6
How to produce the statistic

• Model the data
• Input, output, intermediary results
• Specify process steps to apply the chosen
  statistical methods
• Integrate these steps in a process flow

7
Statistics How?

• Specify a statistic
• Design a process that will produce this statistic
• Build a system that will execute this process

8
Let the machine do it

• Implement the data models
• Implement the process steps
• Implement the process flow

9
Why is this approach good? (1)

• Variability vs. stability
• Statistical products are specific
• There is a great variety of products
• A given product will vary in time
• Statistical processes are generic
• The same method can be applied to many products
• Process steps implementing methods can be reused
• A significant change in the product can be
  implemented with some simple changes in some
  process steps

10
Why is this approach good? (2)

• It allows a clean specification of the product
• In terms of what it is
• In terms of what is used
• In terms of what the relation is between input
  and output

11
Why is this approach good? (3)

• It separates product design from IT
• The product is defined in terms of what it is
  (and not how it is produced)
• The process is defined in terms of what it does
  (and not how it is implemented)
• Only the system is defined in technical terms

12
Why is this approach good? (4)

• It supports optimalisation of process development
• Possibility of developing standardised, re-usable
  process steps
• Generic process steps are not defined for an
  actual statistic, but for use in different
  statistics

13
Main points

1. An ideal development process for a statistical
   system
2. Why this ideal usually is not met
3. How CORE aims at supporting this ideal
   development process

14
The usual approach

• Statisticians present a project in which product
  and process are combined
• IT people specify and build a system that creates
  the product by performing the process

15
Why is the usual approach inefficient?

• Complexity
• Process product are tightly coupled
• Rigidity
• Maintenance is labour-intensive
• Specificity
• It is not easy to devise a generic solution when
  developing for a specific product

16
Main points

1. An ideal development process for a statistical
   system
2. Why this ideal usually is not met
3. How CORE aims at supporting this ideal
   development process

17
Promoting the better approach

1. The CORA and CORE projects (Jenny)
2. Bringing the results into practice (Jean-Pierre)

18
CORA ESSnet

• COmmon Reference Architecture (CORA)
• Financed by Eurostat under 2009 Statistical
  Workprogramme
• Countries involved it (coordinator), ch, dk, lv,
  nl, no, se
• Duration October 2009 - October 2010

19
CORA deliverables

• Questionnaire
• Set of Requirements
• State of the Art
• Definition of the Layered Model
• Technical Annex
• Instruction Manual
• Commercial and Legal Foundations for the Exchange
  of Software between Statistical Offices
• Requirements Checklist for CORA Tools
• Recommendations for CORA Tools

20
After CORA CORE!

• COmmon Reference Environment (CORE)
• Financed by Eurostat under 2010 Statistical
  Workprogramme
• Countries involved it (coordinator), fr, nl, no,
  pt, se
• Duration December 2010 - January 2012

21
CORE Workpackages

• Design of the information model according to
  GSBPM and alignment with NSI's information models
• Generic interface design for interconnecting
  GSBPM sub-processes
• Research workflow solutions for process
  management
• Implementation library for generic interface and
  production chain for .NET
• Implementation library for generic interface and
  production chain for Java

22
Practical usage of CORA / CORE

• Modeling a process in terms of services (CORA)
• Classifying services (CORA)
• Making services platform-independent (CORE)

23
(No Transcript)
24
An example process

• A transport statistic
• Input
• Loading reports
• Unloading reports
• Date, time, place, type quantity goods, type
  vehicle
• Output
• Monthly transport data
• Same data also used for time series

25
Modeling approach

• Use the CORA space grid

26
Macrodata
Microdata
27
Modeling approach

• Use the CORA space grid
• Display statistical services in the appropriate
  cells

28
(No Transcript)
29
Modeling approach

• Use the CORA space grid
• Display statistical services in the appropriate
  cells
• Join services with arrows to show the
  dependencies

30
(No Transcript)
31
?
?
32
A traditional service
Script (X)
Model (X)
Model (X)
Tool X
Input (X)
Output (X)
33
A CORA service
Script (CORA)
Input (CORA)
Output (CORA)
Model (CORA)
Model (CORA)
Logging
CV
CV
CV
CV
CV
Script (X)
Model (X)
Model (X)
Tool X
Input (X)
Output (X)
CV Convertor
