CERN Safety Alarm Monitoring

1
CERN Safety Alarm Monitoring

• Presented by Luigi Scibile
• ST division / MO group

2
Introduction
CERN
Safety information
Alarm system
Monitoring system
3
Introduction
CERN Safety Alarm Monitoring
CSAM
4
Background
Fire CDIN-00052 B104-R-02
Hard-wired network
Computer-based network
Whats next ?
Detection equipment
5
CSAM Mandate

• The CSAM will provide CERN with an integrated
  safety alarm system covering acquisition,
  transmission, logging and display for all the
  CERN sites, the LHC machine, LHC experiments and
  experimental areas. The system will be
  incorporated into the safety, technical,
  accelerator, and experiment control rooms.
• The requirements of the system were defined by
  the AL3S working group.
• The mandate of the project team covers the system
  specification, prototyping, tendering,
  installation and integration of the product in
  the existing monitoring architecture.

Safety alarms require the immediate
intervention of the fire brigade and are defined
at CERN as 'Alarms of Level 3' (AL3S)
6
CSAM Specification

• For the Fire Brigade
• Safety alarm acquisition from all CERN safety
  zones
• Local monitoring from each safety zone
• Central monitoring, archiving, display, reporting
  and configuration
• Non-interruptible 24h/365d system based on
  redundant networks
• Specific human computer interfaces and tools for
  the alarm handling
• Real-time monitoring of the correct functioning
  of all sub-systems.
• For the Experiments and the other control rooms
• A safety alarm gateway to external systems
• A flexible system architecture for the
  integration of the LHC and LHC experiments future
  alarms.
• A modular acquisition and local monitoring system
  based on standard industrial equipment

7
CSAM Specification, cont.

• No common mode of failure
• Power supply, Location, server, display,
  acquisition module,etc.
• INB compliant system based on redundant
  transmission paths.
• Availability requirements
• In order to meet the availability requirements of
  ? 99.8 set by the AL3 Working Group, a Safety
  Integrity Level (SIL) 2 has been fixed.
• A supervision and monitors the availability of
  all sub-systems and generates performance
  reports.

8
CSAM specifications, cont.
Functional diagram
9
CSAM specifications, cont.




Safety alarm monitoring centre
Safety alarm gateway to external systems (TDS,
experiments, XCR, etc.)
PVSS
Safety alarm networks
CSAM supervision maintenance manager
PVSS
x33
Local safety alarms controller
Technical Data Server (TDS)
CERN safety equipment
10
CSAM-experiments interface




Safety alarm gateway to external systems (TDS,
experiments, XCR, etc.)
Safety alarm Monitoring centre
SCR SCADA
Experiments DCS

• How
• Data exchange protocol
• JCOP conventions
• For the XCR operators
• Only Safety Alarms and safety-related information
  concerning their experiment.
• Also analogue values of safety equipment.
• Possible seamless integration in the experiment
  DCS

Local XCR console
Experiments
11
CSAM animation scenario




Safety alarm gateway to external systems (TDS,
experiments, XCR, etc.)
Safety alarm Monitoring centre
SCR SCADA
Experiments DCS
Local safety alarms controller
Technical Data Server (TDS)
Local XCR console
CERN safety equipment
Experiments
12
Current system
13
Future systems
14
Current System
15
Current System
16
Current system
17
Future system
4 alarms
18
Future system
19
Future system
151615 Flooding Det. INOND-863-E-T
SPS-B-862-R-05 Flooding Detected
came
151615 Flooding Det. INOND-863-E-T
SPS-B-862-R-05 Flooding Detected
came
20
Prototype
21
What has been done ?

• Analysis of technical solutions
• IEC61508 standards
• Prototype
• Technical specifications including
• User requirements
• Functional and safety requirements
• Product requirements
• Interface requirements
• Approval of the finance committee

22
Whats next?

• Detailed design and testing during year 2001
• Pilot installation planned for APRIL 2002
• Deployment of product on the CERN site in
  accordance with the LHC and LHC experiments
  schedule

23
Additional information

• Papers
• S. Grau, P. Ninin, R. Nunes, L. Scibile, C.
  Soler, CERN Safety Alarm monitoring Project, 3rd
  ST workshop Chamonix, February 2000.
• L.Scibile, P.Ninin, S.Grau, Functional Safety a
  Total Quality Approach, 4st WS Chamonix, 2001.
• S. Grau, L. Scibile, F. Balda, A. Chouvelon,
  Application of risk management for control and
  monitoring systems, 4rd ST workshop Chamonix,
  February 2001.
• Visit the CSAM Homepage
• http//nicewww.cern.ch/st/mo/CSAM/CSAM.htm
• Just come and see us!
