Brahms

1
Brahms

• Byzantine-Resilient Random Membership Sampling

Bortnikov, Gurevich, Keidar, Kliot, and Shraer
2
Edward (Eddie) Bortnikov
Maxim (Max) Gurevich
Idit Keidar
Alexander (Alex) Shraer
Gabriel (Gabi) Kliot
3
Why Random Node Sampling

• Gossip partners
• Random choices make gossip protocols work
• Unstructured overlay networks
• E.g., among super-peers
• Random links provide robustness, expansion
• Gathering statistics
• Probe random nodes
• Choosing cache locations

4
The Setting

• Many nodes n
• 10,000s, 100,000s, 1,000,000s,
• Come and go
• Churn
• Every joining node knows some others
• Connectivity
• Full network
• Like the Internet
• Byzantine failures

5
Byzantine Fault Tolerance (BFT)

• Faulty nodes (portion f)
• Arbitrary behavior bugs, intrusions, selfishness
• Choose f ids arbitrarily
• No CA, but no panacea for Cybil attacks
• May want to bias samples
• Isolate nodes, DoS nodes
• Promote themselves, bias statistics

6
Previous Work

• Benign gossip membership
• Small (logarithmic) views
• Robust to churn and benign failures
• Empirical study Lpbcast,Scamp,Cyclon,PSS
• Analytical study Allavena et al.
• Never proven uniform samples
• Spatial correlation among neighbors views PSS
• Byzantine-resilient gossip
• Full views MMR,MS,Fireflies,Drum,BAR
• Small views, some resilience SPSS
• We are not aware of any analytical work

7
Our Contributions

• Gossip-based BFT membership
• Linear portion f of Byzantine failures
• O(n1/3)-size partial views
• Correct nodes remain connected
• Mathematically analyzed, validated in simulations
• Random sampling
• Novel memory-efficient approach
• Converges to proven independent uniform samples

The view is not all bad
Better than benign gossip
8
Brahms

1. Sampling - local component
2. Gossip - distributed component

Gossip
view
Sampler
sample
9
Sampler Building Block

• Input data stream, one element at a time
• Bias some values appear more than others
• Used with stream of gossiped ids
• Output uniform random sample
• of unique elements seen thus far
• Independent of other Samplers
• One element at a time (converging)

next
Sampler
sample
10
Sampler Implementation

• Memory stores one element at a time
• Use random hash function h
• From min-wise independent family Broder et al.
• For each set X, and all ,

next
init
Sampler
Keep id with smallest hash so far
Choose random hash function
sample
11
Component S Sampling and Validation
id streamfrom gossip
init
next
Sampler
Sampler
Sampler
Sampler
using pings
sample
Validator
Validator
Validator
Validator
S
12
Gossip Process

• Provides the stream of ids for S
• Needs to ensure connectivity
• Use a bag of tricks to overcome attacks

13
Gossip-Based Membership Primer

• Small (sub-linear) local view V
• V constantly changes - essential due to churn
• Typically, evolves in (unsynchronized) rounds
• Push send my id to some node in V
• Reinforce underrepresented nodes
• Pull retrieve view from some node in V
• Spread knowledge within the network
• Allavena et al. 05 both are essential
• Low probability for partitions and star topologies

14
Brahms Gossip Rounds

• Each round
• Send pushes, pulls to random nodes from V
• Wait to receive pulls, pushes
• Update S with all received ids
• (Sometimes) re-compute V
• Tricky! Beware of adversary attacks

15
Problem 1 Push Drowning
Push Alice
A
E
M
M
Push Bob
Push Mallory
Push Carol
B
M
M
Push Ed
Push Dana
Push MM
D
Push Malfoy
M
16
Trick 1 Rate-Limit Pushes

• Use limited messages to bound faulty pushes
  system-wide
• E.g., computational puzzles/virtual currency
• Faulty nodes can send portion p of them
• Views wont be all bad

17
Problem 2 Quick Isolation
Ha! Shes out! Now lets move on to the next guy!
Push Alice
A
E
M
Push Bob
Push Carol
Push Mallory
Push Ed
Push Dana
Push MM
Push Malfoy
C
D
18
Trick 2 Detection Recovery

• Do not re-compute V in rounds when too many
  pushes are received
• Slows down isolation does not prevent it

Push Bob
Push Mallory
Hey! Im swamped! I better ignore all of em
pushes
Push MM
Push Malfoy
19
Trick 3 Balance Pulls Pushes

• Control contribution of push - aV ids versus
  contribution of pull - ßV ids
• Parameters a, ß
• Pull-only ? eventually all faulty ids
• Pull from faulty nodes all faulty ids, from
  correct nodes some faulty ids
• Push-only ? quick isolation of attacked node
• Push ensures system-wide not all bad ids
• Pull slows down (does not prevent) isolation

20
Trick 4 History Samples

• Attacker influences both push and pull
• Feedback ?V random ids from S
• Parameters a ß ? 1
• Attacker loses control - samples are eventually
  perfectly uniform

Yoo-hoo, is there any good process out there?
21
View and Sample Maintenance
Pushed ids
Pulled ids
S
? V
?V
?V
View V
Sample
22
Key Property

• Samples take time to help
• Assume attack starts when samples are empty
• With appropriate parameters
• E.g.,
• Time to isolation gt time to convergence

Prove lower bound using tricks 1,2,3(not using
samples yet)
Prove upper bound until some good sample
persists forever
Self-healing from partitions
23
History Samples Rationale

• Judicious use essential
• Bootstrap, avoid slow convergence
• Deal with churn
• With a little bit of history samples (10) we
  can cope with any adversary
• Amplification!

24
Analysis

1. Sampling - mathematical analysis
2. Connectivity - analysis and simulation
3. Full system simulation

25
Connectivity ? Sampling

• Theorem If overlay remains connected
  indefinitely, samples are eventually uniform

26
Sampling ? Connectivity Ever After

• Perfect sample of a sampler with hash h the id
  with the lowest h(id) system-wide
• If correct, sticks once the sampler sees it
• Correct perfect sample ? self-healing from
  partitions ever after
• We analyze PSP(t) probability of perfect sample
  at time t

27
Convergence to 1st Perfect Sample

• n 1000
• f 0.2
• 40 unique ids in stream

28
Scalability

• Analysis says
• For scalability, want small and constant
  convergence time
• independent of system size, e.g., when

29
Connectivity Analysis 1 Balanced Attacks

• Attack all nodes the same
• Maximizes faulty ids in views system-wide
• in any single round
• If repeated, system converges to fixed point
  ratio of faulty ids in views, which is lt 1 if
• ?0 (no history) and p lt 1/3 or
• History samples are used, any p

There are always good ids in views!
30
Fixed Point Analysis Push
Local view node i
Local view node 1
i




Time t
push
lost push
push from faulty node



1

Time t1
x(t) portion of faulty nodes in views at round
t portion of faulty pushes to correct nodes p
/ ( p ( 1 - p )( 1 - x(t) ) )
31
Fixed Point Analysis Pull
Local view node i
Local view node 1
i




Time t
pull from i faulty with probability x(t)
pull from faulty




Time t1
Ex(t1) ? p / (p (1 - p)(1 - x(t))) ?
( x(t) (1-x(t))?x(t) ) ?f
32
Faulty Ids in Fixed Point
Assumed perfect in analysis, real history in
simulations
With a few history samples, any portion of bad
nodes can be tolerated
Perfectly validated fixed pointsand convergence
33
Convergence to Fixed Point

• n 1000
• p 0.2
• aß0.5
• ?0

34
Connectivity Analysis 2Targeted Attack
Roadmap

• Step 1 analysis without history samples
• Isolation in logarithmic time
• but not too fast, thanks to tricks 1,2,3
• Step 2 analysis of history sample convergence
• Time-to-perfect-sample lt Time-to-Isolation
• Step 3 putting it all together
• Empirical evaluation
• No isolation happens

35
Targeted Attack Step 1

• Q How fast (lower bound) can an attacker isolate
  one node from the rest?
• Worst-case assumptions
• No use of history samples (? 0)
• Unrealistically strong adversary
• Observes the exact number of correct pushes and
  complements it to aV
• Attacked node not represented initially
• Balanced attack on the rest of the system

36
Isolation w/out History Samples

• n 1000
• p 0.2
• aß0.5
• ?0

Isolation time for V60
Depend on a,ß,p
37
Step 2 Sample Convergence

• n 1000
• p 0.2
• aß0.5, ?0
• 40 unique ids

Perfect sample in 2-3 rounds
Empirically verified
38
Step 3 Putting It All TogetherNo Isolation with
History Samples

• n 1000
• p 0.2
• aß0.45
• ?0.1

Works well despite small PSP
39
Sample Convergence (Balanced)

• p 0.2
• aß0.45
• ?0.1

Convergence twice as fast with
40
Summary

• O(n1/3)-size views
• Resist Byzantine failures of linear portion
• Converge to proven uniform samples
• Precise analysis of impact of failures

41
Balanced Attack Analysis (1)

• Assume (roughly) equal initial node degrees
• x(t) portion of faulty ids in correct node
  views at time t
• Compute Ex(t1) as function of x(t), p, ?, ?, ?
• Result 1 Short-term Optimality
• Any non-balanced schedule imposes a smaller x(t)
  in a single round

42
Balanced Attack Analysis (2)

• Result 2 Existence of Fixed Point X
• Ex(t1) x(t) X
• Analyze X (function of p, ?, ?, ?)
• Conditions for uniqueness
• For ??0.5, p lt 1/3, exists X lt 1
• The view is not entirely poisoned history
  samples are not essential
• Result 3 Convergence to fixed point
• From any initial portion lt 1 of faulty ids
• From Hillam 1975 (sequence convergence)
