Title: Genetic Engineering Lab


1
Genetic Engineering Lab
  • Bio 101A
  • April 10, 2008

2
  • Describe your results from the PCR lab. Was your
    sample GMO? How do you know?
  • Describe differences between prokaryotes and
    eukaryotes.

3
Brief Overview of Lab Objectives
  1. Obtain Bacterial DNA (plasmids-pAMP and pKAN)
  2. Cut DNA into specific pieces using special
    enzymes (restriction enzymes- BamHI HindIII)
  3. Measure size of pieces cut by enzymes (gel
    electrophoresis)
  4. Glue pieces together using other enzymes (DNA
    ligase)
  5. Take glued pieces and put them into another
    bacterium (plasmid transformation of E. coli)
  6. Separate bacteria with plasmid from those
    without (antibiotic selection)

4
Todays Objectives
  • Obtain Bacterial DNA (plasmids-pAMP and pKAN)
  • Cut DNA into specific pieces using special
    enzymes (restriction enzymes- BamHI HindIII)

5
Schedule
  • 9am- 910 Book check
  • 910-915 Review questions
  • 915-935 Introduction to lab
  • 935-10am Set up restriction digest/cleanup
  • 10am-11am restriction digest
  • 10am-11am Chi square discussion/practice
  • 11am- refrigerate samples

6
Lab Concepts in Detail
7
Two Types of DNA in E. coli
  • Chromosomal DNA necessary for cell survival
    circular, double-stranded
  • Plasmid DNA extrachromosomal DNA (bonus
    material) useful for experimental manipulation
    circular, double-stranded

8
Plasmids contain nonessential (but important)
genes
9
ß-lactamase can destroy penicillin and other
ß-lactam antibiotics
10
Kanamycin interferes with Ribosomes
  • 30S ribosomal subunit is affected
  • Causes frameshift in translation
  • Toxic to humans

11
Plasmids can be cut with restriction enzymes
  • Enzymes homodimerize to make symmetrical cuts

BamHI
GATCCA GT
CG GCCTAG
sticky ends
12
Restriction Enzymes cut very specific sequences
of DNA
13
Plasmid DNA manipula-tion is at the heart of
biotech-nology
Cell containing gene of interest
Bacterium
Gene inserted into plasmid
Bacterial chromosome
Plasmid
Gene of interest
Recombinant DNA (plasmid)
DNA of chromosome
Plasmid put into bacterial cell
Recombinant bacterium
Host cell grown in culture to form a clone of
cells containing the cloned gene of interest
Protein expressed by gene of interest
Gene of interest
Copies of gene
Protein harvested
Basic research and various applications
Basic research on gene
Basic research on protein
Gene for pest resistance inserted into plants
Gene used to alter bacteria for cleaning up toxic
waste
Protein dissolves blood clots in heart attack
therapy
Human growth hor- mone treats stunted growth
14
? Phage is a temperate bacteriophage
  • Infects E. coli
  • Genome is 46,000bp long
  • dsDNA
  • Sequence is known
  • HindIII-digested genome is used as a molecular
    marker (ladder)

15
? Phage digest is a common marker
  • HindIII digest of phage genome always yields the
    same bands

16
  • Draw pictures of what you expect in the microfuge
    tubes from last week. Include as much detail as
    possible. What did the plasmids look like? What
    do they look like now? What else is in the tube?

17
Objective(s) of the lab
  • 1. Digest pAMP and pKAN with BamHI and HindIII
    restriction enzymes
  • 2. Determine size of plasmids using
    electrophoresis
  • 3. Create double antibiotic resistant plasmid
    using DNA ligase
  • 4. Transform E. coli with new plasmid
  • 5. Select for transformants using antibiotic
    media plates

18
Todays Objectives
  1. Ligate pAMP fragment to pKAN fragment
  2. Determine fragment sizes using electrophoresis
    with HindIII ? phage digest

19
Schedule
  • 810-820 Lecture spiel
  • 820-855 Denature/Pour gel
  • 9-1015 Set up/Run gel
  • 930-1015 Discuss last quiz/Drosophila/Chi-square
  • 1015-1030 Visualize gel
  • 1030-1050 Create semilog graphs of
    digest/determine fragment sizes
  • 1050-11 clean up

20
BamHI
BamHI
kanR
pKAN
pAMP
HindIII
ampR
HindIII
Ori
Ori
Restriction digest
Ori
BamHI
Ori
ampR
BamHI
HindIII
HindIII
kanR
BamHI
HindIII
Ligation
)
BamHI
kanR
HindIII
ampR
Ori
21
T4 is a Lytic bacteriophage
  • Why might a lytic bacteriophage need DNA ligase?

22
Undigested plasmids are often supercoiled
  • Supercoiling- increased or decreased number of
    twists/bp
  • Can be caused by topoisomerases (type I and type
    II)

23
Topoisomerases can cut DNA once or twice
  • Either way can increase or decrease supercoiling
  • Dimers can be made or removed by topoisomerases

24
Supercoiled, relaxed and linear DNA do not run
equally
  • Why is supercoiled faster than linear?
  • Why are dimers slower than monomers?

25
Week 3 Transforming Bacteria
  • Review Questions
  • What is our objective for the lab?
  • What was accomplished for this task last week?
  • How did what was done last week further our
    objectives for the lab?
  • Define the following
  • Plasmid
  • Ligase
  • Restriction Enzyme

26
Week 3 Transforming bacteria
  • Outline for today
  • 15 min. introduction
  • Transformation protocol (45 min.)
  • Incubation (60 min)
  • During incubation- Outline of selection (20 min)
    completion of worksheet (due Wed. noon)
  • Plating- 30 min.
  • Predict plating results- (10 min)

27
Bacterial Transformation
  • We will use chemically competent E. coli cells
  • CaCl2, ice incubation, and heat shock facilitate
    the process

28
Procedure
  • Add 200 uL of competent bacteria to LIG vial
  • Add 200 uL bacteria to any controls
  • Gently mix
  • Incubate on ice for 20 min

29
Procedure, cont.
  • Heat shock for 90 sec.
  • Place back in ice for min. 60 sec.
  • Add 800uL sterile LB to tube
  • Incubate on shaker for 60 min.

30
Sterile technique reminder
  • Bacteria are ubiquitous
  • Flame kills bacteria
  • Any contaminants will compete with our bacteria
    of interest

31
Micropipettors Review
Are fragile Expensive Precise They depend on
correct usage for accuracy
32
Competent cells
  • Transformation rate in normal cells is low
  • Transformation rate in competent cells is higher
  • We use CaCl2 to make cells chemically competent

33
How can we determine if our transformation was a
success?
34
Selecting for transformants
  • Antibiotic-infused agar media permits only
    resistant bacteria to grow
  • Our plasmids confer specific antibiotic resistance
