The DataTAG Project 1st European Across Grids
Conference Santiago de Compostela, Spain Olivier
H. Martin / CERN
http//www.datatag.org
2
Presentation outline

• Partners
• Funding agencies cooperating networks
• EU US partners
• Goals
• Networking Testbed
• Grid Interoperability
• Early results
• Status perspectives
• Major Grid networking issues
• PFLDnet workshop headlines

3
Funding agencies
Cooperating Networks

4
EU contributors

5
US contributors

6
Main Goals

• End to end Gigabit Ethernet performance using
  innovative high performance transport protocol
  stacks
• Assess, develop demonstrate inter-domain QoS
  and bandwidth reservation techniques.
• Interoperability between major GRID projects
  middleware/testbeds in Europe and North America.
• DataGrid, CrossGrid, possibly other EU funded
  Grid projects
• PPDG, GriPhyN, iVDGL, Teragrid (USA)
• LCG (LHC Computing Grid)

7
In a nutshell

• Grid related network research (WP2, WP3)
• 2.5 Gbps transatlantic lambda between CERN
  (Geneva) and StarLight (Chicago) (WP1)
• Dedicated to research (no production traffic)
• Very unique multi-vendor testbed with layer 2 and
  layer 3 capabilities
• in effect, a distributed transatlantic Internet
  Exchange Point.
• Interoperability between European and US Grids
  (WP4)
• Middleware integration and coexistence -
  Applications
• GLUE integration/standardization
• GLUE testbed and demo

8
Multi-vendor testbed with layer 2 layer 3
capabilities
STARLIGHT (Chicago)
INFN (Bologna)
CERN (Geneva)
Canarie
Abilene

ESnet
INRIA (Lyon)
GEANT
Surfnet
2.5Gbps
Juniper
Juniper
Research2.5Gbps
Cisco 6509



M
M
Alcatel
Alcatel

GBE
GBE
Cisco
Cisco
M Layer 2 Mux
9
Phase I - Generic configuration(August 2002)
Servers
CERN
StarLight
Servers
GigE switch
GigE switch
2.5Gbps
C7606
C7606
10
Phase II (March 2003)
VTHD
Routers
Servers
GigE switch
A1670 Multiplexer
GigE switch
A7770
C7606
CERN
nGigE
J-M10
C-ONS15454
Amsterdam
GEANT
STARLIGHT
Servers
Ditto
Abilene
ESNet
Canarie
11
Phase III (September 2003, tentative)
VTHD
Routers
Servers
GigE switch
Multi-Service Multiplexer
GigE switch
A7770
10Gbps
nGigE/10GigE
C7606
n2.5Gbps)
CERN
J-M10
C7609
C-ONS15454
Amsterdam
GEANT
STARLIGHT
Servers
Ditto
Abilene
ESNet
Canarie
12
DataTAG connectivity
NewYork
Abilene
32.5G
STAR-LIGHT
ESNET
CERN
2.5G
10G
MREN
STAR-TAP
Major 2.5/10 Gbps circuits between Europe USA
13
DataTAG Network map
R06chi-Alcatel7770
R06gva-Alcatel7770
W01chi w02chi w03chi w04chi w05chi w06chi
ONS15454
ONS15454
W01gva w02gva w05gva w06gva
V10chi v11chi v12chi v13chi
SURFNET
SURFNET
W03gva w04gva
Stm16(GC)
4x1GE
1GE
8x1GE
2x1GE
CANARIE
2x1GE
2x1GE
Alcatel 1670
Alcatel 1670
ONS15454
VTHD/INRIA
2x1GE
4x1GE
10x1GE
2x1GE
1GE
2x1GE
Stm16 (FranceTelecom)
1GE
1GE
1GE
2x1GE
R05gva-JuniperM10
Stm16(DTag)
Extreme Summit5i
Extreme Summit1i
R05chi-JuniperM10
R04chi-Cisco7609
R04gva-Cisco7606
10GE
Stm64(L3)
SUNNYVALE
1GE
2x1GE
DataTAG
Cisco5505-management
ABILENE
1GE
Teragrid JuniperT640
10GE
Chicago
CERN External Network
Geneva
1GE
Vlan4
Vlan5
SWITCH
1GE
Vlan7
Stm4(DTag)
1GE
1GE
Stm16(Swisscom)
Cisco2950-management
GEANT
Cernh4-Cisco7609
Cernh7-Cisco7609
ar3-chicago -Cisco7606
Stm16(Colt) backupprojects
GARR/CNAF
edoardo.martelli_at_cern.ch - last update 20021204
14
DataTAG/WP4 framework and
relationships
HEP applications, Other experiments
Integration
HICB/HIJTB
Interoperability standardization
GLUE
15
Status of GLUE activities in DataTAG

• Resource Discovery and GLUE schema
• Authorization services from VO LDAP to VOMS
• Common software deployment procedures
• IST2002 and SC2002 joint EU-US demos

Interoperability between Grid domains for core
grid services, coexistence of
optimization/collective services

• Data Movement and Description
• Job Submission Services

16
A Terabyte of research data was recently
transferred between Vancouver and CERN from
disk-to-disk at close to Gbps rates This is
equivalent to transferring a full CD in less than
8 seconds (or a full length DVD movie in less
than 1 minute)How much data is a
Terabyte?Equivalent to the amount of data on
approximately 1500 CDs (680M) or 200 full length
DVD movies
Some early results Atlas Canada Lightpath Data
Transfer Trial

• Corrie Kost, Steve McDonald (TRIUMF)
• Bryan Caron (Alberta), Wade Hong (Carleton)

17
Extreme Networks
TRIUMF
CERN
18
Comparative Results
Tool Transferred Average Max Avg
wuftp 100 MbE 600 MB 3.4 Mbps
wuftp 10 GbE 6442 MB 71 Mbps
iperf 275 MB 940 Mbps 1136 Mbps
pftp 600MB 532 Mbps
bbftp (10 streams) 1.4 TB 666 Mbps 710 Mbps
Tsunami - disk to disk 0.5 TB 700 Mbps 825 Mbps
Tusnami - disk to memory 12 GB gt 1GBps
19
Project status

• Great deal of expertise on high speed transport
  protocols is now available through DataTAG
• We plan to make more active dissemination in 2003
  to share our experiences with the Grid community
  at large
• The DataTAG testbed is open to other EU Grid
  projects
• In order to guarantee excluse access to the
  testbed a reservation application has been
  developed
• Proved to be essential
• As the access requirements to the testbed are
  evolving (e.g. access to GEANT, INRIA) and as the
  testbed itself is changing (e.g. inclusion of
  additional layer 2 services)
• Additional features will need to be provided

20
Major Grid networking issues (1)

• QoS (Quality of Service)
• Still largely unresolved on a wide scale because
  of complexity of deployment
• Non elevated services like Scavenger/LBE (lower
  than best effort) or Alternate Best Effort (ABE)
  are very fashionable!
• End to end performance in the presence of
  firewalls
• There is (will always be) a lack of high
  performance firewalls, can we rely on products
  becoming available or should a new architecture
  be evolved?
• Full ransparency
• Evolution of LAN infrastructure to 1Gbps then
  10Gbps
• Uniform end to end performance (LAN/WAN)

21
CERNs new firewall architecture
Gbit Ethernet
Regular flow
HTAR (High Throughput Access Route)
CERNH2 (Cisco OSR 7603)
1/10 Gbit Ethernet
FastEthernet
CiscoPIX
FastEthernet
FastEthernet
Cabletron SSR
Securitymonitor
Gbit Ethernet
22
Major Grid networking issues (2)

• TCP/IP performance over high bandwidth, long
  distance networks
• The loss of a single packet will affect a 10Gbps
  stream with 100ms RTT (round trip time) for 1.16
  hours. During that time the average throughput
  will be 7.5 Gbps.
• On the 2.5Gbps DataTAG circuit with 100ms RTT,
  this translates to 38 minutes recovery time,
  during that time the average throughput will be
  1.875Gbps.
• Link error loss events rates
• A 2.5 Gbps circuit can absorb 0.2 Million 1500
  Bytes packets/second
• Bit error rates of 10E-9 means one packet loss
  every 250 milliseconds
• Bit error rates of 10E-11 means one packet loss
  every 25 seconds

23
TCP/IP Responsiveness (I)Courtesy S. Ravot
(Caltech)

• The responsiveness measures how quickly we go
  back to using the network link at full capacity
  after experiencing a loss if we assume that the
  congestion window size is equal to the Bandwidth
  Delay product when the packet is lost.

C Capacity of the link
2
C . RTT
r
2 . MSS
24
TCP/IP Responsiveness (II) Courtesy S. Ravot
(Caltech)
Case C RTT (ms) MSS (Byte) Responsiveness
Typical LAN in 1988 10 Mb/s 2 20 1460 1.7 ms 171 ms
Typical LAN today 1 Gb/s 2(worst case) 1460 96 ms
Future LAN 10 Gb/s 2(worst case) 1460 1.7s
WAN Geneva lt-gt Chicago 1 Gb/s 120 1460 10 min
WAN Geneva lt-gt Sunnyvale 1 Gb/s 180 1460 23 min
WAN Geneva lt-gt Tokyo 1 Gb/s 300 1460 1 h 04 min
WAN Geneva lt-gt Sunnyvale 2.5 Gb/s 180 1460 58 min
Future WAN CERN lt-gt Starlight 10 Gb/s 120 1460 1 h 32 min
Future WAN link CERN lt-gt Starlight 10 Gb/s 120 8960 (Jumbo Frame) 15 min
The Linux kernel 2.4.x implements delayed
acknowledgment. Due to delayed acknowledgments,
the responsiveness is multiplied by two.
Therefore, values above have to be multiplied by
two!
25
Maximum throughput with standard Window sizesas
a function of the RTT

• W(KB) 16 32 64
• RTTms
• 25 640K 1.28M 2.56MB/s
• 50 320K 640K 1.28MB/s
• 100 160K 320K 640KB/s
• N.B. The best throughput one can hope for, on a
  standard intra-European path with 50ms RTT, is
  only about 10Mb/s!

26
Considerations onWAN LAN

• For many years the Wide Area Network has been the
  bottlemeck, hence the common belief that if that
  bottleneck was to disappear, a global transparent
  Grid could be easily deployed!
• Unfortunately, in real environments good end to
  end performance, e.g. Gigabit Ethernet, is
  somewhat easier to achieve when the bottleneck
  link is in the WAN rather than in the LAN.
• E.g. 1GigE over 622M rather than 1GigE over 2.5G

27
Considerations on WAN LAN (cont)

• The dream of abundant bandwith has now become a
  reality in large, but not all, parts of the
  world!
• Challenge shifted from getting adequate bandwidth
  to deploying adequate LANs and security
  infrastructure as well as making effective use of
  it!
• Major transport protocol issues still need to be
  resolved, however there are very encouraging
  signs that practical solutions may now be in
  sight (see PFLDnet summary).

28
PFLDnet workshop(CERN Feb 3-4)

• 1st workshop on protocols for fast long distance
  networks
• Co-organized by Caltech DataTAG
• Sponsored by Cisco
• Most key actors were present
• e.g. S. Floyd, T. Kelly, S. Low
• Headlines
• High Speed TCP (HSTCP), Limited Slow start
• Quickstart, XCP, Tsunami
• GridDT, Scalable TCP, FAST (Fast AQM (Active
  Queue Management)

29
TCP dynamics(10Gbps, 100ms RTT, 1500Bytes
packets)

• Window size (W) BandwidthRound Trip Time
• Wbits 10Gbps100ms 1Gb
• Wpackets 1Gb/(81500) 83333 packets
• Standard Additive Increase Multiplicative
  Decrease (AIMD) mechanisms
• WW/2 (halving the congestion window on loss
  event)
• WW 1 (increasing congestion window by one
  packet every RTT)
• Time to recover from W/2 to W (congestion
  avoidance) at 1 packet per RTT
• RTTWp/2 1.157 hour
• In practice, 1 packet per 2 RTT because of
  delayed acks, i.e. 2.31 hour
• Packets per second
• RTTWpackets 833333 packets

30
HSTCP (IETF Draft August 2002)

• Modifying TCPs response function in order to
  allow high performance in high-speed environments
  and in the presence of packet losses
• Target
• 10Gbps performance in 100ms Round Trip Times
  (RTT) environments
• Acceptable fairness when competing with standard
  TCP in environments with packet loss rates of
  10-4 or 10-5.
• Wmss 1.2/sqrt(p)
• Equivalent to W/1.5 RTT between losses

31
HSTCP Response Function(Additive Increase HSTCP
vs standard TCP)

• Packet Congestion RTTs between
• Drop Rate Window Losses
• 10-2 12 8
• 10-3 38 25
• 10-4 120(263) 80(38)
• 10-5 379(1795) 252(57)
• 10-6 1200(12279) 800(83)
• 10-7 3795(83981) 2530(123)
• 10-10 120000(26864653) 80000(388)

32
Limited Slow-Start (IETF Draft August 2002)

• Current  slow-start  procedure can result in
  increasing the congestion window by thousands of
  packets in a single RTT
• Massive packet losses
• Counter-productive
• Limited slow-start introduces a new parameter
  max_ssthresh in order to limit the increase of
  the congestion window.
• max_ssthresh lt cwnd lt ssthresh
• Recommended value 100 MSS
• K int (cwnd/(0.5max_ssthresh))
• When cwnd gt max_ssthresh
• Cwnd int(MSS/K) for each receivingACK
• instead of Cwnd MSS
• This ensures that cwnd is increased by at most
  max_ssthresh/2 per RTT, i.e.
• ½MSS when cwndmax_ssthresh,
• 1/3MSS when cwnd1.5max_ssthresh,
• etc

33
Limited Slow-Start (cont.)

• With limited slow-start it takes
• Log(max_ssthresh) RTTs
• to reach the condition where cwnd max_ssthresh
• Log(max_ssthresh) (cwnd max_ssthresh)/(max_sst
  resh/2) RTTs
• to reach a congestion window of cwnd when cwnd gt
  max_ssthresh
• Thus with max_ssthresh 100 MSS
• It would take 836 RTT to reach a congestion
  window of 83000 packets
• Compared to 16 RTT otherwise (assuming NO packet
  drops)
• Transient queue limited to 100 packets against
  32000 packets otherwise!
• Limited slow-start could be used in conjunction
  with rate based pacing

34
Slow-start vs Limited Slow-start
100000
ssthresh (83333)
10000
Congestion window size (MSS)
1000
max-ssthresh (100)
100
10Gbps bandwidth! (RTT100msec, MSS1500B)
16000
1600
Time (RTT)
160
16
35
QuickStart

• Initial assumption is that routers have the
  ability to determine whether the destination link
  is significantly under-utilized
• Similar capabilities also assumed for Active
  Queue Management (AQM) and Early Congestion
  Notifications (ECN) techniques
• Coarse grain mechanism only focusing on initial
  window size
• Incremental deployment
• New IP TCP options
• QS request (IP) QS response (TCP)
• Initial Window size RateRTTMSS

36
QuickStart (cont.)

• SYN/SYN-ACK IP packets
• New IP option Quick Start Request (QSR)
• Two TTL (Time To Live)
• IP QSR
• Sending rate expressed in packet rates per 100ms
• Therefore maximum rate is 2560 packets/seconds
• Rate based pacing assumed
• Non-participating router ignores QSR option
• Therefore does not decrease QSR TTL
• Participating router
• Delete QSR option or reset initial sending rate
• Accept or reduce initial rate

37
Scalable TCP(Tom Kelly Cambridge)

• The Scalable TCP algorithm modifies the
  characteristic AIMD behaviour of TCP for the
  conditions found with high bandwidth delay links.

• This work differs from the High Speed TCP
  proposal by using a fixed adjustment for both the
  increase and the decrease of the congestion
  window.
• Scalable TCP alters the congestion window, cwnd,
  on each acknowledgement in a RTT without loss by
• cwnd -gt cwnd 002
• and for each window experiencing loss, cwnd is
  reduced by,
• cwnd -gt cwnd 0.125cwnd

38
Scalable TCP (2)

• The responsiveness of traditional TCP connection
  to loss events is proportional to
• the connections window size and round trip
  time.
• With Scalable TCP the responsiveness is
  proportional to the round trip time only.
• this invariance to link bandwidth allows Scalable
  TCP to outperform traditional TCP in high speed
  wide area networks.
• For example, the responsiveness of a connection
  with round trip time 200ms
• for a traditional TCP connection it is nearly 3
  minutes at 100 Mbit/s and 28 minutes at 1 Gbit/s
• while a connection using Scalable TCP will have a
  packet loss recovery time about 2.7s at any rate.

39
Scalable TCP status

• Scalable TCP has been implemented on a Linux
  2.4.19 kernel.
• The implementation went through various
  performance debugging iterations primarily
  relating to kernel internal network buffers and
  the SysKonnect driver.
• These alterations, termed the gigabit kernel
  modifications, remove the copying of small
  packets in the SysKonnect driver and the scale
  device driver decoupling buffers to reflect
  Gigabit Ethernet devices.
• Initial results on performance suggest that the
  variant is capable of providing high speed in a
  robust manner using only sender side
  modifications.
• Up to 400 improvement over standard Linux 2.4.19
• It is also intended to improve the code
  performance to lower CPU utilisation where, for
  example, currently a transfer rate of 1 Gbit/s
  uses 50 of a dual 2.2Ghz Xeon including the user
  (non-kernel) copy.

40
Grid DT(Sylvain Ravot/Caltech)

• Similar to MulTCP i.e. aggregate N virtual TCP
  connections on a single connection
• Avoid the brute force approach of opening N
  parallel connections a la GridFTP or BBFTP
• Set of patches to Linux RedHat allowing to
  control
• Slow start threshold behaviour
• AIMD parameters

41
Linux Patch GRID DT

• Parameter tuning
• New parameter to better start a TCP transfer
• Set the value of the initial SSTHRESH
• Modifications of the TCP algorithms (RFC 2001)
• Modification of the well-know congestion
  avoidance algorithm
• During congestion avoidance, for every
  acknowledgement received, cwnd increases by A
  (segment size) (segment size) / cwnd.This is
  equivalent to increase cwnd by A segments each
  RTT. A is called additive increment
• Modification of the slow start algorithm
• During slow start, for every acknowledgement
  received, cwnd increases by M segments. M is
  called multiplicative increment.
• Note A1 and M1 in TCP RENO.
• Smaller backoff
• Reduce the strong penalty imposed by a loss

42
Grid DT

• Very simple modifications to the TCP/IP stack
• Alternative to Multi-streams TCP transfers
• Single stream vs Multi streams
• it is simpler
• startup/shutdown are faster
• fewer keys to manage (if it is secure)
• Virtual increase of the MTU.
• Compensate the effect of delayed ack
• Can improve fairness
• between flows with different RTT
• between flows with different MTU

43
Comments on above proposals

• Recent Internet history shows that
• any modifications to the Internet standards can
  take years before being
• accepted and widely deployed,
• especially if it involves router modifications,
  e.g.
• RED, ECN
• Therefore, the chances of getting Quickstart or
  XCP type proposals implemented in commercial
  routers soon are somewhat limited!
• Modifications to TCP stacks are more promising
  and much easier to deploy incrementally when
• Only the TCP stack of the sender is affected
• Is Active network technology a possible solution
  to the help solve de-facto freeze of the
  Internet?

44
Additional slides

• Tsunami (S. Wallace/Indiana Uni)
• Grid DT (S. Ravot/Caltech)
• FAST (S. Low/Caltech)

45
The Tsunami Protocol(S. Wallace/University of
Indiana)

• Developed specifically to address extremely
  high-performance batch file transfer over
  global-scale WANs.
• Transport is UDP using 32K datagrams/blocks
  superimposed over standard 1500-byte Ethernet
  packets.
• No sliding window (a-la TCP), each missed/dropped
  block is re-requested autonomously (similar to
  smart ACK)
• Very limited congestion avoidance compared to
  TCP. Loss behavior is similar to Ethernet
  collision behavior, not TCP congestion avoidance.

46
Tsunami Protocol
UDP Data Flow

4
3
9
Data
Type
Seq
Data
Type
Seq
Data
Type
Seq
Server
(retransmit request)
(shutdown request)
Client
5
6
7
8
TCP Control Flow
47
Effect of the MTU on the responsiveness
Effect of the MTU on a transfer between CERN and
Starlight (RTT117 ms, bandwidth1 Gb/s)

• Larger MTU improves the TCP responsiveness
  because you increase your cwnd by one MSS each
  RTT.
• Couldnt reach wire-speed with standard MTU
• Larger MTU reduces overhead per frames (saves
  CPU cycles, reduces the number of packets)

48
TCP

• Carries gt90 Internet traffic
• Prevents congestion collapse
• Not scalable to ultrascale network
• Equilibrium and stability problems

Ns2 Simulation
49
Intellectual advances

• New mathematical theory of large scale networks
• FAST Fast Active-queue-managed Scalable TCP
• Innovative implementation TCP stack in Linux
• Experimental facilities
• High energy physics networks
• Caltech and CERN/DataTAG site equipmentSwitches,
  Routers Servers
• Level(3) SNV-CHI OC192 Link DataTAG link Cisco
  12406, GbE and 10 GbE port cards donated
• Abilene, Calren2,
• Unique features
• Delay (RTT) as congestion measure
• Feedback loop for resilient window, and stable
  throughput

50
SCinet Bandwidth Challenge
SC2002 Baltimore, Nov 2002
Highlights

• FAST TCP
• Standard MTU
• Peak window 14,100 pkts
• 940 Mbps single flow/GE card
• 9.4 petabit-meter/sec
• 1.9 times LSR
• 9.4 Gbps with 10 flows
• 37.0 petabit-meter/sec
• 6.9 times LSR
• 16 TB in 6 hours with 7 flows
• Implementation
• Sender-side modification
• Delay based
• Stabilized Vegas

Sunnyvale-Geneva
Baltimore-Geneva
Baltimore-Sunnyvale
SC2002 10 flows
SC2002 2 flows
I2 LSR
29.3.00 multiple
SC2002 1 flow
9.4.02 1 flow
22.8.02 IPv6
C. Jin, D. Wei, S. Low FAST Team Partners
netlab.caltech.edu/FAST
51
Stability from CIT and SLAC Booths to
StarlightSNV and to Abilene
10
9
Rapid recovery after disaster
Power glitch Reboot
8
7
BW Gbps
6
5
4
14 Streams 11.5 Gbps 10 Streams (9 Gbps) to
Starlight SNV, With 150 Mbps of Acks4
Streams to Abilene
3
2
1
0
100
200
300
600
500
400
700
900
800
Secs
52
SCinet Bandwidth Challenge
SC2002 Baltimore, Nov 2002
Bmps pbm/s Thruput Mbps Duratn sec
10 flows 37.0 9,400 300
1 flow 9.42 940 1,152
Multiple 5.38 1,020 82
1 flow 4.93 402 13
IPv6 0.03 8 3,600
FAST 7 flows
Statistics Data 2.857 TB Distance 3,936
km Delay 85 ms Average Duration 60
mins Thruput 6.35 Gbps Bmps 24.99
petab-m/s Peak Duration 3.0 mins Thruput 6.58
Gbps Bmps 25.90 petab-m/s
cwnd 6,658 pkts per flow
17 Nov 2002 Sun
Network SC2002 (Baltimore) ? SLAC (Sunnyvale) GE,
Standard MTU, cwnd 6,658 pkts
netlab.caltech.edu/FAST

• Acknowledgments
• Prototype
• C. Jin, D. Wei
• Theory
• D. Choe (Postech/Caltech), J. Doyle, S. Low, F.
  Paganini (UCLA), J. Wang, Z. Wang (UCLA)
• Experiment/facilities
• Caltech J. Bunn, S. Bunn, C. Chapman, C. Hu
  (Williams/Caltech), H. Newman, J. Pool, S. Ravot
  (Caltech/CERN), S. Singh
• CERN O. Martin, P. Moroni
• Cisco B. Aiken, V. Doraiswami, M. Turzanski, D.
  Walsten, S. Yip
• DataTAG E. Martelli, J. P. Martin-Flatin
• Internet2 G. Almes, S. Corbato
• SCinet G. Goddard, J. Patton
• SLAC G. Buhrmaster, L. Cottrell, C. Logg, W.
  Matthews, R. Mount, J. Navratil
• StarLight T. deFanti, L. Winkler
• Major sponsors/partners

Statistics Data 273 GB Distance 10,025
km Delay 180 ms Average Duration 43
mins Thruput 847 Mbps Bmps 8.49
petab-m/s Peak Duration 19.2 mins Thruput 940
Mbps Bmps 9.42 petab-m/s
FAST 1 flows
cwnd 14,100 pkts
17 Nov 2002 Sun
Network CERN (Geneva) ? SLAC (Sunnyvale) GE,
Standard MTU, cwnd 14,100 pkts
53
FAST Summary (Les Cottrell/SLAC)

• Our team achieved outstanding success with the
  Level(3) circuit from Sunnyvale to
  Chicago/StarLight (for a blow by blow account
  see
• http//www-iepm.slac.stanford.edu/monitoring/bulk/
  sc2002/hiperf.htm
• With a new experimental TCP stack being developed
  by Steven Low his group at Caltech (see
  http//netlab.caltech.edu/) we demonstrated over
  950Mbits/s from SC2002 to Sunnyvale ( 3000km)
  TCP traffic with standard packet sizes (MSS 1460
  bytes).
• Using 12 hosts at SC2002 to Sunnyvale we
  demonstrated over 9 Gbits/s TCP traffic over a
  10Gbit/s circuit (rather stably).
• From Amsterdam to Sunnyvale with the NIKHEF
  CERN people we demonstrated a single TCP stream
  923Mbits/s over 10974 km, and have submitted an
  Internet 2 Land Speed Record Entry (see
  http//www.internet2.edu/lsr/).
• For the SC002 Bandwidth Challenge we were able to
  sustain 11.5 Gbits/s (see http//wwwiepm.slac.stan
  ford.edu/monitoring/bulk/sc2002/bwc-scinet-plot.g
  if) for 15 minutes using the Level (3) Sunnyvale
  link and the SC2002 10GBit/s Abilene link.

54
Single stream vs Multiple streams effect of a
single packet loss (e.g. link error, buffer
overflow)
Streams/Throughput 10 5 1 7.5 4.375 2 9.375
10
Avg. 7.5 Gbps
Throughput Gbps
7 5
Avg. 6.25 Gbps
Avg. 4.375 Gbps
5
Avg. 3.75 Gbps
2.5
T 1.16 hours! (RTT100msec, MSS1500B)
Time
T
T
T
T
