The world wide web

1
The world wide web
Chapter 4
2
Learning outcomes

• Explain in general terms how web documents are
  transferred across the Internet and
• What processes are triggered when you click on
  hyperlink
• Code web pages using HTML and XHTML using style
  sheets.
• Explain why it is advisable to use XHTML rather
  than HTML
• Describe some technologies available for dynamic
  web pages

3
Essential Reading

• Joe Casad, Teach yourself TCP/IP, Ch. 17
• William Buchanan, Mastering The Internet, Ch. 6-8
• Introductory materials on HTML XHTML either a
  text book such as
• John Shelly, HTML AND CSS explained, or
• http/www.webMonkey.com
• http//www.w3schools.com

4
Additional reading

• William Buchanan, Mastering The Internet, Ch.
  9-10
• Andrew Tanenbaum, Computer Networks, Ch. 7.3
• Douglas Comer, Computer Netwoks and Networking,
  ch. 32-33
• Chuck Masciano and Bill Kennedy, HTML and XHTML
  the definitive guide, for reference
• http//www.pcnetworkadvisor.com
• Mike Lewis, Understanding Javascript,
  June-Jully 2000

5
How the web works

• The client-server model
• Client and server operate on machines which are
  able to communicate through a network
• The server waits for requests from a clients
• Server receives a requests from a client
• Performs a the requested work
• Or lookup the requested data
• And send a response to the client
• Servers file servers, web servers, name servers
• Clients browsers, email clients

6
url format

• ltschemegt//ltserver-domain-namegt/ltpathmanegt
• ltschemegt which protocol to use
• http in general
• file which tells the client document is in a
  local machine
• ftp file transfer protocol
• ltserver-domain-namegt identifies the server system
• i.e. www.doc.gold.ac.uk
• ltpathnamegt tells the server where to find the
  file
• http//doc.gold.ac.uk/username/index.html

7
Web browsers and servers

• A browser is a program that can retrieve files
  from the world wide web and render text, images,
  or sounds encoded in the files.
• i.e. IE, Nescape, Mozilla
• A web server is an application which waits for
  client requests, fetches requested documents from
  disk and transmits them the client.
• i.e Apache

8
What happened when you click on hyperlink?

• Determine URL and extract domaine name.
• Use the name server to get IP address (DNS)
• Make a TCP connect to port 80
• And send a request for a web page once the server
  has accepted to connection.
• The server send the file and releases the TCP
  connection
• The client displays the document.

9
Other possibilities

• The steps in the previous slide are for
  displaying a static web page from a remote
  machine.
• Other possibilities are
• Page is loaded from a local system
• no tcp connection
• url begin with file//...
• The page is dynamically generated by a
  client-side script
• No tcp connection
• The page is dynamically generated by a
  server-side script
• The server may carry out other functions
• Secure server
• Check users identity if they are authorised to
  access a particular resources

10
Stateless connection

• Both client and server release TCP connection
  after a page has been transferred.
• HTTP1.0 is stateless
• Connections are not persistent
• There is no indication to the server whether new
  transactions involve the same client
• HTTP 1.1 is persistent
• By keeping track of the client IP addresses
• However, there is no way of identifying a
  repeated visits to the site by the same user.
• Futhermore, ISPs reallocate IP addresses to
  dial-up customers as new user dial in.

11
Cookies

• Request the browser to store a small data file
  (cookie) on the users hard disk.
• Which can serve to identify users only.
• For instance it could contain a key into a
  database on the server machine.
• Most browsers nowadays allow you to decide
  whether or not you want cookies on your machine.

12
Introduction to HTML
13
What is an HTML File?

• HTML stands for HyperText Markup Language
• An HTML file is a text file containing small
  markup tags
• The markup tags tell the Web browser how to
  display the page
• An HTML file must have an htm or html file
  extension
• An HTML file can be created using a simple text
  editor

14
Internet - Services

• Email MIME (Multipurpose Internet Mail
  Extensions)text (text/html), image, video, etc.
• Telnet ssh
• FTP File Transfer Protocol
• Gopher
• IRC Internet Relay Chat
• Newsgroups
• WWW World Wide WebHTTP (Hypertext transfer
  protocol) uses a Question-Answer-Scheme, i.e. a
  browser sends a request und gets a response from
  a server. Note the server does not send out
  anything without a request.

15
Markup languages

• Suppose we have a document containing only plain
  text
• We tag certain parts of the document to indicate
  what they are and how they should be formatted
• This procedure is called marking-up the document
• Tags are usually paired
• e.g. lttitlegtMy Memoirslt/titlegt
• A pair of tags plus their content constitute an
  element
• Un-paired tags are called empty tags

16
Markup languages

• Physical vs Semantic markup
• physical refers to appearance (style) on the page
• semantic refers to structure and meaning
• HTML is the HyperText Markup Language
• HTML is based on SGML (Standard Generalised
  Markup Language) which is more complex
• HTML has a fixed set of tags but is constantly
  evolving, but newer versions are downward
  compatible

17
Markup languages

• HTML places primary emphasis on structure
• paragraphs, headings, lists, images, links, .
• HTML places secondary emphasis on style (CSS)?
• fonts, colours, .
• HTML does not label the meaning of the text (XML)?

18
A basic document

• Every document should start with the following
  line

lt!DOCTYPE html PUBLIC -//W3C//DTD HTML 4.0
Transitional//ENgt

• There are three required elements, defined by the
  tags lthtmlgt, ltheadgt and ltbodygt

lthtmlgt ltheadgt lttitlegtMy Home Pagelt/titlegt
lt/headgt ltbodygt lth1gtWelcomelt/h1gt
lt/bodygt lt/htmlgt
19
Basic structure elements

• first and last tags
• The HEAD section
• must come before the BODY section
• contains generic information about the document
• Elements specified in the HEAD section can
  include
• title, link, script, style
• The BODY section
• contains the content of the document (text,
  images etc)
• this content is structured by other tags

20
Block elements

• Block elements define sections of text, usually
  preceded by a blank line
• ltpgtlt/pgt - paragraph
• lth1gtlt/h1gt...lth6gtlt/h6gt - headings
• ltpregtlt/pregt - preserve (original format)?
• ltblockquotegtlt/blockquotegt - indented text
• ltdivgtlt/divgt - division
• used to identify a section of the document that
  may be subject to special formatting (for
  example, using stylesheets).

21
Paragraphs

• Paragraphs ltpgt...lt/pgt
• force a break between the enclosed text and the
  text surrounding it
• the tagged region of text may be subject to
  special formatting
• ltp align"center"gtHere is another paragraphlt/pgt
• align is an attribute of the paragraph tag
• center is the value of the align attribute

ltpgthere is a piece of text that has been placed
inside a paragraphlt/pgt ltp align"center"gtHere is
another paragraphlt/pgt
22
Headings

• Six levels of importance lth1gt...lth6gt
• Use headings to divide document into sections

lthtmlgt ltheadgt lttitlegtHeadingslt/titlegt
lt/headgt ltbodygt lth2gtChapter 1lt/h2gt lth3gt1.
Introductionlt/h3gt This is the introduction
lth3gt2. Next sectionlt/h3gt This is the next
section lth4gt2.1 A subsectionlt/h4gt This is a
subsection lt/bodygt lt/htmlgt
23
Element relationships

• The elements marked by tags form a hierarchy
• The root element is html (marked by
  lthtmlgt...lt/htmlgt)?
• It usually has two children head and body
• each of these are further subdivided
• There are rules for which elements can contain
  other elements
• e.g. headers cannot contain headers
• see http//www.w3.org/ for a full list of rules
• Elements must not overlap each other
• we cannot have lth1gt...lta..gt ... lt/h1gt...lt/agt
• we can have lth1gt...lta..gt ... lt/agt...lt/h1gt

24
Inline descriptive elements

• Descriptive elements affect the appearance of
  text depending on how the text is described
• ltemgtlt/emgt emphasis, usually with italics
• ltstronggtlt/stronggt strong, usually with bold
• ltcitegtlt/citegt citation, usually in italics
• ltcodegtlt/codegt usually results in monotype spacing

ltbodygt A ltemgtfascinatinglt/emgt subject that I
ltstronggtmustlt/stronggt understand lt/bodygt
25
Inline explicit style elements

• ltboldfacegtlt/boldfacegt
• ltbiggtlt/biggt bigger font than surrounding text
• ltsmallgtlt/smallgt smaller font than surrounding
  text
• ltigtlt/igt italics
• ltsgtlt/sgt strikethrough
• ltsubgtlt/subgt subscripts
• ltsupgtlt/supgt superscripts
• ltspangtlt/spangt delimits text for stylesheet
  control
• ltdivgtlt/divgt delimits blocks of text for
  stylesheet control

26
Inline explicit style elements

• ltfontgt attributes
• face - name of font (must be installed)?
• "arial", "times", "verdana", "helvetica"
• size - absolute size (1-7), or relative to
  previous text
• "2", "5", "7", "1", "-2"...
• color - hexadecimal RGB, or a named color
• "3399dd", "blue", "red"
• weight - boldness from 100, 200, ..., 900
• "100", "300", "900"
• e.g.

ltfont face"arial" size"1" color"pink"
weight"300"gt
27
Ordered and Unordered Lists
some normal text ltolgt ltligtappleslt/ligt ltligtorangeslt
/ligt ltligtpearslt/ligt ltligtbananaslt/ligt lt/olgt
some normal text ltulgt ltligtappleslt/ligt ltligtorangeslt
/ligt ltligtpearslt/ligt ltligtbananaslt/ligt lt/ulgt
28
Comments

• Comments are delimited by lt!-- and --gt
• lt! this is a comment --gt
• Comments may span multiple lines

ltbodygt lt!-- this is a comment --gt lt/bodygt
29
Special characters
ltbodygt A ltemgt lt fascinating gt lt/emgt subject
that I ltstronggtmnbspunbspsnbsptlt/stronggt
understand lt/bodygt

• Some characters such as lt, gt, " and have
  special meanings.
• To prevent them being interpreted as HTML code,
  they must be written as follows lt gt quot
  amp
• Blank space is normally ignored in HTML. To
  include a space in your document use nbsp

30
Links and Images
Link
ltbodygt The Department of lta href"http//www.doc.
gold.ac.uk/index.html"gt Computing lt/agt is a very
.... lt/bodygt
images
ltimg src"mypicture.gif" alt"my picture"gt
src attribute specifies the file containing the
image alt attribute specifies the text to be
displayed if the image is not viewed
31
Colour RGB Model

• ff0000 (red),
• 00ff00 (green)?
• 0000ff (blue)?
• ffff00 (yellow)?
• ...
• 3395ab (a pastel blue)?

ltbody bgcolor"994422"gt
ltbody text"994422"gt
ltbody background"tileimage.gif"gt
32
Forms

• Server-based programs may return data to the
  client as a web page
• Client-side scripts can read input data
• To validate the data, prior to sending to server
• To use in local processing which may output web
  page content that is displayed on the client

33
Example applications

• Questionnaires to provide feedback on a web site
• e-commerce, to enter name, address, details of
  purchase and credit-card number
• request brochures from a company
• make a booking for holiday, cinema etc.
• buy a book, cd, etc
• obtain a map giving directions to a shop
• Run a database query and receive results (an
  important part of e-commerce)?

34
Forms
Input types

• text
• checkbox
• radio (buttons)?
• select (options)?
• textarea
• password
• button
• submit
• reset
• hidden
• file
• image

35
The method and action attributes

• The method attribute specifies the way that form
  data is sent to the server program
• GET appends the data to the URL
• POST sends the data separately
• The action attribute specifies a server program
  that processes the form data (often as a URL)?

ltbodygt ltform method"POST" action"comments.php"gt
lth2gtTell us what you thinklt/h2gt lt!-- etc
--gt lt/formgt lt/bodygt
36
Text, checkbox and Radio button

• The type attribute specifies the type of user
  input
• The name attribute gives an identifier to the
  input data

ltform method"POST" action"comments.php"gt
lth2gtTell us what you thinklt/h2gt Name ltinput
name"name" type"text size"20"gtltbrgt Address
ltinput name"address" type"text"
size"30"gt lt/formgt
How did you hear about this web site?ltbrgt A
friend ltinput type"checkbox" namename"
value"friend"gtltbrgt Search engine ltinput
type"checkbox" namename" value"engine"gtltbrgt
How did you hear about this web site?ltbrgt A
friend ltinput type"radio" namename"
value"friend"gtltbrgt Search engine ltinput
type"radio" namename" value"engine"gtltbrgt lt!
etc --gt
37
The input element type"submit/reset and
select element
Thank youltbrgt ltinput type"submit" name"send"
value"Send"gt ltinput type"reset" name"clear"
value"Clear"gtltbrgt
How do you rate this site?ltbrgt ltselect
name"rating"gt ltoptiongtGood ltoption
selectedgtBad ltoptiongtUgly lt/selectgt
38
Tables
lttable border"1"gt lttrgt ltthgtNamelt/thgt lttdgtA
B Morganlt/tdgt lttdgtD P Joneslt/tdgt lt/trgt lttrgt
ltthgtCourselt/thgt lttdgtFishinglt/tdgt
lttdgtSailinglt/tdgt lt/trgt lttrgt ltthgtYearlt/thgt
lttdgt8lt/tdgt lttdgt5lt/tdgt lt/trgt lttrgt lt/tablegt

• lttablegt main element
• lttrgt table row
• ltthgt table header
• lttdgt table data

39
The align and width attributes

• The align attribute determines the position of
  the text within a cell
• The width attribute determines the width of the
  row relative to the table

lttable border"1" align"center"gt lttrgt ltth
colspan"2" width"60"gtNamelt/thgt ltth
rowspan"2"gtCourselt/thgt ltth rowspan"2"gtYearlt/th
gt lt/trgt lttrgt ltthgtLastlt/thgt ltthgtInit.lt/thgt
lt/trgt lttrgt lttdgtMorganlt/tdgt lttdgtABlt/tdgt
lttdgtFishinglt/tdgt lttd align"center"gt5lt/tdgt
lt/trgt lt! etc --gt
40
Table attributes

• Table attributes
• align alignment relative to the page
• width in pixels or percentage of page width
• border - width of border (pixels)?
• cellspacing separation between cells (pixels)?
• cellpadding - space around data inside cell
  (pixels)?
• bgcolor - background colour (inside cells)?

• Furthermore
• The ltcaptiongt element puts a title above the table

41
Table attributes
lttable border"3" align"center" cellspacing"6"
cellpadding"6" bgcolor"cyan"gt ltcaptiongt
lth2gtCourse Datalt/h2gt lt/captiongt lttrgt
ltthgtNamelt/thgt ltthgtCourselt/thgt ltthgtYearlt/thgt
lt/trgt lttrgt lttdgtA B Morganlt/tdgt
lttdgtFishinglt/tdgt lttdgt5lt/tdgt lt/trgt lt! etc --gt
42
Frames and Framesets

• A frameset partitions a web browser window so
  that multiple web documents can be displayed
  simultaneously.
• Example application To maintain a permanently
  visible directory of links within your site,
  while also displaying one or more selected
  documents from the site.

43
Framesets
lthtmlgt ltheadgtlttitlegtFrames 1lt/titlegtlt/headgt
ltframeset cols"140,"gt ltframe name"navF"
src"navigation.html"gt ltframe name"mainF"
src"intro.html"gt lt/framesetgt lt/htmlgt

• The frameset element replaces the body element
• frameset has attributes cols or rows, defined in
  terms of pixels, percentage() or unspecified ()

• this splits the window into two or more columns
  or rows

44
Noframes

• Some browsers cannot process frames. Alternative
  content should be provided using the noframes
  element

lthtmlgt ltheadgtlttitlegtFrames 1lt/titlegtlt/headgt
ltframeset cols"140,"gt ltframe name"navF"
src"navigation.html"gt ltframe name"mainF"
src"intro.html"gt lt/framesetgt ltnoframesgt
ltbodygt Something here for browsers not
supporting frames lt/bodygt lt/noframesgt lt/htmlgt
45
Styles

• Styles can be defined
• Inline styles
• Global styles
• Stylesheets (Cascading stylesheets)

lth1 style"color2255ff borderridge"gtInline
styleslt/h1gt
ltheadgt lttitlegtStyleslt/titlegt ltstylegt lt!-- h1
color red border thin groove
text-aligncenter --gt lt/stylegt lt/headgt
ltlink rel"StyleSheet" type"text/css" href"URL"gt
46
Classes

• Simple style rules change the appearance of all
  instances of the associated element
• A class is a style definition that may be applied
  as and when we choose
• if we don't want the styles, we don't have to use
  them
• Simple classes are applied to a single type of
  element
• Anonymous classes can be applied to any type of
  element

47
Simple classes
lt/headgt ltstylegt lt!-- h1.fred color
eeebd2 background-color d8a29b border
thin groove 9baab2 --gt lt/stylegt lt/headgt ltb
odygt lth1 class"fred"gtA Simple Headinglt/h1gt
ltpgtsome text . . . some textlt/pgt lt/bodygt
48
Anonymous classes
lt/headgt ltstylegt lt!-- .fred color
eeebd2 background-color d8a29b border
thin groove 9baab2 --gt lt/stylegt lt/headgt ltb
odygt lth1 class"fred"gtA Simple Headinglt/h1gt ltp
class"fred"gtsome text . . . some
textlt/pgt lt/bodygt
49
Divisions and spans

• Rather than applying styles to an element itself,
  we wrap the element in
• a div element (usually for block elements), or
• a span element (usually for inline elements)?
• Any required formatting can then be applied to
  the ltdivgt or ltspangt element.
• Div and span elements become part of the document
• In particular, each can have class and id
  attributes

50
Divisions
ltheadgt ltstylegt lt!-- .myclass color
blue background cyan text-decoration
underline border thin groove red --gt
lt/stylegt lt/headgt ltbodygt ltdiv class"myclass"gt
lth2gtA Simple Headinglt/h2gt ltpgtsome text . . .
lt/pgt lt/divgt lt/bodygt

• Styles can be applied to blocks of HTML code
  using div

51
Spans

• spans are similar to divisions

ltheadgt ltstylegt lt!-- .myclass color red
background cyan text-decoration none
--gt lt/stylegt lt/headgt ltbodygt ltspan
class"myclass"gt lth2gtA Simple Headinglt/h2gt
ltpgtsome text . . . lt/pgt lt/spangt lt/bodygt
52
Summary

• By now you should be able to use
• Tables
• Frames
• Stylesheet CSS
• Inline style
• Embedded style
• External style

53
Typical exam question

• explain why is it important to separate the
  content from the style.
• what is CSS?
• State three ways in which styles can be used. And
  explain the advantages and disadvantages of each
  one.

54
Next

• Look at the disadvantages of html
• XML
• Well formed vs valid xml document
• XHTML vs HTML
• DHTML

55
Useful sites

• http//www.w3schools.com/
• http//www.w3schools.com/html
• http//www.w3schools.com/css
