Energy Transformations: Photosynthesis

1

• Energy Transformations Photosynthesis
  Respiration

2
Read pages 218-220

• What is energy?
• List 2 processes (in the cell) that require
  energy (the ability to do work).
• What is the difference between an autotroph and a
  chemotroph?
• What is metabolism?

3
ATP ADP

• ATP Adenosine triphosphate
• adenine ribose 3 phosphates
• Energy storing molecule, only stores energy for a
  few minutes
• Source of all cell energy
• When one phosphate group breaks off, energy is
  released

Adenine
3 Phosphate groups
Ribose
4

• ADP Adenosine diphosphate
• Adenine ribose 2 phosphates
• Molecule that results from ATP losing one P
• Another P may be added later

ADP
ATP
Energy
Energy
Adenosine diphosphate (ADP) Phosphate
Adenosine triphosphate (ATP)
Partially charged battery
Fully charged battery
5
Describe organelles involved in energy
transformation

• Energy transformation is when energy is converted
  from one form to another.
• Energy transformations involve photosynthesis and
  respiration.

6
Photosynthesis
7

• CHLOROPLASTS
• Found in plant cells, some protists bacteria
  not animal cells
• Contain pigment called chlorophyll (green)
• Allows plants to go through photosynthesis by
  converting light into energy for the cell

8
Overview Photosynthesis

• Photosynthesis process using energy from
  sunlight to convert water and CO2 into oxygen and
  carbohydrates (sugar)
• Two parts
• Light dependent reactions produce O2 converts
  ADP to ATP
• Calvin cycle (dark reactions) use ATP from light
  reactions to produce sugars

Light Energy
Chloroplast
CO2 H2O
Sugars O2
9

• Chlorophyll green pigment in cells that absorbs
  blue red light energy
• Moves energy to electrons that drive reactions
• Equation for photosynthesis
• 6CO2 6H2O energy ? C6H12O6 6O2

10

• MITOCHONDRIA powerhouse of cell
• Releases energy from food molecules
• Found in both animal and plant cells
• A cell that needs more energy has more
  mitochondria
• Ex muscles, growing cells, areas of repair

11
Overview cellular respiration

• Respiration process that releases energy by
  breaking down food when oxygen is present
• Equation for Respiration
• C6H12O6 6O2 ? 6CO2 6H2O energy

12

• Anaerobic respiration (fermentation) occurs
  without oxygen present
• Two types
• Alcoholic form ethyl alcohol and CO2 as waste
  products used to make bread rise
• Lactic acid produces lactic acid in muscles when
  exercising without enough oxygen

13
Photosynthesis Respiration
Function Energy storage Energy release
Location Chloroplasts Mitochondria
Reactants Carbon dioxide water Glucose oxygen
Products Glucose oxygen Carbon dioxide water
Equation 6CO2 6H2O energy ? C6H12O6 6O2 C6H12O6 6O2 ? 6CO2 6H2O energy
