Regular Languages and Expressions

1
RegularLanguages and Expressions

• Surinder Kumar Jain,
• University of Sydney

2
Regular Languages Expressions

• Automaton
• DFA
• NFA
• ?-NFA
• CFG as a DFA
• Equivalence
• Minimal DFA
• Expressions
• Definition
• Conversion from/to Automaton
• Regular Langauges
• Pumping Lemma proving regularness
• Closures
• Equivalence

3
Deterministic Finite Automaton

• A system with many states
• Can transition from one state to another
• Usually caused by external input
• Set of states is finite
• System is in one state at any given time

4
DFA

• Mathematical Definition of a DFA
• A (Q, S,d, q0,F)
• Q States, DFA is in one of these finite states
  at any time.
• S Input symbols, DFA changes its state from
  one state to another state on consuming an input
  symbol.
• d Transition function.
• Given a state and an input symbols, gives the
  next DFA state
• Function over QxS -gt Q.
• q0 Initial DFA state
• F Accepting states. Once DFA reaches one of
  these states, it may not accept any more input
  symbols.

5
DFA Example
Q waiting, pending, rejected, approved, paid
S receive, reject, accept, pay d
(waiting -gt receive -gt pending), (pending -gt
reject -gt rejected), (pending -gt accept -gt
accepted), (accepted -gt pay -gt paid) q0
waiting F rejected, paid
6
Transition Diagrams
start
receive
accept
Accepted
pay
Paid
Waiting
Pending
Paid
reject
Paid
Rejected
Q waiting, pending, rejected, approved, paid
S receive, reject, accept, pay d
(waiting -gt receive -gt pending), (pending -gt
reject -gt rejected), (pending -gt accept -gt
accepted), (accepted -gt pay -gt paid) q0
waiting F rejected, paid
7
Language

• Set of alphabets
• Concatenation (joining)
• Strings
• A subset of strings is a language
• A DFA defines a language
• Alphabet set is the set of input symbols
• Concatenation - one symbol follows another
• Acceptance sequence of symbols takes DFA from
  start state to one of the accepting states

8
Non-deterministic Finite Automaton (DFA)

• Five-tuple like a DFA, (Q, S,d, q0,F)
• Transition function returns a set not one state
• Several outgoing arcs with same symbol
• In several states at the same time
• Language of NFA

9
Equivalence of DFA NFA

• Any NFA language can be described by some DFA
• Adding non-determinism does not give any thing
  more
• Why use NFAs then
• Easier to make for some languages
• May have fewer states and less complex
• Algorithm to convert NFA to DFA
• For n state NFA,DFA may have up to 2n states
• Can throw away inaccessible states
• Observation DFA has practically the same number
  of states as NFA though it often has more
  transitions

10
NFA to DFA conversion

• For an NFA, N Q, S, d, q0, F,
• Construct the DFA, D Qd, S, dd, q0, Fd
• Qd Powerset of Q
• dd(S, a) Up in S d(p,a) for every S in Qd.
• Fd S S is subset of Q and S has an accepting
  state of NFA
• DFA operates on one state at a time, NFA operates
  on sets of states.
• Given a state, NFA gives a set of new states
• Make all possible sets of DFA states as NFA
  states
• Transit from one set of states to a new set of
  all possible state set
• Any set with an accepting state is the accepting
  state in NFA

11
NFA to DFA conversion complexity

• O(2n) (number of subsets of a set)
• Efficient algorithm
• Do not construct the entire power set
• Start with start state
• Only construct subsets that can reach an
  accepting state from the start state
• The number of states in DFA is much less than 2n.

• DFA has practically the same number of states as
  NFA though it often has more transitions

12
epsilon - NFA

• Includes e (the empty string, not in alphabet
  set) as a transition
• e is identity in concatenation
• a.e e.a a for all a
• Spontaneous transition without an input

13
Equivalence to NFA

• An e-NFA language can be described by some NFA
• Every NFA can be described by some DFA
• Adding e transition does not give any thing more
• Why use e-NFAs then
• Easier to make for some languages
• Useful in proving equivalence of languages

14
Conversion to NFA

• Conversion aims to remove e transitions
• Define a new set of states
• e are contained inside the set
• No e arc leaves or enters the new set of states
• Epsilon closure (eclose)
• For a state, set of all states reachable
  spontaneously
• Follow the e arcs recursively and include
  reachable states in the epsilon closure

15
epsilon-NFA to DFA conversion

• For an e-NFA, N Q, S, d, q0, F,
• Construct the DFA, D Qd, S, dd, eclose(q0),
  Fd
• Qd eclose(q) q eclose(q) and q in Q
• dd(S, a) Up in S d(p,eclose(a)) for every S
  in Qd.
• Fd S S is subset of Q and S has an accepting
  state of NFA
• DFA operates on one state at a time, e-NFA
  operates on sets of states with no e transition
  leaving the set
• Make all eclose sets as DFA states
• Transit from one set of states to a new set of
  all eclose state set
• Any set with an accepting state is the accepting
  state in NFA

16
Programs as Automatan

• An imperative program can be represented as a
  Control Flow Graph (CFG) with
• statements at nodes and
• predicates at edges
• It can be converted into a CFG with
• both statements and predicates at edges
• by pushing node statements up incoming edges
• Such a CFG is a DFA
• Program points are States
• Statements are input symbols that change program
  state from program point to point

17
Regular Expression

• Algebraic expression to denote languages
• Composed of symbols e, Ø, , , ., (,
  ) and alphabets
• The language is generated using rules
• L(e) empty set
• L(Ø) empty set
• L(a) a for all alphabets a
• L(pq) L(p) U L(q)
• L(p.q) p.q p in L(p) q in L(q)
• L(p) qn q in L(p) and n gt 0 , q0 e,
  qkq.qk-1

18
Regular Expression Example

• ab.c
• The language generated is
• a, b.c
• a.b.c.d
• the language generated is
• a.b.d, a.b.c.d, a.b.c.c.d, a.b.c.c.c.d,
• A finite way to express an infinite language

19
Equality of Languages

• DEFINITION
• Two regular expression (or automaton)
• are EQUAL
• if they both generate same languages
• Thus
• (a.b) (b.a) a.(b.a) b.(b.a)
• (e b).(a.b).(ea)

20
Algebraic laws of regular expressions

• p q q p
• (p q) r p (q r)
• (p.q).r p.(q.r)
• Ø p p Ø p
• e.p p.e p
• Ø.p p.Ø Ø
• p.(qr) p.q p.r
• (p q).r p.r q.r
• p p p
• (p) p
• Ø e
• e e
• p.p p.p
• (p q) (p.q)

21
Finite Automaton and Regular Expressions

• Every language
• defined by a finite automaton is also defined by
  some regular expression
• defined by a regular expression is also defined
  by some DFA

22
DFA to Regular expression

• Hopcrofts formula
• Rij(k) Rij(k-1)Rik(k-1).(Rkk(k-1)).Rkj(k-1)
• Rij(n) is the regular expression of all paths
  from i to j. (n is the number of states)
• States are sorted in some order and numbered 1 to
  n
• Rij(k) is regular expression of all paths from i
  to j passing thru nodes whose sort order is less
  than k
• Computed for all i,j for k0, then k1,,kn
• Rs,f1(n)Rs,fk(n) is the regular expression of
  the DFA
• s is the start state, f1,,fk are accepting
  states, n is the number of states.

23
DFA to RE - complexity

• Hopcroft formula is O(n34n),
• n3 to compute the table and
• 4n as size of regular expression grows by 4 every
  time.
• In practice it is close to O(n3)
• By simplifying the regular expression at every
  step and
• using judicious algorithm avoiding recomputation
  of Rkk(k)
• Most DFAs have almost n and not 2n accessible
  states
• A faster state elimination method close to O(n2)
  is also available

24
RE to Automatan conversion

• Regular expression is converted to e-NFA
• e-NFA can the be converted to NFA and to DFA
• RE to e-NFA conversion rules
• e -gt One edge (two state) DFA with e
  transition
• Ø -gt Two state DFA with no edges
• a -gt Two state with a transition
• -gt A new start/accept statejoining two
• arguments of in parallel
• . -gt Accept of first is start of second
• -gt An e edge joining star/accept of
  argument and
• a new start/accept state
• Convert resulting e-NFA to a DFA

25
Direct conversion

• Augment regular expression r to (r).
• Position number for each occurrence of alphabet
• Compute for each node of syntax tree
• nullable (e in the language)
• firstpos (set of possible first alphabets)
• lastpos (set of possible last alphabets)
• Compute for each position
• followpos (set of possible next alphabet after
  this position)
• Construct the DFA

26
Applications

• Unix text search, search matching patterns (grep)
• Lexical/Parser analysis
• Parse text against a regular expression
• find set of first tokens at this expression root
• find set of last tkens at this expression root
• can the expression at this root be null set
• find set of next tokens after an alphabet
  position in a regular expression
• Efficient search of patterns in very large
  repository (web text search)

27
Regular Language

• DEFINITION
• A language (a set of strings)
• is defined to be a regular language if
• it can be defined by a finite automaton
• by a DFA or
• by an NFA or
• by an e-NFA or
• by a regular expression
• Four different ways to describe a regular
  language

28
Pumping Lemma

• If L is a regular language then there exists
• integer n such that
• for every string w in L
• we can break w into x, y, z such that wx.y.z
• y ? e
• x.y lt n
• x.yk.z is in L (for all k gt 0)
• Proof based on
• For a DFA of length n
• any string of length gt n
• must revisit a state
• Used to prove that a language is not regular

29
Closure property

• Language is a set of string over finite alphabets
• Language operators
• Union of two languages L(A ? B) L(A) ? L(B) -
  re
• Intersection
• Concatenation L(A.B) a.b a in A, b in B
• Kleene Closure L(A) an a in A, n gt 0
• a0 e for all a and an an-1
• Compliment L(A) a a not in A (with
  respect to some overall alphabet set) - dfa
• Difference L(A-B) L(A) L(B) - dfa switch q0
  F
• Reversal L (A) ak.ak-1a1 a1ak-1.ak in A

• Homomorphism replace an alphabet with another
  regular expression
• Inverse homomorphism

30
Decision properties

• Is the language described empty?
• Is a particualr string in the described language?
• Do two different of languages actually describe
  the same language?

31
Conversions

• Decision properties may require conversion
  between various forms.
• Can the conversion be done in reasonable time?

Conversion Complexity
Computing e closures O(n3) Warshalls O(n)
Subset construction O(2n)
NFA to DFA O(n32n) (In practice O(n3s)
DFA to NFA conversion O(n)
NFA/DFA to Regular Expression O(n34n) (worst case) (Actual is much less)
Regular Expression to eNFA O(n)
Regular Expression to NFA O(n3)
Regular Expression to DFA O(n34n32n)
32
Equivalence of automata

• Equivalence of two states
• States p and q in an automaton are Defined to be
  equivalent if
• For all input strings applied at state p or q
• p ends up in an accepting state
• if and only if
• q also ends up in an accepting state
• The accepting state reached by p does not have to
  be same accepting state as that reached by q

33
Minimization of DFA

• If two states p and q are equivalent
• we can combine them together into a single state
• it wont affect the language accepted by the DFA
• This process of combining states together is
  called Minimization
• Table-filling algorithm can find if two states
  are equivalent or not. Complexity O(n2)
• Non-equivalent pairs are distinguishable

34
MinimuM DFA

• Minimum DFA is unique
• Eliminate all states not reachable from start
• Determine which states are equivalent
• Partition states into blocks of equivalent states
• Equivalence is transitive
• Thus no state is in two blocks
• Equivalence of two Regular Languages
• Convert them into their minimum DFAs
• and check for isomorphism
• Union method
• Make a minimum DFA of the union of the two
• Start state of the two original DFAs must be
  equivalent if and only if DFAs are equivalent
