Condor-G - Your Window to the Grid

1
Condor-G -Your Window to the Grid
2
The Condor Project (Established 85)

• Distributed systems CS research performed by a
  team that faces
• software engineering challenges in a
  UNIX/Linux/NT environment,
• active interaction with users and collaborators,
• daily maintenance and support challenges of a
  distributed production environment,
• and educating and training students.
• Funding - NSF, NASA,DoE, DoD, IBM, INTEL,
  Microsoft and the UW Graduate School
• .

3
National Grid Efforts

• National Technology Grid - NCSA Alliance
  (NSF-PACI)
• Information Power Grid (NASA)
• Particle Physics Data Grid (DoE)
• Grid Physics Network (NSF-ITR)

4
Driving Concepts
5

• Since the early days of mankind the primary
  motivation for the establishment of communities
  has been the idea that by being part of an
  organized group the capabilities of an individual
  are improved. The great progress in the area of
  inter-computer communication led to the
  development of means by which stand-alone
  processing sub-systems can be integrated into
  multi-computer communities.

Miron Livny, Study of Load Balancing Algorithms
for Decentralized Distributed Processing
Systems., Ph.D thesis, July 1983.
6
Every Communityneeds a Matchmaker!
7
Why? Because ...

• .. someone has to bring together members of the
  community who have requests for goods and
  services with members who offer them.
• Both sides are looking for each other
• Both sides have constraints
• Both sides have preferences

8
High Throughput Computing

• For many experimental scientists, scientific
  progress and quality of research are strongly
  linked to computing throughput. In other words,
  they are less concerned about instantaneous
  computing power. Instead, what matters to them is
  the amount of computing they can harness over a
  month or a year --- they measure computing power
  in units of scenarios per day, wind patterns per
  week, instructions sets per month, or crystal
  configurations per year.

9
HW is a Commodity

• Raw computing power is everywhere - on desk-tops,
  shelves, and racks. It is
• cheap
• dynamic,
• distributively owned,
• heterogeneous and
• evolving.

10
Master-Worker (MW) computing is common and
Naturally Parallel.It is by no means
Embarrassingly Parallel. Doing it right is by no
means trivial.
11
The Tool
12
Our Answer to High Throughput MW Computing on
commodity resources
13
The Condor System

• A High Throughput Computing system that
  supports large dynamic MW applications on large
  collections of distributively owned resources
  developed, maintained and supported by the Condor
  Team at the University of Wisconsin - Madison
  since 86.
• Originally developed for UNIX workstations
• Based on matchmaking technology.
• Fully integrated NT version is available.
• Deployed world-wide by academia and industry.
• More than 1300 CPUs at the U of Wisconsin.
• Available at www.cs.wisc.edu/condor.

14
Condor CPUs on the UW Campus
15
Some NumbersUW-CS Pool

• Total since 6/98 4,000,000 hours 450 years
• Real Users 1,700,000 hours 260 years
• CS-Optimization 610,000 hours
• CS-Architecture 350,000 hours
• Physics 245,000 hours
• Statistics 80,000 hours
• Engine Research Center 38,000 hours
• Math 90,000 hours
• Civil Engineering 27,000 hours
• Business 970 hours
• External Users 165,000 hours 19 years
• MIT 76,000 hours
• Cornell 38,000 hours
• UCSD 38,000 hours
• CalTech 18,000 hours

16
I have a job parallel MW application with 600
workers. How can I benefit from Condor?
17
The Application

• Study the behavior of F(x,y,z) for 20 values of
  x, 10 values of y and 3 values of z (20103
  600)
• F takes on the average 3 hours to compute on a
  typical workstation (total 1800 hours)
• F requires a moderate (128MB) amount of memory
• F performs little I/O - (x,y,z) is 15 MB and
  F(x,y,z) is 40 MB

18
Step I - get organized!

• Turn your workstation into a Personal Condor
• Write a script that creates 600 input files for
  each of the (x,y,z) combinations
• Submit a cluster of 600 jobs to your personal
  Condor
• Write a script that collects the data from the
  600 output files
• Go on a long vacation (2.5 months)

19
A Condor Job-Parallel Submit File

• executable worker
• requirement ((OS Linux2.2) Memory gt
  128))
• rank KFlops
• initialdir worker_dir.(process)
• input in
• output out
• error err
• log log
• queue 600

20
Your Personal Condor will ...

• ... keep an eye on your jobs and will keep you
  posted on their progress
• ... implement your policy on when the jobs can
  run on your workstation
• ... implement your policy on the execution order
  of the jobs
• .. add fault tolerance to your jobs
• keep a log of your job activities

21
(No Transcript)
22
Condor Layers
Application
Application Agent
Customer Agent
Environment Agent
Owner Agent
Local Resource Management
Resource
23
Step II - build your personal Grid

• Install Condor on the desk-top machine next door.
• Install Condor on the machines in the class room.
• Install Condor on the O2K in the basement.
• Configure these machines to be part of your
  Condor pool.
• Go on a shorter vacation ...

24
(No Transcript)
25
Step III - Take advantage of your friends

• Get permission from friendly Condor pools to
  access their resources
• Configure your personal Condor to flock to
  these pools
• reconsider your vacation plans ...

26
(No Transcript)
27
Think big. Go to the Grid
28
Condor-G

• A Grid enabled version of Condor that uses the
  inter-domain services of Globus to bring Grid
  resources into the domain of your Personal-Condor
• Supports Grid Universe jobs
• Uses GSIFTP to move glide-in software
• Uses MDS for submit information

29
Condor-glide-in

• Enable an application to dynamically turn
  allocated grid resources into members of a Condor
  pool for the duration of the allocation.
• Easy to use on different platforms
• Robust
• Supports SMPs

30
X509 Certificates

• We are in the process of adding X509 based
  authentication capabilities to Condor services.
• Job submission
• Local file access
• Access to Condor-glide-in software
• Resource authentication

31
GSIFTP

• Enable Condor I/O services to use remote GSIFTP
  servers.
• Move glide-in tar files
• Read executables
• Move Data from/to data repositories
• Access disk caches

32
Grid Universe

• Grid Universe jobs submitted to Condor are
  transformed in the Globus jobs and submitted (via
  GlobusRun) to a grid resource.
• Use MDS to locate resource
• Monitor status of job on remote resource
• Report status via Condor services
• Rewrite in progress with new Globus library.

33
Step IV - Think big (Grid)!

• Get access (account(s) certificate(s)) to a
  Computational Grid
• Submit 599 Grid Universe Condor- glide-in jobs
  to your personal Condor
• Take the rest of the afternoon off ...

34
(No Transcript)
35
Does it work?
36
An example - NUG28

• We are pleased to announce the exact solution of
  the nug28 quadratic assignment problem (QAP).
  This problem was derived from the well known
  nug30 problem using the distance matrix from a 4
  by 7 grid, and the flow matrix from nug30 with
  the last 2 facilities deleted. This is to our
  knowledge the largest instance from the nugxx
  series ever provably solved to optimality.
• The problem was solved using the branch-and-bound
  algorithm described in the paper "Solving
  quadratic assignment problems using convex
  quadratic programming relaxations," N.W. Brixius
  and K.M. Anstreicher. The computation was
  performed on a pool of workstations using the
  Condor high-throughput computing system in a
  total wall time of approximately 4 days, 8 hours.
  During this time the number of active worker
  machines averaged approximately 200. Machines
  from UW, UNM and (INFN) all participated in the
  computation.

37
NUG30 Personal Condor

• For the run we will be flocking to
• -- the main Condor pool at Wisconsin (600
  processors)
• -- the Condor pool at Georgia Tech (190 Linux
  boxes)
• -- the Condor pool at UNM (40 processors)
• -- the Condor pool at Columbia (16 processors)
• -- the Condor pool at Northwestern (12
  processors)
• -- the Condor pool at NCSA (65 processors)
• -- the Condor pool at INFN (200 processors)
• We will be using glide_in to access the Origin
  2000 (through LSF ) at NCSA.
• We will use "hobble_in" to access the Chiba City
  Linux cluster and Origin
• 2000 here at Argonne.

38
It works!!!

• Date Thu, 8 Jun 2000 224100 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt To Miron
  Livny ltmiron_at_cs.wisc.edugt Subject Re Priority
• This has been a great day for metacomputing!
  Everything is going wonderfully. We've had over
  900 machines (currently around 890), and all the
  pieces are working great
• Date Fri, 9 Jun 2000 114111 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt
• Still rolling along. Over three billion nodes in
  about 1 day!

39
Up to a Point

• Date Fri, 9 Jun 2000 143511 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt Hi Gang,
• The glory days of metacomputing are over. Our job
  just crashed. I watched it happen right before my
  very eyes. It was what I was afraid of -- they
  just shut down denali, and losing all of those
  machines at once caused other connections to time
  out -- and the snowball effect had bad
  repercussions for the Schedd.

40
Back in Business

• Date Fri, 9 Jun 2000 185559 -0500 (CDT) From
  Jeff Linderoth ltlinderot_at_mcs.anl.govgt
• Hi Gang,
• We are back up and running. And, yes, it took me
  all afternoon to get it going again. There was a
  (brand new) bug in the QAP "read checkpoint"
  information that was making the master coredump.
  (Only with optimization level -O4). I was nearly
  reduced to tears, but with some supportive words
  from Jean-Pierre, I made it through.

41
The First 600K seconds
42
The First 35K seconds
43
We made it!!!

• Sender goux_at_dantec.ece.nwu.edu Subject Re Let
  the festivities begin.
• Hi dear Condor Team,
• you all have been amazing. NUG30 required 10.9
  years of Condor Time. In just seven days !
• More stats tomorrow !!! We are off celebrating !
• condor rules !
• cheers,
• JP.

44
Do not be picky, be agile!!!
