RF Measurement and Control

1
1. Background Information
4. PSoC Microcontroller
A plasma is an electrically conductive gas
containing charged particles. When atoms of a gas
are excited to high energy levels, the atoms
loose hold of some of their electrons and become
ionized producing a plasma containing
electrically charged particles - ions and
electrons. Below is a Paschen curve that shows
the breakdown voltages for various gasses.

• PSoC Designer with GUI
• Pre-configured user modules
• USB 2.0 integrated
• Cheap and widely used

2. Applications

• Surgical applications
• Surface decontamination
• Water purification
• Plasma medicine

Acknowledgments Thanks to the following
companies for donating materials to our project
Analog Devices, AVX, RFMD(Sirenza), Texas
Instruments, Covidien, SiTime and Advanced
Energy. Thanks to Dr. Collins, Dr. Moore, Dr.
Grinolds, Doug Scott, Brian Campbell, Mike
Kabala, Ashish Sharma and Olivera Notaros for
their advice and technical guidance for this
project.
Fig 2 RF Control Circuit with Dynamic Feedback
Frequency of operation 13.56 MHz /- 500kHz VCO
TI4046 _at_ 600 Hz per mV resolution Pre-amp AD8001
low power amplifier Amplifier Sirenza 18 dB
amplifier LC Load L 12.5uH C 22pF Q
720 ?Phase AD8302 PSoC A to D and D to A
converter. External supplies /- 5Vdc, 28Vdc
