Plate Tectonics

1
Plate Tectonics

• Relative Dating and Rock Layers

https//www.youtube.com/watch?v_mcC8kFacrk
2
Earths History
3
1. How old is our Universe?
13.7 billion years old
4
2. How old is Earth?
4.6 billion years old
5
3. Earth was once made of molten lava and magma,
eventually cooling to form igneous rock
6
Weathering, Erosion, Compaction, Cementation,
Heat, and Pressure eventually formed the rocks
that cover our Earths surface.
7
4. What we know about Earths history comes from
studying its rocks, rock formations, rock layers,
and even the rocks from outer space
8
Meteorites

• 5. All meteorites formed about the same time that
  Earth formed, so studying them helps us study
  Earth.
• 6. Meteorites have not been affected by erosion,
  weathering or other forces the way Earths rocks
  have.

9
Studying Earths Rocks
10
Rock Layers

• Which book was placed here first?
• The bottom one!
• 7. When rocks form, the oldest ones are usually
  found beneath younger rocks

https//www.youtube.com/watch?v9Df4CtlZ0AQ
11
(No Transcript)
12
Fossils

• 8. Most fossils are found in Sedimentary rock
  layers
• 9. Why?
• Heat, pressure, and melting would probably
  destroy fossils during the formation of Igneous
  and Metamorphic rocks

13

• 10. Sedimentary rocks, and the fossils they trap,
  are often found in layers, oldest rocks are found
  on the bottom.

http//www.prehistoricplanet.com/news/index.php?id
48
14

• 11. Digging through the layers of rocks, helps us
  understand more about the history of Earth.

15

• 12. The Grand Canyon (Arizona) was carved by the
  Colorado river, exposing millions of years worth
  of rock layers.

16
(No Transcript)
17
13. Sometimes, the rock layers arent always
horizontal
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
14. And sometimes ocean fossils are found high in
the mountains
Why?
22

• 15. Turns out, our Earths surface is constantly
  shifting, changing, and eroding.
• And the layers get pushed around.

23

• 16. Only in the last 200 years, have we begun to
  understand the structure, formation and history
  of our Earth.

I wonder whats inside Earth?
24
(No Transcript)
25
Relative Age of Rocks

• To figure out the ages of rocks and their
  fossils, geologists rely on a few rules

26
Law of Superposition

• In any undisturbed rock, the oldest layer is at
  the bottom and the youngest layer is at the top.

27
The Cross-Cutting Law

• Any feature that cuts across a body of rock is
  younger than the body of sediment or rock it cuts
  across.

28
The Law of Inclusions

• If one rock layer contains fragments (inclusions)
  of another rock layer, it must be younger than
  the fragments of rocks it contains.

Younger
Oldest
Youngest
29
Oldest? Youngest?
30
Oldest? Youngest?
31
Oldest? Youngest?
D oldest at the bottom superposition law A
next to bottom superposition law B Tilt
plate tectonics Law of Horizontality E
intrusion cross-cutting law Erosion not
horizontal/straight line - Law of Horizontality C
intrusion Law of cross-cutting Erosion
Horizontality   DABEC (old to young)   E and C
are igneous (magma rising) A, B, D are
sedimentary (layers)
32
Oldest? Youngest?
33
Oldest? Youngest?
http//www.youtube.com/watch?vEadTLGMu3LI
