Transcript and Presenter's Notes

Title:


1
Promoting the Use of End-to-End Congestion
Control in the Internet
  • Sally Floyd, Kevin Fall in Proceedings of
    IEEE/ACM Transactions on Networking, 1999
  • A Summary by Ashish Samant
  • CS577 Spring 2005

2
Outline
  • Need for end-to-end congestion control
  • Unfairness, Congestion Collapse
  • Per flow based scheduling Vs Congestion Control
    mechanisms at the router
  • Identifying candidate flows for regulation
  • Other incentives for flows

3
Introduction
  • End hosts/applications may not use end-to-end
    congestion control schemes.
  • Problem - This may lead to congestion collapse
    and unfairness, in times of congestion.
  • Solution Isolate ill-behaving flows, use
    per-flow based queuing at routers.
  • This may not be sufficient !!

4
Introduction . continued
  • Authors suggest -
  • Routers must support congestion control and
    regulate high-bandwidth flows.
  • Routers must regulate best effort flows that
  • are TCP-Unfriendly,
  • unresponsive to congestion,
  • use disproportionate bandwidth.

5
Introduction . continued
  • Unresponsive flows cause two problems
  • - Unfairness well-behaved flows may suffer
    bandwidth starvation because unresponsive flows
    do not react to congestion.
  • - Congestion collapse the scarce bandwidth
    of the network is consumed by packets from
    unresponsive flows, that will be discarded
    sooner or later.

6
Experimental Setup
7
Unfairness 3 TCP, 1 UDP flow, FCFS
8
Fairness 3 TCP, 1 UDP flow, WRR
9
Congestion Collapse 3 TCP, 1 UDP flow, FCFS
10
Congestion Control 3 TCP, 1 UDP flow, WRR
11
Congestion Control 3 UDP, 1 TCP flow, WRR
12
Identifying non TCP-Friendly Flows
  • TCP Friendly Flow arrival rate does not exceed
    that of any other TCP conformant flow.
  • Maximum sending rate for a TCP Friendly flow
  • T - sending rate p - packet drop rate B
    max packet size R minimum RTT
  • Actual rates will be less than T.

13
Identifying non TCP-Friendly Flows
  • Limitations
  • Inconsistencies in finding packet size, round
    trip time.
  • Measurements should be taken over a long
    interval of time.
  • Bursty packet drops.
  • Router Response
  • Routers should freely restrict the bandwidth of
    non
  • TCP Friendly flows.

14
Identifying Unresponsive Flows
  • TCP Friendly test cannot be used at routers that
    are unable to determine packet sizes and RTTs.
  • If packet drop rates increase by x , the arrival
    rate should drop by vx .
  • When packet drop is constant, no flow will be
    identified as unresponsive.

15
Identifying Unresponsive Flows
  • Limitations
  • Packet drop may be because of various reasons,
    hard for flows with variable demand.
  • Flows might be tempted to start with a higher
    initial bandwidth demand.
  • Response
  • Actively regulate the bandwidth of unresponsive
    flows in times of congestion.

16
Identifying flows using disproportionate flows
  • Flows that require larger bandwidth than other
    flows that reduce their demand.
  • These might be TCP friendly but still be
    disproportionate.
  • Arrival rate lt log(3n) / n n no of flows
  • Arrival rate lt c / vp p pkt drop rate
  • c some constant

17
Comments and Conclusion
  • Alternate approaches
  • - use schemes that are a mix of FCFS and
    per-flow based approach ( FCFS scheduling with
    differential dropping ).
  • - pricing incentives.
  • granularity of flows
  • - apply fairness tests to single/aggregate of
    flows.
  • min-max fairness measure
  • - need to look at the entire path, all the
    congested links.

18
Comments and Conclusion continued
  • Breaking a TCP connection, increased local
    throughput but also increases global packet drop
    rate.

19
Derivation of TCP Friendly Rate
  • Once congestionWindow gt W a packet is dropped
    and the congestion window is halved.
  • As long as congestionWindow lt W window is
    increased by 1, per RTT
  • W/2 (W/21) (W/22) W 3/8W2
  • gt per packet drop max 3/8W2 packets are
    sent
  • gt max packet drops lt 1/(3/8W2)

20
Derivation of TCP Friendly Rate Continued
  • Max bytes transferred per cycle of steady state
  • Total packets sent Avg. packet Size
  • Avg Round Trip Time
  • ( Total packets sent 0.75W )
  • gt (0.75 W B) / R
  • gt
