Network File System NFS

1
Network File System (NFS)

• Architecture and system model
• Communication and processes

2
Network File System (NFS)

• Developed by Sun Microsystems Inc.
• Used widely (version 3)
• Interoperable with various operating systems,
  mostly used in UNIX systems
• Version 4 specification has been announced
• Basic idea is that file server provides a
  standardized view of its local file system
• Communication protocol allows clients access the
  files stored on a server
• This makes possible to processes on different
  operating systems and machines to share a common
  file system

3
NFS Architecture

• NFS model is remote file service model
• Clients are normally unaware of the actual
  location of files (local/remote)
• File system interface supports normal file
  operations (read, write etc) and it is called as
  remote access model (in contrast to
  upload/download model)
• Files are accessed (typically in UNIX) via one
  interface to file system, Virtual File System
  layer that is hides differences between local and
  remote file systems
• Communication is done through Remote Procedure
  Calls and server converts calls to normal local
  file system calls via VFS
• NFS is largely independent of local file systems
  / operating systems

4
NFS Architecture

• The remote access model (for example NFS)
• The upload/download model (for example FTP)

5
NFS Architecture

• The basic NFS architecture for UNIX systems.

6
NFS File System Model

• File system model is almost the same than in
  UNIX-based systems (Files are sequences of bytes,
  hierarchical naming graph represents directories
  and files)
• Hard and symbolic links are supported
• Files are named but accessed via file handles
• There are some differences in system operations
  between versions 3 and 4 of NFS protocol
• Files have various attributes associated with
  them

7
NFS File System Model

• An incomplete list of file system operations
  supported by NFS.

8
NFS Communication

• Design of NFS makes it independent of operating
  systems, network architectures and transport
  protocols. For example Windows system can
  communicate with a UNIX file server
• That is possible because NFS is placed on top of
  and RPC layer that hides the differences between
  various systems
• Every NFS operation is implemented as a single
  RPC to a file server (in NFS v3). Version 4 of
  NFS protocol supports compound procedures by
  which several RPCs can be combined to a single
  request
• Compound procedures are executed in order and if
  some operation fails error is returned and no
  further operations are executed at server side

9
NFS Communication

• Reading data from a file in NFS version 3
• Reading data using a compound procedure in
  version 4

10
NFS Processes

• NFS is traditional client-server system in which
  clients request a file server to perform
  operations on files
• Server implementation can be stateless (in NFS
  v3) and therefore simple. In version 4 of NFS
  server maintains information of clients.
• For example locking of file and authentication
  requires server to maintain information of
  clients. In NFS v3 file locking is done with a
  separate NFS lock manager
• NFS v4 maintains only very little information of
  clients and it is expected to also work in Wide
  Area Networks (WANs)
• WAN usage requires efficient client cache and
  cache consistency protocol. It often works best
  when server maintains some information on files
  used by its clients

11
Network File System (NFS)

• Naming
• File handles
• Automounting
• File attributes

12
NFS Naming

• Idea of NFS naming model is to provide clients
  complete transparent access to a remote file
  system maintained by a server
• Transparency is achieved by letting a client be
  able to mount a remote file system into its local
  file system
• Instead of mounting an entire file system of
  server, NFS allows clients to mount only a part
  of file system. Server is said to export a
  directory when it makes a directory and it
  entries available to clients
• A directory exported by server can be mounted
  into a client's local name space (as some
  directory, called as mount point)
• Clients can have different name spaces and for
  example two clients can refer to a same file on
  server with different path name because of
  different local name spaces
• NFS server can mount a directory from other NFS
  server but it cannot export mounted directory to
  its clients. If clients want to access files on
  other server, clients can mount directory
  directly from other server

13
NFS Naming

• Mounting (part of) a remote file system in NFS.

14
NFS Naming

• Mounting nested directories from multiple servers
  in NFS.

15
NFS File Handles

• File handle is reference to a file within a file
  system
• It is independent of the name of the file it
  refers to
• File handle is created by a server hosting the
  file system and it is unique with respect to all
  file systems exported by the server
• Client is unaware of actual content of file
  handle
• Length of file handle is up to 64 bytes (NFS v3)
  and 128 bytes (NFS v4)
• File handle is true identifier for a file
  relative to a file system. It must be same all
  the time for a file and it cannot be reused after
  the file has been deleted

16
NFS Automounting

• Because of different local namespace problemNFS
  client namespaces can be partly standardized
• Remote file system can also be mounted when
  needed, this is called automounting
• Automounting is done by automounter which runs a
  separate process on the client's machine
• For example automounter can mount directory /home
  as automounting directory. When a process wants
  to access some directory in /home directory, file
  access operation is forwarded from kernel to NFS
  client, then from NFS client to automounter
• Then automounter creates mount point and mounts a
  required remote file system and file can be
  accessed.

17
NFS Automounting

• A simple automounter for NFS.

18
NFS Automounting

• Problem with this simple automounter is that the
  automounter will have to be involved in all file
  operations to guarantee transparency. This can
  cause performance problems
• A simple solution is to let the automounter mount
  directories in a special subdirectory, and create
  a symbolic link to each mounted directory

19
NFS Automounting

• Using symbolic links with automounting.

20
NFS File Attributes

• An NFS file has a number of associated attributes
• In version 3 of NFS, set of attributes is fixed
  and every NFS implementation is expected to
  support those attributes (Fully implementing NFS
  on non-UNIX systems was sometimes difficult or
  impossible)
• In version 4 of NFS, set of attributes has been
  split into a set of mandatory attributes that
  every implementation must support, and a set of
  recommended attributes that should be preferably
  supported, and an additional set of named
  attributes
• Named attributes are actually not part of the NFS
  protocol, but are encoded as array (attribute,
  value)-pairs where attribute is string and value
  sequence of bytes
• Attributes and values are stored with file or
  directory and there are NFS operations to read
  and write them. Interpretation of attributes and
  their values is left to an application, it is not
  defined in NFS specification

21
NFS File Attributes

• Some general mandatory file attributes in NFS.

22
NFS File Attributes

• Some general recommended file attributes.

23
Network File System (NFS)

• File sharing
• File locking
• Caching and replication

24
NFS File Sharing

• When two or more users share the same file, it is
  necessary to define the semantics of reading and
  writing precisely to avoid problems
• In single-processor systems semantics normally
  state that when a read operation follows a write
  operation, the read returns the value just
  written. Similarly, when two writes happen in
  quick succession, followed by a read, the value
  read is the value stored by the last write.
  System enforces an absolute time ordering and
  always returns the most recent value. This model
  is called as UNIX semantics.
• In distributed system UNIX semantics can be
  achieved easily as long there is only one file
  server and clients do not cache files
• Performance in single server system is frequently
  poor
• If client caching (local) is allowed, other
  problems will occur
• If a client locally modifies a cached file and
  shortly after that another client reads the same
  file from the server, the second client will get
  an obsolete file

25
Semantics of File Sharing

• On a single processor, when a read follows a
  write, the value returned by the read is the
  value just written.
• In a distributed system with caching, obsolete
  values may be returned.

26
Semantics of File Sharing

• It is difficult to propagate all changes to
  cached files back to the server immediately
• An alternative solution is to relax the semantics
  of file sharing, for example defining new rule
  "Changes to an open file are initially visible
  only to the process that modified the file"
• New rule doesn't change behaviors, it only
  defines them to be correct. It is known as
  session semantics and NFS supports it.
• If two or more clients are caching and modifying
  the same file at the same time and session
  semantics is used, most recently processed close
  file operation wins. Or winning modification is
  one of the candidates and leave the winner
  unspecified
• Immutable semantics only create and read
  operations are supported. Simplifies
  implementation of sharing and replication
• Transactions BEGIN_TRANSACTION, operations,
  END_TRANSACTION. System guarantees that all
  operations are executed correctly or returns
  error and none of the operations is actually
  executed. If two or more at same time, final
  result is verified to be correct.

27
Semantics of File Sharing

• Four ways of dealing with the shared files in a
  distributed system.

28
File locking in NFS

• Locking files can be problematic on stateless
  servers
• In NFS v3, file locking is handled by a separate
  protocol and implemented by a stateful lock
  manager. Performance is not good and
  implementations can be faulty
• In NFS v4, file locking is integrated in NFS
  protocol making locking simpler
• There are only four operations related to locking
  and NFS distinguishes read locks from write
  locks.
• Multiple clients can simultaneously access the
  same part of a file provided they only read data.
  A write lock is needed to obtain exclusive access
  to modify part of a file
• Locks are granted for a specified time (leases).
  Client must renew the lease if it wants to keep
  lock. Server automatically removes locks that
  have not been renewed
• In addition to these locking operations, there is
  also implicit way to lock a file referred to as
  share reservation. It is independent of locking
  and it can be used to implement NFS for
  Windows-based system

29
File Locking in NFS

• NFS version 4 operations related to file locking.

30
Client Caching

• Like many distributed file systems, NFS makes
  extensive use of client caching to improve
  performance
• Caching in NFS v3 has been mainly left outside of
  the protocol. This has led to the implementation
  of different caching policies, of which most
  never guaranteed consistency
• NFS v4 solves some of the consistency problems,
  but essentially still leaves cache consistency to
  be handled in an implementation-dependent way
• General caching model of NFS consists a client
  having a memory cache that contains data
  previously read from the server. In addition,
  there may be also a disk cache that is added as
  an extension to the memory cache, using the same
  consistency parameters.
• Typically clients cache file data, attributes,
  file handles and directories. Different
  strategies exist to handle consistency of the
  cached data

31
Client Caching

• Client-side caching in NFS.

32
Client Caching

• NFS v4 supports two approaches for caching file
  data
• Simplest Client opens file, caches data from
  read operations, allows write operations to
  cache, when client closes the file and
  modifications is made, cached data must be
  flushed back to the server (Session semantics)
• Second Once (part of) a file has been cached, a
  client can keep its data in the cache even after
  closing the file. NFS requires that when a client
  opens previously closed file that has been
  (partly) cached, the client must immediately
  revalidate the cached data. Revalidation takes
  place by checking when the file was last modified
  and invalidating the cache in case it contains
  stale data.
• Server may delegate some of its rights to a
  client when a file is opened. Open delegation
  takes place when the client machine is allowed to
  locally handle open and close operations from
  other clients on the same machine. This reduces
  need to communicate with server.
• Server is able to recall the delegation for
  example if another client needs to obtain access
  rights. Recalling is implemented as callback RPC
  and that requires that the server keeps track of
  clients to which it has delegated a file

33
Client Caching

• Using the NFS version 4 callback mechanism to
  recall file delegation.

34
Replication

• NFS version 4 provides minimal support for file
  replication
• Only whole file systems can be replicated
• Support is provided in the form of the
  FS_LOCATIONS attribute that is recommended for
  each file
• Attribute contains list of locations where the
  replica of file system in which the associated
  file is contained, may possibly occur
• Each location is given as DNS name or IP address
• It is up to a specific NFS implementation to
  actually provide replicated servers. NFS v4 does
  not specify how replication should take place

35
Network File System (NFS)

• Fault tolerance
• Security

36
Fault tolerance

• Fault tolerance in NFS v3 has hardly been an
  issue, because NFS protocol did not require
  servers to be stateful and no state was ever
  lost. Of course separate lock managers were
  stateful and special measures were needed
• In NFS v4 statefulness occurs in file locking and
  delegation
• In addition special measures need to be taken to
  handle the unreliability of the RPC mechanism
  underlying the NFS protocol
• RPC stubs can be configured to use reliable TCP
  or unreliable UDP
• If RPC reply is lost, client can send request
  again and server executes operation again (more
  than once, the original was exactly once)
• Situation can be handled with duplicate-request
  cache
• Each RPC request from a client carries a unique
  transaction identifier (XID) in its header, which
  is cached by the server when the request comes
  in.
• As long as the server has not sent a reply, it
  will indicate that the RPC request is in
  progress. When the request has been handled, its
  associated reply is also cached, after which the
  reply is returned to the client.

37
RPC Failures

• Three situations for handling retransmissions.
• The request is still in progress
• The reply has just been returned
• The reply has been some time ago, but was lost.

38
Fault tolerance

• File locking
• Client must renew lease, but false removal may
  happen for example if network is (temporary)
  partitioned and client's renew message don't
  reach the server. No special measures are taken
  to handle such situations.
• When the server crashes and subsequently
  recovers, it may have lost information on locks
  it granted to clients. Solution is to enter grace
  period in which client can reclaim locks that
  were previously granted to it. In this way server
  builds up its previous state with respect to
  locks. During the grace period normal lock
  requests are refused.
• There are also numerous problems that using
  leases introduces. For example leasing requires
  clocks to be synchronized and that may not easily
  solved in wide-area systems.

39
Fault tolerance

• Delegation
• Open delegation introduces additional problems
  when a client or server crashes
• If a client to which the opening of the file has
  been delegated crashes, it presumably had not
  propagated updates to the server. In that case,
  unless the client's updates are locally saved to
  stable storage, full recovery of the file will be
  impossible.
• In any case, client is made partially responsible
  for file recovery
• When the server crashes an subsequently recovers,
  it follows a procedure similar to lock recovery.
  A client to which the opening of a file has been
  delegated will reclaim that delegation when the
  server comes up again. However server forces the
  client to flush all modifications back to the
  server, effectively recalling the delegation.
• Because of that file server is up-to-date with
  respect to the most recent modifications of each
  file it had delegated to a client. And server is
  again in full charge of the file, and may decide
  to delegate the file to another client

40
Security

• Basic idea behind NFS is that a remote file
  system is presented to clients as it were a local
  file system. Therefore security of NFS mainly
  focuses on the communication between a client and
  a server. Secure communication means that a
  secure channel between the two should be set up.
• Because of NFS is layered on top of an RPC
  system, setting up a secure channel in NFS boils
  down to establishing secure RPCs
• In addition to secure RPCs, it is necessary to
  control access to files which are handled by
  means of access control file attributes in NFS.
  A file server is in charge of verifying the
  access rights of its clients
• NFS security architecture is so based in secure
  RPCs and access control attributes

41
Security

• The NFS security architecture.

42
Security

• Secure RPCs
• In NFS v3 secure RPC meant that only
  authentication was taken care of. Possible ways
  to do authentication were system authentication
  (User ID Group ID), secure NFS (Diffie-Hellman
  key exchange to establish session key) and
  Kerberos (tickets).
• In NFS v4 security is enhanced by the support for
  RPCSEC_GSS.
• RPCSEC_GSS is general security framework, it
  provides the hooks for different authentication
  methods and supports also message integrity and
  confidentiality which were not supported in NFS
  v3
• RPCSEC_GSS is based on standard interface for
  security services, namely GSS-API. RPCSEC_GSS is
  layered on top of this interface.
• For NFS v4 RPCSEC_GSS should be configured with
  support for Kerberos v5, LIPKEY (public-key
  system that allows clients to be authenticated
  using a password while servers can be
  authenticated using a public key)

43
Secure RPCs

• Secure RPC in NFS version 4.

44
Security

• Access control
• Access control is supported by means of ACL file
  attribute
• This attribute is a list of access control
  entries, where each entry specifies the access
  rights for a specific user or group
• The operations that NFS distinguishes with
  respect to access control are relatively
  straightforward
• Compared to the simple access control mechanisms
  in, for example UNIX systems, NFS distinguishes
  many different kinds of operations
• NFS has more richer semantics than most UNIX
  systems

45
Access Control

• The classification of operations recognized by
  NFS with respect to access control.

46
Coda distributed file system

• Overview
• Communication and naming
• File sharing and transactional semantics

47
Overview

• Coda was designed to be a scalable, secure and
  highly available distributed file system
• Coda is descendant of version 2 of the Andrew
  File System (AFS)
• AFS was designed to support large community and
  to meet this requirement nodes are partioned into
  two groups. One group consists of a relatively
  small number of dedicated Vice file servers,
  which are centrally administered. The other group
  consists of a very much larger collection of
  Virtue workstations that give users and processes
  access to the file system
• Coda follows the same organization as AFS. Every
  Virtue workstation hosts a user-level process
  called Venus, whose role is similar to that of an
  NFS client. A Venus process is responsible for
  providing access to the files that are maintained
  by the Vice file servers. Venus is also
  responsible to continue operation even if access
  to file servers is (temporary) impossible.

48
Architecture

• The overall organization of Coda.

49
Architecture

• Internal architecture of Virtue workstation
• Important issue is that Venus runs as user-level
  process
• Virtual File System (VFS) layer intercepts all
  calls from client applications and forwards these
  calls either to the local file system or to Venus
• Organization with VFS is same than in NFS
• Venus communicates with Vice file servers using
  user-level RPC system
• RPC system is constructed on top of UDP datagrams
  and provides at-most-once semantics
• At the server-side there are three different
  processes
• Vice servers are responsible for maintaining a
  local collection of files
• Trusted Vice machines are allowed to run
  authentication server
• Update processes are used to keep
  meta-information on the file system consistent at
  each Vice server
• Coda appears to its users as a traditional
  UNIX-based file system
• Coda provides a globally shared name space that
  is maintained by the Vice servers. Clients have
  access to this name space via local /afs
  directory. When client looks up a name in this
  directory Venus ensures that the appropriate part
  of shared name space is mounted locally

50
Architecture

• The internal organization of a Virtue workstation.

51
Communication

• Interprocess communication is performed using
  RPCs
• RPC2 system for Coda is more sophisticated than
  traditional RPC used for example in NFS
• RPC2 offers reliable RPCs on top of the
  (unreliable) UDP protocol
• Each time a remote procedure is called, the RPC2
  client code starts a new thread that sends an
  invocation request to server and subsequently
  blocks until it receives an answer. As request
  processing may take an arbitrary time to
  complete, the server regularly sends back
  messages to the client to let it know it is still
  working on the request. If the server dies,
  sooner or later the thread will notice it and
  return error to the calling application
• An interesting aspect of RPC2 is its support for
  side effects. A side effect is a mechanism by
  which client and server can communicate using and
  application-specific protocol. For example
  opening a file at a video server can be done as
  continuous data stream. There are routines for
  setting up connection and transferring data
• RPC2 also supports multicasting and it is used
  for invalidating client caches in parallel

52
Communication

• Side effects in Coda's RPC2 system.

53
Communication

• Sending an invalidation message one at a time.
• Sending invalidation messages in parallel.

54
Naming

• Coda maintains a naming system analogous to that
  of UNIX
• Files are grouped into units referred to as
  volumes. A volume is similar to a UNIX disk
  partition, but generally has a much smaller
  granularity. It corresponds to a partial subtree
  in the shared name space. Like disk partitions,
  volumes can be mounted.
• Volumes form the basic unit by which the entire
  name space is constructed. This construction
  takes place by mounting volumes at mount points.
  Clients can only mount the root of volumes.
  Volumes form also the unit for server-side
  replication
• Granularity of volumes causes that name lookup
  will cross several mount points. To support
  naming transparency, Vice file server returns
  mounting information to a Venus process during
  name lookup. This allows Venus to automatically
  mount a volume into the client's name space when
  necessary. This is similar to crossing mount
  points as supported in NFS v4
• Shared name space is accessible by means of a
  subdirectory /afs in client's local namespace

55
Naming

• Clients in Coda have access to a single shared
  name space.

56
File identifiers

• Because the collection of shared files may be
  replicated and distributed across multiple Vice
  servers, it becomes important to uniquely
  identify each file in such way it can be tracked
  to its physical location, while at the same time
  maintaining replication and location transparency
• Each file in Coda is contained in exactly one
  volume. Because a volume may be replicated across
  several servers, Coda makes a distinction between
  logical and physical volumes.
• A logical volume represents a possibly replicated
  physical volume and has associated Replicated
  Volume Identifier (RVID). An RVID is a location
  and replication independent volume identifier.
  Multiple replicas may be associated with the same
  RVID
• Each physical volume has its own Volume
  Identifier (VID), which identifies specific
  replica in a location independent way.
• Each file has 96-bit file identifier, first part
  is 32-bit RVID, second part is 64-bit file
  identifier that uniquely identifies the file
  within a volume

57
File Identifiers

• The implementation and resolution of a Coda file
  identifier.

58
Sharing files

• When a client successfully opens a file, an
  entire copy of file is transferred to client's
  machine. The server records that the client has
  copy of this file.
• If client has opened file for writing and another
  client wants to open the same file, opening will
  fail. This is caused by the fact that the server
  has recorded that first client might have
  modified file. If first client had opened file
  for reading and another for writing, both will
  have succeeded.
• If several copies of the same file is stored
  locally on clients and one client modifies file
  and closes it, file will be transferred back to
  the server. Other clients may proceed to read
  their own copies of file despite the fact that
  the copy is actually outdated.
• The reason for this apparently inconsistent
  behavior, is that a session is treated as a
  transaction in Coda.

59
Sharing Files

• The transactional behavior in sharing files in
  Coda.

60
Transactional Semantics

• In Coda, the notion of a network partition plays
  a crucial role in defining transactional
  semantics
• A partition is a part of the network that is
  isolated from the rest and which consists of a
  collection of clients or servers, or both. The
  basic idea is that series of file operations
  should continue to execute in the presence of
  conflicting operations across different
  partitions. Two operations are said to conflict
  if they both operate on the same data and at
  least one is a write operation.
• Coda recognizes different types of sessions. For
  example, each UNIX system call is associated with
  a different session type. More complex session
  types are the ones that start with a call to
  open.
• As an example, the store session type starts with
  opening a file for writing as a specific user.
  Meta-data entries associated with file is read
  and modified as needed.
• Conflicting transactions force clients to save
  its local version of file for manual
  reconciliation.

61
Transactional Semantics

• The metadata read and modified for a store
  session type in Coda.

62
Coda distributed file system

• Caching and replication

63
Client Caching

• Client-side caching is crucial to the operation
  of Coda for two reasons. First, caching is done
  to achieve scalability. Second, caching provides
  a higher degree of fault tolerance as the client
  becomes less dependent on the availability of the
  server. For these reasons, clients in Coda always
  cache entire files
• When a file is opened for either reading or
  writing, an entire copy of the file is
  transferred to the client, where is subsequently
  cached
• Cache coherence in Coda is maintained by means of
  callbacks. Server keeps track of which clients
  have a copy of that file. A server is said to
  record a callback promise for a client. When a
  client updates its local copy for the first time,
  it notifies the server, which sends an
  invalidation message to the other clients.
  Invalidation message is called a callback break,
  because server will then discard the callback
  promise it held for the client it just sent an
  invalidation
• As long as client knows it has an outstanding
  callback promise at the server, it can safely
  access the file locally.

64
Client Caching

• The use of local copies when opening a session
  in Coda.

65
Server replication

• Coda allows file servers to be replicated and
  unit of replication is a volume. The collection
  of servers that have a copy of a volume, are
  known as that volume's Volume Storage Group (VSG)
• In presence of failures, a client may not have
  access to all servers in VSG. Client maintains a
  list of servers that are accessible. It is called
  Accessible Volume Storage Group (AVSG). If the
  AVSG is empty, the client is said to be
  disconnected.
• Coda uses a replicated-write protocol to maintain
  consistency of a replicated volume. It uses a
  variant of Read-One, Write-All.
• If client needs to read a file, it contacts one
  of the members in its AVSG. If client needs to
  write, the closing of the file is different.
  Client transfers modified file back in parallel
  to each member of AVSG. Parallel transfer is done
  with multicast RPC2.
• This scheme works fine as long as there are no
  failures. (For each client, that client's AVSG of
  a volume is the same as its VSG)

66
Server Replication

• Two clients with different AVSG for the same
  replicated file.
