Effects of Crystal Growth/Annealing

1
Effects of Crystal Growth/Annealing on
Supersolidity of Helium 4
Motoshi Kondo Shun-ichi Takada Hitomi
Yoshimura Yoshiyuki Shibayama Keiya
Shirahama Keio University, Yokohama, Japan
Support Grand-in-Aid for Scientific Research on
Priority Area Physics of Superclean Materials
2
Outline

• Effect of Crystal Growth Velocity
• 2. Effect of Crystal Annealing
• 3. Discussion Dislocations?
• 4. Bulk Porous Media Preliminary Result

3
Torsional Oscillator and Pressure Cells
Thermometers on platform and cell
f 1496 Hz
4
Confirmation of the Kim-Chan Experiment
M. Kondo et al. cond-mat/0607032, JLTP in press
Rim Velocity
Velocity-dependent Frequency (period) Shift
Dissipation Peak
Supersolid Fraction 1/3 1/10 of KC
2.97 MPa
5
Phase Diagram
6
Crystal Growth with Constant Velocity
Solidification Start
Conjecture
End
Growth Velocity 10 mm /sec
7
Effect of Growth Velocity
8
Growth-Velocity Dependence of NCRI
Velocity-Dependent NCRI
Velocity-Independent NCRI
9
Quench Cooling
Quench
Time(sec )
10
NCRI of Quench-Cooled Samples
T 70 mK
Quench Cooled
Quenched
Slowly Grown
Slowly Grown
Quenched sample shows large rs, but not
systematic.
11
Phased Annealing for Single Samples
Quench
0.8K
1K
1.2K
1.4K
1.6K
CRI increases by annealing / NCRI decreases
12
NCRI after Annealings at Various Temperatures
We repeated the annealing at 0.8, 1.0, ...., 1.6
K.
2.75 MPa
Annealing at Higher T Smaller Supersolid
Fraction But could not be eliminated.
13
Effect of Annealing on NCRI and CRI
14
Effect of Annealing on NCRI and CRI
Change in CRI
NCRI
15
Pressure and NCRI
Change in Pressure (65 mK)
NCRI
16
Annealing for Many Samples
Change in CRI
NCRI
17
Growth and Annealing Result
Fragile?
Robust Supersolid Component 0.04
18
Growth and Annealing Results

• NCRI increases as the growth velocity increases.
• VGrowth?0 Limit Finite NCRI (0.04 at 70 mK)
• Quenching can further increase NCRI,
• but up to 0.25.
• NCRI decreases little by little,
• by phased annealing above 0.8 K.
• 2. CRI increases by annealing above 1 K.
• 3. NCRI of 0.04 could not be eliminated
• 1. 1-Day annealing, 20 mK below Tm x 5 times
• 2. Annealing without torsional oscillation
• ?Robust Supersolid Component exists
• ? Consistent with single crystal result (Clark
  et al.)
• Velocity-Independent NCRI Robust NCRI

19
Discussion Increase in CRI
Conjecture
Annealing
20
Dislocations formed in Crystal Growth
Single Crystal Growth by Chochralsky Method
Dislocation Density (cm-2)
(T. Suzuki, in Lattice Defects (in Japanese),
edited by H. Suzuki (1978))
21
Crystal Growth with Constant Velocity
Solidification Start
Conjecture
End
Growth Velocity 10 mm /sec
22
Growth Velocity and Temperature Gradient
23
Origin of Temperature Gradient
Latent Heat
Balance of Cooling Power and Latent Heat
(F.D.Rosi, RCA Review 19, 349 (1958) (Germanium))
24
Dislocations formed in Crystal Growth
F. R. N. Nabarro, Theory of Crystal Dislocations
(1967)

1. Impingement of two lattices
2. Thermal stresses
3. Aggregation of vacancies
4. Segregation of impurities

25
Dislocations formed by Thermal Stresses
Solid 4He has very large thermal expansion
coefficient. This causes large thermal stress
under temperature gradient.
thermal expansion coefficient (K-1)
Ge 6x10-6
Cu 2.5x10-5
hcp 4He (20.5cm3/mol, 1.65 K) 10-2
26
Dislocations formed by Thermal Stress
Y. Hiki and F. Tsuruoka, Phys. Rev. B 27, 696
(1983)
Ultrasound study for hcp 4He grown at
constant pressures
Sudden temperature change DT 50 mK produces
dislocations of 109 cm-2 (diminished 1 hr)
27
Speculation Edge/Screw Dislocations
Edge Dislocations
Screw Dislocations
28
Annealing Effect Exceptional Behavior
Increase in NCRI Chan et al. Kubota et al.
Only once in about 40 annealings
Change in Dislocation Connectivity?
29
Helium in Porous Media
Helium 4 in Vycor (Adams, Beamish, Brewer, Reppy)
S-S-S Junction
(alias U-Mass Sandwich)
Vycor chunk
Svistunov, Hallock Davis et al.
30
Helium in Nanoporous Gelsil Glass
4He in porous Gelsil (25 A)
4He in Vycor (70 A)
(Yamamoto et al. PRL 93, 075302
(2004)) (Shirahama, JLTP 146, 485 (2007) )
31
Torsional Oscillator
Bulk helium
32
Ideas

• P gt 25 bar
• Search for NCRI in bulk solid (0.5 mm thick
  disk)
• 2. P gt 35 bar
• Search for NCRI of solid in 25 A nanopores
• 3. 25 lt P lt 35 bar
• Supersolid in contact with
• Superfluid Reservoir
• 4. Where is 3He impurity going?
• (Kojima, Ceperley, Huse)

33
Preliminary Result
2.99 MPa
Solid Tonset
liquid Tc
Coexistence of bulk supersolid and nanopore
superfluid
34
Preliminary Result Dissipation Peak
2.99 MPa
Velocity-Dependent Dissipation Supersolid
Signal
35
Summary

• Effect of Crystal Growth
• NCRI is altered by the growth velocity
• or temperature gradient in the crystal growth.
• Velocity-Independent NCRI
• 2. Effect of Annealing
• NCRI decreases by annealing above 0.8 K.
• NCRI of 0.04 could not be eliminated.
• ?Robust NCRI
• 3. Supersolid-Superfluid Double Layer

36
Frequency and Pressure
37
Control of Crystal Growth Velocity
38
(No Transcript)
39
Slow Cooling is equivalent to Annealing
Robust Supersolid Fraction
40
Annealing Effect Pressure
41
Annealing Effect
42
Annealing Effect
43
Superglass State?
Boninsegni, Prokofev Svistunov, PRL 96, 105301
(2006)
ODLRO exists in glassy solids
In a glass at low temperatures
C a T P b T2
T linear specific heat has been observed by Lin
et al. Note Mobile Dislocations can also
give T2 Term in Pressure (A. Granato, Phys.
Rev. 111, 740 (1958))
44
Pressure T2 term indicates a glassy state?
T2 Term smaller than other data (Grigorev
et al., cond-mat/0702133)) decreased after
annealing
45
Summary

• Attempt of rapid cooling
• produces large supersolid fraction
• 2. Substantial annealing effect
• depending on annealing temperature
• These results support the Disorder/Defect
  Scenarios.
• 3. Robust supersolid fraction (0.1)
• could not be eliminated by annealing
• 4. Pressure small T2 term decreases by
  annealing?
