Precision Engineering Micro Engineering and Nano Technology An Overview

1
Precision Engineering Micro Engineering and
Nano Technology An Overview

• Prof. C. Gajendran
• Director
• Central Manufacturing Technology Institute,
• Tumkur Road, Bangalore 560 022

2
Central Manufacturing Technology Institute
Tumkur Road,Bangalore
Web www.cmti-india.org
3
Current Themes in Manufacturing

• Flexible Automation -
• CNC machine tools, FMS, CIM and Factory
  Automation
• Ultra Precision Engineering-
• It is the result of synthesis of Metrology with
  Manufacturing
• Its application has lead to the evolution of many
  high-tech products like Computers,
  Electro-optical systems, Biomedical devices,
  consumer electronics

4
Ultra Precision Engineering has lead to the
growth of...

• Aerospace industries
• Atomic Energy
• Defence Research and Production
• Biomedical Engineering
• Information Technology
• Communication Engineering
• Entertainment Electronics

5
Ultra Precision Engineering benefits product
development through...

• Greater interchangeability
• High service life
• High reliability
• Better product quality
• Greater comfort to the users
• Low frictional losses
• Miniaturisation- leading to saving in raw
  material, energy conservation better
  environment

6
In manufacture of Precision products, we use,

• High precision and Ultra precision machine tools
  like DTMs, Ultra precision grinding and lapping
  machines, High precision EDMs, Laser cutting
  machines
• Apart from human skill, the other important
  ingredients of precision manufacture are good
  metrology practices, controlled environmental
  conditions for temperature, Humidity, Vibrations
  and dust levels

7
Conventional Precision Engg.

• High Precision Turning (Schaublin, Hardinge,
  Hambrug)
• Jig Boring (SIP, DIXI, Moore)
• High Precision Grinding (Studer, Kellenberger,
  Tripet)
• Lapping Super Finishing (Sufina, Nagel)

8
(No Transcript)
9
Ultra Precision Engineering
Micro Engineering Components and assemblies of
very small size
Nano technology units of measurement is Nano
metres
10
Micro Engineering is also known as

• Micro System Technology (MST)
• Micro Electro Mechanical Systems (MEMS) Technology

11
MEMS relate to

• Devices and and machines of extremely small size
  comprising tiny but highly sophisticated elements
  that allow them to perform minute and complicated
  tasks
• They are invariably integrated with signal
  processing electronic circuitry
• They are not just assemblies of Micro-fabricated
  components-but they imply radically new concepts
  in their design and production processes.

12
CMTI/PENT/PVS/MEMS-01
13
Micro gear with an ant
CMTI/PENT/PVS/MEMS-01
14
Miniaturisation 1 GB HDD (IBM)
15
CMTI/PENT/PVS/MEMS-01
16
Micro Engineering products find application
in..

• Watches
• Diving equipment
• Hand held pressure gauges
• Sports shoes (pressure sensors)
• Electronic fuel injectors
• Flow sensors
• Printer mechanisms Ink jet nozzles
• Sensors for condition monitoring of machinery

17
Micro Engineering products find application
in..

• Scanning Tunneling Microscopes
• Atomic Force Microscopes
• Implantable smart pills
• Catheter based devices
• Prosthetic devices
• Micro surgical tools

18
Examples of Micro Engineering devices

• Electro statically driven micro motors, Micro
  robots,
• Micro pumps, Micro Actuators, Micro gears,
• Accelerometers, Sensors, Transducers, Connectors
  etc.
• Micro and Remote Surgical tools
• Micro machine tools and Micro factories
• Their over all dimensions are in the order of a
  few mm

19
Travels through 8mm diameter bent tube
inspecting micro cracks
Micro Machine for pipe inspection
20
Micro Actuator with Optoelectric Device
21
Micro robots with silicon gears and
motors Overall size 6 mm
22
Comb drives
23
Wobble Motors
24
Piezoelectric Actuators
25
Thermal Actuators
26
Hydraulic Actuators
27
Micro Engg - applications

• Medical instrumentation
• Environmental control
• Safety engineering
• Communication technologies
• Aerospace and Automobile Engineering
• Consumer Products

28
MEMS used in automobile for monitoring for
various units like navigation system, Air
Conditioning system, Suspension system, throttle,
brake, fuel tank, air bag, crash sensor
CMTI/PENT/PVS/MEMS-01
29
MEMS used in bio-medial field for monitoring for
various units like pacemaker, muscle stimulator,
bladder stimulator, Blood pressure,
musculosckeletal prosthesis, etc.
CMTI/PENT/PVS/MEMS-01
30
MEMS Application in Intraluminal Diagnostics
31
MEMS Application in Power Plant
32
Micromachining Guide Lines

• Reduce Unit Removal (UR)
• Improve Equipment Precision

33
Types of Micromachining Processes

• Material Removal by
• Mechanical Force
• Melting Vapourisation
• Ablation
• Dissolution
• Plastic Deformation
• Solidification
• Lamination (Stereolithography)
• Recomposition

34
Micro Components by Microcutting
35
Micro Turn Mill Centre Drilling capacity ?100 ?m
36
Micro Milling machine Drilling capacity ?30 ?m
37
Microlap
38
Micromachining Melting Vapourisation

• Electrical Discharge Machining (EDM)
• Laser Beam Machining (LBM)
• Electron Beam Machining (EBM) Deformation

39
Wire EDM for Micro Machining
Submerged Cutting Threading Dual Measuring
System for X,Y axes Temperature Controlled
Dielectric
40
Micro Components Machined on Wire EDM
41
Micropin Fabricated by WEDG
42
Silicon Microstructure Fabricated by EDM
43
Micromachining Ablation

• When energy of laser beam exceeds binding energy
  atoms are removed form work piece (Excimer
  Lasers)
• When laser beam power is extremely high material
  is removed by vapourising skipping melting phase
  (Femto Second Lasers)

44
Laser (Excimer) Micro Machining System
45
Microslits Machined by FS laser
46
Laser machined via holes 10 micron wide
3D structures
Microcomponents Machined with Excimer laser
47
Micromachining Dissolution

• Chemical etching
• Wet Chemical etching
• Dry Chemical etching
• Bulk Machining
• Surface Micromachining
• Elecro Chemical etching (ECM)
• Photolithography
• LIGA Process

48
CMTI/PENT/PVS/MEMS-01
49
CMTI/PENT/PVS/MEMS-01
50
CMTI/PENT/PVS/MEMS-01
51
LIGA Process
LIGA- German acronym meaning Lithography
Electroplating and Injection Moulding
CMTI/PENT/PVS/MEMS-01
52
LIGA Process- Examples
Micromotor ______________100 µm
Micro gripper constructed by Berkely Sensor
and Actuator Center with released Polysilicon
surface
53
LIGA Process- Example
300 µm size structure of Micro gears made by
Sacrificial LIGA technique
54
Micromachining Lamination
Microturbine Rotor - Stereolithography
55
Micromachining Plastic Deformation
Lead Frame Produced by Micro Punching
56
Micromachining Solidification
Micromould by EDM and Replica
57
Nano Technology encompasses

• Nano Materials
• Nano Processes
• Nano Machining
• Nano Metrology

58
Nanotechnology Tree
59
Products of Nano Technology

• VLSI circuits
• Nano positioning systems
• Atomic Force Microscopes
• Scanning Tunnelling Microscopes
• Nano metrology instruments
• Nano lenses to focus light to a spot smaller than
  its wavelength

60
Opportunities include

• Thin film deposition - Drug deliver systems, gene
  therapy etc.
• Energy storage
• Development nano-structured materials with
  improved mechanical properties
• Bio sensors

61
Materials Used in Nano Technology...

• Optical Materials
• Self Assembling materials
• Longmuir Blodgett (LB) Films
• Liposomes
• Nano Tubes

62
Manufacturing processes related to Nano
Technology

• Ultra precision Diamond turning and grinding
• Lapping, polishing
• Energy Beam Processes Electron Beam machining,
  Ion Beam Machining, Laser Ablation
• Lithography (Photo, UV, X-Ray, Electron Beam etc.)

63
Manufacturing processes related to Nano
Technology

• Scanning Probe Microscopy
• Resistless Pattering by Evapouration
• Energy Beam Processes Electron Beam machining,
  Ion Beam Machining, Laser Ablation

64
Nano Technology machines
65
Schematic of Double Disc Grinding Machine (1 x0.5
m) for Super Flat Silicon wafer
66
Tetraform for Grinding of Optical Components to 4
nm Surface Finish
67
Molecular Measuring Machine
68
Nano Technology Applications
69
Nano Technology Applications
70
Nano Technology Applications
Self assembly of Synthetic DNA for Electronic
Circuitry
71
Nano Technology - Latest Trends

• Self Assembly
• Interfacing of Molecules

72
Nano Metrology Instruments

• Scanning Probe Instruments
• Interference Microscopes
• Scanning Probe Microscopes
• Molecular Measuring machine

73
Conics Aspherics
Range 1 mm Vertical Resolution up to 0.6
nm Accuracy for SF 2 nm Accuracy for Form 10
nm
Scanning Probe Instrument Form Taly Surf
74
Interferometer for 3D Surface Mapping
75
Scanning Probe Microscopes

• Scanning Tunnelling Microscope
• Atomic Force Microscope
• Magnetic Force Microscope
• Lateral Force Microscope
• Force Modulation Microscope
• Phase Detection Microscope
• Electrostatic Microscope
• Scanning Capacitance Microscope
• Thermal Scanning Microscope
• Near Field Scanning Optical Microscope

76
Generalised Scanning Probe Microscopes
-Schematic
77
Schematic of Tip and Sample Interaction in STM
78
Comparison of Constant Height and Constant
Current Mode for STM
79
Scanning Tunneling Microscope
80
Inter Atomic Force Vs Distance Curve
81
Beam Bounce Detection Scheme for AFM
82
Atomic Force Microscope
83
Magnetic Force Microscope (MFM) Mapping on
Sample Surface
84
Lateral Force Microscope (LFM) Operating
Principle
85
Principle of Force Modulation Microscope (FMM)
86
Principle of Phase Detection Microscope (PDM)
87
Principle of Electrostatic Force Microscope (EFM)
88
CMTI Initiatives in Precision Engineering
89
Precision Engineering Centre at CMTI
90
Environmental conditions of the Precision
Engineering Centre at CMTI
91

• CMTIs Activities
• in Micro Engg Nano Technology
• Micro Machining
• Manufacture of Ultrasonic Test Blocks
• Manufacture of Thin Rod and Button
• Manufacturing of Micro Gauges
• Manufacture Connectors
• Manufacture of Acoustic Sensors
• Micro Measurements
• Measurement of Micro Gauges (Dia 100nm)
• Calibration of SR Masters
• Calibration of Form Masters

92
Diamond Turning Machine Developed at CMTI
93
Mirror being machined on DTM
94
Mirrors Machined on DTM
Surface Finish 5 to 10 nm
95
Polygon Mirror
96
Ultrasonic Standard Reference Blocks
?0.5 x 8 mm deep Flat Bottom Hole Flatness 5 ?m
97
Ultrasonic Test Reference Master
98
Master Sphere
Sphericity 60 nanometer
99
Thin Rod for Hydrodynamic Bearing
Sphericity 0.5?m dia control ? 0.5?m Surface
finish 15 nm
100
Button for Hydrodynamic Bearing
Sphericity 0.5?m dia control ? 0.5?m Surface
finish 30 nm
101
Flexure
Groves must be concentric to OD within 0.05
?m Thickness 300 ?m
102
Bearing Housing
Concentricity 5 ?m Size Tolerance 10 ?m
103
Micro Component for Radar
Dimension to be controlled 0.175mm
104
Flexible Membrane Mirror Used in Astro
Applications
105
Thickness 0.8 ?m
Analysis of Micro Mirror deformation pattern
106
CMTI Future Plans in Micro EngineeringNano
Technology
107
Sphere Lapping Machine
108
Structure for Acoustic Sensor
109
Development of Gyroscope
110

• CMTIs Future Plans in Micro Engineering covers,
• Micro Machining Facility
• Micro measurement Facility
• Development of Micro positioning Stages
• Development of Micro Structures
• Development of Packaging Tech for MEMS
• Development of Sensors Sensor Technology

111
CMTIs Future Plans in Nano Technology Covers

• Sphere Lapping Machine
• Aspherical Grinding Machine
• Nano Positioning Systems
• Non Contact Nano Measuring Machines

112
Work on various facets of Nano Technology are
going on at

• IIT- Chennai
• IIT- Kharagpur
• IIT - Mumbai
• IISc, Bangalore
• Aerospace and Defence laboratories
• Precision Engineering centre, CMTI, Bangalore

113
Prominent Personalities In Micro Engg Nano
Technology

• Prof. Nario Taniguchi introduced the term Nano
  Technology
• Dr. Richard Feyman, a Nobel Laureate, first
  enunciated the concept of Nano Technology
• Mr. Evic Drexrea, known for Molecular Nano
  Technology

114
Prominent Personalities In Micro Engg Nano
Technology

• Prof. P.A. Mckeown, CUPE, UK
• Prof. T. Moriwaki, Kobe Univ., Japan
• Prof. D. Chetwynd, Univ. of Warwick, UK
• Prof. H. Kunzmann, PTB, Germany
• Prof. R.J. Hocken, UNCC, Charlotte, USA
• Prof. D.J. Whitehouse, Univ. of Warwick, UK
• Prof. E. Brinksmeier, Univ. of Bremen, Germany
• Prof. Lim Gnian Cher, SIMT, Singapore

115
We do look forward to your sustained interest
and interaction with us!
THANK YOU!
Visit us at website www.cmti-india.org
