Title: Routing in Mobile Ad Hoc Networks


1
  • Routing in Mobile Ad Hoc Networks
  • using
  • Collective Intelligence based Strategies

VIVEK KUMAR SINGH Department of Computer
Science, Banaras Hindu University,
Varanasi-221005 Email vivekks12_at_yahoo.co.in
PROF ASHOK K. GUPTA J. K. Institute of Applied
Physics Technology, University of Allahabad,
Allahabad-211002
NCAICT 2008
2
Mobile Ad hoc Networks (MANETs)
Consists of mobile nodes which communicate with
each other through wireless medium without any
fixed infrastructure
3
Mobile Ad hoc Networks (MANETs)
  • Nodes are mobile and they communicate with each
    other via wireless connections i.e., Dynamic
    Topology
  • Limited Processing Storing Capabilities of the
    Devices. (WSN)
  • Bandwidth Constraints
  • No centralized control, i.e., all nodes can serve
    as routers.

4
MANET Applications
  • Personal area networking
  • Cell phone, laptop, ear phone
  • Emergency operations
  • Search and rescue
  • Policing and fire fighting
  • Civilian environments
  • Taxi cab network
  • Meeting rooms
  • Sports stadiums
  • Boats, aircrafts
  • Military use
  • On the battle field

5
Problems / Challenges for MANETs
  • Without a central infrastructure, things become
    much more difficult
  • Problems are due to
  • Lack of central entity for organization available
  • Limited range of wireless communication
  • Mobility of participants
  • Battery-operated entities

6
Routing Protocol for Ad Hoc Networks
Characteristics and tradeoffs
  • Characteristics
  • Decentralized
  • Self-organized
  • Self-deployed
  • Dynamic network topology
  • Tradeoffs
  • ?? Bandwidth limited
  • ?? Multi-hop router needed
  • ?? Energy consumption problem
  • ?? Security problem
  • Why traditional routing protocols are not
    suitable for
  • MANET networks ?

7
MANET
X
X
X
8
Routing Protocol for Ad Hoc Networks
  • Proactive
  • (table-driven)

Reactive (on-demand)
Hybrid
  • DSDV
  • WRP
  • CGSR
  • DSR
  • AODV
  • TORA
  • ZRP

9
(No Transcript)
10
Table Driven Routing Algorithms
11
Demand Driven Routing Algorithms
12
Collective Intelligence

13
Collective Intelligence
  • Collective Intelligence is a form of Intelligence
    that emerges from the collaboration/ coordination
    of many individuals/ entities.
  • Collective intelligence appears in a wide variety
    of forms of consensus decision making in
    bacteria, animals, humans, and computers.
  • MIT, USA studying the question How can people
    and computers be connected so thatcollectivelyth
    ey act more intelligently than any individuals,
    groups, or computers have ever done before?'

14
Collective Intelligence (2)
  • Google uses the knowledge millions of people have
    stored in the World Wide Web to provide
    remarkably useful answers to users' questions.
  • Wikipedia motivates thousands of volunteers
    around the world to create the world's largest
    encyclopedia.
  • Innocentive lets companies easily tap the talents
    of the global scientific community for innovative
    solutions to tough RD problems.

15
Collective Intelligence (3)
16
Collective Intelligence (4)
  • Cooperative and Coordinated effort can be used to
    solve computationally hard problems.
  • Examples are Particle Swarms, Bee Colonies, Ant
    Colony Optimization etc.

17
Collective Intelligence - Advantages
  • Scalability
  • Fault tolerance
  • Adaptation
  • Speed
  • Modularity
  • Autonomy
  • Parallelism

18

Ant Colony Optimization (1)
  • Ant Colony Optimization (ACO) studies artificial
    systems that take inspiration from the behavior
    of real ant colonies and which are used to solve
    discrete optimization problems.
  • In 1999, the Ant Colony Optimization
    metaheuristic was defined by Dorigo, Di Caro and
    Gambardella.
  • In ACO, a set of software agents called
    artificial ants search for good solutions to a
    given optimization problem.

19
Ant Colony Optimization (2)
  • To apply ACO, the optimization problem is
    transformed into the problem of finding the best
    path on a weighted graph.
  • The artificial ants incrementally build solutions
    by moving on the graph.
  • ACO has been applied to a number of areas ranging
    from combinatorial optimization problems to
    telecommunication networks.

20

Ant Colony Optimization (3)
21
Ant Colony Optimization (4)
22

Ant Colony Optimization (5)
  • During the route finding process, ants deposit
    pheromone on the edges. the amount of pheromone
    of the edge (vi, vj) on movement from node
    vi to node vj is changed as follows
  • Like real pheromone the artificial pheromone
    concentration decreases with time. Typically
    given as

23
Key Components of ACO
24
Collective Intelligence Based Routing Algorithm
for MANETs
  • Many routing algorithms based on the idea of
    collective intelligence, particularly ACO, have
    been proposed.
  • Ant Net ( for wired Nets)
  • Ant Based Control (ABC)
  • Ant Routing Algorithm (ARA)

25
Ant Net
  • Routing is determined by means of very complex
    interactions of forward and backward network
    exploration agents (ants).
  • The backward ants utilize the useful information
    gathered by the forward ants on their trip from
    source to destination .

26
Ant Routing Algorithm (ARA)
  • The algorithm has three phases
  • Route Discovery Phase
  • Route Maintenance
  • Route Failure Handling

27
Route Discovery Phase (Forward Ant)
Ant Routing Algorithm (2)
28

Ant Routing Algorithm (3)
Route Discovery Phase (Backward Ant)
  • Route discovery phase in ARA. a) A forward
    ant (F) is sent from the sender (vS) to the
    destination node (vD). The forward ant passes
    through by other nodes which initialize their
    routing table and the pheromone values. b) The
    backward ant (B) has the same task as the forward
    ant. It is sent by the destination node (vD) to
    the source node vS.

29

Ant Routing Algorithm (4)
  • A FANT is an agent which establishes the
    pheromone track back to the source node.
  • a BANT establishes the pheromone track back to
    its origin, namely the destination node.
  • A node which receives a FANT for the first time
    creates a record in its routing table.
  • An entry in the routing table is a triple
    (destination address, next hop, pheromone value).

30

Ant Routing Algorithm (5)
  • Before updating

After updating
31

Ant Routing Algorithm (6)
  • Duplicate F-ANTs are identified through the
    unique sequence number, and are removed. The
    destination node extracts the information of the
    F-ANT, creates a B-ANT and returns it to the
    source node.
  • The B-ANT's task is similar to that of the F-ANT,
    i.e., to establish a track to this node. When the
    sender receives the B-ANT from the destination
    node, the path is established and data packets
    can be sent.

32
Route Maintenance
Ant Routing Algorithm (7)
  • Established paths do not keep their initial
    pheromone values forever.
  • When a node vi relays a data packet to
    destination vd through a neighbor node vj , it
    increases the pheromone value of the entry (vd,
    vj , ) by i.e. this path to the
    destination is strengthened by the data packet.
  • Likewise, the next hop vj increases the pheromone
    value of the entry (vs, vi, ) by i.e.
    the backward path to the source node is also
    strengthened.

33
Route Failure Handling
Ant Routing Algorithm (8)
  • If a node receives a ROUTE_ERROR message for a
    certain link, it deactivates this link by setting
    the pheromone value to 0.
  • the node searches for an alternative link in its
    routing table. If there is another route to the
    destination it will send the packet via this
    path.
  • Otherwise, the node informs its neighbors, hoping
    that they can forward the packet to the
    destination.

34
Ant Routing Algorithm (9)
35
Ant Routing Algorithm (10)
36
Ant Routing Algorithm (11)
37
Conclusion
  • Collective Intelligence based approach is
    suitable to dynamic, self organizing problems
    such routing control.
  • Collective Intelligence Based strategies have
    been applied to Network Routing problem with a
    reasonable degree of goodness.
  • Many strategies in simulated settings outperform
    almost all traditional approaches on a number of
    QOS parameters.

38
