Nerve physiology

1
Nerve physiology
2
Physiology of Nerves

• There are two major regulatory systems in the
  body, the nervous system and the endocrine
  system.
• The endocrine system regulates relatively slow,
  long-lived responses
• The nervous system regulates fast, short-term
  responses

3
Neuron structure

• Neurons all have same basic structure, a cell
  body with a number of dendrites and one long axon.

4
Types of neurons
5
Divisions of the nervous system
6
Non-excitable cells of the nervous system
7
Structure of gray matter
8
Signal transmission in neurons
9
Resting potential
10
Ionic basis of Em

• NaK-ATPase pumps 3Na out for 2 K pumped in.
• Some of the K leaks back out, making the
  interior of the cell negative

11
Electrochemical Gradients
Figure 12.12
12
Ion channels

• Remember Ohms Law IE/R
• When a channel opens, it has a fixed resistance.
• Thus, each channel has a fixed current.
• Using the patch-clamp technique, we can measure
  the current through individual channels

13
Gated channels ligand-gated
14
Gated channels voltage-gated
15
Gated channels mechanically-gated
16
Graded potential

• A change in potential that decreases with
  distance
• Localized depolarization or hyperpolarization

17
Graded Potentials
18
Graded Potentials
19
(No Transcript)
20
Action Potential

• Appears when region of excitable membrane
  depolarizes to threshold
• Steps involved
• Membrane depolarization and sodium channel
  activation
• Sodium channel inactivation
• Potassium channel activation
• Return to normal permeability

21
The Generation of an Action Potential
Figure 2.16.1
22
Graded potentials vs Action Potential
23
(No Transcript)
24
(No Transcript)
25
Characteristics of action potentials

• Generation of action potential follows
  all-or-none principle
• Refractory period lasts from time action
  potential begins until normal resting potential
  returns
• Continuous propagation
• spread of action potential across entire membrane
  in series of small steps
• salutatory propagation
• action potential spreads from node to node,
  skipping internodal membrane

26
The Generation of an Action Potential
27
Induction of an action potential I
28
Induction of an action potential II
29
Voltage-gated Na channels

• These channels have two voltage sensitive gates.
• At resting Em, one gate is closed and the other
  is open.
• When the membrane becomes depolarized enough, the
  second gate will open.
• After a short time, the second gate will then
  shut.

30
Voltage-gated K channels

• Voltage-gated K channels have only one gate.
• This gate is also activated by depolarization.
• However, this gate is much slower to respond to
  the depolarization.

31
Cycling of V-G channels
32
(No Transcript)
33
Action potential propagation

• When the V-G Na channels open, they cause a
  depolarization of the neighboring membrane.
• This causes the Na and K channels in that piece
  of membrane to be activated

34
AP propagation cont.

• The V_G chanels in the neighboring membrane then
  open, causing that membrane to depolarize.
• That depolarizes the next piece of membrane, etc.
• It takes a while for the Na channels to return
  to their voltage-sensitive state. Until then,
  they wont respond to a second depolarization.

35
Propagation of an Action Potential along an
Unmyelinated Axon
36
Saltatory Propagation along a Myelinated Axon
37
Saltatory Propagation along a Myelinated Axon
38
Schwann cells cont.

• In unmyelinated nerves, each Schwann cell can
  associate with several axons.
• These axons become embedded in the Schwann cell,
  which provides structural support and nutrients.

39
Synaptic transmission
40
g Aminobutyric Acid

• Also know as GABA
• Two know receptors for GABA
• Both initiate hyperpolarization in the
  post-synaptic membrane
• GABAA receptor allows an influx of Cl- ions
• GABAB receptors allow an efflux of K ions

41
Transmitter effects on Em

• Most chemical stimuli result in an influx of
  cations
• This causes a depolarization of the membrane
  potential
• At least one transmitter opens an anion influx
• This results in a hyperpolarization.

42
EPSPs and IPSPs

• If the transmitter opens a cation influx, the
  resulting depolarization is called an Excitatory
  Post Synaptic Potential (EPSP).
• These individual potentials are sub-threshold.
• If the transmitter opens an anion influx, the
  resulting hyperpolarization is called an
  Inhibitory Post Synaptic Potential (IPSP
• All these potentials are additive.

43
Post-synaptic integration
44
Signal integration
45
Signal integration cont.
46
Presynaptic inhibition
47
Presynaptic facillitation
48
(No Transcript)
49
Neural circuits I
50
Neural circuits II
51
Myelination I

• In the central nervous system, myelin is formed
  by the oligodendrocytes.
• One oligodendrocyte can contribute to the myelin
  sheath of several axons.

52
Myelination II

• In the peripheral nervous system, myelin is
  formed by Schwann cells.
• Each Schwann cell associates with only one axon,
  when forming a myelinated internode.

53
White and gray matter in the nervous system
54
Structure of the spinal cord I

• The CNS is made up not only of the brain, but
  also the spinal cord.
• The spinal cord is a thick, hollow tube of nerves
  that runs down the back, through the spine.

55
Structure of the spinal cord II
56
Structure of the spinal cord III
57
Structure of the spinal cord IV
