EAGLE Interface Update

1
EAGLE Interface Update
2
EAGLE Interface Update
3
EAGLE Interface Update
New pages are FAST! Graphics reduced to 2, about
13K total.
4
EAGLE Interface Update
Everything else is CSS and HTML.
5
EAGLE Interface Update
Navigation placement is consistent regardless
of page.
6
EAGLE Interface Update
Buttons that dont make sense are not seen, but
do not affect others positions
7
EAGLE Interface Update
Behavior of the interface is determined on each
MTE (details in a moment)
8
EAGLE Interface Update
and can be overridden in the MTE using
JavaScript.
9
EAGLE Interface Update
Most used navigation within the mouse swoosh
10
EAGLE Interface Update
Error messages are in red and consistently placed
11
EAGLE Interface Update
confirmation messages appear in green and are
also consistently placed
12
EAGLE Interface Update
in fact, all pages are designed to keep your
focus in a restricted area
13
EAGLE Interface Update
reducing eyestrain and keeping other nav paths
available but peripheral.
14
EAGLE Interface Update
This address is specified in the MOB HELPADR1
and has been added to all errors
15
EAGLE Interface Update
and the colors can be modified sitewide in
MOB EAG-JVASC.
16
EAGLE Interface Update
Most controls for the interface behavior are in
this small form on the MTE.
17
EAGLE Interface Update
This specifies what MMS will be called when you
click on Browse
18
EAGLE Interface Update
if the value is blank (e.g., ), then the
Browse button will not appear on the page.
19
EAGLE Interface Update
This specifies the URL that will be opened when
you click on HELP
20
EAGLE Interface Update
it defaults to eagle.ufl.edu/eDoc.
21
EAGLE Interface Update
This line determines visibility of the Page Down,
Page Up, Top and Bottom buttons
22
EAGLE Interface Update
a value of Y will cause them to be visible
23
EAGLE Interface Update
a value of B will cause only Top and Down
to appear (for browses).
24
EAGLE Interface Update
This field determines whether the Run button
will appear on the page
25
EAGLE Interface Update
again, a value of Y will cause it to be
visible, and any other value will not.
26
EAGLE Interface Update
This field determines whether the page will have
prev/next. Y will cause it to appear.
27
EAGLE Interface Update
These three FORMS create the EAGLE interface.
28
EAGLE Interface Update
Scrolling down, the rest of the MTE is pretty
standard
29
EAGLE Interface Update
with the exception of the two closing ltDIVgt tags.
30
EAGLE Interface Update

• Just a few more changes

31
EAGLE Interface Update
Browses are more consistent in appearance and
function
32
EAGLE Interface Update
again, notice no browse, prev/next, add/delete,
run, or submit buttons
33
EAGLE Interface Update
Go To and Search For buttons have
appropriate text, and are on the same line as
the entry box.
34
EAGLE Interface Update
The UTILITIES page looks somewhat different
35
EAGLE Interface Update
however, all the functions are still here, plus
some new ones
36
EAGLE Interface Update
and the Copy Objects interface is somewhat
changed, hopefully simpler and better.
37
EAGLE Interface Update
More DB/2 utilities are now accessible from the
main interface.
38
EAGLE Interface Update

• Questions or Comments?

39
EAGLE Interface Update

• Questions or Comments?
• eaglesupport-l_at_lists.ufl.edu
