Candy and the Solid State of Matter:

1
Candy and the Solid State of Matter Connecting
the Molecular to the Macroscopic World Richard
D. Ludescher Food Systems Summer Institute June
27-29, 2006
2
Consider TheseKinds of Solid Candy

• Chocolate
• Hard Candy
• Gummi Bears
• How are their physical properties similar?
• How different?Why?

3
Molecular Structure of Solid Candy

• Chocolate
• Crystalline Solid Cocoa butter matrix
• Hard Candy
• Amorphous Solid Sucrose solution
• Gummi Bears
• Soft Polymeric Solid Gelatin gel

4
Chocolate Theobroma cocao
5
?
Cocoa LiquorSugarCocoa Butter(Milk Powder)
6
Cocoa Beans
Chocolate liquor
Roast Mill
Add cocoa butter, sugar, (milk powder, flavor)
Conch
Temper
Chocolate Manufacturing Process
Mold or Enrobe
7
Chocolate Liquor The melangeur grinds chocolate
nibs into liquor
8
Melts in Your Mouth (Not in Your Hand)
Chocolate Matrix is Crystalline Fat (Cocoa Butter)
9
Cocoa Butter is made of Triglycerides
Tripalmitin
10
Cocoa Butter Composition

• Palmitic acid (25)
• C160 16 carbon saturated fatty acid
• Stearic acid (35)
• C180 18 carbon saturated fatty acid
• Oleic acid (35)
• C181 18 carbon unsaturated fatty acid
• One cis double bond at C9
• Primarily P/StOP/St and P/StOO structures

11
Cocoa Butter Crystals Proposed structures
12
Crystal Forms of Cocoa Butter Chocolate Tempering
Tempered chocolate
Cocoa butter is a polymorphic fat It can form
six different crystal structures with different
melting points and properties
13
Chocolate Fashion ShowChocolate Show New York,
November 8, 2005
14
When Chocolate Goes Bad
Chocolate Bloom Formation of new crystals on
surface
15
Chocolate Bloom
Tempered
Bloomed
Thermal abuse melts form V crystalsLiquid fat
migrates to the surface where it crystallizes
into unappetizing small, polymorphic crystals of
arbitrary form
16
Hard Candy Saccharum officinarum
17
Rock Candy Table Sugar Crystalline Sucrose
Hard Candy Lollipops Amorphous Glassy Sucrose
18
Hard Candy Recipe Sugar 5 cupsCorn syrup 1
cupWater 1 cupFlavor 1-2 teaspoons oil of
peppermint, orange, anise, cinnamon, wintergreen,
cloves, or spearmint, etc.Color 1-2 drops of
food coloring (if desired) Mix sugars and water,
cook to hard crack stage (300?F), remove from
heat, add flavor, mix well, pour into molds and
cool. Store in sealed container.
19
Glass Forms Because Crystallization is
Frustrated by High Viscosity of Liquid Sugar
20
Properties of Amorphous Glassy Sucrose

• Solid-like
• Hard, rigid and brittle
• Liquid-like
• Can dissolve colors and flavors
• Supersatuated liquid
• Softens at high temperature Glass transition
  (Tg)
• Hard brittle below Tg
• Soft malleable above Tg

21
Crystal Long Range Molecular OrderAmorphous
Glass No Long Range Order
22
Rose Window Notre Dame, Paris One of the more
attractive applications of glass technology
23
Sugar Sculpture American Culinary Federation
National Convention, 2003
24
Triboluminescence Light emission after excitation
by rubbing or striking
Wintergreen (methyl salicylate)
25
Triboluminescence of Sucrose(nitrogen emission)
Absorption and Fluorescence of Wintergreen
26
Gummi Bears Hard Jell-O
27
Gummi Bear Recipe Water Corn syrup Sucrose
GelatinCitric acid Coconut oilCarnauba
waxFlavors ColorsDissolve sugar and gelatin
in boiling water, add syrup, oil and wax, mix
well. Add citric acid, juice, and flavors and
colors. Pour into molds. Cool. Gelatin is added
at levels about 6x that used in Jello.
28
Gelatin has been around for millennia, Jell-O for
about a century
29
Sus scrofa The source of most food gelatin
30
Jell-O is a Gel A 3-D Polymer Network
31
Mechanism of Gel Formation in Jell-O
Dissolve gelatin in boiling water
Cool to T
Gelatin crosslinks to form polymer network
32
Gelatin Triple Helix The Physical Crosslinks in
a Gelatin Gel
