Decision Support Systems for Forest Biodiversity

1
Decision Support Systems for Forest Biodiversity
Evaluation of Current Systems and Future Needs

• K. Norman Johnson
• Sean Gordon
• Oregon State University

2
Project Questions

• What types of decision support systems exist for
  use in sustainable forestry and biodiversity
  management?
• How they are being applied?
• How can existing tools could be adapted and
  applied elsewhere?
• What additional tools (or capabilities) are
  required to meet forest management needs?

3
What are Decision Support Systems?

• situations where human judgment is important
  but where limitations in human information
  processing impede decision making.
• bring together the intellectual flexibility and
  imagination of humans with the speed, accuracy,
  and tirelessness of the computer.
• Our definition DSS help
• evaluate alternative decision options (decision)
• deal with complexity (support)
• have a clear, reproducible protocol (system)

4
What is Biodiversity?

• variety and variability among living organisms
  and the ecological complexes in which they
  occurnumber of different items and their
  relative frequency (OTA 1987)
• "Biodiversity is the totality of genes, species,
  and ecosystems in a region (UNEP 1992)
• Montreal Protocol Criterion 1
• ecosystems (1-5 coarse filter), species genetic
  (6-9 fine filter)
• composition, structure, and function (Franklin)

5
Approach

• Top down identification of priority needs for
  forest biodiversity decisions
• review of literature and interviews with experts
  decision makers
• Bottom-up inventory of available systems
• previous surveys, literature, interview system
  designers
• Comparison
• to what extent are existing DSS able to assist
  with priority needs?
• Suggestions for improvement

6
Literature Review Decision Needs

• Smythe, K.D. Bernabo, J.C. Carter, T.B. Jutro,
  P.R. 1996. Focusing Biodiversity Research on the
  Needs of Decision Makers. Environmental
  Management 20(6) 865-872.
• 100 decision makers government, environmental,
  industry
• 5 types of decision areas
• protection/ conservation, management,
  organizational authority and responsibility,
  siting, and laws and regulations.
• 4 levels of decision making
• operational, tactical, strategic, policy
• 4 categories of info needed
• (l) significance of biodiversity, (2) status and
  trends of biodiversity, (3) management for
  biodiversity, and (4) linkage of social and
  biological objectives.

7
Interviews with Forestry and Conservation Leaders

• Tony Melchoirs, Weyerhaeuser
• Rick Brown, Defenders of Wildlife
• Dennis Grossman, Nature Serve
• Jerry Franklin, Univ. of Washington
• Sally Duncan, Consultant
• Carlton Owen, Consultant
• Barry Noon, Colorado State Univ.

8
Problems in Assessing Biodiversity from
Literature and Interviews

• Need for credible measures tools for assessing
  biodiversity
• Need for standardization in ways to characterize
  and assess biodiversity across a region
  (currently many different ways)

9
Major Forest Biodiversity Influences From
Interviews and Literature

• Development
• Climate change
• Invasive species
• Uncharacteristic disturbance
• Timber harvest

10
Typical Decisions that Involve Biodiversity
Evaluations from Interviews and Literature

• Recovery Plans, HCPs, and Safe Harbor Agreements
• Conservation easements
• Certification
• Adoption of state forest practice laws
• Federal and state plans
• Private forest plans
• Development choices
• Restoration opportunities
• Land exchanges

11
Important Framing Issues for Decisionsfrom
Interviews and Literature

• Consideration of the entire relevant landscape,
  such as whole watersheds for riparian issues
• Consideration of short-term and long-term risk,
  especially relative to the relative risks of
  action and inaction

12
Important Institutional Issues from Interviews
and Literature

• Commitment to assess and organize information on
  biodiversity, set trigger points, identify
  cause-effect relationships
• Trust among agencies responsible for biodiversity
  protection
• Acceptance of, and ownership in, landscape-level
  (cross-ownership) evaluation tools
• Existence of landscape-level institutions

13
Literature Review DSS

• Mowrer, H.T. et al. 1997. Decision support
  systems for ecosystem management an evaluation
  of existing systems. General Technical Report
  RM-GTR-296.
• Rauscher, H.M. 1999. Ecosystem management
  decision support for federal forests in the
  United States a review. Forest Ecology and
  Management 114 173-197.
• Johnson, P. Lachman, B. 2001. Rapid scan of
  decision support system tools for land-use
  related decision making. Unpublished draft.
  Arlington, VA NatureServe.

14
Some Conclusions from DSS Literature Review

• Successful tool kits address the process of
  decision-making (social negotiation), rather than
  just putting information in front of
  decision-makers
• Consideration of TE species a common thread in
  decisions at different levels
• At county level, rarely deal with individual
  species unless legally required
• Federal forest planning focused on individual
  species, but tools lacking

15
Inventory of Systems 86 systems in current
inventory
16
Prioritization of Systems 24 systems currently
ranked priority 1-2
17
System Description Template

• purpose, core outputs, major components
• simulation, evaluation, optimization
• capabilities for evaluating biodiversity concerns
• coarse vs. fine filter approaches
• examples of use
• brief description contact info
• transferability
• development status, cost, technical resources
  required
• future development plans

18
System Description NED

• Purpose
• help managers develop goals, assess current and
  future conditions, and produce management plans
  for forests in the eastern United States
• Core Outputs
• evaluation of goals, for any or all of five
  resources visual quality, wildlife, water, wood
  production, and health

19
System Example NED

• management options

forest growth model (simulation)
stand conditions
habitat suitability indices (evaluation fine
filter)non-spatial
other factorsvisual quality, water, wood
production, and general ecological objectives
management goals (evaluation)
20
System Description NED

• Major Components
• NED/SIPS stand inventory analysis, treatments, 4
  integrated growth models
• NEWILD evaluates the habitat suitability of
  stand inventory
• NED-Health estimates effects of numerous insects
  and diseases, along with detrimental aspects of
  adverse weather, logging damage, animal grazing,
  and air pollution.
• NED-1 evaluates how a management unit as a
  whole, or an individual stand, may provide
  conditions required for specific goals
  (aesthetics, ecology, forest health, timber,
  water and wildlife)

21
System Description NED

• Capabilities for evaluating biodiversity concerns
• Includes Habitat Suitability Indices for 338 New
  England vertebrate species
• Fine filter approach
• Analysts choice of which to include
• Analyze existing or work towards desired habitat
• Non-spatial
• Species richness but not abundance or interaction
• Coarse filter interaction between
  invasives/pathogens and biodiversity

22
System Description NED

• Examples of use
• 1. Numerous (in hundreds) East Coast federal,
  state and private foresters use NED to prepare
  forest stewardship plans.
• 2. Mike Rauscher of the Forest Service
  (828-667-5261) has adapted and used it on private
  lands in South Carolina.
• 3. It is being used on Ft. Campbell's 70,000
  acres (contact Steve Forry 270-956-3376).
• 4. Maryland DNR is working to adapt and use NED
  to analyze different properties in terms of water
  quality, wildlife, recreation and biodiversity
  (contact Rob Northrop 410-287-2918).

23
System Description NED

• Transferability
• (development status, cost, technical resources
  required)
• Production system prepared for use by others
• Growth models operate with species and diameter
• Wildlife, health, aesthetics require understory
  conditions and additional data beyond
  traditional, timber-oriented, forestry stand
  exams.

24
Ability of NED to address Montreal Process
Criterion 1 indicators
25
Other Evaluation Criteria?

• 7 Elements of sustainability (Davis, et. al. 2001)

26
System example EMDS

• Ecosystem Management Decision Support is
  primarily designed to help users conduct
  ecological assessments. It provides a framework
  for users to integrate spatial information (using
  ArcGIS) with models of how to evaluate this
  information (using the Netweaver knowledge-base
  builder).

27
EMDS Knowledge bases

• A form of meta database
• A formal logical representation of how to
  evaluate information
• Networks of interrelated topics
• Mental map
• Advantages
• Interactive, graphic design (modularity)
• Numerous diverse topics can be analyzed within
  a single integrated analysis

28
EMDS
Applied to the Montreal C I.
29
Willamette Basin Alternative Futures Analysis

• Purpose Help diverse stakeholders understand
  the ecological consequences of possible societal
  decisions related to changes in human populations
  and ecosystems in the Pacific Northwest.
  Simulates the effects of 3 possible development
  scenarios on regional measures of biodiversity
  over the next 50 years.

30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Interim Conclusions onSystem Capabilities

• Diversity of approaches, but relatively few fully
  developed and accepted DSS for forest
  biodiversity
• Many systems link a variety of independent
  components
• Traditional systems (e.g. NED) fit well within
  our description template, but many do not
• generic systems like EMDS
• prototypical systems like Willamette Futures
• Often difficult to evaluate transferability

37
DSS for Commercial Timber Supplies and Forest
BiodiversityA Comparison

• The 1970sthe golden age of DSS for commercial
  timber supplies. For this work, we had
• A widely-accepted, integrated mathematical theory
  of the decision problem
• Agreement on a limited number of forest types of
  interest
• Existence of quantitative models of growth and
  yield for most major forest types
• General agreement among landowners/agencies about
  how to formulate the problem

38
DSS for Commercial Timber Supplies and Forest
BiodiversityA Comparison

• Is now the golden age for forest biodiversity
  DSS?
• A widely-accepted, integrated mathematical theory
  of the decision problem? NO
• Agreement on the major species of interest? NO
• Published models of how species of interest react
  to changes in forest conditions? NO
• General agreement among landowners/agencies about
  how to formulate the problem? NO

39
DSS for Commercial Timber Supplies and Forest
BiodiversityA Comparison

• DSS for forest biodiversity often must develop
  all this information on the flytheoretical
  model, species of interest, relation of species
  to habitat, agreement among affected parties
• It should not be surprising that relatively few
  DSS exist for forest biodiversity or that they
  are often so difficult and expensive to create.

40
Interim Conclusions Comparison of Major Issues to
DSS Capabilities

• Most focus on timber harvest as the central issue
• Some now allow consideration of the hazard of
  fuel build-up
• Very few deal with pests, pathogens, climate
  change, or development (esp. effects on
  biodiversity)

41
What is a DSS?

• Many important decisions include biodiversity
  evaluations not covered by the traditional
  computer-based definition
• forest certification standards
• Expert committee approaches (e.g. FEMAT) used in
  bioregional assessment and planning

42
Communication of Results

• Report presentation for NCSSF
• Electronic distribution of report
• Web-linked database of DSS (searchable by items
  in our template)
• Publication in forestry and conservation journals

43
Questions for NCSSF Group

• What uses might you have for decision support
  systems (DSS) to assist you with decisions that
  affect forest biodiversity?
• If you havent used them much for this purpose,
  why not?
• 3. What would you need to know to help you select
  appropriate tools?
• a. What attributes of systems are likely to
  make them most useful?
• b. What aspects of DSS cause you to have
  reservations about their use?
• 4. How would biodiversity implications from these
  systems need to be expressed to make them
  comparable to other major factors that typically
  influence your decisions?
