GPS in Civil Aviation: Safety, Capacity, and Efficiency

1
GPS in Civil Aviation Safety, Capacity, and
Efficiency

• Captain Rocky Stone
• Chief Technical Pilot
• United Airlines

2
What does GPS do for civil aviation?

• Space-based navigation allows more aircraft in
  our airspace
• Guarantee of a 27-30 satellite constellation will
  reduce en-route and terminal spacing
• GPS will reduce fuel burn and greenhouse gas
  emissions
• More direct, time-based routings
• GPS Timing better precision operations
• GPS Surveillance for safer and more efficient
  operations due to position awareness
• Reduced runway incursions
• Provides greater situational awareness
• Increased capacity with increased safety

3
NextGen is GPS!

• RNAV/RNP
• VNAV
• EFB
• FANS/Data Communications
• GBAS/LAAS
• WAAS
• ADS-B
• CDTI
• Curved Path - Approaches
• Surface Traffic Applications
• ASDE-X, RAAS, TIS

4
NextGen GPS dependency

• RNAV/RNP - GPS
• VNAV - GPS
• EFB - GPS
• FANS/Data Communications - GPS
• GBAS/LAAS - GPS
• WAAS - GPS
• ADS-B - GPS
• CDTI - GPS
• Curved Path Approaches - GPS
• Surface Traffic Applications - GPS
• ASDE-X, RAAS, TIS

5
ATL departure paths before RNAV
6
ATL with RNAV accuracy!
7
RNP Enables Lower Minimums
Slide courtesy of
Juneau
Procedure
Standard
Alaska Non-RNP
Alaska RNP
724/1
Runway 8 arrival
2,880/4
1,000/2
Day800/2 Night2,000/5
Day800/2 Night2,000/5
Runway 8 departure
RVR 1,600
RNP also enables increased maximum takeoff weight
Runway 26 arrival
None
None
337/1
8
Slide courtesy of
9
Juneau Approach
Video courtesy of
10
Optimum Profile Descents are the future of all
approaches huge fuel savings!
11
United has pioneered the use of Tailored
Arrivals Ex HNL-SFO Fuel Saved 1600 lbs!
12
UAL Surface Moving Map Test
13
RAAS SystemApproaching Runway - On Ground
44 of Runway Incursions in our study
involve loss of position awareness.

• Conditions for advisory
• Advisory depends on aircraft groundspeed, heading
  and nearest runway end
• Earlier call-out at higher speeds
• Inhibited above 40 knots
• No distraction during take-off/landing ground roll

Approaching One-One
14
GPS based Terrain Awareness

• Using RNP enabled by GPS in the vicinity of high
  terrain increases safety margin and adds capacity
• Much better performance from the Terrain
  Awareness and Warning System (TAWS)
• No RADAR required!

15
What is ADS-B?
ADS-B Enables Safety In the air and on the
ground

• Automatic
• Dependent
• Surveillance
• Broadcast

Surface / Terminal / En Route / Oceanic
16
SFO Paired Approach Concept
Final Approach Path
RW28R
Collision Danger Area
Final Approach Path
RW28L
Trailing
Aircraft
No Wind
Window
Wake Vortex
Hazard Area
17
ADS-B for Wake Vortex Avoidance

• Adding wake vortex avoidance information in ADS-B
  allows for ground based wake vortex capacity
  prediction systems and air-to-air wake vortex
  visualization systems
• Ground based system needs to accurately predict
  capacity at least two hours in advance
• Needed parameters
• Wind, Temperature, Aircraft Wake Vortex Category,
  Eddy Dissipation Rate, Flap setting

18
Motivation for Wake Visualization
IFR vs. VFR Separation
FAA Regulated Separation Distances for IFR
Leader Aircraft
Follower Aircraft
Note Distance behind 757 is 4 nm for all
aircraft.
Distances in nautical miles
Slide courtesy Dr. J. David Powell, Stanford
University
19
Wake Visualization Display
Picture courtesy Dr. J. David Powell, Stanford
University
20
How does GPS benefit civil aviation?

• Precision Navigation MORE CAPACITY, MORE ALL
  WEATHER OPS
• Reduced fuel burn
• Reduced block times
• Position Awareness SAFETY, INCREASED CAPACITY
• Precision Timing BETTER FLOW MANAGEMENT

21
Thank you!
