Henry S. Baird

1
A Highly Legible CAPTCHAthat Resists
Segmentation Attacks

• Henry S. Baird
• Michael A. Moll
• Sui-Yu Wang

2
Some Typical CAPTCHAs


AltaVista
eBay/PayPal
Yahoo!
PARCs PessimalPrint
3
All These Are Vulnerable to Segment-then-Recogniz
e Attack

• Effective strategy of attack
• Segment image into characters
• Apply aggressive OCR to isolated chars
• If its known (or guessed) that the word is
  spellable (e.g. legal
  English), use the lexicon to constrain
  interpretations
• Patrice Simard (MS Research) et al report that
  this breaks many
  widely used CAPTCHAs

4
We try to generate word-imagesthat will be hard
to segment into characters

• Slice characters up -vertical
  cuts then -horizontal cuts
• Set size of cuts to constant within a word
• Choose positions of cuts randomly
• Force pieces to drift apart scatter horiz.
  vert.
• Change intercharacter space

5
Character fragments can interpenetrate

• Not only is it hard to segment the word into
  characters, .
• it can be hard to recombine characters
  fragments into characters

6
Character fragments can interpenetrate

• Not only is it hard to segment the word into
  characters, .
• it can be hard to recombine characters
  fragments into characters

7
Nonsense Words

• We use nonsense (but English-like) words (as in
  BaffleText)
• generated pseudorandomly by a stochastic
  variable-length character n-gram model
• trained on the Brown corpus
  this
  protects against lexicon-driven attacks
• Why not use random strings?
• We want to help human readers feel confident they
  have made a plausible choice, so theyll put up
  with severe image degradations (Cf. research in
  psychophysics of reading.)

M. Chew H. S. Baird, BaffleText a Human
Interactive Proof, Proc., 10th SPIE/IST
Document Recognition and Retrieval Conf.,
(DRR2003), Santa Clara, CA, January 23-24, 2003.
8
How Well Can People Read These?

• We carried out a human legibility trial with the
  help of
• 60 volunteers students, faculty, staff
  at Lehigh Univ.
• plus colleagues at Avaya Labs Research

9
Subjects were told they got it right/wrong
after they rated its difficulty
10
Subjective difficulty ratingswere correlated
with objective difficulty

• People often know when theyve done well
• This can be used to ensure that challenges arent
  too hard (frustrating, angering)

11
The same data, graphically
1 Easy 2 3 4 5 Impossible
Right Wrong
12
People Rated These Easy (1/5)

• aferatic
• memmari
• heiwho
• nampaign

13
Rated Medium Hard (3/5)

• overch / ovorch
• wouwould
• atlager / adager
• weland / wejund

14
Rated Impossible (5/5)

• acchown / echaeva
• gualing / gealthas
• bothere / beadave
• caquired / engaberse

15
Why is ScatterType legible?

• Does it surprise you that this is legible?
• I speculate that we can read it because
• we exploit typeface consistency
• the evidence is small details of
  local shape
• this ability seems largely unconscious

16
Ensuring that ScatterType is Legible

• We mapped the domain of legibility
  as a function of engineering
  choices
• typefaces
• characters in the alphabet
• cutting scattering parameters

cut fraction expansion fraction horizontal
scatter mean vertical scatter mean h v scatter
variance character separation
17
Some typefaces remain legiblewhile others
degrade quickly
18
Raising Legibility byPruning Typefaces
19
Some Characters QuicklyBecome Confusable
overch o e c confusions
20
Raising Accuracy byOmitting Characters
21
Ensuring Legibility

• Pruning characters typefaces
• raised legibility in the top two difficulty
  levels to 90
• Next step
• restrict the range of cutting scatter parameters

22
Mean Horizontal Scattervs Mean Vertical Scatter
1 Easy 2 3 4 5 Impossible
Right Wrong
Mirage data analysis tool, Tin Kam Ho, Bell Labs.
23
Cut Fraction Histogram
1 Easy 2 3 4 5 Impossible
Right Wrong
24
Character Separation Histogram
1 Easy 2 3 4 5 Impossible
Right Wrong
25
Finding Parameter Rangesfor High Legibility
d Euclidean distance from origin of Mean Horiz
Scatter vs Mean Vertical Scatter
26
Guided by this Analysis, We Can Define
Legibility Regimes
Trivial large cut fraction and small expansion
Simple character separation also decreases
Easy in original trial, correct 81 of time
Medium Hard larger scatter distances degrades
legibility noticeably
27
Other Examples - Easy
wexped - difficult to segment e, x and p.
Shows difficulty of achieving 100 legibility
veral - same parameters as above but different
font. Not as difficult to segment
28
Other Examples - Too Hard
thern difficult to read, but easier than most
with the same parameter values. Font makes a big
difference.
wezre satisfactorily illegible, though probably
segmentable
29
Next Steps

• By judicious restrictions on engineering
  parameters, attempt to ensure human legibility
  better than 99.5
• Similarly, attempt to ensure 90 of challenges
  have low subjective difficulty ratings (e.g. 1-3
  out of 5)
• You are welcome to try out ScatterType
• arcturus.cse.lehigh.edu/CAPTCHAs
• Also, we invite you to attack it
• Well send you large batches, with ground-truth
• Try to train a classifier to break it!

30
Future Work

• We have exhausted the experimental data from the
  1st trial
• How can we automatically create images with given
  difficulty?
• We have generated many images that seem difficult
  to segment automatically, but we dont understand
  how to guarantee this
• We need to understand the effects of typefaces on
  ScatterType legibility
• We want to study character-confusion pairs more
• Attacking ScatterType
• Testing on best OCR systems
• Invite attacks from other researchers
• Is it credible if we attack it ourselves, and
  fail?

31
Contacts

• Henry S. Baird
• baird_at_cse.lehigh.edu
• Michael Moll
• mam7_at_lehigh.edu
