Understanding and Supporting Hard Drives

1
Chapter 7

• Understanding and Supporting Hard Drives

2
You Will Learn

• About hard drive technologies
• How communication with hard drive BIOS is
  accomplished
• How a hard drive is logically organized to hold
  data
• How to install a hard drive
• How to troubleshoot hard drives

3
Hard Drive Technology

• Technology of how the hard drive interfaces with
  the system
• Technology used within the hard drive to read and
  write data to the drive

4
Types of Hard Drive Interfaces

• EIDE standards
• Other interface standards
• SCSI
• IEEE 1394
• Fibre Channel

5
(No Transcript)
6
IDE Channels on a Motherboard
7
How Hard Drives Work

• Platter(s) are stacked together and spin in
  unison
• Read/write heads are controlled by an actuator
  and move in unison across disk surfaces as disks
  rotate on a spindle
• Require hard drive controller for instructions

8
Hard Drive with Four Platters
9
IDE Technology

• Most hard drives use IDE standards

10
Tracks and Sectors on IDE Drive

• Older MFM and RLL technologies
• Have either 17 or 26 sectors per track over
  entire drive platter
• All tracks contain same number of bytes
• IDE drives use zone bit recording formatting
  system
• Number of sectors per track is not the same
  throughout the platter
• Tracks near center have smallest number of
  sectors per track

11
Older Technologies
12
Zone Bit Recording
13
IDE Drives

• Low-level formatting
• Track and sector markings are written on hard
  drive at the factory
• High-level formatting (OS formatting)
• Executed by the OS
• Creating a boot sector, FAT, and root directory

14
Hard Drive Manufacturers
15
Communicating with the Hard Drive BIOS

• Calculating drive capacity on older drives
• Adjusting for more complex hard drive
  organization
• Calculating capacity on newer drives
• CHS or normal mode
• Translation methods
• ECHS mode or large mode
• LBA mode

16
Calculating Drive Capacity on Older Drives
17
Installations Using Legacy BIOS

• Let the BIOS see the drive as a smaller drive
• Upgrade the BIOS
• Upgrade entire motherboard
• Use software that interfaces between older BIOS
  and large-capacity drive
• Use an adapter card that provides the BIOS to
  substitute for system BIOS

18
How System BIOS Helps Manage Data Transfer

• Provides interrupt handler for software
  interrupts
• Automatically detects/configures hard drive
• Helps manage data transfer over I/O bus between
  hard drive and memory
• Using PIO mode, CPU is in charge
• Using DMA with DMA controller in charge (no CPU
  involvement)
• With bus mastering using DMA, hard drive BIOS
  controls data transfer

19
How a Hard Drive Is Logically Organized to Hold
Data

• Requirements to boot from hard drive and get to a
  command prompt
• Drive must have track and sector markings written
  on it
• A file system must be installed
• Files needed to boot the PC must be copied to
  root directory of drive

20
How a Hard Drive Is Logically Organized to Hold
Data

• Steps for preparing a hard drive to hold files
  (after physical installation)
• Low-level format
• Partition hard drive
• High-level format

21
Hard Drive Partitions and Logical Drives

• Partitions
• High-level divisions
• Logical drives (volumes)
• Further division of partitions
• Have letters assigned to them
• Each has its own file system (eg, FAT16, FAT32)

22
Drive Partitions and Logical Drives
23
Contents of a Partition Table
24
How Many Logical Drives?
25
When to Partition a Drive

• When installing a new hard drive
• If existing hard drive is giving errors
• If you suspect a virus has attacked the drive
• To wipe hard drive clean and install new OS

26
What Happens During Formatting

• OS format for each logical drive creates these
  file system items at beginning of each logical
  drive
• OS boot record
• FAT
• Root directory

27
Layout for the Boot Record
28
Disk Type and Descriptor Byte
29
Installing a Hard Drive

• Set jumpers or DIP switches on drive physically
  install drive inside case attach power cord and
  data cable
• Inform CMOS setup of new drive, or verify that
  autodetect correctly detected the drive
• Use Fdisk utility to create partition(s) on
  drive divide extended partition into logical
  drives
• Use Format command to high-level format each
  logical drive
• Install OS and other software

30
Prepare for Installation

• Read documentation
• Plan drive configuration
• Prepare work area and take precautions

31
Prepare for Installation
32
Set Jumpers and DIP Switches
33
Set Jumpers and DIP Switches
34
Set Jumpers and DIP Switches
35
Mount Drive in the Bay
36
Mount Drive in the Bay
37
Mount Drive in the Bay
38
Mount Drive in the Bay
39
Mount Drive in the Bay
40
Mount Drive in the Bay
41
Mount Drive in the Bay
42
If Bay Is Too Large
43
Use CMOS Setup to Change Hard Drive Settings
44
Use CMOS Setup to Change Hard Drive Settings
45
Use CMOS Setup to Change Hard Drive Settings
46
Use CMOS Setup to Change Hard Drive Settings
47
Use Fdisk to Partition a Drive
48
Use Fdisk to Partition a Drive
49
Use Fdisk to Partition a Drive
50
Format Each Logical Drive

• Format C/S
• Format D
• Format E

51
Managing and Troubleshooting Hard Drives

• Error messages
• Tools for troubleshooting and maintaining hard
  drive
• Solving common hard drive problems
• General troubleshooting guidelines

52
An Ounce of Prevention

• Make backups and keep them current
• Run antivirus software regularly
• Defragment files scan hard drive occasionally
• Dont smoke around the hard drive
• Dont leave PC turned off for weeks/months at a
  time
• High humidity can be dangerous for hard drives
• Be gentle with a hard drive

53
Commands to Usewith Hard Drives

• Fdisk
• Format
• Defrag and Windows Disk Defragmenter
• ScanDisk to correct cross-linked and lost clusters

54
Lost and Cross-Linked Clusters
55
ScanDisk fromCommand Prompt
56
ScanDisk from the Desktop
57
Resolving CommonHard Drive Problems

• Computer recently moved?
• New hardware recently installed?
• New software recently installed?
• Software recently reconfigured or upgraded?
• History of similar problems?

58
Common Hard Drive Problems

• Computer will not recognize newly installed hard
  drive
• Hardware problems
• Hard drive not found
• Invalid drive or drive specification
• Damaged boot record
• Damaged FAT or root directory or bad sectors
• Cannot boot from hard drive
• Drive retrieves and saves data slowly

59
Getting Technical Support

• Before you call
• Drive model and description
• Manufacturer and model of computer
• Exact wording of error message, if any
• Description of problem
• Hardware and software configuration for the system

60
Chapter Summary

• Hard drive technology
• Communicating with hard drive BIOS
• Logical organization of a hard drive
• Installing and troubleshooting hard drives
• Importance of good backups
