Chemistry

1
Chemistry
Chemical Reactions
2
Biosphere II
Engagement
3
Engagement
Biosphere II habitat biome
4
Engagement
Biosphere II agriculture biome
5
Engagement
Biosphere II rainforest biome
6
Engagement
Biosphere II Desert and Savannah biomes
7
Engagement
Biosphere II coral reef biome
8
Engagement
Biosphere II lungs
9
Engagement
Biosphere II the idea

• Humans can design and build a totally contained
  ecosystem
• SOMEDAY, an ecosystem could sustain life on Mars
  without outside help
• September 1991

10
Engagement
Biosphere II the problem

• Falling OXYGEN levels
• Initial levels ? 21 v
• Falling by 0.5 per month
• Carbon dioxide levels rising
• Fluctuated 2000ppm to 4000ppm
• High but not dangerous
• Stabilized ? 4000ppm

11
Engagement
Biosphere II the problem

• Crew would ADJUST
• January 1993 ?16 months
• OXYGEN Level at 14 ? 4,360 meters (about
  14,300 feet)
• Added oxygen
• Crew recovered and finished the final 8 months

12
Engagement
Biosphere II where is the oxygen?

• Design a poster to give possible explanations for
  the decreasing oxygen levels.
• What solutions might be possible if Biosphere II
  had been located on Mars?

13
Engagement
Biosphere II what happened

• Weather?
• Clouds, slow plant growth
• Manufactured soils?
• Rust
• Nitrogen in the soil ? nitrates
• Water Supply ? Not there
• Microbial metabolization?
• Microbes using oxygen to process excess organic
  matter in soil
• Carbon dioxide should have been 40,000ppm

14
Engagement
Biosphere II what happened

• Calcium silicate ? calcium carbonate
• No Limestone
• No Scale on pipes
• Rubber membranes
• No leakage
• Concrete?
• Lots of concrete in the facility
• Calcium carbonate 10 times more

15
Engagement
Biosphere II what happened

• Concrete
• Sand
• Gravel
• Binding agent- portland cement
• Portland Cement
• Powered mixture of limestone
• Clay
• Sand
• 1350 Co in a rotating kiln
• Calcium silicates and calcium aluminates
• Mixed with water
• Calcium silicate and calcium hydroxide

16
Engagement
Biosphere II what happened

• Calcium silicate hydrates
• Strength
• Calcium hydroxide
• Secret to the missing carbon dioxide
• Diffusion
• Carbon dioxide diffuses into the cement
• Reacts with calcium hydroxide
• Forms calcium carbonate and water
• Ca(OH)2 CO2 ? CaCO3 H2O

17
Engagement
Biosphere II what happened

• Normal Conditions ? slow reaction
• Carbon dioxide ? 10 X higher
• In 2 years ? 2cm penetration
• 500,000 to 1,500,000 moles of carbon dioxide were
  HIDING in the concrete

18
Engagement
Biosphere II what happened

• Structural ? calcification of concrete
• Buried Iron reinforcing bars
• pH 8 ? bars will not corrode
• pH will decrease causing corrosion

CO2 H2O ? H2CO3
19
Engagement
Biosphere II what happened

• Problems and solutions
• What problems could be caused by this unexpected
  situation?
• What would have happened if the structure had
  been located on Mars?
• How would you meet this challenge?

20
Engagement
Biosphere II what happened

• Solutions
• Concrete
• Seal all surfaces
• Soils
• Too much organic matter
• New formulations
• Clouds?
• New lights

CO2 H2O ?  H2CO3
21
Engagement
Biosphere II the future

• Columbia University ? ecology experiments
• Study solutions to original experiment
• Carbon dioxide levels
• Slowed coral growth
• Drought conditions in the rainforest

22
Exploration
Biosphere II Out of Oxygen HO 5.1
In this activity you will determine if various
substances contain calcium carbonate by reacting
each with vinegar.

• Materials
• Safety goggles
• 500 mL vinegar
• 6 small plastic cups

• Samples (small pieces)
• Eggshells
• Potato peels
• Chalk
• Glass
• Limestone
• Granite

23
Exploration
Biosphere II procedure HO 5.1

• Put on your safety goggles.
• Collect samples to be tested and describe them.
• Predict which samples contain calcium carbonate.
• Place each substance to be tested in a labeled
  plastic cup.
• Pour in enough vinegar to cover each sample.
• Carefully observe each sample during the class
  time and make three observations.
• Record your observations.

24
Explanation
Biosphere II

• How did you detect the presence of calcium
  carbonate? Why?
• What samples contain calcium carbonate?
• What type of property is being tested in the
  investigation?
• What is a chemical property? How does it differ
  from a physical property?

25
Elaboration
Alka-Seltzer HO 5.2

• Many people take Alka-Seltzer to soothe an acid
  stomach. The tablet contains sodium hydrogen
  carbonate and citric acid. When Alka-Seltzer is
  added to water, the acid and base react
  chemically to neutralize each other according to
  the following balanced chemical equation

NaHCO3 HC6H7O7 ? CO2 H2O NaC6H7O7 Energy

• Record the active and inactive ingredients of
  the Alka-Seltzer.
• Predict what happens when your tablet is dropped
  into water.
• Describe the change that occurs.

26
Elaboration
Alka-Seltzer HO 5.2

• Materials
• Two 250 mL beakers
• Thermometer
• Two Alka-Seltzer tablets
• Masking tape
• Two stop watches
• 1 Liter bottle
• Balloon
• Balance

27
Alka-Seltzer HO 5.2
Elaboration

• Which tablet will dissolve first? Why?
• Write a hypothesis.
• Design an experiment to test your hypothesis.
• Graph your results.
• Compare your results with the rest of the class.
  How did your procedures differ? How did it
  affect your results?
• As a group discuss the changes that took place.
• Using the data, design an experiment to measure
  the density of the gas. Carefully describe the
  procedure in writing.

28
Elaboration
Alka-Seltzer procedure HO 5.2
Dissolve two Alka-Seltzer tablets in water at two
different temperatures.

• Which tablet will dissolve first? Why?
• Write a hypothesis.
• Design an experiment to test your hypothesis.

29
Elaboration
Alka-Seltzer results HO 5.2

• Compare your results with the rest of the class.
  How did your procedures differ? How did it
  affect your results?
• As a group discuss the changes that took place.
• Using the data, design an experiment to measure
  density of the gas.
• Carefully describe the procedure.

30
Ion Cards HO 5.3
Exploration

• Matter can be neither created nor destroyed.
• Use your ion cards to find the products and
  balance the equations on Handout 5.3.

31
Chemical Reactions HO 5.4
Evaluation

• What happened to the oxygen in Biosphere II?
• What is a physical property?
• Give an example.
• What is a chemical property?
• Give an example.
