Title: Win32 Programming


1
Win32 Programming
  • Lesson 8 Processes

2
Where are we?
  • Were starting to have some foundational
    understanding of Windows
  • But really, we dont know how to get any work
    done (doesnt that sound like your Sophomore
    year?)

3
Executing Code
  • The Operating System organizes executing code
    into a logical hierarchy
  • Processes
  • Threads
  • Fibers

4
Definition
  • A Process is defined as
  • An instance of a running program, which consists
    of two components
  • A kernel object used by the operating system to
    manage the process
  • An address space which contains all the DLLs,
    executable code and data used by the process
  • Processes are inert to accomplish anything, a
    process must have at least one thread that runs
    in its context

5
Threads
  • Each thread executes simultaneously (in some
    sense of the word why, why not?)
  • Each thread has its own stack frame, and set of
    CPU registers

6
Scheduling
  • The OS schedules some time for each thread
  • Each thread gets a time slice or quantum from the
    CPU which provides the illusion of concurrency
  • We can think of it as a round robin scheduler
    but it is significantly much more complicated
  • When a process is created, it is generally
    created with one thread, called the primary
    thread this thread can create other threads

7
Windows Applications
  • Two flavors
  • GUI (all that Windowsy stuff)
  • CUI (command line the One True Way)
  • Of course, life isnt so simple its not a
    binary decision
  • Every program needs an entry point WinMain,
    wWinMain etc.
  • The Operating System doesnt call this it calls
    a special startup function

8
Startup Code
  • The Runtime Libraries do a number of things
  • Retrieve a pointer to the command line parameters
    of the process
  • Retrieve a pointer to the new environment
    variables of the process
  • Initialize the RTLs global variables
  • Initialize the heap for the RTL
  • Call constructors for global and static objects

9
A Process Instance Handle
  • Every DLL or executable gets its own Instance
    Handle, which is unique
  • Used when we load resources (like icons)
  • Can get the handle of a DLL with something like
  • HMODULE GetModuleHandle(PCTSTR pszModule)

10
The Command Line
  • Can use the global variables __argv
  • Can call down to PTSTR GetCommandLine()
  • Can go from here to an argv-like structure using
  • PWSTR CommandLineToArgvW(     PWSTR pszCmdLine,
        int pNumArgs)

11
Free alloced memory
  • int nNumArgs PWSTR ppArgv  CommandLineToArgvW(
    GetCommandLineW(),  nNumArgs)
    // Use the arguments if (ppArgv1  L'x')

  • // Free the memory block HeapFree(GetProcessHeap(
    ), 0, ppArgv)

12
Environment Variables
  • Associated on a per-process basis
  • Stored in the environment block
  • Stored in the form
  • VarName1Value1\0VarName2Value2\0VarNameXVal
    ueX\0\0

13
Associated Functions
  • GetEnvironmentVariable( PCTSTR pszName, PTSTR
    pszValue, DWORD dwSize)
  • Often in the form USERPROFILE\My Documents
  • Windows supplies a helper function for this case

14
ExpandEnvironmentString
  • ExpandEnvironmentStrings( PCTSTR pszSrc, PTSTR
    pszDst, DWORD nSize)
  • Where nSize is the maximum space available for
    expansion

15
ErrorModes
  • A process can choose to trap certain errors
    itself instead of having the Operating System
    trap those errors
  • UINT SetErrorMode(UINT fuErrorMode)

16
CurrentDirectory and Directory
  • Example CreateFile
  • DWORD GetCurrentDirectory ( DWORD
    cchCurDir, PTSTR pszCurDir)
  • BOOL SetCurrentDirectory(PCTSTR pszCurDir)
  • Current Directories are also stored in the
    environment variables

17
Finally
  • GetVersion and GetVersionEx
  • Read the history, its somewhat amusing

18
Creating a Process
  • Simple use CreateProcess
  • BOOL CreateProcess( PCTSTR pszApplicationName,
    PTSTR pszCommandLine, PSECURITY_ATTRIBUTES
    psaProcess, PSECURITY_ATTRIBUTES
    psaThread, BOOL bInheritHandles, DWORD
    fdwCreate, PVOID pvEnvironment, PCTSTR
    pszCurDir, PSTARTUPINFO psaStartInfo, PPROCESS
    _INFORMATION ppiProcInfo)
  • I could write out the usage, but lets just look
    it up

19
Terminating a Process
  • Four ways
  • The primary threads entry-point function returns
    (YES)
  • One thread in the process calls ExitProcess (NO)
  • A thread in another process calls
    TerminateProcess (NO)
  • All the threads just happen to die on their own
    (Never happens)

20
Entry point returns
  • When the primary thread dies
  • Any C objects are destroyed using destructors
  • Memory from the stack is correctly freed
  • The process exit code is set
  • The process kernel object is decremented

21
ExitProcess
  • Fine from an OS perspective
  • Horrible from the RTL perspective as Destructors
    arent called you can prove this to yourself if
    you want to

22
ChildProcesses
PROCESS_INFORMATION pi DWORD dwExitCode
// Spawn the child process. BOOL fSuccess  Creat
eProcess(..., pi) if (fSuccess)
   // Close the thread handle as  //
soon as it is no longer needed!
    CloseHandle(pi.hThread)    // Suspend our e
xecution until  // the child has terminated.
    WaitForSingleObject(pi.hProcess, INFINITE)
    // The child process terminated  //get its
exit code.     GetExitCodeProcess(pi.hProcess, d
wExitCode)     // Close the process handle as so
on as it // is no longer needed.
    CloseHandle(pi.hProcess)
23
Detaching a Process
  • In the previous example, the processes are linked
    the child process wont be destroyed until the
    Parent reads the exit code
  • However, you can detach a process by closing the
    associated handles in the parent process

24
Enumerating Processes
  • Assignment time!
  • Easily create a simple application which
    enumerates all the processes on a machine. You
    may use a command-line application if you wish,
    or a GUI. Print out as much information about
    each process as you can.
  • This looks really nice in .NET but thats a
    little more tricky.
  • Your call CLI is okay.
  • Use the Submit server!
