WP2: Data Management

1
WP2 Data Management

• Gavin McCance
• University of Glasgow
• November 5, 2001

2
Overview

• Deliverables
• Replication GDMP
• Meta-data Spitfire
• GridPP effort
• Future work
• Query Optimisation

3
Deliverables

• EU DataGrid WP2 Major M9 deliverables met
• GDMP delivered
• Spitfire delivered
• Architecture Document
• http//www.cern.ch/grid-data-management

4
GDMP
http//cmsdoc.cern.ch/cms/grid/

• Generic mirroring tool for any file type (read
  only replica)
• Particular plug-ins for Objectivity database
  files
• Subscription model for automatic synchronisation
  of files
• Automatic update of replica catalogue
• Currently uses Globus Replica Catalogue

5
GDMP

• BrokerInfo API from WP1
• Allows users of GDMP to obtain information from
  the job scheduler
• Mass Storage Interface from WP5
• e.g. Support for file staging
• Security is provided via standard GSI (single
  sign-on)
• Authorisation via grid mapfile
• File transfer made using GridFTP
• Installation RPM and tarball

6
GDMP usage
Site A
Site B

• A,B) Start GDMP services (inetd)
• B) Registers itself with site A
• gdmp_host_subscribe
• A) New files ?Register them
• gdmp_register_local_file ltpath-to-filegt
• This updates the local (on A) catalogue
• A) Tell the world (well..all subscribed sites)
• gdmp_publish_catalogue
• Will update the import catalogue on all
  subscribed sites

7
GDMP usage
Site A
Site B

• B) Get the new files from site A
• gdmp_replicate_get
• The new files will be transferred from site A ?
  site B
• Globus replica catalogue updated
• Filters so you only get files you want
• CRC checking of file transfer

8
Spitfire
http//hep-proj-spitfire.web.cern.ch/hep-proj-spit
fire/

• Provides grid enabled access to any relational
  database
• SQL Database Service
• Storage of general meta-data
• Service Index soon
• Secure access via GSI (single sign-on)
• Installation RPM and tarball

9
Spitfire
JAVA Servlet based

• Allows any HTTP compliant system e.g.
  Web-browsers / standard C HTTP libraries to
  access any relational database across the grid

Oracle PostgreSQL
Grid Security
Standard communication protocols (XML over HTTPS)
SQL Database Service (Spitfire)
10
Spitfire security

• Authentication is currently provided
• Standard user server grid certificates
• For both application programs and web browsers
• Authorisation matrix coming soon
• Will map grid identity to role(s)
• Reader, info-update, manager
• Roles will then map to a given database
  connection with given permissions on a database
• Eg. query-only, insert, update, create new tables

11
Spitfire

• Easy to install
• Good documentation
• Ready to run examples
• For grid-based meta-data catalogue needs..
• we need feedback!

12
WP2 GridPP Effort

• Based at Glasgow
• Effort will focus on primarily the query
  optimisation task of WP2
• 1 PhD student, 1.5 RA
• Continuing effort in development of Spitfire and
  related applications
• 0.7 RA

13
Future Spitfire work

• Look at common ground between WP2 and WP3
• Spitfire and R-GMA?
• Security
• Authorisation mechanisms
• Other spitfire applications
• Service Index, Replica Catalogue
• Work on scaleable architectures
• Common with e.g. replica catalogue work

14
Query Optimisation work

• Categorise possible areas for optimisation
• User oriented high performance
• Minimising cost for specific job
• Grid oriented high throughput
• Maximise efficient usage of resources
• Site oriented local policy
• Respond to specific site policies / requirements
• Much preliminary work done!
• Workshop in December 2001

15
Query Optimisation

• Short term
• Data Access optimisation
• Replica Optimiser component
• How long will it take to get the data here?
• Developing and evaluating appropriate algorithms
  for working this out and choosing best replica

16
Query Optimisation

• Modelling and Simulation
• Best not to test out the more crazy algorithms on
  the experiment testbed
• Work underway with MONARC tool
• Evaluating suitability as simulation tool for
  this particular work
• Integrate into the QO work

17
Summary

• Major deliverables for M9 met
• GDMP and Spitfire
• GridPP will concentrate effort on Query
  Optimisation task of WP2
• continued Spitfire development
• Work already underway
