Web Analytics

1
Web Analytics User Behavior
An update on Ajaxalytics and CBMGSKelly
StormMarch 17th, 2008
2
Web Analytics

• The study of the behavior of website users.
• Use of the data collected from a website to
  determine which aspects of the website are
  'working' or 'effective'.
• Data is currently derived from web server logfiles

3
Web Server Logfile Analysis

• Web servers record all transactions in a logfile
• ex. a single line from Toxodb's
  logfile58.61.39.237 - - 19/Dec/2007232601
  -0500 "GET /restricted/data/Genome/nuc/TgME49B7_G
  ENOMIC_2003.04.17_TIGR.fasta.gz HTTP/1.1" 404 347
  "http//www.toxodb.org/restricted/data/Genome/nuc/
  " "Mozilla/4.0 (compatible MSIE 6.0 Windows NT
  5.1)"
• These logfiles can be read by a program to
  provide data on the popularity / usefulness of
  the website.

4
Web Server Logfile Analysis

• Initially, statistics consisted primarily of
  counting the number of client requests (or hits)
  made to the web server.
• Now we wish to more accurately gauge the amount
  of human activity on web servers by analyzing
  page views, visits (sessions), and user-agents

5
Web Server Logfile Analysis

• Page views are different from a hits. A page view
  is when a user accesses a particular web page, a
  hit encompasses both page views, image loads,
  JavaScript includes, etc.
• Visits, or sessions, are sequences of requests
  from a uniquely identified client (host IP
  address) that expired after a certain amount of
  inactivity, usually 30 minutes.
• User-agents indicate what operating system /
  browser type and version the host is currently
  using.

6
Web Server Logfile Analysis

• By analyzing page views and user-agents we're
  able to provide detailed reports showing
• Monthly, weekly, daily history
• Hourly Average
• Usage by location (country, state, city)?
• Page load activity
• Percentage of operating system and browser
• References
• Google Keywords

7
Web Server Logfile Analysis

• By analyzing sessions, instead of counting hits,
  we can better understand user behavior
• By creating model graphs of user sessions
• By creating customer behavior model graphs
  (CBMG)?
• By grouping users together based upon their
  individual usage and separating them with a
  clustering algorithm

8
Customer Behavior Model Graphs
9
Customer Behavior Model Graphs
10
Customer Behavior Model Graphs

• For instance, this shows that half the users came
  into the website and browsed, and half came into
  the website and searched

11
Customer Behavior Model Graphs

• When you have a website with thousands of pages
  the CBMGs quickly become unreadable and thus
  unhelpful, so we'd like to be able to group
  users according to
• user-agent information
• time
• how often they view the site / at what frequency
• how deep they're diving into the site
• As well as group pages according to keywords to
  limit the size of the CBMG and give us a clearer
  view of user behavior.

12
Clustering

• By analyzing each user's sessions and deriving a
  distance for each particular user, we can
  cluster groups of users together based upon their
  performance.
• Doing so will allow us to separate the normal web
  users from the power users.
• Observing the power users will give us more
  pertinent information as to the effectiveness of
  the site.

13
For the Comp Sci Kid in all of Us

• By distance, I mean Euclidean distance
• Each user will have a particular matrix showing
  the transition frequency from one page to the
  next, the distance will come from examining
  each individual value with respect to it's
  domain.
• Once the number's are crunched, each matrix will
  be associated with it's own unique value.
• This process is repeated for all users, and each
  user's matrix is grouped accordingly
• Rinse, lather, and repeat until alpha
  (inter/intra) is large enough.

14
Since last we met

• Create a definitions page for Ajaxalytics to help
  clarify some of the verbiage for future users
• Create schema for parsing the log files to pick
  up where it last left off using timestamps
• Shift log parser to C for faster parsing
• Drill-down pages to give precise information (149
  returning visits for a particular day become a
  list of all the Ips, their frequency, the pages
  viewed). Drill-down information will be available
  for each month, day, and hour.
• Rules for CBMGs based upon Apidb specific
  information.

15
Papers in the pipeline

• ARPC in Apidb (Working with Cary)?
• Asynchronous Remote Procedure Calls in Apidb
• CBMGs in Apidb (Case study of use through
  Toxodb)?
• Ajaxalytics write-up for the biological community
  ( to preface the release of the software once
  it's ready to go )?
