Memory Hierarchies Chapter 7

1
Memory HierarchiesChapter 7

• N. Guydosh
• 4/18/04

2
The Basics

• Fake out the program (application) into thinking
  it has a massive high speed memory - limited only
  by the address space.
• The appearance of a massive high speed memory
  system is an illusion - but the performance
  enhancement is real.
• Will consider three levels of memory media
• Cache
• Main Memory
• Disk
• Principle of locality (pp. 540-541)Programs
  access only a very small part of the address
  space at any instant of time
• Temporal locality If an item is referenced, it
  will probably be referenced again soon.
• Spatial localityIf an item is referenced, items
  whose addresses are close by will tend to be
  referenced soon

3
Memory Hierarchy

• Organize memory into levels according to cost
  speed factors
• The higher the level the faster, smaller, and
  more expensive (per bit) the memory is
• The lower the level the slower, larger, and
  cheaper (per bit) the memory becomes
• The highest level is directly accessed by the
  microprocessor. ... The cache
• The levels to be considered areSRAM ... Super
  fast memory - expensive DRAM ... Ordinary ram
  memory - minimum speed - cheapDISK (DASD) ...
  Very slow, very cheap

4
Memory Hierarchy Levels
Cache
Main memory
Disk
Fig. 7.1
5
Data Transfer Between Levels

• Block
• The minimum unit of data that can be present or
  not present in a two level memory (cache system).
  It can be as small as a word or may be multiple
  words.
• This is the basic unit of data transfer between
  the cache and main memory
• At lower levels of memory, blocks are also known
  as pages

6
Data Transfer Between Levels
?blocks
Fig. 7.2
7
The Basic Idea

• The data needed by the processor is loaded into
  the cache on demand
• The data needed by the processor is loaded into
  the cache on demand
• If the data is present in the cache, the
  processor used it directly. This is called a hit

• Hit rate or ratio
• The fraction (or percent) of the time the data is
  found at the high level of memory without
  incurring a miss.
• Miss rate or ratio
• 1 - hit rate (or 100 - hit rate in percent)

8
The Basic Idea (cont.)

• Hit TimeThe time it takes to access an upper
  level of memory of a memory hierarch (cache for
  two level)
• Miss penaltyThe time it takes to replace a block
  in an upper level of a hierarchy with a
  corresponding block from a lower level
• A miss in a cache is serviced by hardware
• A miss at a level below the cache (ex main
  memory) is serviced in software by the operating
  system (must do I/O at disk level).

9
Why the Idea Works

• Fundamental phenomenon or properties which make
  this scheme work
• Hit ratios must be and are generally very high
• High hit ratios are a result of the locality
  principle described above
• Success is statistical and could never be
  deterministically guaranteed. A good (or bad?)
  Programmer could always write a program which
  would kill a memory hierarchy ... cause thrashing

• Memory hierarchies must be tuned via level sized,
  block (page) sized to get optimal performances

10
The Basics of Caches

• Simplest type single word block
• On start up the cache is empty, and as references
  are made, it fills up via block misses and
  transfers from ram
• Once it fills locality principle takes over a
  there are very few misses.
• Question
• Where are the blocks put in the cache and how are
  they found and related to main memory blocks?
• There must be a mapping scheme between cache and
  main memory

11
The Basics of Caches

• Direct mapping assuming addresses are block
  numbers
• A word from memory can map into one and only one
  place in the cache.
• The cache location is directly derived from the
  main memory address.
• Direct mapping ruleCache address of a block
  (block number) is the main memory block number
  address modulo the cache size in units of
  blocks
• For example if the main memory block number is
  21decimal and the cache size was 8 blocks, then
  cache address is 21 mod 8 5 decimal.
• If we keep the size of the cache (in blocks) a
  power of 2, then the cache address is directly
  given by the log2 (cache size in blocks) low
  order bits. Ex 21(base 10) 010101(base 2).
  Log28 3. Three low order bits are 101 5
  decimal.
• Note that Memory ? cache mapping is many to one
  (see P. 546, fig 7.5)
• Preview If this is direct mapping, then there
  must be a non-direct mapping set associative
  more that one place to put a block See later.
  a block number is a byte address which has the
  low order bits designating the word within a
  block, and the byte within a word stripped off.
  If an block were a byte, then these addresses
  would be complete.

12
Memory Cache MappingSpecial Case One Word Per
BlockPiano Keys
Every block ( word) in memory maps into a
unique location in cache. Two low order bits
for byte within a word stripped off.
Fig. 7.5
13
Memory Cache Mapping (cont.)

• Questions
• Because each cache location can contain the
  contents of a number of different memory
  locations, how do we know whether the data in the
  cache corresponds to a requested word ie., the
  block containing this word?
• How do we know if a requested word is in the
  cache or not?
• The answer is in the contents of a cache entry
  blowing in the wind
• 32 bit data field - the desired raw data
• Tag field high order address after modulo low
  order cache bits stripped out this identifies
  the entry with a unique memory block.
• A one bit valid field (validity bit).The valid
  bit is turned on if a block has been moved into
  the cache on demand If the valid bit is, on the
  tag and data field are valid

14
How a Block is Found

• The low order address bits of the block number
  (log cache size in blocks) from the main memory
  address is the index into the cache.
• If the valid bit is on, the tag is compared with
  the corresponding field in the main memory
  address.
• If it compares we have a hit
• If it does not compare, or if the valid bit is
  off, we have a miss and the hardware copies the
  desired block from main memory to this location
  in cache
• Whatever was at this cache location gets overlaid.

15
How a Block is Found
One word (4 bytes) per block
Byte offset within a word bits 0,1
block (frame) number within cache 2, , 11
tag 12, 13, , 31 block number in ? logical
space compare with Page Table
4 bytes
Cache by definition is size 210 Contrast to main
memory in VM Scheme where mem size is arbitrary
Fig. 7.7 Similar to DEC example Fig 7.8
Data is 32 bits Entry has 32201 53
bits Emphasis is more on temporal rather than
spatial locality
16
Handling a Cache Miss

• Instruction miss p. 551
• Access main memory at address PC-4 for the
  desired instruction block. (Read).
• Write the memory data in the proper cache
  location (low order bits) and the upper bits in
  the tag field, then turn on the valid bit
• Restart the instruction execution from the
  beginning, it will now re-fetch and find it in
  the cache.
• A cache stall occurs by stalling the entire
  machine (rather than only certain instructions as
  in a pipeline stall.)

17
Handling a Page Fault

• Read data miss
• Similar to instruction miss - simply stall
  processor until cache is updated - simply retain
  ALU address output for processing the miss (where
  to move mem data in cache).
• Write miss (see pp. 553-554)
• If we simply write to data cache without updating
  main memory, then cache and memory would be
  inconsistent
• Simple solution is to use write-through index
  to cache with low order bits
• Write the data and tag portion into the block
  set valid, then write data word to main memory
  with entire address.Contrast this later to the
  case of more that one word per block.
• This method impacts performance - an alternate
  approach is gt

18
Handling a Page Fault (cont.)

• Write buffer technique (p. 554)
• Write data into cache and buffer at the same time
  (buffer is fast) ... processor continue execution
  sort of a lazy evaluation .
• While the processor proceeds, the buffer data is
  copied to memory
• When write to main memory completes, the write
  buffer entry is freed up
• If the write buffer is full when a write is
  encountered, the processor must stall until a
  buffer position frees up.
• Problem even though the writes are generated at
  a rate less than the rate of absorption by main
  memory (average), bursts of writes can stall
  the processor ... only remedy is to increase
  buffer size.
• Buffer is generally small (lt 10 words
• A preview of other problems associated with
  caches
• In a multiprocessing scheme where each processor
  may have its own cache and there is a common main
  memory
• Now we have a cache coherency problem
• Not only must we keep the caches in steep with
  main memory, but we must keep them in step with
  each other more later.

19
Taking advantage of Spatial locality

• Up to now there was essentially no spatial
  locality
• Block size was too small the unit of memory
  transfer to the bus is a word
• The block size was one word
• A block consist of multiple contiguous words
  from main memory
• Need a cache block of size greater than one word
  for spatial locality
• Load the desired word and its local companions
  into cache
• A miss always brings in an entire block
• Assume the number of words per block is a power
  of 2

20
Taking advantage of Spatial locality

• Mapping an address to a multiword cache block
• Exampleblock size 16 bytes gt low 4 bits is
  byte offset into a block gt low 2 bits is
  byte offset into a word gt bits 2 and 3
  are word offset into block cache size 64
  blocks thus low 6 bits is the block number in
  cache.What does byte address of 1202 (decimal)
  0x4B2 map to?
• Block given by (block address) mod (number of
  cache blocks)where block address (actually block
  number in logical space) (byte
  address) / ( bytes per block) floor(1202/16)
  75d 0x4B drop low 4 bit offset in
  blockcache block number 75 mod 64 0x4B mod
  64 11decimal 001011b
  low 6 bits of block number
• Summary1202d 0x00004B2 0000 0000 0000 0000
  0000 0100 1011 0010
  block number? cache location? blk
  offsetRemember block_address block_number
  block_offset book is a bit sloppy. Also
  001011 (in red) field is cache locationAlso
  bits in index log2(sets in cache)
  log2((size of cache)/(size of set))
  log2(64blocks/1 block/set) log264 6. see
  later

21
64K Cache Using a 16 Byte Block
16 byte blocks directly mapping or 4 word blocks
directly mapped preview 1 way associative
64 KB 16K words 4K blocks 12 bit index in
cache
Tag associated with block not the word?
12 low bits
Pick off word in a block
Still direct mapping! See set associative later
Fig. 7.10
Fig. 7.10
22
Taking advantage of Spatial locality Miss
Handling

• Read miss handling
• Processed the same way as a single word block
  read miss
• A read miss always brings back the entire block

23
Taking advantage of Spatial locality Miss
Handling (cont.)

• Write miss handling
• Cant simply write the data and corresponding tag
  because block contains more than a single word.
• When we had one word per block, we simply wrote
  the data and tag into the block set valid, then
  write data word to main memory.
• Must now first bring in the correct block from
  memory if the tagmismatches, and then update the
  block using write-through or buffering. If we
  simple wrote the tag and word, we could possible
  be updating the wrong block (intermixing two
  blocks) multiple blocks could map to the same
  cache location.See bottom page 557.

24
Tuning Performance With Block Size

• Very small blocks may lose spatial locality (ex.
  1 word/block)
• Very large blocks may reduce performance if the
  cache is relatively small - competition for space
• Spatial locality occurs over a limited address
  range - large blocks may bring in data which will
  never get referenced dead wood.
• Miss rate may increase for very large blocks

25
Tuning Performance With Block Size (cont.)
Fig. 7.12
Cache? size
Cover cache performance later
26
Performance Considerations

• Assume that a cache hit gives normal
  performance, that is, this is our base line for
  no performance degradation peak performance.
• We get performance degradation when a cache miss
  occurs.
• Recall that a cache stall occurs by stalling
  the entire machine (rather than only certain
  instructions as in a pipeline stall.)
• Memory stall cycles are dead cycles elapsing
  during a cache stall. This consists of
• Memory-stall clock cycles read-stall cycles
  write-stall cycles.For example on a per program
  basis.Where
• Read-stall cycles (reads/program) x (read miss
  rate) x (read miss penalty)where read miss
  penalty is in cycles, and may be given by some
  formula involving say block size.
• Write-stall cycles (writes/program) x (write
  miss rate) x (write miss penalty) write
  buffer stallswhere write buffer stalls accounts
  for the case where a buffer is used to update
  main memory when a cache write occurs. If write
  buffer stalls are a significant part of the
  equation, it probably means this is a bad design!
  We shall assume a good design where the buffer
  is deep enough for this to be an insignificant
  term

27
Performance Considerations (cont.)

• Assuming that the read and write miss penalty are
  the same, and that we can neglect write buffer
  stalls, we can write a more general formula.
• Memory-stall clock cycles (memory
  accesses)/program x (miss rate) x (cache miss
  penalty)
• For example in homework problem 7.27, the cache
  miss penalty we given by the formula 6 (block
  size in words) number of cycles.
• An example (page 565) gt

28
Performance Considerations (cont.)

• Assuming an instruction cache miss rate for gcc
  of 2 and a data cache miss rate of 4. If a
  machine has a CPI of 2 without any memory stalls
  (ie., ideal case of no cache misses), and the
  miss penalty is 40 cycles for all misses,
  determine how much faster a machine would run
  with a perfect cache that never misses. Use
  instruction frequencies from page 311 of text.
• For instruction count Iinstruction miss cycles
  I x 2x 40 0.80I
• Data miss cycles I x 36 x 4 x 40
  0.56Iwhere the frequency of instructions doing
  memory references is 35 from page 311
• Total memory stall cycles 0.80I 0.56I
  1.36I gt 1 cycle of memory stall per instruction.
• The CPI with stalls 2 1.36 3.36
• Thus (CPU time with stalls)/(CPU time for
  perfect cache) IxCPIstall x (clock cycle
  time)/I x CPIperfect x (clock cycle time)
  CPIstall / CPIperfect 3.36/2 1.68 ideal
  case is 68 better.

29
Performance Considerations (cont.)

• Effects of cache/memory interface options on
  performance
• Cache interacts with memory for cache misses
• Goalminimize block transfer time (maximize
  bandwidth)minimize cost
• Must deal with tradeoffs
• Cache and memory communicate over a bus
  generally not the main bus
• Assume memory is implemented in DRAM and cache in
  SRAM
• Miss penalty (MP) is the time (in clock cycles)
  it takes to transfer between memory and cache
• Bandwidth is the bytes/second to transfer a block
• ExampleAssume 1 clock cycle to send address to
  memory (just need initial address)
  15 clock cycles for each DRAM access
  initiated effective access time 1 clock
  cycle to send a word to cache
• Bandwidth (words/block)/(miss penalty)
• See fig. 7.13 for three cases gt

30
Bandwidth Example
?------------4 words --------?
MP 11x15 4x1 20 cycles BW (4x4)/20
0.8 read 4 words in parallel and Deliver to
cache one word at a time
1 word ?---?
MP 11x15 1x1 17 cycles BW (4x4)/17
0.94 read 4 words in parallel and Deliver to
cache 4 words at a time
Miss penalty (MP) 14x15 4x1 65
cycles Bandwidth BW (4x4)/65 0.25 read 1
word from memory and deliver to cache one word at
a time
Fig. 7.13
31
Now Comes Amdahls Law!

• Summary CPIstall / CPIperfect 3.36/2 1.68
  ideal case is 68 better
• Lets speed up the processor
• The amount of time spent on memory stalls will
  take up an increasing fraction of the execution
  time.
• Example speed up the CPU by reducing CPI from 2
  to 1 without changing he clock rate.
• The CPI with cache misses is now 1 1.36
  2.26perfect cache is now 2.36/1 times faster
  instead of 3.36 faster
• Amount of execution time spent on memory stalls
  would have risen
• from 1.36/3.36 41 (slow CPU)
• to 1.36/2.36 58 (fast CPU)
• !
• Similar situation for increasing clock rate
  without changing the memory system.

32
The Bottom Line

• Relative cache penalties increase as the machine
  becomes faster thus if a machine improves both
  clock rate and CPI, it suffers a double hit.
• The lower the CPI, the more pronounced the impact
  of stall cycles.
• If main memory of two machines have the same
  absolute accesses times, the higher CPU clock
  rate leads to a larger miss penalty.
• Bottom line put the improvement where it is
  needed improve memory system not CPU.

33
More Flexible Placement of BlocksSet
Associative

• Up to now we used direct mapping for block
  placement in the cache
• Only one place to put a block in cache.
• Finding a block is easy and fast
• Simple directly address it with low order block
  number bits.
• The other extreme is fully associative
• A block could be placed anywhere in the cache.
• Finding a block is now more complicated must
  search the cache looking for a match on the
  tag.
• In order to keep the performance high, we do the
  search in hardware (see later) at a cost tradeoff
• Let us look at schemes between these two
  extremes.

34
Set Associative Block Placement

• There is now a fixed number of locations (at
  least two) where a block can be placed
• For n locations it is called an n-way associative
  cache
• An n-way associative cache consists of a number
  of sets, ech having n blocks
• Each block in memory maps to a unique set in the
  cache using the index field (low mod bits).
• Recall that in a direct mapped cache, the
  position of a memory block was given by (block
  number) mod (number of cache blocks) low order
  block bits
• Note that the number of cache blocks in this case
  is same as the number of sets one block per
  set.
• In general use set-associative cache the set
  number containing the desired memory block is
  given by(block number) mod (number of sets in
  the cache) .Again this is low order block
  bits
• See diagram gt

35
Set Associative Block Placement (cont.)
Direct mapped Set associative
Fully associative 8 sets 8 blocks
4 sets 8 blocks 1 set 8 blocks
Set 0 (one set)
Block set
12 mod 8 4
Set 12 mod 4 0
Fig. 7.15
One tag per set
Example above uses cache block number of 12 dec
0xC 1100 bin Note 0xC results when block
offset bits stripped off.
36
Set Associative Block Placement (cont.)
Definition the (logical) size or capacity of
a cache usually means the amount of real or
userdata it can hold. The physical size is
larger to account for tags and status bits (such
as valid bits) also stored there.
Set
DefinitionsAssociatively blocks/set A block
is one or more words The Tag is associated with
a block within a set.
Fig. 7.16
37
Set Associative Mapping

• For direct mapped, the location of a memory block
  (one or more words) given by index (Block
  number) mod (number of cache blocks)
• For a general set associative cache, the set
  containing a memory block is given byindex
  (Block number) mod (number of sets in the cache)
• This is consistent with the direct mapped
  definition, since for direct mapped, there was
  one block per set.
• Each block in memory maps to a unique set in the
  cache given by the index field.
• The placement of a block within a set is not
  unique it depends on a replacement algorithm
  (example LRU).
• Must logically search a set to find a particular
  block identified by its tag.
• The tag is the high order remaining bits after
  the index and offset into the block is stripped
  off.
• In the case of fully associative (only one set),
  there is no index because there is only one place
  to index into ie., the entire cache.
• The number of bits in the index field is
  determined by the size of the cache (in units of
  sets). The size of a set is the block size x the
  associatively of the set.

38
Set Associative Mapping (cont.)
lt-------block number-------------gt
index (block number) mod (number of sets in
the cache) block size 2(number of bits in block
offset) bytes number of bits in index
Log2(number of sets in cache) number of bits in
index is directly a function of the size of the
cache and the associativity of the sets.
number of bits in index Log2 (size of
cache)/(size of set) Log2 (size of
cache)/(associativity of set)(size of block)
consistent units must be used in
calculations (bytes, words, etc.) Size of
cache mean the amount of real data it holds.
It does not account for validity and tags
stored. Assumes associativity of set is defined
as number of blocks in a set.
39
Set Associative Block Placement (cont.)Example 4
way associative
Block tag index
Block size 1 word 4 bytes
?block offset(2 bits)
tag
index
bits in index log2(sets in cache)
log2(cache size)/set size) log21024/4
log2(256)8
Cache size sets x size of set
256 x 4 words 1024 words 4Kbytes
Fig. 7.19
40
Set Associative Mapping an Example pp. 571-572
Cache size 4 words 4 blocks Sequence of block
numbers 0, 8, 0, 6, 8 CASE 1 direct mapping
one block per setthus sets in cache 4
index bits log2(sets in cache) log2(cache
size)/(set size) log24/1 2
bits in the index The tag must have 32 2 bits
in index 2 bits in block offset 28 bits
lt-------block number----------------------------gt
blk offset
31
4 3 2 1
0 Tag bits 4 31Index bits 2,3 Block offset
bits 0,1block 0 gt set index (0 mod 4)
0 block 6 gt set index (6 mod 4) 2 block
8 gt set index (8 mod 4) 0 Total of 5
misses see text.
41
Set Associative Mapping an Example pp. 571-572
Cache size 4 words 4 blocks Sequence of block
numbers 0, 8, 0, 6, 8 CASE 2 2 way
associative mapping two blocks per setthus
sets in cache 4 blocks/(2 blocks/set) two
sets in the cache bits in index log2(sets in
cache) log22 1 bit in the index The tag must
have 32 1 bits in index 2 bits in block
offset 29 bits
lt-------block number----------------------------gt
blk offset
31
3 2 1 0 Tag
bits 3 31 Index bit 2 Block offset bits
0,1block 0 gt set index (0 mod 2)
0 block 6 gt set index (6 mod 2) 0 block
8 gt set index (8 mod 2) 0 Total of 4
misses see text. use LRU for replacement
42
Set Associative Mapping an Example pp. 571-572
Cache size 4 words 4 blocks Sequence of block
numbers 0, 8, 0, 6, 8 CASE 3 fully associative
mapping 1 set, 4 blocks per setthus sets in
cache 4 blocks/(4 blocks/set) one set in the
cache bits in index log2(sets in cache)
log21 0 bits in the index The tag must have 32
0 bits in index 2 bits in block offset 30
bits
lt-------block number---------------------------gt
blk offset
31
2 1
0 Tag bits 2 31 Index none Block offset bits
0,1block 0 gt set index (0 mod 1)
0 block 6 gt set index (6 mod 1) 0 block
8 gt set index (8 mod 1) 0 Total of 3
misses see text. use LRU for replacement
43
Virtual Memory

• An extension of the concepts used for cache
  design (or maybe vise-versa?)
• Key differences
• The cache is now main memory
• The backing store is now a hard drive
• The size of logical space is now orders of
  magnitude larger and in a cache scheme
• The hardware search on the tag used in locating
  a block in a cache, is no longer feasible in a VM
  scheme
• A fully associative scheme is used in order to
  get the highest hit ratio
• No restrictions on where the block (page) goes
• Dragging along a tag is prohibitive in space
  usage
• Searching for a tag is also not practical too
  many of them
• Thus software is used and addresses are mapped
  using a page table
• Sometimes the PT is cached using a TLB which
  works like a cache

44
Virtual Memory Mapping
Virtual page
Fig. 7.23
45
Virtual Memory Mapping
Virtual address
Fig. 7.21
46
Virtual Memory Mapping
Fig. 7.22
47
Page Faults

• Page Faults
• If the page referenced by the virtual address is
  not in memory we have a page fault.
• A page fault is determined by checking the valid
  bit in the page table entry indexed by the
  virtual page number.
• If valid bit is off we have a page fault
• Response to a page fault
• An exception is raised, and the OS takes over to
  fetch the desired page from memory.
• Must keep track of disk address to do this
• Disk addresses typically kept in page table but
  there are other schemes also (p. 586)
• If memory has an unused page frame, then load the
  new page there.
• If memory is full choose an existing valid
  memory page to be replaced if this page is
  modified, disk must be updated.

48
Page Faults (cont.)

• How to we locate the page to be brought in from
  the disk?
• Need a data structure similar to the page table
  to keep track of map virtual page number to disk.
• One way is to keep disk addresses in the page
  table along with real page numbers other
  schemes may be used also.
• Used for reading from as well as writing to disk.
• Where do you put the page from disk if memory is
  full?
• Replace some existing page in memory which is
  least likely to be needed in the future.
• Least Recently Used (LRU) algorithm commonly
  used.
• LRU in its exact form is costly to implement.
• LRU status updates must be made on each
  reference.
• At least from a logical point of view, must
  manage an LRU stack
• A number of LRU approximations possible which are
  more realistic to implement example use a
  reference bit(s) and only replacing pages whose
  reference bits are off.

49
Writes to the Memory System

• What about writes to cache?
• Must keep main memory in step with cache
• Use write through or write buffer to memory for
  cache writes
• Write buffer hides the latency of writing to
  memory.
• Main memory updated at the time of write.
• What about writes to memory?
• Must keep disk backing store in step with memory
• Disk access is too slow to use write through.
• Use lazy evaluation and do updates only on a
  replacement.
• Write back only when page is to be replaced or
  when process owning the page table ends
  minimizes disk access.
• Keep track of modified pages with a dirty bit
  in page table.

50
Virtual Memory Mapping (Cont.)Houston We have
a problem!

• We have both a space and time problem
• Space would be bad enough but time also!
• Page tables can be huge.
• If the address is 32 bits and the page size is
  2K, then there are 221 ? 2 Million entries at,
  say, 4 bytes per entry 8 Megabytes!
• To make matters worse, each process has a page
  table.
• Memory access time is doubled
• Even for a page hit, we must first access access
  the page table stored in memory, and then get the
  desired data,
• Two memory accesses to get the desired data in
  the most ideal situation (a page hit).

51
Two-Level Paging Example

• One solution to the large page table problem
  Paging the page table distinct from paged
  segment table on p. 588. see other solutions
  on pp. 587-588.
• A logical address (on 32-bit machine with 4K page
  size) is divided into
• a page number consisting of 20 bits.
• a page offset consisting of 12 bits.
• Since the page table is paged, the page number is
  further divided into
• a 10-bit page number.
• a 10-bit page offset.
• Thus, a logical address is as followswhere
  pi is an index into the outer page table, and p2
  is the displacement within the page of the outer
  page table.

From Silberschatz et. al., Operating System
Concepts 6th ed. Colored changes by Guydosh
page number
page offset
pi
p2
d
10
10
12
52
Two-Level Page-Table Scheme
One solution to the large page table problem
Page the page table
For a 32 bit address, and a 4k page, the
non-paged PT would have 1 meg entries - at 4
bytes /entry, the PT would take
up 4MB! Solution demand page in only those
blocks of the page table that are needed.
Outer Page Table (1st level) non-pageable, ie.,
pinned in memory gt
2nd level page table gt Each block (page) is
demand paged into memory. Only a fraction of all
pages of this table is resident in memory.
From Silberschatz et. al., Operating System
Concepts, 6th ed. Colored changes by Guydosh
53
Two-Level Page-Table Scheme

• Address-translation scheme for a two-level 32-bit
  paging architecture

Outer Page Table (1st level), non-pageable, ie.,
pinned in memory
2nd level page table Each block (page) is
demand paged into memory. Only a fraction of all
pages of this table is resident in memory.
From Silberschatz et. al., Operating System
Concepts, 6th ed. Colored changes by Guydosh
Main memory. Where the data is
54
The TLB Preventing Doubling of Memory Access
Time With Page Table

• Use a Translation Lookaside Buffer the TLB
• A cache for the Page Table distinct from the
  main memory cache aready studied
• Holds only page table mappings (entries)
• Uses the principle of locality of references in
  the page table
• Contains the most used page table entries a
  working set.
• Most of the time we should find the desired
  address translation in the TLB.
• The TLB uses all the principles we already
  discussed for general memory caches
  associatively, etc.
• When a TLB miss occurs, we must determine if this
  is a true page fault, or is it do we only need a
  TLB update from the page table.
• If the latter, then process the reference using
  the page table and copy the PT entry to the TLB
  with possible replacement.
• If a dirty bit is on in the TLB entry being
  replaced, then the corresponding entry in the PT
  entry must be updated.

55
TLB and PT Relationship
?TLB
Page Table ?
Fig. 7.24
56
TLB Integration With the Data Cache
TLB fully associative
Virtual Address ?
Steps for hits VA xlated by TBL Cache
PAconstructed PA sent to cache Cache page
number split into cache tag and index Data
retrieved as described previously
? 1 word/block
Cache direct mapped
Fig. 7.25 DECStation 3100
Fig. 7.25
57
Read Write Process for TLB/Cache system
Fig. 7.25 DECStation 3100
58
Common Framework for all Memory Hierarchies

• We studied three concepts that may look different
  on the surface
• Caches, TLBs, and virtual memory
• All three ideas rely on the fundamental principle
  of spatial and temporal locality to work
• All three ideas deal with four fundamental
  questions
• Q1 where can a block be placed?A1 One and only
  one place direct mapped cache. A few
  places set associative cache. Any place
  fully associative cache or VM (with table lookup
  instead of search).
• Q2 How is a block found?A2Indexing as in
  direct mapped Limited search as in set
  associative Full search as in a fully
  associative cache. Separate lookup table as
  in a page table in VM
• Q3 What block is replaced on a miss?A3 Must
  choose an algorithm for keeping track of
  reference behavior or the resident
  pages. Typically some variation of LRU or random
• Q4 How are writes handled?A4 Write through
  use buffers in order to hide write through
  latency and lazy evaluation (update on
  faults only) if backing store extremely slow as
  in VM and

59
Common Framework for all Memory Hierarchies
(cont.)

• Key relationship between VM/page table approach
  and Cache approach
• Both VM and fully associative cache do not
  restrict where a page could go The real memory
  in a VM scheme resembles a fully associative
  cache.
• In a true fully associative cache we must search
  the cache (in hardware) for the tag (block
  number) must store tag along with the data.
• In VM we only store the data in memory, and use a
  separate indexed page table look up to look up
  the physical address of the page a page
  searching real memory would be impractical
  because of it large size and the waste of space
  for tags would be prohibitive.
• OK for caches because they are small.
• Some generalizations of the meaning memory
  hierarchy misses 3 Cs
• Compulsory misses initial loading of a cache
  cold start
• Capacity misses cache cannot contain the entire
  working set or the blocks needed for execution
  of the program replacement needed danger of
  thrashing
• Conflict misses cache misses in a set a
  associative (not fully associative) or direct
  mapping. Multiple blocks compete for same set
  and set is full but there may be empty blocks
  in other sets which would be off limits to use.
  cannot happen in fully associative.

60
Other Memory Hierarchy Topics

• Memory performance and bandwidth issues and
  tradeoffs see section 7.2
• Protection in Virtual Memory see pp. 596-598.
• Critical due to multiprogramming environment
• Each process has its own virtual address space
• Must keep processes from interfering with each
  others address spaces and stay away from the
  Operating system space.
• Perhaps provide some reading ability (read only)
  ouside of the process space, but no writi8ng
• Sharing memory spaces for functional reasons must
  be totally under control of OS
• Page tables must be protected put them in
  Kernel space
• Maintain user and kernel mode
• If you want privileges outside of your own space,
  you must execute a system call allow the OS to
  control the privilege (example shared memory)
