Day 3: The Command and Visitor Patterns

1
Day 3 The Command and Visitor Patterns
2
Preliminaries

• The Java static type system uses simple rules to
  infer types for Java expressions.
• The inferred type for an expression is
  conservative it is guaranteed to be correct, but
  it may be weaker than what is required for a
  particular computation. Example recall the
  finger exercise from Day 1 involving the
  DeptDirectory class hierarchy.Given a variable d
  of type Cons bound to a directory containing two
  entries, the expression d.getRest().getRest
  ()is ill-typed. Why?

3
Explanation

• The variable d has type Cons which supports the
  method getRest. What is the type of d.getRest()?
  The return type of the method getRest, which is
  DeptDirectory. Does DeptDirectory support the
  method getRest? No. Hence, the method call
  (d.getRest()).getRest()is not well-typed.

4
Casting The Standard Work-Around

• Java allows any expression of object (reference)
  type A to be cast to another object type
  B--provided that the types A and B overlap (have
  a non-empty intersection ignoring null.
• Given a Java expression e of type A, the
  notation(B)emeans expression e of type B. The
  value of e is unchanged.

5
Finger Exercise

• In DrJava, open the file DeptDirectory.java from
  the code library at the TeachJava website.
  Compile it.
• In the Interactions pane, evaluatee1 new
  Entry("Corky","DH3104","x 6042")e2 new
  Entry("Matthias","DH3106","x 5732")d new
  Cons(e1, new Cons(e2, new Empty()))dd.getRest()
  e (Cons) d.getRest()
• e.getRest()

6
More Practice with the Composite and Interpreter
Patterns

• In DrJava, open the file IntList.java. We want
  to convert IntList.java to a program List.java
  that implements heterogeneous lists (lists that
  can hold arbitrary objects, not just elements of
  a particular type). The element type in the
  program List.java must be Object. Otherwise the
  code is unchanged.
• Rewrite the concat and rev methods for
  heterogeneous lists. Test your code on some
  lists of Integer.

7
List

• abstract class List
• abstract Object getFirst()
• abstract List getRest()
• abstract String toStringHelp()
• class Empty extends List
• static Empty ONLY new Empty() // singleton
  pattern
• private Empty()
• Object getFirst() throw new
  IllegalArgumentException(
• "first requires a non Empty List")
• List getRest() throw new IllegalArgumentExcept
  ion(
• "rest requires a non Empty List")
• public String toString() return "()"
• String toStringHelp() return ""
• class Cons extends List
• Object first

8
Discussion Question

• We want to define a method to sort heterogeneous
  lists. The method should work on lists of
  Integer, Double, Float Long, Short, Byte, Char,
  String, etc.
• How can we do this?

9
Some Possible Answers

• Pass the comparison method as an argument to the
  sort method. How can we do this? We will discuss
  a pattern for doing this later.
• Exploit an interface in all of the built-in types
  with a sensible total ordering called Comparable.

10
Java Interfaces

• In Java, an interface is a language construct
  that resembles a "lightweight" abstract class (an
  abstract class with no concrete methods). An
  interface definition has the syntax interface
  ltnamegt ltmembersgt
• which looks exactly like a class definition
  except for the use of the keyword interface
  instead of class. But the members of an
  interface are restricted to abstract methods and
  static final fields.

11
Examples

• The interface Comparable is built-in to Java
  (part of the core library java.lang) has the
  following definition
• interface Comparable int
  compareTo(Object other) The value returned
  by compareTo is negative, zero, or positive
  depending on whether this is less than other,
  equal to other, or greater than other.
• The built-in class String also implements the
  interface CharSequence which includes methods
  such as int length(). The built-in class
  StringBuffer (mutable strings) also implements
  this interface.

12
Writing a Sort Program

• Our task is to add a method
• List sort() to the List class. We will
  decompose this problem into smaller tasks.
• Our first subtask is to write a method List
  insert(Object o) that inserts o in proper
  order in this assuming that this is in
  (ascending) sorted order. Your code will be
  littered with casts.
• Our remaining task is to write sort() using
  insert as a help function.

13
List Sort

• abstract class List
• abstract Object getFirst()
• abstract List getRest()
• abstract List insert(Object e)
• abstract List sort()
• abstract String toStringHelp()
• abstract List sort()
• class Empty extends List
• static Empty ONLY new Empty() // singleton
  pattern
• private Empty()
• Object getFirst() throw new
  IllegalArgumentException(
• "first requires a non Empty List")
• List getRest() throw new IllegalArgumentExcept
  ion(
• "rest requires a non Empty List")
• List sort() return Empty.ONLY

14
List Sort

• class Cons extends List
• Object first
• List rest
• Cons(Object f, List r)
• first f
• rest r
• Object getFirst() return first
• List getRest() return rest
• List insert(Object e)
• Comparable ce (Comparable) e
• Comparable cf (Comparable) first
• if (ce.compareTo(cf) lt 0) return new
  Cons(e,this)
• else return new Cons(first, rest.insert(e))
• List sort() return rest.sort().insert(first)

• public String toString()
