Title: The Structure and Function of Macromolecules


1
Chapter 5
  • The Structure and Function of Macromolecules

2
Concept 5.1 Most macromolecules are polymers,
built from monomers
  • A polymer is a long molecule consisting of many
    similar building blocks called monomers
  • Three of the four classes of lifes organic
    molecules are polymers
  • Carbohydrates
  • Lipids
  • Proteins
  • Nucleic acids

3
Macromolecules
  • Smaller organic molecules join together to form
    larger molecules
  • macromolecules
  • 4 major classes of macromolecules
  • carbohydrates
  • lipids
  • proteins
  • nucleic acids

4
Polymers
  • Long molecules built by linking repeating
    building blocks in a chain
  • monomers
  • building blocks
  • repeated small units
  • covalent bonds

Dehydration synthesis
5
How to build a polymer
You gotta be open tobonding!
  • Synthesis
  • joins monomers by taking H2O out
  • one monomer donates OH
  • other monomer donates H
  • together these form H2O
  • requires energy enzymes

Dehydration synthesis
Condensation reaction
6
How to break down a polymer
  • Digestion
  • use H2O to breakdown polymers
  • reverse of dehydration synthesis
  • cleave off one monomer at a time
  • H2O is split into H and OH
  • H OH attach to ends
  • requires enzymes
  • releases energy

Breaking upis hard to do!
Hydrolysis
Digestion
7
Carbohydrates
8
Carbohydrates
  • Carbohydrates are composed of C, H, O carbo -
    hydr - ate
  • CH2O
  • (CH2O)x C6H12O6
  • Function
  • energy u energy storage
  • raw materials u structural materials
  • Monomer sugars
  • ex sugars, starches, cellulose

9
Concept 5.2 Carbohydrates serve as fuel and
building material
  • Carbohydrates include sugars and the polymers of
    sugars
  • The simplest carbohydrates are monosaccharides,
    or single sugars
  • Carbohydrate macromolecules are polysaccharides,
    polymers composed of many sugar building blocks

10
Sugars
  • Most names for sugars end in -ose
  • Classified by number of carbons
  • 6C hexose (glucose)
  • 5C pentose (ribose)
  • 3C triose (glyceraldehyde)

6
5
3
11
Functional groups determine function
carbonyl
aldehyde
carbonyl
ketone
12
Sugar structure
5C 6C sugars form rings in solution
Where do you find solutions? In cells!
Carbons are numbered
13
Numbered carbons
C
6'
C
O
5'
C
C
1'
4'
energy stored in C-C bonds
C
C
2'
3'
14
Simple complex sugars
  • Monosaccharides
  • simple 1 monomer sugars
  • glucose
  • Disaccharides
  • 2 monomers
  • sucrose
  • Polysaccharides
  • large polymers
  • starch

15
Building sugars
  • Dehydration synthesis

monosaccharides
disaccharide
glucose
glucose
maltose
glycosidic linkage
16
Building sugars
  • Synthesis

monosaccharides
disaccharide
fructose
glucose
sucrose (table sugar)
Lets go to the videotape!
17
Polysaccharides
  • Polymers of sugars
  • costs little energy to build
  • easily reversible release energy
  • Function
  • energy storage
  • starch (plants)
  • glycogen (animals)
  • structure building materials
  • cellulose (plants)
  • chitin (arthropods fungi)

18
Linear vs. branched polysaccharides
starch (plant)
What doesbranching do?
energystorage
glycogen (animal)
Lets go to the videotape!
19
Polysaccharide diversity
  • Molecular structure determines function

in starch
in cellulose
  • isomers of glucose
  • structure determines function

20
Digesting starch vs. cellulose
starcheasy todigest
cellulosehard todigest
21
Cellulose
  • Most abundant organic compound on Earth
  • herbivores can digest cellulose
  • most carnivores cannot digest cellulose
  • thats why they eat meat to get their energy
    nutrients
  • cellulose roughage

BIG DEAL!Who can liveon this stuff?!
22
  • Cow
  • can digest cellulose well no need to eat other
    sugars
  • Gorilla
  • cant digest cellulose well must add another
    sugar source, like fruit to diet

23
Helpful bacteria
  • How can cows digest cellulose?
  • bacteria live in their gut help digest
    cellulose-rich (grass) meals

24
Lipids Fats Oils
25
Concept 5.3 Lipids are a diverse group of
hydrophobic molecules
  • Lipids are the one class of large biological
    molecules that do not form polymers
  • The unifying feature of lipids is having little
    or no affinity for water
  • Lipids are hydrophobic because?they consist
    mostly of hydrocarbons, which form nonpolar
    covalent bonds
  • The most biologically important lipids are fats,
    phospholipids, and steroids

26
  • Lipids

energy storage
27
Lipids
  • Lipids are composed of C, H, O
  • long hydrocarbon chain
  • Diverse group
  • fats
  • phospholipids
  • steroids
  • Do not form polymers
  • big molecules made of smaller subunits
  • not a continuing chain

fat
28
Fat subunits
  • Structure
  • glycerol (3C alcohol) fatty acid
  • fatty acid long HC tail with COOH group at
    head

dehydration synthesis
29
Building Fats
  • Triacylglycerol
  • 3 fatty acids linked to glycerol
  • ester linkage between OH COOH

30
Dehydration synthesis
dehydration synthesis
31
Fats store energy
Why do humanslike fatty foods?
  • Long HC chain
  • polar or non-polar?
  • hydrophilic or hydrophobic?
  • Function
  • energy storage
  • very rich
  • 2x carbohydrates
  • cushion organs
  • insulates body
  • think whale blubber!

32
Saturated fats
  • All C bonded to H
  • No CC double bonds
  • long, straight chain
  • most animal fats
  • solid at room temp.
  • contributes to cardiovascular disease
    (atherosclerosis) plaque deposits

33
Stearic acid
Saturated fat and fatty acid.
34
Unsaturated fats
  • CC double bonds in the fatty acids
  • plant fish fats
  • vegetable oils
  • liquid at room temperature
  • the kinks made by doublebonded C prevent the
    molecules from packing tightly together

mono-unsaturated? poly-unsaturated?
35
Oleic acid
cis double bond causes bending
Unsaturated fat and fatty acid.
36
Saturated vs. unsaturated
saturated
unsaturated
?
37
Phospholipids
  • Structure
  • glycerol 2 fatty acids PO4
  • PO4 negatively charged

Its just like apenguin A head at one end a
tail at the other!
38
Phospholipids
  • Hydrophobic or hydrophilic?
  • fatty acid tails hydrophobic
  • PO4 hydrophilic head
  • dual personality

It likes water also pushes it away!
interaction with H2O is complex very important!
39
Phospholipids in water
  • Hydrophilic heads attracted to H2O
  • Hydrophobic tails hide from H2O
  • can self-assemble into bubbles
  • bubble micelle
  • can also form bilayer
  • early evolutionary stage of cell?

bilayer
40
Why is this important?
  • Phospholipids create a barrier in water
  • define outside vs. inside
  • cell membranes

41
Phospholipids cells
  • Phospholipids of cell membrane
  • double layer bilayer
  • hydrophilic heads on outside
  • in contact with aqueous solution outside of cell
    and inside of cell
  • hydrophobic tails on inside
  • form core
  • forms barrier between cell external environment

Tell themabout soap!
42
Steroids
  • ex cholesterol, sex hormones
  • 4 fused C rings
  • different steroids created by attaching different
    functional groups to rings

cholesterol
43
Cholesterol
  • Important cell component
  • animal cell membranes
  • precursor of all other steroids
  • including vertebrate sex hormones
  • high levels in blood may contribute to
    cardiovascular disease

44
Cholesterol
Important component of cell membrane
  • helps keep cell membranes fluid flexible

45
From Cholesterol ? Sex Hormones
  • What a big difference a few atoms can make!

46
Proteins
47
Concept 5.4 Proteins have many structures,
resulting in a wide range of functions
  • Proteins account for more than 50 of the dry
    mass of most cells
  • Protein functions include structural support,
    storage, transport, cellular communications,
    movement, and defense against foreign substances

48
  • Proteins

Multipurposemolecules
49
Proteins
  • Most structurally functionally diverse group of
    biomolecules
  • Function
  • involved in almost everything
  • enzymes (pepsin, polymerase, etc.)
  • structure (keratin, collagen)
  • carriers transport (membrane channels)
  • receptors binding (defense antibodies)
  • contraction (actin myosin)
  • signaling (hormones insulin)
  • storage (bean seed proteins)

50
(No Transcript)
51
Proteins
  • Structure
  • monomer amino acids
  • 20 different amino acids
  • polymer polypeptide
  • protein can be one or more polypeptide chains
    folded bonded together
  • large complex molecules
  • complex 3-D shape

hemoglobin
growthhormones
Rubisco
52
Amino acids
  • Structure
  • central carbon
  • amino group
  • carboxyl group (acid)
  • R group (side chain)
  • variable group
  • confers unique chemical properties of the amino
    acid

R
53
Nonpolar amino acids
Why are these nonpolar hydrophobic?
54
Polar amino acids
Why are these polar hydrophillic?
55
Ionizing in cellular waters
H donors
56
Ionizing in cellular waters
H acceptors
57
Sulfur containing amino acids
  • Form disulfide bridges
  • cross links betweens sulfurs in amino acids

H-S S-H
You wonderedwhy permssmelled like rotten eggs?
58
Building proteins
  • Peptide bonds
  • linking NH2 of one amino acid to COOH of another
  • CN bond

dehydration synthesis
59
Building proteins
  • Polypeptide chains
  • N-terminus NH2 end
  • C-terminus COOH end
  • repeated sequence (N-C-C) is the polypeptide
    backbone
  • can only grow in one direction

60
Protein structure function
  • Function depends on structure
  • 3-D structure
  • twisted, folded, coiled into unique shape

pepsin
61
4 Levels of Protein Structure
  • The primary structure of a protein is its unique
    sequence of amino acids
  • Secondary structure, found in most proteins,
    consists of coils and folds in the polypeptide
    chain
  • Tertiary structure is determined by interactions
    among various side chains (R groups)
  • Quaternary structure results when a protein
    consists of multiple polypeptide chains

62
Primary (1) structure
  • Order of amino acids in chain
  • amino acid sequence determined by gene (DNA)
  • slight change in amino acid sequence can affect
    proteins structure its function
  • even just one amino acid change can make all the
    difference!

lysozyme enzyme in tears mucus that kills
bacteria
63
Sickle cell anemia
64
Secondary (2) structure
  • Local folding
  • folding along short sections of polypeptide
  • interaction between adjacent amino acids
  • H bonds between R groups
  • ?-helix
  • ?-pleated sheet

65
Secondary (2) structure
66
Tertiary (3) structure
  • Whole molecule folding
  • determined by interactions between R groups
  • hydrophobic interactions
  • effect of water in cell
  • anchored by disulfide bridges(H ionic bonds)

67
Quaternary (4) structure
  • More than one polypeptide chain joined together
  • only then is it a functional protein
  • hydrophobic interactions

collagen skin tendons
hemoglobin
68
Protein structure (review)
R groups hydrophobic interactions, disulfide
bridges
3
1
2
4
69
Denature a protein
  • Unfolding a protein
  • disrupt 3 structure
  • pH ? salt ? temperature
  • unravels or denatures protein
  • disrupts H bonds, ionic bonds disulfide
    bridges
  • destroys functionality
  • Some proteins can return to their functional
    shape after denaturation, many cannot

In Biology,size doesnt matter, SHAPE matters!
70
What Determines Protein Conformation?
  • In addition to primary structure, physical and
    chemical conditions can affect conformation
  • Alternations in pH, salt concentration,
    temperature, or other environmental factors can
    cause a protein to unravel
  • This loss of a proteins native conformation is
    called denaturation
  • A denatured protein is biologically inactive

71
Chaperonin proteins
  • Guide protein folding
  • provide shelter for folding polypeptides
  • keep the new protein segregated from cytoplasmic
    influences

72
Protein models
  • Protein structure visualized by
  • X-ray crystallography
  • extrapolating from amino acid sequence
  • computer modelling

lysozyme
73
Enzymes
  • Enzymes are a type of protein that acts as a
    catalyst, speeding up chemical reactions
  • Enzymes can perform their functions repeatedly,
    functioning as workhorses that carry out the
    processes of life

74
(No Transcript)
75
HELIXHELIX
76
Concept 5.5 Nucleic acids store and transmit
hereditary information
  • The amino acid sequence of a polypeptide is
    programmed by a unit of inheritance called a gene
  • Genes are made of DNA, a nucleic acid

77
  • Nucleic Acids

Informationstorage
78
Nucleic Acids
  • Function
  • store transmit hereditary information
  • Examples
  • RNA (ribonucleic acid)
  • DNA (deoxyribonucleic acid)
  • Structure
  • monomers nucleotides

79
Nucleotides
  • 3 parts
  • nitrogen base (C-N ring)
  • pentose sugar (5C)
  • ribose in RNA
  • deoxyribose in DNA
  • phosphate (PO4) group

Are nucleic acidscharged molecules?
80
RNA DNA
  • RNA
  • single nucleotide chain
  • DNA
  • double nucleotide chain
  • N bases bond in pairs across chains
  • spiraled in a double helix
  • double helix 1st proposed as structure of DNA in
    1953 by James Watson Francis Crick (just
    celebrated 50th anniversary in 2003!)

81
Types of nucleotides
  • 2 types of nucleotides
  • different nitrogen bases
  • purines
  • double ring N base
  • adenine (A)
  • guanine (G)
  • pyrimidines
  • single ring N base
  • cytosine (C)
  • thymine (T)
  • uracil (U)

82
Building the polymer
83
Nucleic polymer
  • Backbone
  • sugar to PO4 bond
  • phosphodiester bond
  • new base added to sugar of previous base
  • polymer grows in one direction
  • N bases hang off the sugar-phosphate backbone

Dangling bases?Why is this important?
84
Pairing of nucleotides
  • Nucleotides bond between DNA strands
  • H bonds
  • purine pyrimidine
  • A T
  • 2 H bonds
  • G C
  • 3 H bonds

Matching bases?Why is this important?
85
Information polymer
  • Function
  • series of bases encodes information
  • like the letters of a book
  • stored information is passed from parent to
    offspring
  • need to copy accurately
  • stored information genes
  • genetic information

Passing on information?Why is this important?
86
(No Transcript)
87
DNA molecule
  • Double helix
  • H bonds between bases join the 2 strands
  • A T
  • C G

H bonds?Why is this important?
88
Copying DNA
  • Replication
  • 2 strands of DNA helix are complementary
  • have one, can build other
  • have one, can rebuild the whole

Matching halves?Why is this a good system?
89
When does a cell copy DNA?
  • When in the life of a cell does DNA have to be
    copied?
  • cell reproduction
  • mitosis
  • gamete production
  • meiosis

90
DNA replication
  • It has not escaped our notice that the specific
    pairing we have postulated immediately suggests a
    possible copying mechanism for the genetic
    material.
  • James Watson
  • Francis Crick
  • 1953

91
Watson and Crick and others
1953 1962
92
Maurice Wilkins and
1953 1962
93
Rosalind Franklin (1920-1958)
94
Interesting note
  • Ratio of A-TG-C affects stability of DNA
    molecule
  • 2 H bonds vs. 3 H bonds
  • biotech procedures
  • more G-C need higher T to separate strands
  • high T organisms
  • many G-C
  • parasites
  • many A-T (dont know why)

95
Another interesting note
  • ATPAdenosine triphosphate
  • modified nucleotide
  • adenine (AMP) Pi Pi


Write a Comment
User Comments (0)
About PowerShow.com
