Click Modular Router

1
Click Modular Router

• Userlevel Click Development
• Bart Braem Michael Voorhaen
• firstname.lastname_at_ua.ac.be

2
Writing your own element header

• Necessary in the header
• Macros
• Include-guards
• Click element macros
• Include click/element.hh
• The class declaration
• containing 3 special methods
• const char class_name() const
• const char port_count() const
• const char processing() const

3
simplepushelement.hh

• ifndef CLICK_SIMPLEPUSHELEMENT_HH
• define CLICK_SIMPLEPUSHELEMENT_HH
• include ltclick/element.hhgt
• CLICK_DECLS
• class SimplePushElement public Element
• public
• SimplePushElement()
• SimplePushElement()
• const char class_name() const return
  "SimplePushElement"
• const char port_count() const return 1/1

• const char processing() const return PUSH
• int configure(VectorltStringgt, ErrorHandler)
• void push(int, Packet )
• private
• uint32_t maxSize

4
Writing your own element

• Necessary in the source file
• Include click/config.hh first!!
• Macros
• CLICK_DECLS
• CLICK_ENDDECLS
• EXPORT_ELEMENT
• Implementations of the methods

5
simplepushelement.cc

• include ltclick/config.hgt
• include ltclick/confparse.hhgt
• include ltclick/error.hhgt
• include "simplepushelement.hh"
• CLICK_DECLS
• SimplePushElementSimplePushElement()
• SimplePushElement SimplePushElement()
• int SimplePushElement configure(VectorltStringgt
  conf, ErrorHandler errh)
• if (cp_va_parse(conf, this, errh, cpKeywords,
  "MAX_SIZE", cpInteger, "maximum packet size",
  maxSize, cpEnd) lt 0) return -1
• if (maxSize lt 0) return errh-gterror("maxsize
  should be larger than 0")
• return 0
• void SimplePushElement push(int, Packet p)
• if (p-gtlength() gt maxSize) p-gtkill()
• else output(0).push(p)

6
simplepullelement

• simplepullelement.hh
• class SimplePullElement public Element
• public
• const char processing() const return PULL
• Packet pull(int)
• simplepullelement.cc
• Packet SimplePullElementpull(int)
• Packet p input(0).pull()
• if (p-gtlength() gt maxSize) p-gtkill()
• return p

7
simpleagnosticelement1

• simpleagnosticelement1.hh
• class SimpleAgnosticElement1 public Element
• public
• const char processing() const return
  AGNOSTIC
• Packet simple_action(Packet )
• simpleagnosticelement1.cc
• Packet SimpleAgnosticElement1simple_action(Pack
  et p)
• if (p-gtlength() gt maxSize)
• p-gtkill()
• return 0
• else
• return p

8
simpleagnosticelement2

• simpleagnosticelement2.hh
• class SimpleAgnosticElement2 public Element
• public
• const char processing() const return
  AGNOSTIC
• void push(int, Packet )
• Packet pull(int)
• simpleagnosticelement2.cc
• void SimpleAgnosticElement2push(int, Packet
  p)
• if (p-gtlength() gt maxSize) p-gtkill()
• else output(0).push(p)
• Packet SimpleAgnosticElement2pull(int)
• Packet p input(0).pull()
• if (p-gtlength() gt maxSize) p-gtkill()
• return p

9
Portcount

• Defined by const char port_count() const
• can return
• "1/1" one input port, one output port
• "1/2" one input port, two output ports
• Or more complicated
• "1-2/0" one or two input ports and zero output
  ports.
• "1/-6" One input port and up to six output
  ports.
• "2-/-" At least two input ports and any number
  of output ports.
• "3" Exactly three input and output ports. (If no
  slash appears, the text is used for both input
  and output ranges.)
• "1-/" At least one input port and the same
  number of output ports.
• "1-/" At least one input port and one more
  output port than there are input ports.

10
Parsing configurations

• Required arguments
• First in cp_va_parse
• Optional arguments
• After cpOptional
• Arguments by keyword
• After cpKeywords
• Optional if after cpOptional
• Much clearer
• Lots of types parsed
• Integers (cpInteger)
• Strings (cpString)
• Elements (cpElement)
• IP addresses (cpIPAddress)

11
Parsing configurations examples

• cp_va_parse(conf, this, errh,
• cpString, "packet data", data,
• cpOptional,
• cpUnsigned, "sending rate (packets/s)", rate,
• cpKeywords,
• "DATASIZE", cpInteger, "minimum packet size",
  datasize,
• "ACTIVE", cpBool, "active?", active,
• SOURCE", cpIPAddress, source ip", source,
• cpEnd)
• SimpleElement(data,800,DATASIZE -67, SOURCE
  1.2.3.4)
• SimpleElement(data)
• SimpleElement(data,ACTIVE false)
• SimpleElement(data,800)
• SimpleElement(data,ACTIVE false, 800)

12
Parsing configurations elements

• Elements might need other elements
• Pass them in the configuration
• Check their name and type
• Calling public methods and accessing public
  members is possible
• Click script
• SimpleElement(IPRouteTable)or
• myIpRouteTableIPRouteTable
• SimpleElement(myIpRouteTable)

13
Parsing configurations elements (2)

• Add an element to the header
• include usedelement.hh
• class ElementUser public Element
• private
• UsedElement used
• Use the element in the C code
• ElementUserpush() used-gtdoSomething()

14
Parsing configurations elements (3)

• Check and configure the element in the configure
  function
• int ElementUserconfigure(VectorltStringgt conf,
  ErrorHandler errh)
• Element tempUsedElement
• int res cp_va_parse(conf, this, errh,
  cpElement, Used element", tempUsedElement, 0)
• if(res lt 0) return res // parsing failed
• if (tempUsedElement-gtclass_name() !
  UsedElement")
• return errh-gterror("Supplied element is not a
  UsedElement element but a s", UsedElement-gtclass_
  name())
• if (!(used (UsedElement ) UsedElement))
• return errh-gterror("Supplied element is not a
  valid UsedElement element (cast failed)")

15
Click library functions

• The C STL cannot be used in the kernel
• Click provides its own implementation, use it
• Equivalents to most STL datastructures available
• E.g. vector, hashmap,
• Additional types
• Timers and tasks (schedule actions)
• Additional functions
• Manipulate strings
• Manipulate packets
• E.g. click_gettimeofday(struct timeval tv)

16
Using Click STL example

• ifndef AODVSETRREPHEADERS_HH
• define AODVSETRREPHEADERS_HH
• include ltclick/element.hhgt
• CLICK_DECLS
• typedef HashMapltPacket, IPAddressgt
  DestinationMap
• class AODVSetRREPHeaders public Element
• public
• virtual void push (int, Packet )
• void addRREP(Packet,IPAddress )
• private
• DestinationMap destinations
• CLICK_ENDDECLS
• endif

17
Usign Click STL example (2)

• AODVSetRREPHeadersAODVSetRREPHeaders()
  destinations()
• void AODVSetRREPHeaderspush (int port, Packet
  p)
• // packet should be in destinations
• DestinationMapPair pair destinations.find_p
  air(packet)
• assert(pair)
• IPAddress destination pair-gtvalue
• // do something with destination
• delete pair-gtvalue // free memory properly
• destinations.remove(packet) // then remove from
  map
• void AODVSetRREPHeadersaddRREP(Packet rrep,
  IPAddress ip)
• destinations.insert(rrep,ip)
• // macro magic to use bighashmap
• include ltclick/bighashmap.ccgt

18
Creating and destroying packets

• You want to make your own packets, heres how
• Format closely mirrors RFCs
• Use structs
• Fill them with signed/unsigned ints, in_addr,
• Easy packet manipulation
• Avoids dirty operations with chars and bytes
• Define those in shared headers for reuse
• Create your packet format
• struct MyPacketFormat
• uint8_t type // 8 bit 1 byte
• uint32_t lifetime // 32 bit 4 bytes
• in_addr destination // IP address

19
Creating and destroying packets (2)

• Provide headroom and tailroom to
  Packetmake(unsigned headroom, const unsigned
  char data, unsigned len, unsigned tailroom)
• int tailroom 0
• int packetsize sizeof(MyPacketFormat)
• int headroom sizeof(click_ip)sizeof(click_udp)
  sizeof(click_eth)
• WritablePacket packet Packetmake(headroom,0,
  packetsize, tailroom)
• if (packet 0 )return click_chatter( "cannot
  make packet!")
• memset(packet-gtdata(), 0, packet-gtlength())
• MyPacketFormat format (MyPacketFormat)
  packet-gtdata()
• format-gttype 0
• format-gtlifetime htonl(counter)
• format-gtdestination ip.in_addr()
• Destroy with packet-gtkill()
• Frees your memory!

20
Processing packets

• Cast the packet data to the right format
• my_header head (my_header ) (packet-gtdata()
  someoffset)
• Use the format to read from and write to
• if (head-gtsomefield 2)head-gtotherfield
  htons(38)
• Only write to writable packets!

21
Manipulating packets

• Add data with push(unsigned len)
• Inserts the data at the beginning of the packet
• Create enough headroom, otherwise expensive push!
• Remove data with pull(unsigned len)
• Removes the data at the beginning of the packet
• Frees headroom
• Equivalents at tail of packet put and take

22
Packet headers

• Get IP header
• packet-gtip_header()
• Set IP header of length len
• packet-gtset_ip_header(const click_ip header,
  unsigned len)
• Both operations require header annotations, set
  by the MarkIPHeader element!
• Similar operations exist for TCP and UDP headers

23
Timers (simple, without extra data)

• Runs the run_timer function upon expiry
• class MyElement public Element
  public void run_timer()private ... Timer
  timer
• MyElementMyElement() timer(this)int
  MyElement configure(VectorltStringgt conf,
  ErrorHandler errh) timer.initialize(this)
  timer.schedule_after_ms(1000) return 0void
  MyElement run_timer() click_chatter(we are
  now 1 second later) timer.schedule_after_ms(100
  0)

24
Timers (with extra data)

• Run your callback function upon expiry, with data
• Because you want to know some context information
• Code is a little bit harder
• class MyElement public Element private struc
  t TimerData // callback data MyElement
  me Something s static void
  handleExpiry(Timer, void ) // callback
  function void expire(const MyElement ,
  TimerData )

25
Timers (with extra data) (2)

• void MyElementsomeFunction() TimerData
  timerdata new TimerData() timerdata-gts new
  Something() timerdata-gtme this Timer t
  new Timer(MyElementhandleExpiry,timerdata) t-
  gtinitialize(this) t-gtschedule_after_ms(2500)
  void MyElementhandleExpiry(Timer, void
  data) TimerData timerdata (TimerData)
  data assert(timerdata) // the cast must be
  good timerdata-gtme-gtexpire(timerdata-gts,timerdat
  a)void MyElementexpire(const Something
  s, TimerData timerdata) // do things with
  Something // timerdata passed to free memory
  after timer expiry

26
Handlers basics

• Like function calls to an element
• ReadHandler
• Request a value from an element
• Or WriteHandler
• Pass a string to an element
• You can parse the string with cp_va_parse!
• There is no ReadWriteHandler
• You cant call a ReadHandler with arguments
• Can be called from other elements or through
  socket
• Take a look at Pokehandlers!

27
Handlers Write implementation

• class WriteElement public Element public
  static int handle(const String conf, Element
  e, void thunk, ErrorHandler errh) void
  add_handlers()
• int WriteElementhandle(const String conf,
  Element e, void thunk, ErrorHandler
  errh) WriteElement me (WriteElement )
  e if(cp_va_parse(conf, me, errh, , cpEnd) lt 0)
  return -1 me-gtdoSomethingWithParsed() return
  0
• void WriteElementadd_handlers() add_write_hand
  ler(a_handle", handle, (void )0)

28
Handlers Read implementation

• class ReadElement public Element public
  static int handle(const String conf, Element
  e, void thunk, ErrorHandler errh) void
  add_handlers()
• String ReadElementhandle(Element e, void
  thunk) ReadElement me (ReadElement )
  e return me-gtgiveSomeValue()void
  ReadElementadd_handlers() add_read_handler(a_
  handle", handle, (void )0)

29
Handlers calling

• Start click
• click p ltport_nrgt ltclick_scriptgt
• click p 10000 somescript.click
• Connect to click with telnet
• telnet localhost 10000
• read ltelementnamegt.lthandlernamegt
• read rt.table
• write ltelementnamegt.lthandlernamegt ltvaluesgt
• write arptable.insert 0050BA8584B1 10.0.1.2

30
References

• Click website http//www.read.cs.ucla.edu/click/

• Element documentation (by name or category)
• Programming Concepts
• Doxygen documentation
• Click thesis (online publications, Ph.D. thesis)
• Comprehensive documentation of every concept
• Interesting chapters
• Introduction
• Architecture elements, packets, connections,
  push and pull, packet storage, element
  implementation
• Language syntax, configuration strings, compound
  elements
• Click source code
• /elements/ dozens of elements, some more trivial
  than others
• /include/ the Click STL headers
