Speech Interface to Virtual Reality Applications

1
Speech Interface to Virtual Reality Applications
Authors Wauchope, K., S. Everett, D. Tate, T.
Maney M.Cernak, A.Sannier

• Reporter
• Chun-Feng Liao

2
References
This report discuss 2 implementations of Speech
Interface to Virtual Reality Applications.

• M.Cernak, A.Sannier ,Technical Report, Command
  Speech Interface to Virtual Reality
  Applications,Virtual Reality Applications Center
  at Iowa State University of Science and
  Technology, June 2002.
• Wauchope, K., S. Everett, D. Tate, T. Maney,
  "Speech-Interactive Virtual Environments for Ship
  Familiarization," 2nd International
  EuroConference on Computer and IT Applications in
  the Maritime Industries (COMPIT '03), Hamburg,
  Germany, May 14-17, 2003, pp. 70-83.

3
(No Transcript)
4
Agenda

• Introduction
• Paper I
• Paper II
• Conclusion
• System design Discussion

5
Introduction

• Both papers are newly published.(2002,2003)
• These 2 papers address technical details of
  Speech-VR integration.\
• The 2nd paper take more modern approach .
• Both of them use similar architecture.(and are
  also similar to ours!)

ExChoosing VRML Java Speech API platform and
encountered serveral difficult problems such as
java security constraint and were force to use a
brwoser as an application instead of browser
as an applet
6
Paper I

• M.Cernak, A.Sannier ,Technical Report, Command
  Speech Interface to Virtual Reality
  Applications,Virtual Reality Applications Center
  at Iowa State University of Science and
  Technology, June 2002.

7
Purposes of this paper

• Describe an approach to control VR applications
  using multimodal command speech interface
  (CSI)based on dialog modeling.
• Used to imporve the usability of VRACs C6 .

VRAC Virtual Reality Applications Center C6 is
a Virtual Reality System developed by VRAC.
8
Multimodal Interaction
Command Addressing,used to trigger system start
to record users voice for recognition.

• U MoleBio
• S Yes
• U (Targeting the atom 512 by mouse)
• U Go There !
• S OK (goto Atom number 512 ).

U User , S System
9
System Architecture
Dialog Management and Speech facilities
VR System
10
System Architecture

• VR VRACs C6
• TTS Festival
• SR CSLU Toolkit
• Platform Windows OS on PII 400

11
Three Main Components(1)

• Speech Synthesis (TTS) Festival .

12
Three Main Components(2)

• CSLU Toolkit Dialog Modeling , Speech
  Recognition and Nature Language Processing.
• CSLU was implemented in C and Tcl/tk , developed
  by OGI (Oregon Graduate Institute )

CSLU (Center of Spoken Language Understanding)
13
(No Transcript)
14
Three Main Components(3)

• Communication Bridge to VR application.
• To Integrate CSLU(Speech) and C6(VR).

15
How to Integrate CSLU and C6

• Initial Attempt CORBA
• C6 support CORBA .
• Try to use Combat as tcl extension as CORBA
  Client but failed.
• Try to use Tcl Blend
• Tck-gtJava-gtCORBA-gtC6 (efficient problems)
• Result use TCP socket.

16
Natural Language Processing

• Instead of using standard JSGF , the authors use
  a custom grammar and wrote a specific parser to
  evaluate it.
• Very similar to JSGF.
• We will not discuss the custom grammar in detail
  here.

17
SCI Test Environment

• A RAD (GUI) tool that help developers to quickly
  build the dialog flow.

18
Paper I Conclusion

• Major advantage of this system is quick
  deployment.
• The problematic area is the Speech Recognition
  Accuracy(provided by CSLU) was poor.
• US Navy also developed a Speech Inteface to VR
  System , they will imporved the interaction with
  VR in terms of their method.

19
Future Work

• Change TTS and SR to IBM ViaVoice .
• Support JSAPI(Java Speech API)
• Java is easier to communicate with C6 via CORBA.

20
(No Transcript)
21
Paper II

• Wauchope, K., S. Everett, D. Tate, T. Maney,
  "Speech-Interactive Virtual Environments for Ship
  Familiarization," 2nd International
  EuroConference on Computer and IT Applications in
  the Maritime Industries (COMPIT '03), Hamburg,
  Germany, May 14-17, 2003, pp. 70-83.

22
Introduction

• This paper intruduce 2 systems which help
  newly-aboard crews of US Navy ships to be
  familiar with their environment quickly.

User Tell me where is Rom 101 !
23
Motivation

• Architects of US Navy Ships heavily use CAD tools
  to design ship models.
• CAD file can be transferred to 3D model format
  with little effort.
• Accroding to authors previous research ,this
  Virtual Envirionment did shorten crews learning
  time.

24
Systems introduced

• 2 Systems
• MSFT(Multimodal Ship Familiarization Tool)
• ISFS(Interactive Ship Familiarization System)
• ISFS is a recent transition fo MSFT.

25
System ArchitectureMSFT
Run as different process
26
MSFT

• VE veiwer component and speech interface run as
  two separate processes.
• Speech interface using a total IBM solution
• ViaVoice.
• IBMs SMAPI.
• IBMs SRCL grammar.

Platform PIII 500MHz
27
ISFS

• A recent transistion of MSFT.
• Using VRML as 3D modeling language.
• Using JSAPI as interface to speech engine.
• ViaVoice totally support JSAPI.
• VRML support Java as a scripting language
• Other structure is identical to MSFT system.

Platform Xeon 2.0GHz -gtNeed more computing
power!
28
Why Chose to Use Standalone VRML Brwoser?

• Security Limitations.(detail will be discussed
  later)
• VM Limitations.(detail will be discussed later)
• Provide opportunities to customize interface to
  VRML browser.

In my personal experience,system usually become
unstable when speech engine work with VRML
Plug-in via EAIs Java interface.
29
Security Limitations

• JRE imposes security limitations on Java Applets.
• JSAPI was unable to establish a connection with
  speech engine unless we explicitly reconfig the
  security settings.

30
Limited VM

• Most VRML Browser s EAI were implemented using
  ActiveX thus only support Microsofts old VM
  which dosent support most modern functions of
  Java.
• ExThis may force us to use Java AWT instead of
  swing which provide better GUI.

31
Providing GUI as VUI Fallback

• GUI provides a fallback in case the speech
  recognizer is having trouble accurately
  transcribing the users voice.
• GUI is adjusted dynamically to provide one-to-one
  correspondence to VUI .

32
Paper 2 Conclusion

• The Speech Interface is needed because GUI and VE
  Viewer both rely on direct manipulation and keep
  our hand too busy.
• As HCI become increasingly multimodel,care must
  be taken to integrate in natural manner.

33
Future Work

• VRML is more close to Object oriented and
  tree-structured.
• It is hard to represent them in RDBMS.
• Must find some way to store model data easily and
  efficiently.

Personal thought Using XML Database.
34
Discussions
35
Q A
