Math 416

1
Math 416
Class Times T, Th 200-315,
MTH0303   Instructor Dennis Healy, 2111
Math Building dhealy_at_darpa.mil
_at_math.umd.edu Textbook Math
for Multimedia
Mladen Victor Wickerhauser Web
www.math.umd.edu/dhealy   Office hours
Tuesdays 1-2, Thursdays 345-445, by appt.
BASICs
Applied Harmonic Analysis Introduction to Signal
Processing
2
Homework

• Read Chapter 1 in text
• Do the following 3 problems
• Prove the orthogonality relations for the cosines
  and sines of period 1

3
Homework (continued)

• If f(t) is a fixed period 2 p function of the
  form
• where the coefficients Ai Bj are assumed to be
  given fixed numbers,
• then show that these coefficients satisfy the
  formulae

f(t) A0/2 A1 Cos( t) A2 Cos(2 t) A3
Cos(3 t) B1 Sin( t) B2 Sin(2 t)
B3 Sin(3 t)
4
Homework (continued)

• Write a program in Mathematica or Matlab that
  computes the best least squares fit to a table of
  sample values input using
• A) Polynomial basis up to some degree input
• B) Bandlimited Fourier basis (sins and cosines)
  up to some degree input
• Output is a table of the best fit coefficients
  and a plot of the data points and fitting curve.
• Make and plot some interesting examples

5
Last time
6
Computational Errors

• To err is human to forgive, divine.

but to really foul up you need a computer..
7
Example Square wave Fit, 2 bases
Polynomial Basis
Sin Basis
8
Mathematica Demo of fitting
Polys
Slider changes order of model (number of sin
terms, bandwidth of fit)
Sins

Order 14 fit
Also played with the precision of the
computations used to obtain the fit.
9
Mathematica Comparison
Sins
Polys

Order 14 fit Order 24 fit
10
Mathematica Comparison
Polys
Sins

Dependence on word length 5 digits of precision
11
Comparison of Designs
64 Samples
Z
Sin
Poly

14 basis elts
24 basis elts
Angle Matrix White 0 Black 60
ZTZ
12
Suggests it is important to think about Errors

• A lot of roundoff errors can happen with the many
  operations in solving a matrix system like the
  one we get with least squares.
• More critical issue for some matrices, very
  small differences in matrix elements can lead to
  big changes in the solutions.
• These are called Ill conditioned systems
• Small roundoff errors and noise can get amplified
  into big errors in the solution.

13
Example Ill-conditioned System
(0,-3)
2x1 x2 3
2.1x1 x2 3
14
Suppose noise /quantization at 1 relative input
error
Output relative error 100
(0,-3)
2x1 x2 3
(.50125,-4.0125)
2.1x1 x2 3
15
Polynomial Basis is Not the best choice for
Numerical work

• Sampled Polynomial Basis elements become
  essentially parallel for even moderate powers.
• Like the two lines in the last example

16
The Point!

• Important to know the limits of digital signal
  processing methods due to errors
• Where does error come from and how can we reduce
  it?
• Model error Capturing the real
  situation in mathematics
• Truncation error Approximating the mathematics
  into a computer
• Numerical error How accurately the computer
  algorithm works
• How do we interpret computational results
• Can we get some idea of how much of our answer is
  bogus?
• Do we know how sensitive our answer is to
  uncertainty in the model?

These issues and related determine if, when, how
we use numerical computations in DSP problems
17
Accuracy Precison in numerical procedures for
approximating desired result

• Error generally arises from the a combination of
  inaccuracy and imprecision

Accuracy unbiased, no systematic error
Precision specificity,small variance
18
Quantifying error
(Absolute) Error The difference between the true
value and the numerical approximation
i.e. Approximation true value true error
Generally more useful to think about the size of
the error in a scale set by the size of number
being approximated
19
ERROR SOURCES

• Truncation error Method dependent
• Errors resulting from the use of an approximation
  rather than an exact mathematical procedure
• Round-off error Machine/Standard dependent
• Errors resulting from being forced to approximate
  numbers.

Eg Error in representing 2 by
1.414
20
Example First Derivatives

• Use forward, backward, central divided difference
  approximations to estimate the first derivative
  of
• at x 0.5 with h 0.5 and 0.25 (exact sol.
  -0.9125)

Results
21
Centered Difference truncation scales best with
refinement
Proof Taylor Polynomial with Remainder

)
(
x
f
i
backward
forward
central
h
i
x i-2 x i-1 x i
x i1 x i2
-
)
(
)
(
x
f
x
f



i
1
i
O(h)
)
(


x
f
forward
i
h
-
)
(
)
(
x
f
x
f


-
O(h)
1
i
i
)
(


x
f
backward
i
h
-
)
2
)
(
)
(
x
f
x
f
O(h


-

)
(

1
i
1
i

x
f
central
i
h
2
22
ERROR SOURCES

• Truncation error Method dependent
• Errors resulting from the use of an approximation
  rather than an exact mathematical procedure
• Round-off error Machine/Standard dependent
• Errors resulting from being forced to approximate
  numbers.

Eg Error in representing 2 by
1.414
23
Round-off Errors

• Computers can represent numbers to a finite
  precision
• Integer math can be exact, but only in a limited
  in range (fixed point)
• Real number math is approximate on computers.
  (floating point)

So how do computers represent numbers? Binary
representation of the integers and real numbers
in computer hardware
24
Binary Signed Integer Representation

• First bit of word indicates the sign 0
  negative (off), 1 positive (on)
• Remaining bits store a number
• Example, 8 bit integer representation of 22

1 0 0 1 0 1 1 0
Sign Integer
( 0 x 26 0 x 25 1 x 24 0 x 23 1
x 22 1 x 21 0 x 20 ) 16 4 2 22
25
Signed Integer Representation

• 8-bit word
• /- 0000000 are the same, therefore we may use
  -0 to represent -128
• Total number of 8 bit integers 28 256 -128
  , 127

• 16-bit word
• Range -32,768 to 32,767
• 32-bit word
• Range -2,147,483,648 to 2,147,483,64

26
Signed Integer Operations

• Signed Integer arithmetic can be exact as long as
  you don't get remainders in division
• Eg 7/2 3 in integer math
• or overflow the maximum integer
• For a 8-bit computer max abs 127 (or -128)
• So 123 45 overflow
• and -74 2 underflow

27
Twos complement binary representation of
integers
Much more common than signed integer
representation
For an N-bit (unsigned) binary representation,
full range of integers is 0,, 2 N -1 Low
half of that range (msb 0) consists of
integers 0,1,, 2 N-1 -1 Obvious
thing to do is use these to represent the
non-negative integers up to 2 N-1 -1 Upper half
of the range (msb 1) consists of integers 2
N-1 , 1 2 N-1 1,, 2 N -1
Can write this set as -2 N-1 , -2
N-1 1,, -1 2 N Equivalent to the set -2
N-1 , -2 N-1 1,, -1 modulo 2 N (up to
multiples of 2 N )
Eg N 8 000000000 to 12701111111
0 0/1 0/1 0/1 0/1 0/1
0/1 0/1
Eg N 8 12810000000 to 25511111111
0 0/1 0/1 0/1 0/1 0/1
0/1 0/1
28
Residue classes and residue arithmetic

• am is a set integers equivalent to a mod m
• a represents this set, but so would a - 527 m
  of course.
• Zm am a in Z
• Eg Z4
• There are m elements in Zm Eg 0 m, 1
  m,,m-1 m
• am bm defined a bm
• Example 34 24 54 14
• -24 -14 -3 4 1
  4
• Likewise multiplication is well defined

29
Twos complement binary representation of
integers
Much more common than signed integer
representation
For an N-bit (unsigned) binary representation,
full range of integers is 0, 2 N -1 Low
half of that range (msb 0) consists of
integers 0,1,, 2 N-1 -1 Obvious thing
to do is use those as our non-negative integers
up to 2 N-1 -1 Upper half of the range (msb
1) consists of integers 2 N-1 , 1 2 N-1 1,, 2
N -1 Can write this set as -2 N-1 ,
-2 N-1 1,, -1 2 N Equivalent to the
set -2 N-1 , -2 N-1 1,, -1 modulo 2 N (up
to multiples of 2 N ) Use the upper half
of the range represents negatives -2 N-1 , -2
N-1 1,, -1
-4 -3-2 -1 0 1 2 3
0 1 2 3 4 5 6 7
Equivalent mod 8
30
Twos complement binary representation of
integers
Heres what it would be for example with 8 bit
representation The positives 0 to 127
represented (usual) using the least significant 7
of the 8 bits
0 1 1 0 0
1 1 1
Eg 103
The negatives of integers 1 to 127 are
represented by their twos complement i.e. -k
is represented as 28 -k 256 - k
Eg find twos complement of - 103
1 0 0 1 1 0
0 0
Flip each bit of 103 (same as 255-103)
1 0 0 1 1
0 0 1
Add 1
153 -103 mod 256
(same as 256-103)
31
Twos complement binary representation of
integers
Much more common than signed integer
representation
For an N-bit (unsigned) binary representation,
full range of integers is 0, 2 N -1 Low
half of that range (msb 0) consists of
integers 0,1,, 2 N-1 -1 Obvious thing
to do is use those as our non-negative integers
up to 2 N-1 -1 Upper half of the range (msb
1) consists of integers 2 N-1 , 1 2 N-1 1,, 2
N -1 Can write this set as -2 N-1 ,
-2 N-1 1,, -1 2 N Equivalent to the
set -2 N-1 , -2 N-1 1,, -1 modulo 2 N (up
to multiples of 2 N ) Use the upper half
of the range represents negatives -2 N-1 , -2
N-1 1,, -1
-4 -3-2 -1 0 1 2 3
0 1 2 3 4 5 6 7
Equivalent mod 8
POINT if we use the N-bit strings but consider
them and operations done on them as being
done modulo 2 N we get many benefits.
Best is that we can add and subtract the
integers within range using same
circuitry since both are done as addition modulo
2 N .
32
Twos complement binary subtraction of integers
Heres subtraction as addition mod 28 in 8 bit
twos complement representation Eg 127 -
103
0 1 1 1 1
1 1 1
127
0 1 1 0 0
1 1 1
103
Know 127 -103 is the same as 127 twos
complement of 103 mod 256
twos complement of - 103 256 -103 153
1 0 0 1 1 0
0 0
153 -103 mod 256
0 0 0 1 1
0 0 0
127 153 Mod 256
24 as expected
33
Other representations of numbers

• We have looked at integer representations for
  computer.
• There are also floating point computer
  representations for real numbers
• Thats what was used in the Mathematica demos we
  looked at.

34
Floating-Point Representation

• Integer representations are exact within some
  bounded range of integers- Real numbers are
  represented differently
• Representation aims for approx. constant relative
  error from tiny fractions to huge numbers
• Store as
• sign is 1 or 0 for negative or positive
• exponent is the power (positive or negative) of
  base (usually 2)
• Significand or mantissa contains significant
  digits

35
A Floating-Point Representation

sign of number
signed exponent mantissa

• m mantissa
• B Base of the number system
• e signed exponent
• Note the mantissa is usually normalized first
  nonzero digit is at decimal point (bit at binary
  point)
• Otherwise representation is not unique.

36
8 digit base 10 example

• 8-place word

sign signed exponent mantissa

10951467 (base B 10) mantissa m
-(110-1 410-2 610-3 710-4 )
-0.1467 signed exponent e (9101 5100)
95

-

95
e
10
1467
0
mB
.
37
8 bit base 2 example
sign signed exponent
mantissa
11011010 base B 2 mantissa m
(12-1 02-2 12-3 02-4 ) ½ 1/8
signed exponent e (021
120) 1

1
e

5/4
2
5/8
mB


38
Attributes of Floating Point Representations

• Range from largest positive float to largest
  negative. Primarily determined by the base B
  and the range of exponents
• Precision determined by number of digits in the
  mantissa (significand)
• Gap between adjacent floats is not constant, as
  it would be for integer or fixed point
• Gap varies to give (roughly) constant relative
  error in representing and numbers in range.
• Overflow number too large to be represented as a
  float (outside range)
• Underflow nonzero number which is too small in
  absolute value to be represented with the given
  representation

39
Visualizing 8 bit base 2 floats
sign signed exponent
mantissa
mantissa
M
0
M
M
Ms
(restrict to positive, positive exponents for the
moment)
40
Range and coverage (positive, positive exponents)
underflow
9/2
9/16 15/16
0
1
1/2
2
4
8 values with steps of 1/8
8 values with steps of 1/16
8 values with steps of 1/4
8 values with steps of 1/2
8 values with steps of 1/16
mantissa
15/8
41
Range and coverage
underflow
underflow
9/2
9/16 15/16
0
0
1
1/2
2
4
8 values with steps of 1/8
8 values with steps of 1/16
8 values with steps of 1/4
8 values with steps of 1/2
8 values with steps of 1/16
mantissa
15/8
42
Range and coverage
underflow
underflow
9/2
9/16 15/16
0
0
1
1/2
2
4
8 values with steps of 1/8
8 values with steps of 1/16
8 values with steps of 1/4
8 values with steps of 1/2
8 values with steps of 1/16
mantissa
15/8
43
Range and coverage
Negative numbers here
Negative exponents let you represent numbers here
underflow
overflow
9/2

15/2
-15/16 -9/16
-1
-2
-1/2
4
8 values with steps of 1/16
8 values with steps of 1/16
8 values with steps of 1/4
8 values with steps of 1/8
8 values with steps of 1/16
8 values with steps of 1/2
mantissa
0
15/8
44
Range and coverage
Negative numbers here
Negative exponents let you represent numbers here
underflow
overflow
9/2

15/2
-15/16 -9/16
-1
-2
-1/2
4
8 values with steps of 1/16
8 values with steps of 1/16
8 values with steps of 1/4
8 values with steps of 1/8
8 values with steps of 1/8
8 values with steps of 1/16
8 values with steps of 1/2
underflow
45
Range and coverage
Negative exponents let you represent numbers here
underflow
overflow
9/2

15/2
-15/16 -9/16
-1
-2
-1/2
4
8 values with steps of 1/16
8 values with steps of 1/16
8 values with steps of 1/4
8 values with steps of 1/8
8 values with steps of 1/8
8 values with steps of 1/2
In General For floating point system w/ base B,
precision p mantissa Only finitely many numbers
can be represented Given x, let fl(x) be the
closest floating point number (round) Can show
relative error of fl(x) for any x between
underflow and overflow is bounded by ½ B1-p
46
Errors in Floating Point Arithmetic

• In addition to the intrinsic errors in
  representing an arbitray number in floating
  point

• Arithmetic is approximate a reasonable model for
  arithmetic combination of floats is
• Form the true arithmetic combination
• Normalize
• Round the mantissa to the allowed precision
• There will in general be round off error

Normalize .10448 x 10 2
Round .1045 x 10 2
47
Errors in Floating Point Arithmetic
Normalize .10448 x 10 2
Round .1045 x 10 2
Error 2 x 10 -2
EG 5227 x 10 1 .5221 x 10 1 .9976 x
10 2 - .1103 x 10 3
This might be an intermediate step in a long
calculation.
Add .9976 x 10 2
48
Errors in Floating Point Arithmetic
Normalize .10448 x 10 2
Round .1045 x 10 2
Error 2 x 10 -2
This might be an intermediate step in a long
calculation. Next step
Add .9976 x 10 2
.1045 x 10 2
Normalize .11021 x 10 3
Round .1102 x 10 3
.9976 x 10 2
1 .1021 x 10 2
Error -1 x 10 -2
49
Errors in Floating Point Arithmetic
This might be an intermediate step in a long
calculation. Next
Subtract .1103 x 10 3

.1102 x 10 3
Normalize -.1000 x 10 0
Only one digit significant at this point
- .1103 x 10 3
- .0001 x 10 3
True cumulative result in exact arithmetic 5227
x 10 1 .5221 x 10 1 .9976 x 10 2 -
.1103 x 10 3
- .0920
Out of 4 digits of precision, only one is
significant after 4 arithmetic operations!
50
Errors in Floating Point Arithmetic
5227 x 10 1 .5221 x 10 1 .9976 x 10
2 - .1103 x 10 3
Try same calculation with a different order of
operations

Try right to left this time!
- .1103 x 10 3
.09976 x 10 3
Normalize -.1054 x 10 2
No need to round
- .01054 x 10 3
Next Add .5221 x 10 1
-.1054 x 10 2
Normalize -.5319 x 10 1
No need to round
- .05319 x 10 2
51
Errors in Floating Point Arithmetic
Working the same calculation with a different
order of ops
5227 x 10 1 .5221 x 10 1 .9976 x 10
2 - .1103 x 10 3

Finally Add .5227 x 10 1
- .5319 x 10
No need to round
Normalize -.9200 x 10 -1
.5227 x 10 1
- .0092 x 10 1
This time, Answer is correct to original
precision
Arithmetic depends on ordering of steps in
floating point
52
Common Floating Point Lingo Single Precision

• bit (binary digit) 0 or 1
• byte 4 bits, 24 16 possible values
• word 2 bytes 8 bits, 28 256 possible values


In single precision, a real variable (number) is
stored in four words, or 32 bits (64 bits for
Supercomputers)
23 for the digits 32 bits 8
for the signed exponent 1 for
the sign
53
Double Precision

• In double precision, a real variable is stored in
  eight words, or 64 bits
• 16 words, 128 bits for supercomputers
• signed exponent ? 210 ? 1024

52 for the digits 64 bits 11
for the signed exponent 1 for
the sign
54
MATLAB

• MATLAB uses double precision
• 4 bytes 64 bits

55
Some things to bear in mind

• Intrinsic errors in representing numbers in
  floating point.
• Arithmetic is approximate a reasonable model for
  arithmetic combination of floats is
• Form the true arithmetic combination
• Normalize
• Round the mantissa to the allowed precision
• There will in general be round off error

Build up of errors in simple combinations
(catastrophic loss of precision) Even in simple
things like repeated adds.
56
function sout SumPrecisionLoss(tenmillions,tick)
Demonstrates loss of precision in repeated
floating point operations Implements a "clock"
which increments "elapsed time" by adding time
increment "tick." Time is displayed every 10
million ticks. User specifies how long to run
the clock by indicating how many "tenmillions"
Error at the end of this time is indicated in
"ticks" For example, tick 100 nanosecs
(.0000001) will show a lot of error in ticks
after not so long, say 100 or 1000 secs.
57
function sout SumPrecisionLoss(tenmillions,tick)
Demonstrates loss of precision in repeated
floating point operations s0 for
m1tenmillions for n110000000 s s
tick end disp( 'iteration ')
disp(nm) sout s end disp( 'iteration
') disp(m107) sout s disp( 'error
in clock ticks') disp ((s -
tenmillions107tick)/tick )
58
Run this clock for 10 billion ticks One tick
.1 microsec, so 1000 seconds
gtgt SumPrecisionLoss(1000,.0000001) iteration
1.000000000000000e010 sout
9.999998790135827e002 error in clock ticks
-1.209864173006281e003
121 microseconds off, or .12 milliseconds
59
The Patriot Missile Failure From Doug Arnolds
website On February 25, 1991, during the
(First) Gulf War, an American Patriot Missile
battery in Dharan, Saudi Arabia, failed to track
and intercept an incoming Iraqi Scud missile.
The Scud struck an American Army barracks,
killing 28 soldiers and injuring around 100 other
people .
A report of the General Accounting office,
GAO/IMTEC-92-26, entitled Patriot Missile
Defense Software Problem Led to System Failure
at Dhahran, Saudi Arabia reported on the cause of
the failure. It turns out that the cause was an
inaccurate calculation of the time since boot due
to computer arithmetic errors in a running sum.
60
Specifically, the time in tenths of second as
measured by the system's internal clock was
multiplied by 1/10 to produce the time in
seconds. This calculation was performed using a
24 bit fixed point register. In particular, the
value 1/10, which has a non-terminating binary
expansion, was chopped at 24 bits after the radix
point. The small chopping error, when
multiplied by the large number giving the time in
tenths of a second, led to a significant error.
Indeed, the Patriot battery had been up around
100 hours, and an easy calculation shows that the
resulting time error due to the magnified
chopping error was about 0.34 seconds. (The
number 1/10 equals 1/241/251/281/291/2121/213
.... In other words, the binary expansion of
1/10 is 0.0001100110011001100110011001100.... Now
the 24 bit register in the Patriot stored instead
0.00011001100110011001100 introducing an error of
0.0000000000000000000000011001100... binary, or
about 0.000000095 decimal. Multiplying by the
number of tenths of a second in 100 hours gives
0.0000000951006060100.34.) A Scud travels
at about 1,676 meters per second, and so travels
more than half a kilometer in this (error) time.
This was far enough that the incoming Scud was
outside the "range gate" that the Patriot
tracked. Ironically, the fact that the bad time
calculation had been improved in some parts of
the code, but not all, contributed to the
problem, since it meant that the inaccuracies did
not cancel.
61
Financial meltdown and poor numerics in
Excel?INQUIRING MINDS WANT TO KNOW!

• Whats 77.1 x 850 ? Dont ask Excel 2007
• 65,535 the Number of the Beast
• By Dan Goodin
• http//www.theregister.co/uk/2007/09/26/excel_200
  7_bug/

62
Perils of computer number representation Ariane 5
French rocket Ariane 501 was scheduled to launch
on the morning of June 4, 1996, from the launch
site in Kourou, French Guiana.
Failure of the launch due to the un-manned rocket
exploding after 42 seconds from the time of the
launch.
63
On June 4, 1996 an unmanned Ariane 5 rocket
launched by the European Space Agency exploded
just forty seconds after its lift-off from French
Guiana                                    The
rocket was on its first voyage, after a decade of
development costing 7 billion. The destroyed
rocket and its cargo were valued at 500 million.
A board of inquiry investigated the causes of the
explosion and in two weeks issued a report. It
turned out that the cause of the failure was a
software error in the inertial reference system.
Specifically a 64 bit floating point number
relating to the horizontal velocity of the rocket
with respect to the platform was converted to a
16 bit signed integer. The number was larger than
32,767, the largest integer storeable in a 16 bit
signed integer, and thus the conversion failed.
(from Doug Arnolds web site)
