NOTES: Ionic Bonding and Ionic Compounds CH 15

1
NOTES Ionic Bonding and Ionic Compounds (CH 15)
2
Valence Electrons

• ? Knowing electron configurations is important
  because the number of valence electrons
  determines the chemical properties of an element.
• ? Valence Electrons The e- in the highest
  occupied energy level of an elements atoms.

3
(No Transcript)
4
Valence Electrons

• ? All elements in a particular group or family
  have the same number of valence electrons (and
  this number is equal to the group number of that
  element)
• Examples
• ? Group 1 elements (Na, K, Li, H) 1 valence e-.
• ? Group 2 elements (Mg, Ca, Be) 2 valence e-.
• ? Group 17 (7A) elements (Cl, F, Br) 7 valence
  e-.

5
(No Transcript)
6
LEWIS STRUCTURES

• ? Electron dot structures show the valence
  electrons as dots around the elements symbol
• ? Li
• ? B
• ? Si
• ? N
• ? O
• ? F
• ? Ne

7
LEWIS STRUCTURES

• ? Electron dot structures show the valence
  electrons as dots around the elements symbol
• ? Li
• ? B
• ? Si
• ? N
• ? O
• ? F
• ? Ne

8
(No Transcript)
9
Which elements form ionic compounds and which
elements form covalent (molecular)
compounds?? General Rule of Thumb metal
nonmetal IONIC metal polyatomic anion
IONIC polyatomic cation anion
IONIC nonmetal nonmetal(s) COVALENT
10
Why are ionic compounds so stable?

• ? IONIC BONDS
• -metal plus a nonmetal
• -cations plus anions
• -opposite charges attract
• ? Examples
• ? Na and Cl- form NaCl
• ? Al3 and Br- form AlBr3

11
Ionic Bonds

• Isnt it ionic that opposites attract?

12
OCTET RULE

• ? Noble gas atoms are very stable they have
  stable electron configurations. In forming
  compounds, atoms make adjustments to achieve the
  lowest possible (or most stable) energy.
• ? Octet rule atoms react by changing the number
  of electrons so as to acquire the stable electron
  structure of a noble gas.

13
Formation of Cations and Anions

• ? can be predicted using the octet rule (not
  always followed, but a good general rule to
  follow for the representative elements)
• -full outer energy level
• -eight electrons (s2p6)
• explains formation of both cations and anions

14
CATIONS

• ? Na 1s2 2s2 2p6 3s1
• ? Na
• ? Mg 1s2 2s2 2p6 3s2
• ? Mg2

15
CATIONS

• ? Na 1s2 2s2 2p6 3s1
• ? Na 1s2 2s2 2p6
• ? Mg 1s2 2s2 2p6 3s2
• ? Mg2 1s2 2s2 2p6

16
OCTET RULE

• ? Atoms of METALS obey this rule by losing
  electrons.
• Na
• Na

17
OCTET RULE

• ? Atoms of METALS obey this rule by losing
  electrons.
• Na
• Na

18
ANIONS

• ? Cl 1s2 2s2 2p6 3s2 3p5
• ? Cl-
• ? O1s2 2s2 2p4
• ? O2-

19
ANIONS

• ? Cl 1s2 2s2 2p6 3s2 3p5
• ? Cl- 1s2 2s2 2p6 3s2 3p6
• ? O 1s2 2s2 2p4
• ? O2- 1s2 2s2 2p6

20
OCTET RULE

• ? Atoms of NONMETALS obey this rule by gaining
  electrons.
• Cl
• Cl-

21
OCTET RULE

• ? Atoms of NONMETALS obey this rule by gaining
  electrons.
• Cl
• Cl-

22
OCTET RULE

• ? Transition metals are exceptions to this rule.
• Example silver (Ag) ? Ag
• By losing one electron, it acquires a relatively
  stable configuration with its 4d sublevel filled
  (pseudo noble-gas)

23
OCTET RULE

• ? Transition metals are exceptions to this rule.
• Example silver (Ag) ? Ag
• By losing one electron, it acquires a relatively
  stable configuration with its 4d sublevel filled
  (pseudo noble-gas)

24
IONIC BONDS

• ? Anions and cations have opposite charges
• ? Ionic compounds are electrically neutral groups
  of ions joined together by electrostatic forces.
  (also known as salts)
• ? the positive charges of the cations must equal
  the negative charges of the anions.
• ? use electron dot structures to predict the
  ratios in which different cations and anions will
  combine.

25
(No Transcript)
26
(No Transcript)
27
Examples of Ionic Bonds

• Na Cl
• Al Br
• K O
• Mg N
• K P

NaCl- NaCl
Al3Br- AlBr3
KO2- K2O
Mg2N3- Mg3N2
KP3- K3P
28
(No Transcript)
29
Properties of Ionic Compounds

• ? must contain an ionic bond
• ? crystalline solids at room temperature
• ? ions are arranged in repeating 3-D patterns
• ? high melting point
• ? melted or dissolved in water they conduct
  electricity

30
Metallic Bonds

• ? METALS made up of closely packed cations
  surrounded by mobile valence electrons

31
Metallic Bonds

• ? METALLIC BOND attraction of free-floating
  (mobile) valence electrons for the positively
  charged metal ions (sea of electrons around the
  cations)
• ? Explains properties of conductivity of
  electricity, malleability, and ductility

32
(No Transcript)
33
Metallic Properties

• ? CONDUCTIVE can conduct electricity because
  electrons can flow freely in them
• ? DUCTILE can be drawn into wires
• ? MALLEABLE can be hammered or forced into
  different shapes
• WHY??...the sea of free-flowing electrons
  insulates the metal cations from each other so
  they slide easily past one another.

34
ALLOYS

• ? most metallic items we use every day are not
  pure metalsthey are ALLOYS.
• ? ALLOYS mixtures composed of 2 or more
  elements, at least one of which is a metal.
• ? prepared by melting a mixture of the
  ingredients together and then cooling

35
(No Transcript)
36
ALLOYS

• Examples
• ? BRASS Cu Zn
• ? STERLING SILVER Ag Cu
• ? BRONZE Cu Sn
• ? CAST IRON Fe C
• ? STAINLESS STEEL Fe, Cr, C, Ni
• ? SURGICAL STEEL Fe, Cr, Ni, Mo
