Creating Animations

1
Creating Animations

• Lesson 7

2
Objectives

• Add a reusable animation symbol to the Library
  panel.
• Create animation by using frames.
• Preview and edit animations by using onion
  skinning.
• Control the playback of frame animations.
• Automate the animation process with tweening.
• Export an animation as an animated GIF file.
• Optimize your animation settings by using Export
  Preview.
• Import and export symbols for use in other files.

3
Create animations in Fireworks MX

• You can create animations in Fireworks MX and
  export them as animated GIFs.
• You can create an animation in two ways
• Tweening With this method, you create the
  starting and ending frames of the animation and
  Fireworks MX automatically creates the
  intervening frames.
• Frame-by-frame You can create each frame of the
  animation yourself, one frame at a time.

4
Use animation symbols

• If you are creating an animation in Fireworks MX
  that you want to use more than once, create it as
  an animation symbol.
• Once the animation is in the symbol library, you
  can add as many instances of the symbol as you
  want to your document.
• Changes made to the symbol are reflected in all
  instances of the symbol, but changes made to an
  instance do not affect the master copy in the
  library.
• Symbols can also be exported for use in Web sites
  or other Fireworks MX documents.

5
Create an animated symbol

• To create an animated symbol from a new or
  existing object
• Select the object to be converted.
• Click the Modify menu, point to Symbol, then
  click Convert to Symbol.
• Assign a name to the symbol, click the Animation
  option, and click OK to open the Animate dialog
  box.
• Specify the number of frames, then set the Move
  and Direction options and other settings as
  required.
• Click the OK button.
• If you see a message that frames need to be added
  for the animation, click OK.

6
Create a frame-by-frame animation

• To animate an object moving across the screen
• Select the object and make as many duplicates of
  the object as you need for your animation.
• Space them on the screen in the direction of the
  animation, then select all objects.
• Click the Distribute to Frames button on the
  Frames panel, and each object will be placed on a
  frame of its own.
• Click Frame 1 (if necessary) and click the Play
  button at the bottom of the window. You will see
  your object march across the screen.

7
Example of frame-by-frame animation
The figure on the left shows nine copies of a
compass image spaced across the screen. When
selected and distributed to frames, the Frame
panel (right-side figure) shows that a separate
frame was created for each object.
Distribute to Frames button
8
Use onion skinning to edit your animation

• When you have created your animation, the onion
  skinning technique can help you refine it and
  adjust it.
• Onion skinning allows you to see objects in
  frames before and after the current frame without
  having to skip back and forth.
• This is helpful in aligning objects and
  repositioning objects so your animation will look
  as expected.
• Turn onion skinning on with the Onion Skinning
  button in the Frames panel.

9
Onion skinning options
The figure on the left below shows the Onion
Skinning button and the pop-up menu where you can
choose the option you want to use. The Before and
After option shows the current frame, plus the
previous and the next frame. The figure on the
right shows the Frame panel. The vertical bar in
the left column shows the before frame, the
current frame, and the after frame.
Onion Skinning menu Onion Skinning button
10
Control the playback of your animation

• The frame delay determines how long each frame is
  displayed when played.
• To control the playback frame delay
• Select all frames of the animation.
• Click the Frame panels Options menu, then click
  Properties.
• Enter the frame delay value in the Frame Delay
  box.
• Frame delays are specified in hundredths of a
  second.
• You can also set a looping value if you want your
  animation to play repeatedly.
• Click the GIF Animation Looping button on the
  Frames Panel.
• Choose a loop value (or No Looping) from the
  pop-up menu.

11
Create animation with tweening

• Let Fireworks do the animating for you using
  tweening. You create the first frame and the last
  frame and Fireworks does the rest.
• Select the object to be animated and convert it
  to a symbol.
• Drag another instance of the symbol to the canvas
  and position it where it should be for the last
  frame of the animation.
• Edit it to make any other changes that are
  required.
• Select both instances, click the Modify menu,
  point to Symbol, then click Tween Instances.
• Enter a value for the number of steps, click
  Distribute to Frames, and click OK.
• Fireworks creates the frames between the start
  and end frame.

12
Export a GIF animation

• Once your animation is complete in Fireworks MX,
  it can be exported for use in a Web page. To do
  so
• Click the Window menu and then Optimize to open
  the Optimize panel.
• Select Animated GIF as the file format.
• Set the Indexed Palette to WebSnap Adaptive or
  Web Adaptive.
• Click the File menu, then Export. Assign a name
  for the file, and select Images Only in the Save
  As box.
• Click the Save button to export the image.

13
The Optimize panel for an animated GIF
This figure shows the Optimize panel for a file
being exported as an animated GIF image.
14
Optimize your image using Export Preview

• You can choose default settings when exporting
  your file or set custom settings in the Export
  Preview window.
• One option you can set is the disposal method,
  which determines what happens to the previous
  frame when the next frame is loaded. Disposal
  methods you can choose include
• Unspecified Creates the smallest possible
  animated GIF file.
• None Use for full-frame animations and for
  frame optimization and transparency.
• Restore to background Use when moving an object
  across the screen.
• Restore to Previous Use when animating objects
  across a background image within the animation.

15
The Export Preview window
In addition to the disposal method, the Export
Preview window allows you to set many other
options to optimize your image. This window shows
a preview of the image using the current settings.
16
Import and Export symbols

• Once an animation is created as a symbol, it can
  be exported from the library for use in another
  document.
• You can export all symbols in the library or just
  selected symbols.
• Exporting all symbols allows you to import the
  entire library for one document into some other
  Fireworks MX document.
• To export one or all symbols, click the Options
  menu in the Library panel, click the Export
  Symbols option, choose Select All or some other
  option from the menu, and then click Export.

17
The Import Symbols dialog box
This figure shows the Import Symbols dialog box.
To open this from a Fireworks MX document, click
the Options menu in the Library panel and then
click Import Symbols. Locate the file to import.
You can select all symbols in the file or just
selected symbols.
18
Summary

• In this lesson, you learned
• How to add a reusable animation symbol to the
  Library panel.
• To create animation by using frames.
• To preview and edit animations by using onion
  skinning.
• How to control the playback of frame animations.
• How to automate the animation process with
  tweening.
• How to export an animation process with tweening.
• How to export an animation as an animated GIF
  file.
• How to optimize your animation settings by using
  Export Preview.
• How to import and export symbols for use in other
  files.
