Chapter 25 Biomolecules: Carbohydrates

1
Chapter 25Biomolecules Carbohydrates
2
The Importance of Carbohydrates

• Carbohydrates are
• widely distributed in nature.
• key intermediates in metabolism (sugar).
• structural components of plants (cellulose).
• key components of industrial products (wood,
  fibers).
• key components of food sources (sugar, flour).

3
Chemical Formula

• Carbohydrates are highly oxidized.
• They have approximately as many oxygen atoms as
  carbon atoms.
• Carbons of carbohydrates are usually bond to an
  alcohol and hydrogen atom therefore, the
  empirical formula is roughly (C(H2O))n.

D Glucose (C6H12O6)
4
Sources of Carbohydrates

• Glucose is produced in plants from CO2 and H2O
  via photosynthesis.
• Plants convert glucose into other small sugars
  and polymers (cellulose, starch).
• Dietary carbohydrates provide the major source of
  energy required by organisms.

5
Classifications of Carbohydrates

• Monosaccharide simple sugars that can not be
  converted into smaller sugars by hydrolysis
• Carbohydrate (Oligosaccharide, Polysaccharide)
  two or more simple sugars connected as acetals
• Sucrose disaccharide of two monosaccharides
  (glucose linked to fructose)
• Cellulose polysaccharide of several thousand
  glucose units connected by acetal linkages

6
Aldose and Ketose

• The prefixes aldo- and keto- identify the nature
  of the carbonyl group.
• Aldo carbonyl is located at the end of the
  chain
• Keto carbonyl is located within the chain
• The suffix -ose denotes a carbohydrate.
• The number of carbons is indicated by the root.

7
Aldose and Ketose
8
Fischer Projections

• Carbohydrates have multiple chiral centers.
• A chiral center carbon is projected into the
  plane of the paper and other groups are drawn as
  horizontal and vertical lines.
• The oxidized end of the molecule is always up
  on the paper.

9
Fischer Projections
10
Minimal Fischer Projections

• In order to work with the structure of an aldose
  more easily, only the essential components are
  shown.
• An alcohol is designated by a - and a carbonyl
  is designated by an ?.
• The terminal OH in the CH2OH is not shown.

11
Stereochemical References

• The reference compounds for stereochemistry are
  the two enantiomers of glyceraldehyde (C3H6O3).
• The stereochemistry depends on the hydroxyl group
  attached to the chiral center farthest from the
  oxidized end of the sugar.
• D hydroxyl group is on the right
• L hydroxyl group is on the left

12
Stereochemical References
13
The D Sugar Family
14
D and L Sugars

• The two enantiomers of glyceraldehyde were first
  identified by their opposite rotation of plane
  polarized light.
• Naturally occurring glyceraldehyde rotates light
  in a clockwise rotation and is denoted as .
• The enantiomer rotates light counterclockwise and
  is denoted as -.
• The direction of the rotation of light does not
  correlate to structural features.

15
Configurations of Aldoses

• Because R and S designations are difficult to
  work with when multiple chiral centers are
  present, the D,L designations are used with
  aldoses.

16
Aldotetrose

• Aldotetroses have two chiral centers therefore,
  there are two pairs of enantiomers.
• There and four sterioisomeric aldotertroses.

17
Aldopentose

• Aldopentoses have three chiral centers, four
  enantiomers and eight stereoisomer.
• Only D enantiomers are shown.

18
Aldohexose

• Aldohexose has eight pairs of enantiomers
  allose, altrose, glucose, mannose, gulose, idose,
  galactose, talose.

19
Hemiacetal Formation

• Alcohols add reversibly to aldehydes and ketones
  to form hemiacetals.

20
Hemiacetals in Sugar

• Intramolecular nuclephillic addition creates a
  cyclic hemiacetal in sugars.
• Five- and six-membered rings are stable.
• The formation of a cyclic hemiactal creates an
  additional chiral center creating two
  diasteromeric forms called anomer, which are
  designated a and ß.
• a the OH at the anomer center is on the same
  side as the hydroxyl that determines D,L naming
  in the Fischer projection
• ß the OH at the anomer center is on the
  opposite side of the hydroxyl that determines D,L
  naming in the Fischer projection

21
Fischer Projections of Anomers
22
Williamson Ether Synthesis

• Treatment with a alkyl halide in the presence of
  a base
• Silver oxide is used as a catalyst for
  base-sensitive compounds.

23
Glycosides

• Carbohydrate acetals are named by sighting the
  alkyl group and replacing the -ose ending of the
  sugar with -oside.
• Glycosides are stable in water therefore, they
  require an acid catalyst for hydrolysis.

24
Glycoside Formation

• Treatment of a monosaccharide hemiacetal with an
  alcohol and an acid catalyst yields an acetal in
  which the anomeric -OH has been replace with an
  -OR group.

25
Reduction of Monosaccharides

• Treatment of an aldose or ketose with NaBH4
  reduces it to a polyalcohol (alditol).

26
Oxidation of Monosaccharides

• Br2 in water is an effective oxidizing reagent
  for converting an aldose to an aldonic acid
  (carboxylic acid).

27
Maltose and Cellobiose

• Maltose two D-glycopyranose units with a
  1,4-a-glycoside bond
• Formed from the hydrolysis of starch
• Cellobiose two D-glycopyranose units with a
  1,4-ß-glycoside bond
• Formed from the hydrolysis of cellulose

28
Lactose

• Lactose 1,4-D-galactopyranosyl-D-glucopyranoside

• Lactose is a disaccharide that occurs naturally
  in milk.
• Lactose is cleaved during digestion to form
  glucose and galactose.

29
Sucrose

• A disaccharide that hydrolyzes to glucose and
  fructose.

30
Cellulose

• Cellulose thousands of D-glucopyranosyl
  1-4-ß-glucopyranosides
• Cellulose molecules form a large aggregate
  structure held together by hydrogen bonds.

31
Starch

• Starch 1,4?-?-glupyranosyl-glucopyranoside
  polymer
• Starch is digested into glucose
• Starch is made of two components
• Amylose
• insoluble in water 20 of starch
• Amylopectin
• soluble in water 80 of starch

32
Glycogen

• Glycogen is a polysaccharide that serves the same
  energy storage function in animals that starch
  does in plants.
• Glycogen is highly branched and contain up to
  100,000 glucose units.
