Title: Overview of the Airport Safety Data Program


1
Overview of the Airport Safety Data Program
2
OFFICE OF AIRPORTS Mission
  • To collect airport data
  • To give the airport data
  • to Air Traffic

3
OFFICE OF AIR TRAFFIC Mission
  • To publish the
  • airport data and all other
  • aeronautical data

4
OFFICE OF AIRPORTS
  • Has three programs for collecting airport data
  • Airport Safety Data Program
  • (aka the 5010 Program)
  • Obstruction Evaluation/Airport
  • Airspace Analysis Program
  • (aka the OE/AAA Program)
  • Airport GIS Program
  • (GIS Geographic Information Systems)

5
OFFICE OF AIR TRAFFIC
  • Has one program for publishing aeronautical data
  • Aeronautical Information Services
  • Aeronautical Information Services is
  • the single authoritative government source
  • for collecting, validating, storing, maintaining
  • and disseminating aeronautical data concerning
  • the United States and its territories to support
  • real-time aviation activities.

6
Airport Safety Data Program Mission
  • The Airport Safety Data Program is a
  • pro-active program whose mission is
  • to collect airport data through the
  • inspection of all civil public use
  • airports, and a mail solicitation to all
  • private use airports, and to give the
  • airport data to Air Traffic.

7
Airport Safety Data Program
  • FAA AC 150/5200-35 Submitting The Airport Master
    Record In Order To Activate a New Airport
  • FAA Order 5010.4 Airport Safety Data Program

8
Obstruction Evaluation/Airport Airspace Analysis
Program Mission
  • To receive airport
  • proposals from airport
  • operators and proponents
  • To analyze the airport
  • proposals
  • To provide the results
  • of the proposals to the
  • airport operators and
  • proponents

9
OE/AAA Program
  • internet Obstruction Evaluation/Airport Airspace
    Analysis (iOE/AAA) database
  • FAA Order 7400.2 Procedures for Handling Airspace
    Matters
  • AC 70/7460-1 Obstruction Marking and Lighting
  • Form 7460-1 Notice of Proposed Construction or
    Alteration
  • Form 7460-2 Supplemental Notice
  • Form 7480-1 Notice of Landing Area Proposal

10
Airport GIS Program Mission
  • To collect airport surveying data.

However this program and its web site is planned
to be the one stop shopping program and web
site for the collection and storage of all
airport data.
11
Airport GIS Program
  • FAA AC 150/5300-16 GENERAL GUIDANCE AND
    SPECIFICATIONS FOR AERONAUTICAL
  • SURVEYS ESTABLISHMENT OF GEODETIC CONTROL AND
    SUBMISSION TO THE
  • NATIONAL GEODETIC SURVEY
  • FAA AC 150/5300-17 GENERAL GUIDANCE AND
    SPECIFICATIONS FOR AERONAUTICAL
  • SURVEY AIRPORT IMAGERY ACQUISITION AND SUBMISSION
    TO THE NATIONAL
  • GEODETIC SURVEY
  • FAA AC 150/5300-18 GENERAL GUIDANCE AND
    SPECIFICATIONS FOR SUBMISSION OF
  • AERONAUTICAL SURVEYS TO NGS FIELD DATA
    COLLECTION AND GEOGRAPHIC
  • INFORMATION SYSTEM (GIS) STANDARDS PLANNING
    GUIDANCE ONLY

12
Airport Safety Data Program SUMMARY
  • The role of the Airport Safety Data Program
  • To collect airport non-airspace
    non-surveying data
  • To give the airport data to Air Traffic
  • Not the role of the Airport Safety Data Program
  • To collect or analyze the airport airspace data
    that is
  • analyzed in the Airspace Program
  • To collect the airport surveying data that is
    collected
  • in the Airport GIS Program

13
Airport Safety Data Program
  • GCR Associates is a contractor with the Office
    of Airports, Airport Safety Data Program
  • GCR Associates provides technical assistance in
    giving the FAA the airport inspection data to
    Air Traffic electronically
  • GCR Associates also provides a wide range of
    administrative services to the FAA Office of
    Airports
  • http//www.gcr1.com/5010web

14
Airport Safety Data Program
Form 5010-1 is used for existing public use
airports Form 5010-2 is used for existing
private use airports
15
FAA Form 5010-1
  • Form 5010-1 is a computer report
  • downloaded from Air Traffics NASR
  • database.
  • Form 5010-1 was designed in an easy to
  • read format in order to enable the reader
  • to view airport data conveniently at a
  • glance.
  • Form 5010-1 may also be used as a
  • planning document.
  • Form 5010-1 also serves as a checklist
  • for conducting airport inspections.

16
FAA Form 5010-2
  • Form 5010-2 may be used as
  • a planning document.
  • Form 5010-2 may be used for
  • mail solicitation for private use
  • airports.

17
FAA Form 5010-1
  • Today you have the option of
  • downloading the airport data
  • contained in Form 5010-1
  • electronically and you may view
  • the airport data in an excel
  • spreadsheet or in any format
  • you want.
  • http//nfdc.faa.gov/index.jsp

18
OE/AAA Program
  • The mission of the OE/AAA Program is to conduct
    aeronautical
  • studies so as to analyze obstacle data /and/ on
    airport
  • construction proposals /and/ airport airspace
    matters.
  • These aeronautical studies analyze the impact of
    airport
  • construction and potential hazards to navigation
    on the National
  • Airspace System.

19
FAA Form 7480-1
  • 14 CFR Part 157 Required notice shall be
    submitted
  • on Form 7480-1 from each person who intends to do
  • any of the following
  • 1. Establish a new airport.
  • 2. Add or modify or delete a runway.
  • 3. Add or modify or delete a taxiway on a public
    use airport.
  • 4. Abandon an airport.
  • 5. Abandon a taxiway.
  • 6. Change the status of an airport from private
    use to public use and from public use to private
    use.
  • 7. Change status from IFR to VFR or from VFR to
    IFR.
  • 8. Establish or change any traffic pattern or
    traffic pattern altitude or direction.

20
Airport GIS Program
  • This programs web site will ensure that airport
    surveying data is collected, processed and made
    available for airport use and airport planning
    and instrument apch procedure development.
  • This program provides guidance on the proper
    collection and submission of airport surveying
    data to the National Geodetic Service for
    validation.
  • This programs web-based application will also
    allow airport operators and their consultants
    access to detailed technical guidance on the
    performance and accuracy requirements of airport
    and aeronautical surveys.

21
SUBMITTAL OF AIRPORT DATA
  • It is the responsibility of the airport operator
    to make sure that the airport data shown in the
    Airport/Facility Directory is current and
    correct.
  • It is the responsibility of the airport operator
    to submit changes to airport data to the FAA in a
    timely manner.
  • How?

22
SUBMITTAL OF AIRPORT DATA FOR OBLIGATED AIRPORTS
  • Submit surveying data directly on line at
  • HTTP//AIRPORTS-GIS.FAA.GOV
  • TPSS is opnl and uses UDDF based on FAA 405
    specifications
  • AGIS is under development based on AC
    150/5300-18B
  • Submit changes to all other airport data directly
    to Air Traffics
  • Aeronautical Information Services by email using
    the following
  • email address
  • 9-ATOR-HQ-AIS-AIRPORTCHANGES_at_FAA.GOV
  • You must insure that AIP funded airspace data
    was ALP
  • approved and you include wording in your email
    message
  • showing that the data was analyzed and approved
    during the
  • ALP process.

23
SUBMITTAL OF AIRPORT DATA FORNON-OBLIGATED
AIRPORTS
  • Submit surveying data on line at
  • HTTP//AIRPORTS-GIS.FAA.GOV
  • TPSS is opnl and uses UDDF based on FAA 405
    specifications
  • AGIS is under development based on AC
    150/5300-18B
  • Submit changes to all other airport data directly
    to Air Traffics
  • Aeronautical Information Services by email using
    the following
  • email address
  • 9-ATOR-HQ-AIS-AIRPORTCHANGES_at_FAA.GOV
  • You must insure that airspace data (see FAA
    Form 7480-1)
  • was first airspaced and you include the airspace
    case number
  • in your submittal

24
FAA INSP
50 STATES
GCR
AIRSPACE
ARPT GIS
5010
APT- NAV- AIR- IAP- CARTO
Aeronautical Information Services
25
AIRPORT OPERATORS
FAA INSP
50 STATES
AIRPORT GIS
APT- NAV- AIR- IAP- CARTO Aeronautical
Information Services
26
Aeronautical Information Services
  • The mission of Aeronautical Information Services
  • To publish airport data
  • To publish navaid data
  • To publish airspace data
  • To publish instrument apch proc data
  • To publish airport diagrams

27
Aeronautical Information Services
  • What does the National Airspace System look like
    on paper?
  • One major component of the NAS is a database
    called the NASR database.
  • What is the National Airspace System Resources
    (NASR) database?
  • Its a third-degree normalized relational
    data model database containing over 1000 tables.

In other words, NASR is an incredibly complex
database.
28
NASR database contents
  • Runway data
  • Remarks data
  • Navaids data
  • Airspace Fixes
  • Holding Patterns
  • Victor Airways
  • Airport data
  • Jet Airways
  • Parachute jump areas
  • US Location identifiers
  • Canadian Loc ids
  • Mexican Loc ids
  • Preferred Routes
  • Restricted Areas
  • Special Use Airspace
  • Military Opns areas

And on and on and on
29
NASR database has two purposes
  • To publish safety critical aeronautical
    information
  • To generate computer reports for planning and
    programming

30
NASR database computer reports
  • The NASR database generates two kinds of
    computer reports
  • Ad hoc reports
  • Pre-canned reports

31
NASR database ad hoc reports
  • Here are two examples of ad hoc computer reports
    downloaded from Air Traffics NASR database

A list of all the airports in the State of
Pennsylvania with a 5,000 ft hard surface runway
and an instrument approach procedure A list of
all the airports in the State of Pennsylvania
alphabetically by airport name
32
NASR database pre-canned reports
  • Here are four examples of pre-canned computer
  • reports downloaded from the NASR database

Airport Master Record (Form 5010-1) Airport
Master Record (Form 5010-2) FAA Order JO 7350.8
Location Identifiers List of all the Airports
in the USA
33
Aeronautical Information Services
  • Where can I get NASR aeronautical
  • data for free?
  • http//nfdc.faa.gov/index.jsp
  • How often is the data on this site
  • updated?
  • It is updated every 56 days on the effective
  • date of every 56-day airspace cycle.

34
Aeronautical Information Services
  • See the inside cover of any AFD for airport and
    airspace cut-off schedules.
  • See the inside cover of any AFD for instructions
    on how and to whom to submit corrections to the
    airport data shown in the AFD
  • 9-ATOR-HQ-AIS-AIRPORTCHANGES_at_FAA.GOV
  • Address
  • Phone number
  • Fax number
  • email address

35
Aeronautical Information Services
  • If you need to submit changes to the Airport
    Diagram, use this email address

9-AWA-ATS-Diagrams_at_FAA.GOV
36
FAA HQ WASHINGTON DC
  • Where is the staff that updates Air Traffics
    NASR database physically located?
  • At FAA HQ Washington DC, Office of Air Traffic,
    Aeronautical Information Services

37
Aviation System StandardsNational Aeronautical
Charting Office (NACO)
  • NACO publishes and distributes United States
    government civil aeronautical charts and flight
    information publications.

38
USEFUL WEB SITES
  • FAA Airport Owner and Manager Info and other
    Airport Data http//www.faa.gov/airports_airtraf
    fic/airports/airport_safety/airportdata_5010/
  • FAA Aeronautical Information Services
    http//www.faa.gov/about/office_org/headquarters_o
    ffices/ato/service_units/systemops/aaim/organizati
    ons/aeronautical_im/aero_info_svcs/
  • FAA National Aeronautical Charting Office
    http//www.naco.faa.gov/
  • Airport Master Records airport data
    http//www.gcr1.com/5010web/
  • Aviation organizations (alphabet groups)
    http//www.faa.gov/airports_airtraffic/air_traffic
    /publications/ifim/organizations/
  • digital AFDs http//naco.faa.gov/index.asp?xmlna
    co/online/d_afd
  • digital Airport Diagrams http//naco.faa.gov/inde
    x.asp?xmlnaco/online/d_tpp
  • FAA Forms http//www.faa.gov/library/forms/

39
  • Questions?
Write a Comment
User Comments (0)
About PowerShow.com
