Title: Click here to proceed.


1
PHARMACEUTICAL SOLID DOSAGE FORMS
2
  • Drug product means a finished dosage form, e.g.,
    a tablet or capsule that contains a drug
    substance (active ingredient), generally, but not
    necessarily, in association with one or more
    other ingredients.

3
VARIOUS ROUTES OF ADMINISTRATION
  • ORAL
  • - SUBLINGUAL
  • PARENTERALS (bypasses GIT)
  • INJECTIONS
  • DERMAL
  • INHALATION
  • OTIC
  • OPTHALMIC
  • RECTAL, VAGINAL

4
DOSAGE FORMS
Various Dosage Forms available
  • ORAL
  • Tablets
  • Capsules
  • Powders
  • Liquid (Syrups, Elixirs Suspensions)
  • Lozenges / Pastilles/ Trouches

PARENTERALS Injectables (IM, IV, Infusion,
) Aerosols Dermatologicals (Creams, Ointments)
Pesaries, Suppositories Bougies Eye/ Ear/ Nose
drops
5
Solid dosage forms
  • Tablets
  • Capsules
  • Powders
  • Lozenges, Pastilles
  • Suppositories

6
Solid dosage forms
  • Tablets
  • Solid dosage forms, of varying weight, size, and
    shape, which may be molded or compressed, and
    which contain a medicinal substance in pure or
    diluted form. (Dorland, 28th ed)

7
Solid dosage forms
  • Capsules
  • A solid dosage form in which the drug is
    enclosed in a hard or soft soluble container,
    usually of a form of gelatin.
  • - Hard gelatin capsules (Powder filled, enteric
    coated pellets called as SPANSULES)
  • Soft gelatin capsules

8
Solid dosage forms
  • Powders - Substances made up of an aggregation of
    small particles, as that obtained by grinding or
    trituration of a solid drug. (From Dorland,
    28th ed)

9
Solid dosage forms
  • Lozenges/ Pastilles
  • A oral solid preparation containing one or more
    medicaments, usually in a flavored, sweetened
    base which is intended to dissolve or
    disintegrate slowly in the mouth.
  • They are placed in the mouth where they slowly
    dissolve and liberate the active ingredient.
    They can contain antiseptics, antibiotics, local
    anaesthetics etc for a topical effect and also
    substances for a systemic effect e.g. vitamins.

10
Solid dosage forms
  • Suppositories
  • Medicated dosage forms that are designed to be
    inserted into the rectal, vaginal, or urethral
    orifice of the body for absorption. Generally,
    the active ingredients are packaged in dosage
    forms containing fatty bases such as cocoa
    butter, hydrogenated oil, or glycerogelatin that
    are solid at room temperature but melt or
    dissolve at body temperature.

11
Importance of oral dosage form
  • Oral route of administration employed for 90 of
    the drugs used to produce the systemic effect
  • Important point considered by the pharma company
    before going to the further development stages
  • Ability for Self-administration criteria affects
    the sales of the drug
  • Unit dosage forms (one usual dose of drug is
    accurately placed)
  • Unlike liquid dosage forms given in multidose
    containers and asked to take with the
    teaspoon/tablespoon
  • Chances of error in the Dosage Measurement when
    given in liquid dosage form

12
TABLETS
  • Advantages of Tablets
  • tamper proof dosage form
  • greatest dose precision and least content
    variability
  • low cost compared to other dosage forms
  • product identification is simple
  • ease of administration
  • can be manufactured with certain release patterns
  • best properties of chemical, mechanical and
    microbiological stability
  • ease of manufacturing

13
TABLETS
  • Disadvantages of Tablets
  • Some drugs resist compression into dense compacts
    owing to their amorphous nature, low density
    character.
  • Bitter tasting drugs may need encapsulation.
  • Drugs with poor wetting, slow dissolution
    properties impossible to formulate as they
    increase the absorption in the GIT

14
Tablet properties
  • 1) should be elegant having its own identity
    while being free of defects such as chips,
    cracks, discoloration, contamination
  • 2) should have strength to withstand the rigors
    of mechanical shock encountered during
    production, packing, shipping and dispensing.
  • 3) should have the chemical and physical
    stability to maintain its physical attributes
    over time.
  • 4) must be able to release the medicinal agent
    in the body in a predictable and reproducible
    manner.

15
TABLETS
  • Types and Classes of Tablets

Single / Multi layered
  • - Uncoated Tablet

Chewable Tablets
Sublingual Tablets
Effervescent Tablets
Lozenges/ Pastilles
  • - Coated Tablets

Film coated Tablets
Sugar coated Tablets
Enteric coated Tablets
- Sustained Release/ Extended Release/ Controlled
Release Tablets
16
Types of Tablets
  • Multi layered Tablets
  • These are compressed tablets made by one or more
    compression cycles.
  • Chewable Tablets
  • These are compressed tablets made by adding
    sweetners and flavorants so that the tablet can
    be chewed.

17
Types of Tablets
  • Sublingual Tablets
  • These are small flat tablets to be placed below
    the tongue for dissolving rapidly and absorb
    readily.
  • Effervescent Tablets
  • In addition to the drug substance they contain
    sodium carbonate. In presence of water, these
    additives react, liberating carbon dioxide that
    acts as a disintegrator and produces
    effervescense .

18
Types of Tablets
  • Film-coated Tablets
  • These are compressed tablets having a thin layer
    or film of water soluble material. Film coating
    protects materials sensitive to oxidation and
    enhances the look of the product.
  • Sugar-coated Tablets
  • These are compressed tablets having a sugar
    coating. Done to mask the objectionable taste and
    protects materials sensitive to oxidation and
    enhances the look of the product.

19
Types of Tablets
  • Enteric-coated Tablets
  • These are compressed coated tablets with
    substances that resist solution in gastric fluid
    but disintegrate in the intestine. It can be used
    for substances that get destroyed in the stomach,
    for those that irritate the mucosa or as means of
    delayed release of the medicine.

20
Types of Tablets
  • Controlled release/ Sustained release and
    Extended Release Tablets
  • Sustained release
  • A tablet that releases its active ingredient in
    specified doses at timed intervals. Also called
    sustained-release tablets.
  • Delayed Release
  • products are modified-release, but by definition
    are not extended-release. They involve the
    release of discrete amount(s) of drug some time
    after drug administration, e.g. enteric-coated
    products, and exhibit a lag time during which
    little or no absorption occurs.

21
Ingredients used for Tablet manufacture
  • Active ingredient
  • is the main drug
  • Inactive ingredient
  • additional agents added to give shape and size
    and improve the properties of the drug

22
Ingredients used for Tablet manufacture
  • Inactive Ingredients
  • Diluent
  • An inert substance to give bulk to make the
    tablet a practical size for compression (Maize
    Starch, Lactose, Cellulose)
  • Binders/ Granulators
  • Agents used to impart cohesive qualities to the
    powder material. (Maize Starch, gelatin,
    Cellulose)
  • Lubricants
  • Materials added to prevent adhesion of the
    tablet material to the surface of the dies and
    punches, reduce interparticle friction,
    facilitate ejection of the tablet from the die
    cavity (Talc, Magnesium stearate, calcium
    stearate)

23
Ingredients used for Tablet manufacture
  • Glidants
  • Substance which improves the flow
    characteristics of a powder mixture. (Colloidal
    Silicon dioxide, Talc)
  • Disintegrants
  • Substance added to facilitate its break-up or
    disintegration after administration. (Sodium
    starch glycollate, croscarmellose, crospovidone)
  • Colouring agent/ Colorant
  • used either to improve the appearance, or
    control product during its preparation. (FD C
    colourants)
  • Solvents
  • to make granules. (Purified Water, Isopropyl
    Alcohol)

24
Ingredients used for Tablet manufacture
  • Flavouring agent/ Flavorant
  • used for masking taste. (Peppermint, aspartame)
  • Ingredients added for coating
  • Coating agent
  • used to coat the tablet after compression.
    (Hydroxypropyl methyl celllulose, Wincoats)
  • Solvents
  • to dissolve the coating material/ to carry the
    coating material. (Methylene chloride, Isopropyl
    Alcohol)

25
Process of Manufacture of Tablets
  • Dispensing / Weighing
  • The raw materials (active/ inactive ingredients)
    are weighed in the stores in presence of a
    production personnel and the stores incharge and
    dispensed to the production department.
  • Equipment used- Weighing balance
  • Sifting/ Sieving
  • The raw materials (active/ inactive ingredients)
    are sifted through respective sieve to get the
    desired particle size.
  • Equipment used- Mechanical sifter

26
Process of Manufacture of Tablets
  • Mixing / Milling
  • The raw materials (active/ inactive ingredients)
    are mixed in blenders to attain uniform
    distribution. Or they are milled to attain the
    required particle size and then sieved again.
  • Equipments used- Cone blender, Planetary mixer,
    Colloidal mill

27
Process of Manufacture of Tablets
  • Granulation
  • Density may affect compressibility, tablet
    porosity, dissolution and other properties.
    Dense, hard granules require higher compressible
    loads to produce a cohesive compact
  • Strength and Friability Granule is an
    aggregation of component particles held together
    by bonds of finite strength.

28
GRANULATION CHARACTERISTICS
  • Flow Properties
  • may result from forces acting between solid
    particles.
  • Response angle
  • Hopper Flow Rates
  • Compaction (the process of consolidating and
    compacting powder or granule material to form a
    tablet

29
GRANULATION CHARACTERISTICS
  • Particle size and shape
  • Affects weight, weight variation,, disintegration
    time, granule friability, granulation
    flowability, drying rate characteristics of wet
    granulation
  • Depends in-turn upon formulation ingredients,
    concentrations, equipment and processing
    conditions
  • Surface Area
  • Inverse relation normally exists between particle
    size and surface area

30
GRANULATION
  • BASIC CHARACTERISTICS OF TABLET
  • Compactness
  • Physical Stability
  • Rapid Production capability
  • Chemical Stability
  • efficacy
  • for a material to be compressed into the tablet
  • It has to have a fluidity for transport of
    material through the hopper, into and through the
    feed frame and into the dies
  • and compressibility

31
GRANULATION
  • Physical form that allows the tablet material to
    flow smoothly and uniformly is
  • SPHERES
  • Offer minimum contact surface between themselves
    and walls of the machine parts

32
GRANULATION
  • A pharmaceutical process that attempts to improve
    the flow of powdered materials by forming a
    spherelike or regularly shaped aggregates called
    granules. It also converts the mixture of
    powders, which have poor cohesion, into
    aggregates capable of compaction
  • .

33
Manufacture of granulation
  • Compression Granulation
  • Wet Granulation
  • Direct Compression

34
Process of Manufacture of Tablets
  • Types of Granulation
  • 1) Compression granulation/ dry granulation
  • carried out when the drug is sensitive to heat,
    moisture or both. Eg Aspirin or vitamins
  • Formulations are prepared for tabletting by
    compression granulation.
  • Compression granulation involves the compaction
    of the components of a tablet formulation by
    means of tablet press or specially designed
    machinery followed by milling and screening,
    prior to final compression into the tablet.
  • Slugs are formed in the tablet press which are
    then screened or milled to form tabletting
    material.
  • Equipment used- chilsonator

35
Process of Manufacture of Tablets
  • Types of Granulation
  • 2) Wet granulation
  • forms the granules by binding the powders
    together with an adhesive/ binder. The technique
    employs a solution, suspension or slurry
    containing a binder, which is usually added to
    the powder mixture.
  • Once the granulating liquid has been added,
    mixing continues until a uniform dispersion is
    attained and all the binder has been activated.
  • A drying process is required in all wet
    granulation procedures to remove the solvent.
  • Equipment used Mixer granulator (Diosna)

36
Process of Manufacture of Tablets
  • 3) Direct Compression
  • Few crystalline substances such as NaCl, KBr,
    may be compressed directly.
  • done on tablets in which the drug itself
    constitutes the major portion of the total tablet
    weight.
  • the compression of a single ingredient may
    produce tablets that do not disintegrate. Then
    other components are added.
  • A direct compressible diluent is an inert
    substance that can be compacted with little
    difficulty and may compress even when quantities
    of drugs are mixed with it.

37
Process of Manufacture of Tablets
  • Drying
  • Granules are dried at specified temperature for
    specified time.
  • Equipments used - Fluidized Bed drier
  • Lubrication
  • The granules are lubricated with lubricating
    agents.
  • Compression
  • The granules alongwith the glidants, lubricants,
    disintegrants are then compressed to form the
    tablet of desired shape and size.
  • Compression machine
  • Tooling set consists of a die and upper and
    lower punches.
  • Equipments used Rotary compression machines
  • Sent to QC for Analysis


38
(No Transcript)
39
Compression
  • At the start of a compression cycle granulation
    stored in a hopper empties into the feed-frame
    (A), which has several interconnected
    compartments. These compartments spread the
    granulation over a wide area to provide time for
    the dies (B) to fill. The pull down cam (C)
    guides the lower punches to the bottom of their
    vertical travel, allowing the dies to overfill.
    The punches then pass over a weight control cam
    (E), which reduces the fill in the dies to the
    desired amount. A wipe off blade (D) at the end
    of the feed frame removes the excess granulation
    and directs it around the turrent and back into
    the front of the feed-frame. Next, the lower
    punches travel over the lower compression roll
    (F) while simultaneously the upper punches ride
    beneath the upper compression roll (G)

40
Compression
  • The upper punches enter a fixed distance into the
    dies, while the lower punches are raised to
    squeeze and compact the granulation within the
    dies. To regulate the upward movement of the
    lower punches, the height of the lower pressure
    roll is changed. After the moment of compression,
    the upper punches are withdrawn as they follow
    the upper punch raising cam (H) the lower
    punches ride up the cam (I), which brings the
    tablets flush with or slightly above the surface
    of the dies. The exact position is determined by
    a threaded bolt called the ejector knob. The
    tablets strike a sweep-off blade affixed to the
    front of the feed-frame (A) and slide down a
    chute into receptacle. At the same time, the
    lower punches re-enter the pull down cam (C) and
    the cycle is repeated.

41
Process of Manufacture of Tablets
  • Coating
  • Equipment used Coating pans
  • The compressed tablets are then coated with the
    coating agent dissolved in the solvent.
  • Polishing
  • Coated tablets after drying are polished on the
    polishing belt and visually inspected for any
    defects.

42
Flow Chart for Tablet Manufacture
Weighing active / inactive ingredients
Sifting/ Sieving
Direct compression
Mixing/ Milling
Wet granulation/ dry granulation
Drying
Lubrication / Glidant
Lubrication / Glidant
Uncoated
Inspection
Compression
After QC analysis of fp
After QC analysis
Packing
Coating
Polishing
43
Problems during Tablet manufacturing/ processing
  • Chipping
  • Tablets getting chipped from the sides during
    compression.
  • Capping and lamination
  • Capping is term used to describe the partial or
    complete separation of the top or bottom crowns
    of a tablet from the main body of the tablet.
  • Picking and Sticking
  • Picking is used to describe the surface material
    from a tablet that is sticking to and being
    removed from the tablets surface by a punch.
  • Sticking refers to tablet material adhering to
    the die wall.

44
Problems during Tablet manufacturing/ processing
  • Spotting / Mottling
  • Mottling is an unequal distribution of color on
    a tablet, with light or dark areas standing out
    in an otherwise uniform surface.
  • Weight variation
  • The weight of tablet being compressed is
    determined by the amount of granules in the die
    prior to compression.

45
Problems during Tablet manufacturing/ processing
  • Granule size and Size distribution before
    compression
  • Variations in the ratio of small and large
    granules and in the magnitude of difference
    between the granule sizes influence how the void
    spaces between particles are filled. Thus the
    apparent volume in the die is same, different
    proportions of large and small particles may
    change the weight of fill in each die.
  • Punch variation
  • When punches are of different sizes, even small
    difference, the fill in each die varies because
    the fill is volumetric.

46
Problems during Tablet manufacturing/ processing
  • Poor flow
  • When the granules do not flow readily, it tends
    to move spasmodically through the feed frame so
    that the dies are incompletely filled.
  • Poor Mixing
  • Sometimes the lubricants and glidants are not
    thoroughly distributed. The flow of particles is
    then impaired and the granules do not move
    efficiently into the dies.
  • Hardness variation
  • Hardness depends on weigh of material and space
    between the upper and lower punches at the moment
    of compression
  • If the volume of the material or the distance
    between the punches varies hardness is likewise
    inconsistent.
  • Double impression
  • improper punch die movement coordination may
    result in double impression of the monogram or
    engraving on the tablet and hamper its
    appearance.

47
Tests/ Evaluations conducted on Tablets
General Appearance General Appearance of a
tablet, its visual identity and overall elegance
is essential for consumer acceptance. Tablet
size, shape, colour, presence/ absence of an
odour, taste, surface texture, consistency and
legibility of any identifying marks.
Hardness and friability Tablet require certain
amount of strength and resistance to friability
to withstand mechanical shocks of handling in
manufacture, packaging and shipping. Tablet
hardness is the force required to break a tablet
in diametric compression test. Instrument for
Hardness testing Monsanto Hardness
tester. Instrument for Friability testing Roche
friabilator
48
Hardness and friability
  • The hardness of a tablet, like its thickness, is
    a function of the die fill and compression force
  • At a constant die fill, the hardness values
    increase and thickness decreases as additional
    compression force is applied
  • Tablet hardness is not an absolute indicator of
    strength since some formulations, when compressed
    into very hard tablets, tend to cap on
    attrition, losing their crown portions Another
    measure of a tablets strength, its friability,
    is often measured

49
Hardness and friability
  • Another measure of a tablets strength, its
    friability, is often measured
  • Tablets that tend to powder, chip and fragment
    when handled lack elegance and consumer
    acceptance and can create excessively dirty
    processes in such areas of manufacturing as
    coating and packaging
  • They can also add to a tablets weight variation
    or content uniformity problems

50
(No Transcript)
51
(No Transcript)
52
Tests/ Evaluations conducted on Tablets
Weight variation Weight variation is conducted
by weighing 20 tablets individually, Calculating
the average weight and comparing the individual
tablet weights to the average. Instrument used
Weighing balance
  • Content uniformity
  • To check the amount of drug present in each
    tablet. 10 tablets
  • are assayed individually.
  • Factors contributing to content uniformity
  • Non-uniform distribution of the drug throughout
    the powder
  • mixture or granulation stage.
  • 2) Segregation of powder mixture or granulation
    during various
  • manufacturing stages.
  • 3) Tablet weight variation.

53
Tests/ Evaluations conducted on Tablets
  • Disintegration
  • Breakdown of tablet into smaller particles or
    granules.
  • Instrument Disintegration apparatus as per USP/
    BP.
  • Apparatus 6 glass tubes, open at the top and
    held against a 10 mesh screen at the bottom end
    of the basket rack assembly.
  • Method 1 tablet is placed in each of the tube
    and the basket rack
  • Assembly is positioned in water/ simulated
    gastric fluid or simulated
  • Intestinal fluid at 37C 2C, such that the
    tablet remains below the
  • surface of the liquid. A standard motor-driven
    device is used to move the basket assembly
    containing the tablets up and down.
  • All the tablets must disintegrate and all the
    particles must pass through the 10 mesh screen.
  • Sometimes discs may be used on the tablet to
    prevent the tablet from floating.

54
Tests/ Evaluations conducted on Tablets
  • Dissolution
  • Is conducted to determine the rate of drug
    absorption for acidic drug
  • moieties that are absorbed high in the GI tract.
  • Objectives
  • Release of drug from tablet is as close as 100.
  • Rate of drug release is uniform from batch to
    batch.
  • Instrument used USP Apparatus 1 2
  • Apparatus 1
  • Basket type
  • Tablet placed inside the basket, basket is
    immersed into the flask
  • containing the Dissolution medium. The flask is
    cylindrical with a
  • hemispherical bottom. The flask is maintained at
    a temperature
  • at 37C 0.5C. Motor is adjusted for specific
    speed and the samples
  • of fluid are withdrawn at intervals to determine
    the amount of drug in
  • solution.

55
Tests/ Evaluations conducted on Tablets
  • Dissolution contd.
  • Apparatus 2
  • Same as Apparatus 1 except that the basket is
    replaced by a paddle, formed from a blade and a
    shaft as a stirring element. The tablet is
    allowed to sink to the bottom of the flask before
    stirring.
  • The test tolerance is expressed as percentage of
    the labeled amount of drug dissolved in the time
    limit.

56
  • Thank You
Write a Comment
User Comments (0)
About PowerShow.com
