Programming

1
Programming
2
Steps and Stages

• Unix aliases, scripts, emacs
• Programming languages
• Algorithms
• Running codes and handling data
• Analysis
• Astrophysics interpretation

3
Making life more comfortable

• aliases are a great way to get organized and to
  make convenient short-cuts for system-independent
  commands

Examples making human commands
alias dirls -l alias
printlpr alias copycp almost mandatory
alias cpcp
-i alias mvmv -i alias rmrm -i short-cuts
alias
mmore alias xemacs alias
eemacs -nw alias hhistory connection
s alias leo1ssh -X
leo1.aip.de navigation alias CODEcd
HOME/CODE alias RUN1cd scratch/RUN1
4
Connecting to other computer(s)
Use ssh and scp To avoid typing you password
again and again, use ssh-keygen and then ssh-add.
In this case you type your pass only once.
Steps 1)ssh-keygen -t rsa 2)take ...pub file
and scp it to another computer 3)add it to a file
.ssh/authorized-keys(2) 4)run ssh-agent bash on
your computer 5)run ssh-add. You will be prompted
to give passphrase. Next time you login to your
computer make (4) and (5). Your system may be
setup so that you do not need (4). Connection
with the external computer may be slow. To edit
files use emacs -nw, which makes editing
possible with emacs even with very slow
connection. You lose some functionality of emacs
cannot use buttons. Yet, it is better than
using vi.
5
EMACS

• Emacs is a standard editor, which you can find in
  any unix or Mac OS system. It has many options
  and can be adjusted to make your editing more
  efficient.
• The best way to customize emacs is to make
  changes to .emacs

6
(No Transcript)
7
Shell Scripts

• Simulations often create many files. For example,
  code may produce many snapshots.
• Analysis of many snapshots requires special tools
  of handling repetitive tasks
• Archiving and retrieving of many models and
  snapshots

8
Simple example
This script creates a list of snapshots
(variables file1, 2,3). Then it calls executable
PMgalaxy3 many times and feeds it with current
snapshot number. It works fine given the number
of the snapshots is not large. Place the text in
a file run.bat. Make it executable (chmod ax
run.bat). Then just run it as if it is a unix
command run.bat
9

• Programming with Fortran

• Style and rules
• Statements
• Examples
• Compilers and options

10
General Assessment
Fortran is designed for number-crunching. It is
not for problems with sophisticated data
structures or logic. If you follow rules, Fortran
provides a very fast and easy to write code. Do
not use archaic features in Fortran. Fortran is
about speed fast codes is our goal.
11
Before we start coding

• Check formulae and algorithms. It takes very long
  time to develop and to debug a code. If at the
  end we find that there was a mistake in
  equations, we lose too much.
• More efficient algorithm has higher priority
  over pretty code writing.
• Start with clearly defining data structures
  arrays, parameters, files.
• Estimate time needed for code developing 10 -
  design, 10 - write, 80 - debug
• High price for making errors write code nice and
  clear learn how find bugs.

12
Example
Declarations
Main body
Finish
13
The same example in Fortran-90 and C
14
Example Main program
Declarations are in file nbody1.h
Open files
Set parameters
Read data
Analyze and print
15
Example subroutine for direct summation
16
Style and rules

• Write Fortran code as C objects and data flow
  are first, arithmetics is second.
• Top down design start with the top level of the
  code. Write the logic of calls of different
  top-level routines. Then fill the gaps by writing
  routines of lower and lower levels.
• Routines should be short. No side effects. If a
  routine is assigning density of particles to some
  array, do not modify potential.

17
Archaic Features, which should be avoided

• Labels or line numbers should be avoided. Code
  can jump to any label (goto N). Because compiler
  does not know from where you can jump in to the
  labeled statement, it does not do many
  optimizations. This makes code very slow.
• Compilers try to optimize pieces of the code,
  which do not contain labels.
• Do not abuse the rule sometimes it is easier to
  use labels.

18
Implicit statement

• It is often recommended (in strong words) not to
  use Implicit statement. The main motivation is
  that one can make a typo in a name of a variable,
  which is difficult to find. Implicit none is
  recommended for the beginners.
• This recommendation comes from people, who do not
  write large and complicated codes.
• Implicit is a powerful tool, which makes coding
  more efficient. Yet, one should always use it or
  never use it. Do not mix explicit declarations
  and implicit style.
• Always follow implicit rules variables and
  arrays starting with letters (i-n) are INTEGER.
  Do not define Mass as real. aMass is as clear
  as Mass.

19
Writing comments

• Rule Number One write text in such a way that
  just looking at it one sees the structure of the
  code. No comments are needed to understand what
  is written.
• Rule Number Two follow rule N1, but then write
  short comments Always. Write them as you type.
  You will not come back to add a comment.
• Rule Number Three comment every subroutine or
  function by putting dividing lines, which clearly
  separate the text.
• Rule Number Four no dividing lines in the main
  text. Comments should not obstruct the text

20
More on Style calling names

• Use long and natural names for global variables
  and arrays. E.g., Nparticles, Niterations.
• For local temporary variables use short names
  x,y,i,k0
• In a long subroutine one should be careful not
  to use names, which are already in use. You may
  give names, which are obviously temporary tmp,
  dummy
• Use grab to check whether name is used.

21
Formal parameters and common blocks

• Data can be passed to a subroutine either using
  formal arguments ( e.g. CALL MySUB(x,y,z) ) or by
  a common block ( e.g. COMMON /A/x,y,z) )
• Those are very different mechanisms. Formal
  arguments are handled through stack and common
  blocks (also SAVE and ALLOCATE) go to the heap.
  Most of the computer RAM is allocated to the
  heap because by design stack is for small
  things.
• Use formal arguments for small arrays, few
  arguments, and for constructs, which cannot be
  handled by common blocks.

22
Formatting I/O

• Fortran has extensive tools and options to read
  and write files. There is nothing like that in C.

write (,10) a,b,c 10 format(f8.2,f9.2,f10.5)
Format can be given as a separate statement or as
an in-line specification
write (,(f8.2,f9.2,f10.5)) a,b,c
23
Implicit Do loops in formats

• You can write in a file n1 an array Z of length
  N in two ways
• write(5) Z or write(5) (Z(i),i1,N)
• The first form is faster, but the second is more
  flexible if we want to modify it
• write(5) (Z(i),i1,N-5,3)
• More complicated example
• write(5) a,b,c,((Z(i,j),i1,N,10),j2,M/2)

24
Formatting outputs

• To produce nice-looking output tables it is
  convenient to use T format. For example,
• write(,(f8.2,T30,a,g12.3)) r,Density,d
• starts text Density at the position 30. This is
  useful for wide tables with many headers

25
Files

• Formatted and Unformatted
• Sequential and direct access
• positionappend

Unit 20 is attached to sequential, formatted file
myfile.dat
Open(20,filemyfile.dat)
Open(20,filemyfile.dat, formunformatted)
Unit 20 is attached to sequential, unformatted
file myfile.dat
Write x,y,z in to Unit 20. Because it is attached
to file.dat, the write command modifies myfile.dat
write(20,) x,y,z
read(20,,error10,end10) x,y,z
Read from Unit 20. If error of end of file
happen, go to statement labeled 10
Close(20)
26
Compilation
Compile and link
ifort -fast file1.f file2.f -o file.exe
ifort -fast -c file1.f
Compile
ifort -fast -c file2.f
link
ifort -fast file1.o file2.o -o file.exe
27
(No Transcript)
28
(No Transcript)
