Title: PVNET
1HMI CIEMAT ECN GENEC-CEA IMEC JRC
Ispra Siemens Teksolar Uni Hull Uni
Ljubljana Uni Utrecht Würth Solar Uni Warsaw ZSW
- PVNET
- European RTD Roadmap for PV
2Vision
- Objectives
- Development of a coherent, accepted PV strategy
- Giving a basis for a consistent PV support
(RTD, market, education) - on both a European and national level
- A competitive Europe and a sustainable society
- In order to
- Make more efficient use of (public) money
- Maintain the needed high growth rates (25 ?
2010) - Achieve the predicted cost reductions
3Vision
- Role of RD community
- Perspective of PV
- Technological challenges
4Role of RD community
Technology Policy Client
5Perspective of PV Implementation
EPIA Industry Roadmap
2010 EC White Paper 3 GWp gt 27 annual
growth System Cost 2,5 /Wp
6Perspective of PV System Cost
Photex FP5 (IEA) Learning Curve Project
7Approach
- Roadmap One Destination
- Different routes/actors
- RTD Roadmap
- Open discussion platform
- PVNET partners initiating discussions
- - workshops
- - discussion papers
- Close cooperation with other initiatives
- EPIA, PV-EC-NET, a-Si-NET, IPs,
NoEs - Input from all interested parties
- - Website www.pv-net.net
8Structure of the RTD Roadmap
- 10 Chapters
- 0 Introduction
- 1 Wafer technologies (x-Si, III-V
(concentrators)) - 2 Thin films (a/mc-Si, CIS, CdTe)
- 3 Novel devices (DSC, polymers, )
- 4 Common technological issues
- 5 BOS (grid connection, storage and mounting)
- 6 Standardization and harmonisation
- 7 Market implementation
- 8 Socio-economic issues
- 9 Cross Fertilization
9Structure of the RTD Roadmap
- Materials
- 1 State-of-the-art
- - Science (Materials)
- - Technology (Production)
- - Commercial status (2000,2010,2020)
- Volume of module production, cost (break down)
- 2 Bottle-necks
- Short term lt 2005 (Production)
technology - Medium term 2005-2010 ?
- Long term gt 2010 (Materials) science
- 3 RD Priorities Short to long term
10Wafer technologies x-Si
- Status
- 2000 x-Si gt 90 Increasing share! multi-X gt
- 2010 x-Si 80-90
- 2020 x-Si 50 (cast Si, sheets, film-Si)
- Cost reduction slower than expected
- x-Si is not taken over by thin-films soon !
- New investments mainly x-Si
- Lower risk lines can be bought
- Synergy with Si-based electronics industry
- Cast Si wafers ? Si Sheets ? Film Si (merge
with thin films)
11Wafer technologies x-Si
Silicon cost dominant Silicon feedstock
Crystal growth Wafering
12Wafer technologies x-Si
- Bottle-necks
- Silicon is the main cost factor
- Efficient use of (lower grade) Si
- Thin wafers
- Si sheets
- Film Si
- Higher efficiency
- Production is batch-like
- High-throughput inline production processes
- Feedstock is mainly a strategic business issue
13Wafer technologies x-Si
- Priorities
- Issue Ready Priority
- Solar Silicon Feedstock 2005 1
- Process (dep. on crystallisation) 2007 1
- High-throughput sheets 2006 1
- Thin wafers (slicing, processing) 2005 2
- Yield, rear passivation, BSR
- New module design 2008 2
- Alternative encapsulants
- Back-contacted cells
- Materials science 2015 2
- (defects, in-process material improvement)
- New routes that offer lower costs (Solsilc)
14Wafer technologies x-Si
- Priorities
- Issue Ready Priority
- Production technology 2007 2
- Low-cost surface passivation 2007 3
- including heterojunctions
- Low-cost bulk passivation 2006 3
- High-efficiency multi x-Si (20) 2008 3
- New designs, light management, passivation
- Ag-less metallisation schemes 2015 3
- High-throughput processing 2010 3-4 LT
(200 m2/h) - 50 m2- 200 m2 /hour (1-5 wafers/sec)
- In-line characterisation 2004 5
- Recycling of modules and BOS 2010 5
-
15Wafer technologies III-V (concentration)
- Status
- III/V Impressive Efficiencies gt 30 eg
Ge/GaAs/InGaP - Very high Substrate Cost
- gt now space, concentrators route to 3rd
generation - Priorities
- Issue Ready Priority
- Low-cost substrate (e.g. lift-off) 2010 1
- New structures ? gt 40 2020 1 LT !
- High-througput deposition 2015 2
- Low-cost Concentrators 2007 3
- TPV 2010 3
- Chalcopyrite on metal for concentrators 2007
3
16Amorphous and thin film silicon
- Status
- 2000 Most important thin-film
- Chronar low-cost 5 eff. (batch 1
chamber) - United Solar expensive 7 eff.
(roll-to-roll) - Kaneka expensive 9 eff. (batch multi
chamber) - 2010 mc-Si/a-Si 12-15
- 2020 film-Si 15?
- Synergy with glass industry (architectural glass
(ZnO)) - Large-scale production technology
17Amorphous and thin film silicon
- Bottle-necks
- Many issues are in common with other thin-film
options - poor image from the first, a-Si prototypes
- still a relatively low efficiency, (few
exemptions) - expected lifetime
- cost of production equipment
- process control
18Amorphous and thin film silicon
19Compound semiconductors
- Status
- 2000 CIS and CdTe in pilot production phase
- Scaling-up is not trivial
- 2010 5 share ? CIS 12-14 eff.
- CdTe 12 eff.
- 2020 20 share ? CIS 20 eff.
- CdTe 14 eff.
- CdTe Cd perspective
- CIS In, Ga availability
- Synergy with glass industry (architectural glass
(ZnO)) - Large-scale production technology
20Compound semiconductors
- Bottle-necks
- Many issues are in common with a-Si
- Health Safety of some materials as well as
availability - cost of production equipment
- process control
- expected lifetime
- image
21Compound semiconductors
Interfaces and point defects LT 1st
priority
22Compound semiconductors
Back contact ST
23Novel devices
- Status
- 2000 DSC (Gratzel) plans for pilot production
- Polymer, organic molecular cells Lab phase
2010 DSC 1 share ? Liquid version ? - Others lab phase
- 2020 DSC 5 share ?
- Others (pilot) production
- Cost Break down
- DSC glass/TCO, dye, TiO2 (purity)
- Others no data !! materials (purity, complexity
?)
24Novel devices
- Bottle-necks
- DSC Stability (Temp)
- Efficiency
- Polymers Low efficiency yet (3)
- Poor stability
- - Little understanding of the relation
between - structure and properties and how to improve
25Novel devices
- Priorities
- Issue Ready Priority
- Collection of generated carriers 2007 1
- (Lifetime, charge separation,
- mobility, distance)
- Microstructure (processing, stability) 2010
1 - Low-cost materials and processing 2015 1
- non-vacuum (eg printing)
- Stability (oxidation) 2015 1
- Suitable materials 2015 2
- bandgap engineering
- Understanding of interfaces 2020 2
26Common Technological Issues
Manufacturing High
Efficiency Concepts Equipment
Material Research Quality Control
Substrates and TCOs
Encapsulation System Technology
Life Cycle Engineering Building
Integration Standards, Certification
Market
Penetration
27BOS grid connection, storage and mounting
IEA PVPS Task 1
28BOS grid connection, storage and mounting
Standardisation
29BOS grid connection, storage and mounting
- PV to light the world
- PV as a building element
- PV for a better grid
- Bottle-necks
- Mounting Standardisation (ease of mounting)
- Inverter Reliability (lifetime)
- Standardisation
- Flexibility (system lay-out)
- Storage Lifetime
- Health Safety of materials
- Cost
-
30BOS grid connection, storage and mounting
- Priorities
- Issue Ready Priority
- Reliable low-cost inverters 2007 1
- Plug-and-play mounting 2007 1
- Module integrated electronics
- Batteries low-cost non-toxic 2010 1
- Module-integrated
- Grid-connected (UPS, grid quality)
- Standardisation of grid connection
- plugs, islanding, grid quality
- economics
31Conclusion
- The RD Roadmap is based on
- vision of all stakeholders (R, I,G,M)
- the potential of science and technology to
realise it (R,I) - It is a living document gt PV Catapult
- ??
- The value is in the discussion not the paper
32(No Transcript)
33Amorphous and thin film silicon
