A History of Modern Weather Forecasting

1
A History of Modern Weather Forecasting
2
The Stone Age

• Prior to approximately 1955, forecasting was
  basically a subjective art, and not very
  skillful.
• Observations were sparse, with only a few
  scattered ship reports over the oceans.
• The technology of forecasting was basically
  subjective extrapolation of weather systems, in
  the latter years using the upper level flow (the
  jet stream).
• Local weather detailswhich really werent
  understood-- were added subjectively.

3
Upper Level Chart
4
The Development of NWP

• Vilhelm Bjerknes in his landmark paper of 1904
  suggested that NWP was possible.
• A closed set of equations existed that could
  predict the future atmosphere (primitive
  equations)
• But it wasnt practical then because there was no
  reasonable way to do the computations and
  sufficient data for initialization did not exist.

5
Numerical Weather Prediction

• The advent of digital computers in the late 1940s
  and early 1950s made possible the simulation of
  atmospheric evolution numerically.
• The basic idea is if you understand the current
  state of the atmosphere, you can predict the
  future using the basic physical equations that
  describe the atmosphere.

6
Numerical Weather Prediction

• One such equation is Newtons Second Law
• F ma
• Force mass x acceleration
• Mass is the amount of matter
• Acceleration is how velocity changes with time
• Force is a push or pull on some object (e.g.,
  gravitational force, pressure forces, friction)

This equation is a time machine!
7
Numerical Weather Prediction
Using a wide range of weather observations we can
create a three-dimensional description of the
atmosphere known as the initialization
8
Numerical Weather Prediction

• This gives the distribution of mass and allows us
  to calculate the various forces.
• Then we can solve for the acceleration using
  Fma
• But this gives us the future. With the
  acceleration we can calculate the velocities in
  the future.
• Similar idea with temperature and humidity.

9
Numerical Weather Prediction

• These equations can be solved on a
  three-dimensional grid.
• As computer speed increased, the number of grid
  points could be increased.
• More (and thus) closer grid points means we can
  simulate (forecast) smaller and smaller scale
  features. We call this improved resolution.

10
NWP Becomes Possible

• By the 1940s there was an extensive upper air
  network, plus many more surface observations.
  Thus, a reasonable 3-D description of the
  atmosphere was possible.
• By the mid to late 1940s, digital programmable
  computers were becoming availablethe first..the
  ENIAC

11
The Eniac
12
First NWP

• The first successful numerical prediction of
  weather was made in April 1950, using the ENIAC
  computer at Maryland's Aberdeen Proving Ground
• The prediction was for 500 mb height, covered
  North America, used a two-dimensional grid with
  270 points about 700 km apart.
• The results indicated that even primitive NWP was
  superior to human subjective prediction. The NWP
  era had begun.

13
Evolving NWP

• Early 50s one-level baratropic model
• Late 50s Two-level baroclinic QG model (just
  like Holton!)
• 1960s Primitive Equation Models of increasing
  resolution and number of levels.
• Resolution increases (distance between grid
  points decrease) 1958 380 km, 1985 80 km,
  1995 40 km, 2000 22 km, 2002 12 km

14
A Steady Improvement

• Faster computers and better understanding of the
  atmosphere, allowed a better representation of
  important physical processes in the models
• More and more data became available for
  initialization
• As a result there has been a steady increase in
  forecast skill from 1960 to now.

15
Forecast Skill Improvement
National Weather Service
Forecast Error
Better
Year
16
The National Weather Service
Forecaster at the Seattle National Weather
Service Office
