Title: MPLS Architecture


1
MPLS Architecture
  • Gautham Pamu
  • CS590F - Design of MultiService Networks

2
Goals of MPLS
  • Scalability of network layer routing.
  • Using labels as a means to aggregate forwarding
    information,while working in the presence of
    routing hierarchies.
  • Greater flexibility in delivering routing
    services.
  • Using labels to identify particular traffic which
    are to receive special services, e.G. QoS.
  • Increased performance.
  • Using the label-swapping paradigm to optimize
    network performance.

3
Goals of MPLS
  • Simplify integration of routers with cell
    switching based technologies.
  • Making cell switches behave as routers.
  • By making information about physical topology
    available to network layer routing procedures.

4
Motivation Behind MPLS
  • MPLS improves internet scalability by eliminating
    the need for each router and switch in a packet's
    path to perform traditionally redundant address
    lookups and route calculation.
  • Improves scalability through better traffic
    engineering.
  • MPLS also permits explicit backbone routing,
    which specifies in advance the hops that a packet
    will take across the network.
  • This should allow more deterministic, or
    predictable, performance that can be used to
    guarantee QoS.

5
Introduction to MPLS
  • These paths function at layer 3 or can even be
    mapped directly to layer 2 transport such as ATM
    or frame relay.
  • Explicit routing will give IP traffic a semblance
    of end-to-end connections over the backbone.
  • The MPLS definition of IP QoS parameters is
    limited.
  • Out of 32 bits total, an MPLS label reserves just
    three bits for specifying QoS.

6
Introduction to MPLS
  • Label-switching routers (LSRs) will examine these
    bits and forward packets over paths that provide
    the appropriate QoS levels. But the exact values
    and functions of these so-called 'experimental
    bits remain to be defined.
  • The MPLS label could specify whether traffic
    requires constant bit rate (CBR) or variable bit
    rate (VBR) service, and the ATM network will
    ensure that guarantees are met.

7
MPLS Architecture
MPLS Egress Node
MPLS Ingress Node
8
Labels
  • A label is short, fixed length physically
    continuous identifier which is used to identify a
    FEC ( forwarding equivalence class), usually of
    local significance.
  • Ru can transmits a packet labeled L to Rd, if
    they can agree to a binding between label L and
    FEC F for packets moving from Ru to Rd.
  • Ru (upstream LSR) ? Rd (downstream LSR with
    respect to a given binding).
  • L becomes Rus outgoing label representing FEC
    F, and L becomes rds incoming label
    representing FEC F.
  • Rd must make sure that the binding from label to
    FEC is one-to-one.

9
Labels
  • Rd must not agree with Ru1 to bind L to FEC F1,
    while agreeing with some other LSR Ru2 to bind L
    to a different FEC F2, unless rd can always tell,
    when it receives a packet with incoming label L,
    whether the label was put on the packet by Ru1 or
    Ru2.

L for FEC F1
Ru1
Rd
L for FEC F2
Ru2
10
Labeled Packet
  • A packet into which a label has been encoded.
  • The label resides in an encapsulation header
    which exists specifically for this purpose.
  • Or the label may reside in a existing data link
    or network layer header.
  • The particular encoding technique which is used
    must be agreed to by both the entities which
    encodes the label and the entity which decodes
    the label.

11
Label Assignment and Distribution
  • The decision to bind a particular label L to a
    particular FEC F is made by the LSR which is
    downstream with respect to that binding.
  • The downstream LSR informs the upstream LSR of
    the binding.
  • The labels are downstream assigned and label
    binding are distributed in the downstream to
    upstream direction.

12
Label Distribution Protocols
  • It is set of procedures by which one LSR informs
    another LSRs of the bindings (label/FEC) it has
    made.
  • Two LSRs which use a distribution protocol to
    exchange label/FEC binding information are known
    as label distributing peers with respect to the
    binding information they exchange.
  • There exists many different distribution
    protocols ( MPLS- BGP, MPLS-RSVP,
    MPLS-RVSP-TUNNELS, MPLS-CR-LDP).

13
Unsolicited Downstream Vs. Downstream-on-demand
  • Downstream-on-demand label distribution.
  • An LSR explicitly request (a label binding for
    that FEC ),from its next hop for a particular
    FEC.
  • Unsolicited downstream label distribution.
  • LSR distribute bindings to LSRs that have not
    explicitly requested them.
  • Both these label distribution techniques can be
    used in the same network at the same time.
  • Which protocol is provided by the MPLS
    implementation depends on the characteristics of
    the interfaces which are supported by a
    particular implementation.

14
Label Retention Mode
  • An LSR Ru receives a label binding for a
    particular FEC from an LSR Rd, even though Rd is
    not Rus next hop. Ru then has the choice of
    whether to keep track or discard it.
  • Liberal label retention mode.
  • It maintains the bindings.
  • Allows for quicker adaptation to routing changes.
  • Conservative label retention mode.
  • It discards such bindings.
  • Requires an LSR to maintain many few labels.

15
The Label Stack
  • Label stack carries a number of labels organized
    as a last-in, first out stack.
  • The processing is always based on the top label.
  • An unlabeled packet can be thought as a packet
    whose label stack is empty.

L1
L2
Packet
L3
16
NHLFE
  • NHLFE (Next Hop Label Forwarding Entry) is used
    when forwarding a labeled packet.
  • It contains the following information.
  • The packets next hop.
  • The operation to perform on the packets label
    stack.
  • Replace the label at the top of the label stack
    with a specified new label.
  • Pop the label stack.
  • Replace the label at the top of the label stack
    with a specified new label, and then push one or
    more specified new labels onto the label stack.

17
Incoming Label Map (ILM)
  • Maps each incoming label to a set of NHLFEs.
  • Used when forwarding packets that arrive as
    labeled packets.
  • Exactly one element of set must be chosen before
    the packet is forwarded.
  • It is used to load balance over multiple
    equal-cost paths.

Set of NHFLE
Label
18
FEC-to-NHFLE Map (FTN)
  • FTN maps each FEC to a set of NHFLEs.
  • It is used when forwarding packets that arrive
    unlabeled, but are labeled before being
    forwarded.

Set of NHFLE
FEC
19
Label Swapping
  • In order to forward a labeled packet, a LSR
    examines the label at the top of the label stack.
    It uses the ILM to map this label to an NHLFE.
  • Using the information in the NHFLE, it determines
    where to forward the packet, and performs an
    operation on the packets label stack. It then
    encodes the new label stack into the packet, and
    forwards the result.

20
Label Swapping
  • In order to forward an unlabeled packet, a LSR
    analyzes the network layer header, to determine
    the packets FEC. It then uses FTN to map this
    label to an NHFLE.
  • Using the information in the NHFLE, it determines
    where to forward the packet, and performs an
    operation on the packets label stack. It then
    encodes the new label stack into the packet, and
    forwards the result.

21
Uniqueness of Labels
  • A given LSR Rd may bind label L to FEC F1, and
    distribute that binding to label distribution
    peer Ru1. Rd may also bind a label to FEC F2, and
    distribute that binding to label distribution
    peer Ru2. If RD can tell when it receives a
    packet whose top label is L, whether the label
    was put there by RU1 or RU2, then the
    architecture does not require that F1F2.
  • Rd may be using different label space for the
    labels it distributed to Ru1 than to Ru2.

22
LSP, LSP Ingress, LSP Egress
  • A label switched path (LSP) of level m for a
    particular packet P is a sequence of routers.
  • ltR1, ., Rngt
  • With following properties
  • R1, the LSP ingress, is an LSR which pushes a
    label onto Ps label stack, resulting in a label
    stack of depth m.
  • For all I, 1lt I lt n, P has a label stack of depth
    m when received by LSR Ri.
  • At no time during Ps transit from R1 to rn-1
    does it label stack ever have a depth of less
    than m.

23
LSP, LSP Ingress, LSP Egress
  • A label switched path (LSP) of level m for a
    particular packet P is a sequence of routers.
  • Which begins with an LSR ( an LSP ingress) that
    pushes on a level m label.
  • All of whose intermediate LSRs make their
    forwarding decision by label switching on a level
    m label.
  • Which ends ( at an LSP egress) when a
    forwarding decision is made by label switching on
    a level m-k label, where k gt 0 or when a
    forwarding decision is made by ordinary,
    non-MPLS forwarding procedures.

24
Penultimate Hop Popping
  • If ltR1, , Rngt is level m LSP for packet P, P may
    be transmitted from rn-1 to Rn with a label
    stack of depth m-1. That is, the label stack may
    be popped at the penultimate LSR of the LSP,
    rather than at the LSP egress.
  • Once rn-1 has decided to send the packet to Rn,
    the label no longer has any function, and need no
    longer be carried.
  • Allows the egress to do a single lookup, and also
    requires only a single lookup by the penultimate
    node.
  • In this case, LSP egress need not even be an LSR.

25
Penultimate Hop Popping
  • There may be situations when penultimate hop
    popping is not desirable.
  • Therefore the penultimate node pops the label
    stack only if this is specifically requested by
    the egress node.
  • Or
  • If the next node in the LSP does not support MPLS.

26
LSP Next Hop
  • The LSP next hop for a particular labeled packet
    in a particular LSR is the LSR which is the next
    hop, as selected by the NHFLE entry used for
    forwarding that packet.
  • The LSP next hop for a particular FEC is the next
    hop as selected by the NHFLE entry indexed by the
    label which corresponds to that FEC.
  • The LSP next hop may differ from the next hop
    which would be chosen by the network layer
    routing algorithm.

27
Invalid Incoming Labels
  • What should an LSR do if it receives a labeled
    packet with a particular incoming label, but has
    no binding for that label ?
  • It must be discarded.
  • It is not safe to strip off the label and the
    packet is forwarded as an unlabeled packet.
  • It could cause a loop.

28
Independent LSP Control
  • Independent LSP control each LSR, upon noting
    that it recognizes a particular FEC, make an
    independent decision to bind a label to that FEC
    and to distribute that binding to its label
    distribution peers.
  • Similar to conventional IP datagram routing,
    where each node makes an independent decision as
    to how to treat each packet, and relies on the
    routing algorithm to converge rapidly so as to
    ensure that each datagram is correctly delivered.

29
Ordered LSP Control
  • Ordered LSP Control an LSR only binds a label
    to a particular FEC if it is the egress LSR for
    that FEC, or if it has already received a label
    binding for that FEC from its next hop for that
    FEC.
  • To ensure that traffic in a particular FEC follow
    a path with some specified set of properties,
    ordered control must be used.
  • It has to be initiated either by the egress or
    the ingress LSR.

30
LSP Control
  • To have ordered control all LSRs in an LSP
    should use ordered control otherwise the overall
    effect on the network behavior is largely that of
    independent control, since one cannot be sure
    that an LSP is not used until it is fully setup.
  • Both methods interoperate.
  • A given LSR needs support of only one or other.

31
Aggregation
  • In MPLS Domain, all the traffic in a set of FECs
    might follow the same route.
  • Example a set of distinct address prefixes
    might all have the same egress node. In such
    case, the union of those FECs it itself a FEC.
  • The procedure of binding a single label to a
    union of FECs which is itself a FEC, and applying
    that label to all traffic in the union is known
    as Aggregation.
  • It reduces the no of labels and reduces the
    amount of label distribution control traffic
    needed.

32
Whose Granularity Is Used ?
  • In ordered control each LSR should adopt, for a
    given set of FECs, the granularity used by its
    next hop for those FECs.
  • In independent control it is possible that
    there will be two adjacent LSRs, Ru and Rd, which
    aggregate some of FECs differently.

33
Granularity of Aggregation
  • If Ru has finer granularity than Rd, this does
    not cause a problem.
  • Ru distribute more labels for that set of FECs
    than Rd does. This means that when Ru needs to
    forward labeled packets in those FECs to Rd, it
    may withdraw the set of n labels into m labels,
    where n gt m. Or it may with draw the set of n
    labels it has distributed and then distribute a
    set of m labels.

34
Granularity
  • If Ru has coarser granularity than Rd, it has two
    choices.
  • It may adopt Rds finer level of granularity,
    This would require it to withdraw m labels it has
    distributed and distribute n labels.
  • It may simply map its m labels into a subset of
    Rds n labels, if it can determine that this will
    not produce the same routing.

35
Route Selection
  • Route selection refers to the method used for
    selecting the LSP for a particular FEC.
  • Hop by Hop Routed LSP each node independently
    choose the next hop for that FEC.
  • Explicitly routed LSP each LSR does not
    independently choose the next hop, rather, a
    single LSR, generally the LSP ingress or the LSP
    egress, specifies several of the LSRs in the LSP.

36
Advantages of Explicit Routing
  • It is useful for policy routing and traffic
    engineering.
  • The explicit route has to be specified at the
    time that labels are assigned, but the explicit
    route does not have to be specified with each IP
    packet.
  • It makes MPLS explicit routing much more
    efficient than the alternative of IP source
    routing.

37
Lack of Outgoing Label
  • If a labeled packet reaches an LSR at which the
    ILM does not map the packets incoming label into
    an NHFLE, even though the incoming label is
    valid.
  • Discard the packet to be safe
  • It is unsafe to strip off the label stack and
    attempt to forward the packet further via
    conventional forwarding, based on its network
    layer header.

38
TTL
  • Provides some level of protection against
    forwarding loops that exist due to
    misconfigurations or due to failure or slow
    convergence of the routing algorithm.
  • It also supports traceroute commands and
    multicast scoping.
  • The MPLS label values are carried in an
    MPLS-specific shim header.
  • If the MPLS labels are carried in an L2 header,
    such as ATM header or a frame relay

39
Loop Control
  • On a non-TTL LSP Segment, TTL cannot be used to
    protect against forwarding loops.
  • It depends on the hardware used to provide the
    LSR functions along the non-TTL LSP segment.
  • Example ATM hardware is used to provide MPLS
    switching function, with the label being carried
    in the VPI/VCI field. Since ATM switching
    hardware cannot decrement TTL, there is no
    protection again loops.
  • If it provides fair access to the buffer pools
    for incoming labels, this looping may not cause
    deleterious effect on other traffic otherwise
    even transient loops may cause severe degradation
    of the LSRs total performance.

40
Label Encoding
  • Architecture supports different encoding
    techniques, the choice of encoding technique
    depends on the particular kind of device being
    used to forward labeled packets.
  • MPLS-specific hardware/software to forward
    packets.
  • To encode the label stack, we need to define a
    new protocol to be used as a shim between the
    data link layer and network layer headers.
  • It is protocol independent, used to encapsulate
    any network layer.

41
ATM switches as LSRs
  • MPLS forwarding procedures are similar to those
    legacy label swapping switches such as ATM
    switches.
  • ATM switches use the input port and the incoming
    VPI/VCI value as the index into a switching
    table, from which they obtain the output port and
    an outgoing VPI/VCI value.
  • If one or more labels can be encoded directly
    into the fields which are accessed by these
    switches, then the switches can be used as LSRs.

42
Encoding labels in ATM Cell header
  • SVC Encoding
  • Use the VPI/VCI to encode the label which is at
    the top of the label stack.
  • Can be used in any network.
  • Label distribution protocol becomes ATM
    signaling.
  • ATM LSRs cannot perform push and pop
    operation on the label stack.

43
Encoding labels in ATM Cell header
  • SVP Encoding
  • Use VPI field to encode the label which is at the
    top of the label stack and VCI field to encode
    the second label on the stack.
  • Cannot always be used, when the network includes
    an ATM Virtual path through a non-MPLS ATM
    network.
  • Since VPI field is not necessarily available for
    use by MPLS.

44
Encoding labels in ATM Cell header
  • SVP Multipoint Encoding
  • Use the VPI field to encode the label which is at
    the top of the label stack, use part of the VCI
    field to encode the second label on the stack, if
    one is present, and use the remainder of the VCI
    to identify the LSP egress.
  • It enables us to do label merging, without
    running into cell interleaving problems, on ATM
    switches which can provide multipoint-to-point
    VPs, but which do not have the VC merge
    capability.

45
Switching Table
  • VPI/VCI label is looked up in switching table
  • Output port is chosen
  • VPI/VCI is relabeled
  • VPI/VCI has local significance only

VPI.in
VCI.in
Port.in
VPI.out
VCI.out
Port.out
46
ATM Switching example
Port 1
Port 1
(2,1)
(3,1)
(2,1)
Port 1
Port 1
(1,1)
(2,1)
(1,1)
(2,2)
(1,2)
(1,2)
(2,2)
Port 2
Port 2
(1,3)
(4,1)
Port 1
Port 1
(2,1)
(4,2)
(1,1)
Port 2
Port 2
(4,1)
(2,1)
(4,2)
(4,2)
(1,3)
Port 2
Port 2
47
Interoperability Among Encoding Techniques
  • If ltR1, R2, R3gt is a segment of a LSP, it is
    possible that R1 will use one encoding of the
    label stack when transmitting packet P to R2 but
    R2 will use a different encoding when
    transmitting a packet P to R3.
  • Architecture supports LSPs with different label
    stack encoding used on different hops.
  • ATM switches have no capability of translating
    from one encoding technique to another.

48
Interoperability Among Encoding Techniques
LSR with SHIM interface
LSR
L1
P
P
L2
LSR
The LSR may swap off an ATM encoded label stack
on the Incoming interface and replace With MPLS
shim header
The LSR may swap off an MPLS shim encoded label
stack on the Incoming interface and replace With
ATM encoded label
LSR
LSR with ATM Interface
49
Label Merging
  • With label merging, the no of outgoing labels per
    FEC need only be one.

L1 for FEC F
LSR
L1
L2 for FEC F
LSR
LSR
L2
L4
L4
L4
LSR
L3
With label merging the no of outgoing Labels per
FEC need only be one.
L3 for FEC F
50
Merge over ATM
  • Methods to eliminate the cell interleaving
    problem in ATM.
  • VP Merge, using the SVP Multipoint Encoding
  • Multiple virtual paths are merged into a virtual
    path, but packets from different sources are
    distinguished by using different VCIs with the
    VP.
  • VC Merge
  • Switches are required to buffer cells from one
    packet until the entire packet is received.

51
Applications of MPLS
  • MPLS and Hop by Hop Routed Traffic
  • MPLS and Explicitly Routed LSP
  • MPLS and Multicast
  • MPLS and Multi-Path Routing

52
Diff-Serv and MPLS
  • Two major IETF standardization efforts are making
    IP QoS a reality. Sometimes perceived as rivals.
  • Both are in fact complementary developments that
    approach the QoS challenge from two different
    network perspectives.
  • DiffServ and MPLS are in fact independent
    developments that can function with or without
    each other's help. Neither specification requires
    the other, but MPLS networks should be able to
    derive QoS status from DiffServ traffic.
  • There is hope that they can be used together as
    access (DiffServ) and backbone (MPLS)
    counterparts.

53
Diff-Serv
  • DiffServ is a layer 3 solution that addresses QoS
    requirements in a connectionless environment.
  • Its main purpose is to standardize a set of QoS
    building blocks with which providers can fashion
    QoS-enhanced IP services.
  • DiffServ QoS is meant to be implemented at the
    network edge by access devices and then supported
    across the backbone by DiffServ-capable routers.
  • Since it operates purely at layer 3, DiffServ can
    be deployed on any layer 2 infrastructure.
    DiffServ and non-DiffServ routers and services
    can be mixed in the same environment.

54
Conclusion
  • MPLS is a strategy for streamlining the backbone
    transport of IP packets across a layer 3/layer 2
    network. Although it does involve QoS issues,
    that is not its main purpose.
  • MPLS is focused mainly on improving internet
    scalability through better traffic engineering.
  • MPLS will help to build backbone networks that
    better support QoS traffic, but it entails
    significant changes in existing network
    architecture.

55
Conclusion
  • MPLS is essentially a hybrid of the network
    (layer 3) and transport (layer 2) structure, and
    may represent an entirely new way of building IP
    backbone networks.
  • In the near term, DiffServ may have more
    relevance. It tackles IP QoS head-on, and it
    provides mechanisms for achieving both access QoS
    and backbone QoS across the network.
  • The specification is drafted, early
    implementations of the technology have proven
    stable for over half a year, and standards-based
    products will soon be available.

56
Conclusion
  • MPLS, on the other hand, is not expected to reach
    RFC status until some time later this year.
    Backed by established and emerging players, such
    as Cisco systems, inc. And juniper networks,
    inc., MPLS should become a major element of
    internet backbone growth next year.
Write a Comment
User Comments (0)
About PowerShow.com
