A Quick Introduction to GIS

1
A Quick Introduction to GIS
2
What is GIS?

• Definition Analysis that combine relational
  databases with spatial interpretation and outputs
  often in form of maps. A more elaborate
  definition is that of computer programs for
  capturing, storing, checking, integrating,
  analyzing and displaying data about the earth
  that is spatially referenced.

3
A GIS Map Contains Layers

• A GIS map is made up of layers, or collections of
  geographic objects that are alike.
• To make a map, you can add as many layers as you
  like.

4
Layers Contain Features or Surfaces

• Each geographic object in a layer --- each city,
  river, lake, or country --- is called a feature.
• Not all layers contain features. A single
  continuous expanse that changes from one location
  to another is called a surface.

5
Features Have Shape and Size

• Features can be represented as one of three
  geometric forms
• A polygon
• A line
• A point
• This kind of data is called vector data.

6
Surfaces have Numeric Values Rather that Shapes

• Surfaces have measurable values for any
  particular location on the earth
• This is raster dataa matrix of identically sized
  cells where each cell contains a measurement for
  that location.

7
Features Have Location

• GIS uses a coordinate system to associate
  features with location
• These coordinate systems make use of Geodetic
  datums

8
Features can be Displayed at Different Sizes

• Zoom and out changes the scale of the map
• Scale is the relationship between the size of the
  features on the map and their size in the
  physical world.

9
Features are Linked to Information

• Information about the features in a layer is
  stored in a table.
• The table has a row for each feature and the
  columns values are attributes of that feature

10
Tables

• The links between features and their attributes
  makes it possible to query and display the
  results on the map.

11
Thematic Maps

• You can use attributes to create thematic
  maps---maps in which colors (or other symbols)
  are used to indicate attribute values.

12
Features have Spatial Relationships

• You can also ask questions about spatial
  relationship among features.
• GIS uses coordinate information to compare
  locations

13
You can Create New Features

• GIS can look for areas of overlap between
  features of different layers and create new
  features to identify these areas.

14
ArcMap and ArcCatalog
ArcCatalog is the data management Application.
ArcMap is the application for making maps and
analyzing data.
