TROLLEYE

1
TROLLEYE
Observe
Communicate
Detect

• Click to add subtitle

Intelligent Video and Sensor based Surveillance
and Security
1
2
TrollEye Observe
3
TrollEye Detect
4
TrollEye Alarm
5
TrollEye Architecture
Observe
Communicate
Detect
TrollEye Visual Surveillance environment
Selectable action modules
Selectable image aquisition modules
Selectable Surveillance modules
6
TROLLEYE
Observe
Communicate
Detect

• The camera or communications can be activated by
• by the Trolleye advanced motion or non motion
  detection software
• any sensor like smoke detectors, microphones,
  etc.

7
TROLLEYE
Observe
Communicate
Detect

• Accepts any sensors with USB interfaces
• Easy to set up detection routines (AND/ OR
  function)
• Example Do not give alarm until smoke detector,
  microphone or motion detector is activated,
• Multi-sensor handling not in all Trolleye
  versions

8
TROLLEYE
Observe
Communicate
Detect

• Trolleye advanced motion or non-motion detection
  algorithms has
• a low rate of unwanted alarms
• adaptable alarm windows (multi alarm windows)
• intelligent detection of
• object size
• direction of movement
• time lapse

9
TROLLEYE
Detect
Observe
Communicate

• Alarm warning directly to your Mobile Phone
• Alarm picture can be sent directly to your PC by
  e-mail
• Smart alarm storage and communication makes it
  possible to observe what happens before and after
  the incident
• Use of MMS/SMS messaging technology

10
TROLLEYE
SOME APPLICATIONS

• Homes
• Gas stations
• Stores
• Banks
• Post Offices
• Industrial Sites
• Military Bases
• Traffic control
• Border Control
• Parking lots
• Airports
• Railroads
• Etc.

11
TROLLEYE
QA

• Can Trolleye - S/W run on old analog camera

  installations?
• Yes, they can be upgraded to a smart TrollEye
  single system or network without re-cabling the
  existing installation(s) of the analog cameras.
• Can Trolleye - S/W convert existing analog (dumb)
  CCTV systems into smart digital systems?
• Yes, by using over the shelf converter!
• Can the existing analog installation(s) run in
  parallel with the digital installations?
• Yes, if you want!

12
TROLLEYE
Conclusion.

• Provides instant detection and observation
• Requires NO new cabling
• Lets the existing analog camera network run in
  parallel
• Allows for additional multi-sensor alarm
  functions with AND/OR functions for cameras and
  communication
• Instant communication by e-mail or SMS to PC or
  mobile phone
• Storage of the incident sequence on your file
  server
