NPDES Permit Compliance Action Plan

1
NPDES Permit Compliance Action Plan

• Presentation to the
• Galt City Council
• January 24, 2006

2
This presentation is structured to outline our
recommended course of action for NPDES compliance.

• Background - Describe the 4 remaining NPDES
  compliance options that received further study
  under this phase of the project.
• Recommendations - Present our recommended
  compliance option and describe the factors that
  support this recommendation.
• Implementation - Recommended next steps, near
  term and long-term.
• Plan Adoption or Modification - Obtain City
  Councils views and input.

3
Four discharge/reuse alternatives for NPDES
compliance were evaluated under this phase of the
project.

• Option A Laguna Creek Seasonal Discharge with
  Continued Reclamation
• Option B Laguna Creek Year-Round Discharge
• Option C Sacramento River Discharge
• Option D Zero Discharge with Full Reclamation

4
Option A is a Laguna Creek seasonal discharge
alternative.
5
(No Transcript)
6
TREATMENT WETLANDS
FILTERS
WWTP PROCESS SCHEMATIC FOR OPTION A (WINTER
OPERATION)
7
Option B involves discharging to Laguna Creek on
a year-round basis.
8
TREATMENT WETLANDS
FILTERS
NEED FOR/ADEQUACY OF WETLANDS IS DEPENDENT UPON
OUTCOME OF WATER QUALITY STUDIES, DILUTION
CREDIT, PILOT TESTING
WWTP PROCESS SCHEMATIC FOR OPTION B
9
Option C is a Sacramento River discharge option
requiring construction of a 12 mile long pipeline
and river outfall facilities.
10
Option D would eliminate effluent discharge
altogether through reuse and storage.
11
Estimated capital costs and OM costs for each
option at 3 mgd
These costs are based on existing information and
assumptions, and are subject to change.
12
Comparison of Capital Costs 3 mgd and 6 mgd
13
Major Conclusions and Recommendations

• Option D, zero discharge with full reclamation,
  is no longer considered a viable alternative.
• Highest cost alternative
• Acquisition of property in the vicinity of the
  WWTP
• For 3 mgd, competing land interests complicate
  acquisition
• Beyond 3 mgd, remote sites are necessary,
  substantially increasing costs
• Current market value of reclaimed water is low
• Development of properties, and management/operatio
  n of the system will be difficult and complex

Recommendation Eliminate Option D from the list
of alternatives.
14
Key Decisions

• Option C Retain until NPDES permit is received
  vs. Abandon in favor of Option A/B
• Option A Retain until benefits of dilution are
  known vs. Abandon in favor of Option B
• Option B Pursue now and abandon Options A C
  vs. Retain as the fallback option

15
Major Conclusions and Recommendations

• Laguna Creek discharge (Options A and B) and
  Sacramento River discharge (Option C) are
  competitive, feasible alternatives.
• Continuation of a Laguna Creek discharge is our
  recommended implementation approach.
• Despite distinct risks, the potential benefits
  associated with a Sacramento River discharge are
  attractive.
• Council may want to consider preserving this
  option while additional information is developed.

16
The Laguna Creek option is preferred, in part,
because of the potential risks associated with
the Sacramento River discharge option.

• Permit requirements for a Sacramento River
  discharge can only been estimated. The actual
  requirements, and therefore the viability of this
  option, are unknown until an NPDES permit is
  obtained.
• Public opposition to a new Sacramento River
  discharge may surface during the CEQA process.
• Potential future regulatory changes may
  eventually nullify the key benefits of this
  option.
• Dilution is a critical element of this option.
  Continuation of current policies regarding
  dilution credits/mixing zones is not guaranteed
  in the long run.
• Possible future mass-based effluent limits (e.g.,
  for mercury) are independent of dilution
• Compliance with other possible future effluent
  limits (e.g., pharmaceuticals) cannot be
  predicted at this time.

17
The Laguna Creek discharge option offers
distinct benefits that make this the preferred
alternative.

• There is very little risk that constructed
  improvements will be throwaway if regulations
  change.
• This option provides flexibility to move from
  Option A to Option B to create cost-effective
  solutions as the project develops over time.
• The ability to phase construction of improvements
  allows costs to be effectively managed over time.

• Safety considerations favor this option.
• Discontinued use of chlorine disinfection.
• Eliminates safety concerns related to pipeline
  maintenance.

18
Major Conclusions and Recommendations

• There are potential risks/disadvantages
  associated with a Laguna Creek discharge.
• Requires significant additional treatment
  processes over Option C (e.g., filtration, UV
  disinfection)
• Possible future effluent limits (e.g., salinity)
  may be difficult to meet without advanced
  treatment processes
• Wetlands performance needs to be confirmed
  through pilot testing additional or alternative
  advanced treatment processes may ultimately be
  needed
• Dilution benefit decreases as effluent flow
  increases

19
Major Conclusions and Recommendations

• Council may wish to preserve the Sacramento River
  discharge option
• Lower cost for 6 mgd and beyond (given the
  assumptions of this analysis)
• Reduced risk of needing advanced treatment
  processes (e.g., MF/RO) in the event of future
  stringent water quality regulations
• Impractical to delay implementation until the
  Laguna Creek option proves unfavorable

20
Key Decisions (revisited)

• Option C Retain until NPDES permit is received
  vs. Abandon in favor of Option A/B
• Option A Retain until benefits of dilution are
  known vs. Abandon in favor of Option B
• Option B Pursue now and abandon Options A C
  vs. Retain as the fallback option

Recommendation Pursue Option A/B consider
preserving Option C until NPDES permit is
received
21
Major Conclusions and Recommendations

• Irrespective of the selected option, an
  integrated approach optimizes your ability to
  achieve NPDES permit compliance.

Refine/Expand Effluent Water Quality Analyses
Pursue Dilution Credit, Negotiate NPDES Permit
Requirements
WWTP Improvements
Define Implement Wellhead Treatment for Arsenic
OR
Conduct Receiving Water Analyses
Submit RWD/NDPES Permit Application
Export Pipeline
Identify Implement Other Cost-Effective Source
Control Measures
Refine List of Problem Constituents
It will be imperative to coordinate with the
Regional Board on all of the activities listed
above.
22
RECOMMENDED ACTION PLAN
23
Recommended Action PlanImmediate Action Items
(2006-2008)

• Take action on Option C (if Council decides it is
  warranted).
• Conduct flow and water quality analyses for
  Laguna Creek.
• Begin pilot test of filtration system.
• Construct and test a pilot-scale treatment
  wetlands to confirm performance.
• Begin preliminary design of selected improvements
  (filtration, UV disinfection) and final design of
  solids processing improvements.
• Use an integrated approach.
• Continue source control efforts.
• Refine sampling techniques and analytical
  testing.
• Develop water quality and flow analyses to
  support NPDES permit negotiations.

24
(No Transcript)
25
If the Sacramento River option is preserved,
additional costs would be incurred to advance
this alternative.
26
Recommended schedule for near-term projects
related to Options A and B.
27
Recommended Action Plan Schedule
28
(No Transcript)
