WiFi Module Product Introduction

1
WiFi Module Product Introduction
2
WiFi Module Usage
Internet
11a AP
11g AP
11b AP
Wireless Connection
WiFi Modules
Mobility
Digital Camera
HDTV
Mobile Phone
Pocket PC
PDA
Notebook PC
Desktop PC
Printer
Game Console
Projector
3
Photo Gallery
SDIO Card
CF Card
PCMCIA Card
External Add-In
40 mm
52 mm
22 mm
36 mm
Mini-PCI Card
Mini Card
SiP Module
Embedded
44 mm
50 mm
10 mm
59 mm
10 mm
30 mm
4
Product Naming Conventions

• WM a b c d e

Wireless Module
5
Product Portfolio
Notebook PC
DSC, Phone
6
Development Schedule
Y2007
Y2006
1Q
3Q.
4Q
1Q
2Q
3Q
2Q.

• WM7518A
• 11a/b/g Mini Card
• Sample Now

Mini Card

• WM7718A
• 11n Mini Card
• Sample Jun 06

• WM8910B
• 16e PCMCIA Card
• Sample Feb 06

PCMCIA Card

• WM1212M
• 11b/g SDIO Card
• Sample Now

SDIO Card

• WM3212M
• 11b/g SiP Module
• Sample Mar 06

• WM3536A
• 11a/b/g SiP Module
• Sample Mar 06

SiP Module

• WM3930M
• 11a/b/gBT SiP Module
• Sample Q2

7
Hardware Specifications

• Module Dimensions
• For SiP module, aiming for 10 x 10 mm.
• Other cards have standard sizes.
• IEEE Standard
• 802.11a (5 GHz / 54 Mbps)
• 802.11b (2.4 GHz / 11 Mbps)
• 802.11g (2.4 GHz / 54 Mbps)
• Data Throughput
• Usually constrained by host interface, CPU
  performance, radio, etc.
• 6 Mbps for 802.11b.
• 18-22 Mbps for 802.11a/g.
• Host Interface
• Communication between components on PCB and to
  the outside world.
• SDIO/SPI most popular for SiP modules.
• PCI Express for Mini Card.
• Chipsets
• Usually one CPU/BB/MAC/RF chip one RF Front-End
  Module chip.
• Operating Voltage
• Usually 3.3V vs. 1.8V.

• Power Consumption mW or mA
• Mobile device is very sensitive to power
  consumption.
• Transmit Power dBm
• Higher transmit power ? longer transmit distance.
• Higher transmit rate ? lower transmit power.
• Receive Sensitivity dBm

dBm
WM3536A Block Diagram
8
Software Specifications

• Supported Operating Systems
• Linux
• Windows
• Windows CE (3.0, 4.20, 4.21, 5.0)
• Windows Mobile (2002, 2003, 2003SE, 5.0)
• Pocket PC platform
• Smart Phone platform
• Portable Media Center platform
• ITRON ? popular in Japan
• Thread X
• Nucleus
• Advanced QoS Power Management for VoIP
• APIs for Automatic Wireless Link Management
• Software Utilities for End Users
• Configure wireless mode (AP-infrastructure,
  Ad-hoc)
• Configure security mode (none, WEP, WPA, TKIP,
  PSK, 802.1x, LEAP, etc.)
• Select operating channel
• Manage security keys (WPA/PSK, WEP)
• Set SSID, site survey, and profile manager

9
Security Specifications

• Security Protocols
• WEP Wired Equivalent Privacy
• WPA Wi-Fi Protected Access
• TKIP Temporal Key Integrity Protocol
• WPA-Personal / WPA-PSK ? password
• WPA-Enterprise / WPA-802.11X ? authentication
  server
• WPA2 (802.11i standard)
• WPA2-Personal ? password
• WPA2-Enterprise ? authentication server
• AES Advanced Encryption Standard
• CCX Cisco Compatible Extensions
• PEAP Protected Extensible Authentication Protocol
• LEAP Lightweight Extensible Authentication
  Protocol

10
Administrative Specifications

• Regulatory Compliance
• FCC (U.S.A)
• IC (Canada)
• CE (EU)
• TELEC (Japan)
• SRMC (China)
• ACA (Australia)
• DGT (Taiwan)
• Certification

Wireless Fidelity (Wi-Fi)
Cisco Compatible Extensions (CCX)
Windows Hardware Quality Labs (WHQL)
11
WM1212M Mini Spec
12
WM3212M Mini Spec
13
WM3536A Mini Spec
14
WM5511A Mini Spec
15
WM7518A Mini Spec
