Membrane

1

• Lecture 9
• Membrane
• transport
• processes

2
Protein-mediated transport can be active or
passive
chemical potential for a given
solute j
Requires energy (hydrolysis of ATP)
3
Electrochemical gradient
Electrochemical gradient exists when there is a
concentration and an electrical gradient.
Concentration Gradient exists when there is
unequal concentration across a membrane.
Electrical Gradient results when there is
unequal distribution of charges across a
membrane. When an anion or a cation moves in one
direction, and there is no accompanying flux of
another ion that neutralizes the charge.
NERNST EQUATION PREDICTS THE DISTRIBUTION OF IONS
AT EQUILIBRIUM
4
Passive and active transporters
Passive transport Active transport
In general Cation uptake passive Cation efflux
active Anion uptake active Anion efflux passive
5
Channels, Carriers and Pumps mediate the
transport of solutes across membranes
6
Channel transporters enhance diffusion across
membranes passive transport
Example K channel, Ca2 channels, anion
channels (Cl_, malate2-, NO3_) K enters
cells via gated channels
One subunit
7
Pumps carry out PRIMARY ACTIVE TRANSPORT
- Primary active transport is coupled to a source
of energy primarily ATP hydrolysis - Most
pumps transport H or Ca2 or large organic
molecules (anthocyanins, flavonoids ABC
(ATP-binding cassette) transporters) -
Plasma membrane H-ATPase generates the gradient
of electrochemical potential of H across the
membrane - Vacuolar H-ATPase and
H-pyrophosphatase (H-PPase) pump protons
into the lumen of the vacuole and Golgi
cisternae
8
H-Pumps generate a proton electrochemical
gradient
Extrusion of protons from the cytosol ? creation
of a membrane potential and pH gradient This
gradient of electro- chemical potential of H is
the proton motive force PMF stored free
energy in form of the H gradient
PM H-ATPase Vacuolar H-ATPase Vacuolar H-PPase

Cytoplasm
H
pH 5.5
H
Vacuole
pH 7.3
pH 5.5
9
Proton transport is a major determinant of the
membrane potential
Membrane potential of a pea cell collapses when
CN_ is added to the external solution
Energy required for active transport through ATP
hydrolysis Study effect of CN_ on membrane
potential CN_ poisons mito-chondria, blocks ATP
production
10
Model of a H-ATPase at work
? regulation of cytoplasmatic pH ? control of
cell turgor, driving organ movement,
stomatal opening, cell growth ? expressed in
guard cells, where they energize the plasma
membrane to drive solute uptake during
stomatal opening
11
Two-dimensional representation of the PM
H-ATPase from yeast
10 transmembrane domains 100 kDa Arabidopsis
12 genes
(Autoin-hibitory domain)
12
SECONDARY ACTIVE TRANSPORT is mediated by carriers
PMF generated by H transport is used in
secondary active transport to drive the transport
of many other substances against their gradients
of electrochemical potential.
13
Two types of secondary active transport
Symport Antiport
14
Transport processes on the plasma membrane
15
Transport processes on the plasma membrane
16
Transport processes on the tonoplast
17
Ions are actively taken up into root cells
18
Summary

• CONCEPTS
• LIPID BILAYERS ARE IMPERMEABLE TO IONS AND
  CHARGED MOLECULES.
• There are 3 main classes of transport proteins.
  Channels Pumps Carriers
• PROTEINS CATALYSE THE TRANSPORT OF SOLUTES ACROSS
  MEMBRANES, JUST AS ENZYMES CATALYZE CHEMICAL
  REACTIONS (Carriers).     High specificity High
  affinity, low Km     Fast Rate Vmax
• PROTEIN-MEDIATED TRANSPORT CAN BE ACTIVE OR
  PASSIVE. Passive transport is movement down an
  electrical and a concen-tration gradient.Active
  transport is movement against an electrical and
  concen-tration gradient.

19
Summary
What is an electrochemical gradient? How is a
gradient formed? Electrochemical gradient exists
when there is a concentration and an electrical
gradient. NERNST EQUATION PREDICTS THE
DISTRIBUTION OF IONS AT EQUILIBRIUM
20
Summary

• H PUMPS ARE THE MAJOR ION PUMPS IN PLANTS. They
  generate an electrical (- inside) and pH gradient
  (acid outside).     a) PLASMA MEMBRANE H-ATPase
  EXTRUDE H out of the cell.     b) VACUOLAR
  H-ATPase ACIDIFIES THE VACUOLE     c) VACUOLAR
  H-PPase ALSO ACIDIFIES THE VACUOLE The stored
  energy generated by H pumps is used for active
  transport of other ions and metabolites.
• ACTIVE TRANSPORT OF MANY NUTRIENTS AND
  METABOLITES IS DEPENDENT ON H-COUPLED
  CO-TRANSPORT.     Symport and Antiport
• CHANNELS ALLOW RAPID, PASSIVE TRANSPORT OF IONS,
  METABOLITES AND WATER.         e.g. Light
  stimulated opening of stomatal pore.
•  Water is transported via AQUAPORINS in membranes
  that conduct large volumes of water rapidly.
• Guard cell movement controls stomatal
  aperture.Example of how pumps, carriers,
  channels and water transport work together to
  regulate stomatal aperture (Opening and Closing)
