1

• John Mutter, David Ho, Marty Odlin,
• Vijay Modi, Marissa Brodney
• Now at University of Hawaii

2
Managing water in the drylands of Ethiopia(Paul
Block IRI)
http//iri.columbia.edu/features/2009/managing_eth
iopia_s_water_resources.html
3
outline

• Background
• Objectives
• Accomplishments
• Future plan

4

• IMPACT
• Simple sustainable mobility in the form of
  bicycles multiplies peoples efforts and
  efficiencies in areas of healthcare, education
  and economic development.
• Healthcare Brings healthcare to patients and
  patients to healthcare.
• Education Brings educators to the field and
  students to schools.
• Economic Development Sustainable mobility is a
  fundamental requirement in all economic systems.
  Bicycles multiply individuals' efforts in the
  following ways
• Bring goods and services to markets
• Enable workers to get to jobs or find better
  jobs
• Bicycles fuel individuals' entrepreneurial
  drives, and entire businesses can be run off the
  back of a bike.

5
S.S. Wilson, "Bicycle Technology", Scientific
American, March 1973.
6
S.S. Wilson, "Bicycle Technology", Scientific
American, March 1973.
7
background

• Economic activity depends heavily on
  transportation infrastructure at all levels of
  development.
• Bicycles are a ubiquitous form of transportation
  in poor rural communities and in many cities
  used for personnel transport, goods, farm
  products, and for health care provision and many
  other purposes.
• Bicycles are relatively cheap even for poor
  people.
• Almost all bicycles in poor rural areas of Africa
  are completely inappropriate for the multiple
  uses to which they are put and the road
  conditions, are very inefficient and dangerous.
• Bicycle design has advanced significantly in the
  last couple of decades but none of the
  improvements have diffused to Africa.
• All bicycles are imported from India or China and
  are poor quality (no bicycles are built anywhere
  in Africa). Manufacturers have no incentive to
  improve the design.

Images from worldbike.org
8
bikes are everywhere
9
bamboo bike project objectives

• Introduce greatly improved bicycle design
  appropriate for use in poor rural Africa to
  improve transportation and health care delivery.
• Ensure that semi-literate people in Africa, with
  limited access to electricity (no power tools),
  can build bicycles in Africa from locally
  available materials and components.
• Introduce bicycle-building skills in Africa that
  can be used to develop manufacturing capability
  to serve Africas needs and create employment and
  business opportunities.
• Build bikes at a scale that meets the need not as
  novelties.

10
challenges

• Getting people to accept bamboo as a material for
  bicycles
• Build bamboo bicycles in Africa
• Make project self-sustaining
• Bringing the project to scale

11
advantage of bamboo bikes

• Can be built without electricity and
  infrastructure.
• Different design without retooling.
• Shipping in 40 ft container (bikes 500 vs. bike
  parts 2000).

Project Rwanda Coffee Bike 120
Bamboo Cargo Bike ca. 100 (including labor,
overhead, profit)
http//www.woodenbikecoffee.com/gallery/41.jpg
12
Ghana

• Availability of bamboo
• Availability of bike parts
• Existing bike culture
• Stable government

13
progress first idea

• Contact with organizations interested in
  promoting use of bamboo
• International Network for Bamboo and Rattan
  (INBAR)
• Forestry Research Institute of Ghana (FORIG)
• Bamboo Rattan Development Program at the
  Ministry of Lands, Forestry Mines (MLFM) of
  Ghana
• Contact with organizations bringing new and used
  bicycles to Africa
• Village Bicycle Project
• Institute for Transportation and Development
  Policy (ITDP)
• World Bike
• Acquired parts and supplies for bamboo bike in
  Ghana
• Conducted bamboo bike building demonstrations in
  Ghana with Calfee
• Built bamboo cargo bike using local parts and
  supplies

14
progress first problem

• Not clear how to bring that process to scale
• No difficulty producing a few bikes but not a
  pathway to producing bikes in the quantities that
  would make a difference

15
progress second phase

• Alliance with Millennium Cities Initiative (MCI)
  of the Earth Institute
• Focus on the city of Kumasi as a site
• Proximal to the MV of Bonsaaso
• Attract serious investment to bring sufficient
  capital to allow production at the right scale.

16
progress second phase

• MCI worked with KPMG to create a business plan
  for scaling the project
• MCI sponsored a Kumasi day at Columbia that
  included the bike project
• Potential investor identified at the Kumasi day
  event

17
progress second phase

• Approach now is to support the investor
  identified by MCI
• Build bikes here in New York (Marty Odlin) for
  acceptance in Ghana BEFORE trying to set up in
  Ghana

18
What is wrong with current solutions?

• Imported roadsters
• Durability is an issue
• Expensive
• Designed for paved roads

19
Why is this bicycle better?

• More durable
• Affordable
• Local
• Cargo rack
• Design for rougher roads

20
How are these bicycles made?
21
What will a factory look like?

• 20 employees
• 20,000 bicycles per year
• Appropriate technologies
• One piece flow
• Lean production

22
But what about the rest of the bicycle parts?

• Supply Chain
• Capacity building
• Future expansion

23
What is our current strategy?

• Ship samples to potential markets to gauge
  interest
• Focus is to develop and test the technology

24
Business is competition. Why bamboo bikes will
win?

• Labor
• Materials
• Shipping
• Equipment/Overhead
• Energy Buffer
• Specificity of Design
• Flexible Production/Low Inventory Costs

25
Why could bamboo bikes lose?

• The bamboo will split.
• The joints will fatigue and break.
• The bikes will be too expensive.
• The production will be too complicated.
• The people will not want to buy them.
• Something else...

26
What is bamboo?

• Hollow Tubes
• Natural composite
• Power fibers
• Woody matrix

27
Structure of Bamboo
28
How do you stop bamboo from splitting?

• Smoking
• Flame Treating
• Boiling in Palm Oil
• Many chemical treatments

There are contradicting anecdotal optimizations,
to scale our production we need to quantify the
structural benefits of each treatment and compare
to costs
29
How do you stop bamboo from splitting?
30
How do you make a bicycle last?
31
How do you make a bicycle cheap?

• KPMG report
• Sourcing
• Development
• Pick up the pennies

32
How do you mass produce a natural material?

• Good question...
• Supply Chain management
• Quality Control
• Build the industry around the material

33
Acceptance
34
Future Projects

• Testing
• Production machine design
• Jig for rack
• Flame treating setup
• Bamboo Smoker
• Solar oven with temperature controls
• Associated bamboo products

35
Thank you.
